Porshe 911 (997). Manual - part 360

Installation position of rear centre panel

Removing sound absorbent film

1. Remove sound absorbent

film.

Loosening inner rear centre panel

2. Unscrew fastening nut -1- and remove seal -2- .

Loosening outer rear centre panel

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Loosening inner rear centre panel

1597

Installation position of rear centre panel

1. Extend rear spoiler manually.

Loosening outer rear centre panel

2. Unscrew fastening screws -1- and remove rear centre panel -2- upwards until the electric plug connection

can be released.

Disconnecting electric plug connection for auxiliary stop light

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Loosening outer rear centre panel

1598

Installation position of rear centre panel

Releasing electric connector

1. Insert a screwdriver from the side and release the locking tab -Arrow A- and pull off the connector.

Installing rear centre panel

Locking electric plug connection for auxiliary stop light

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Disconnecting electric plug connection for auxiliary stop light

1599

Installation position of rear centre panel

Plugging in connector

1. Push in electric plug connection -arrow- until it engages audibly.

Installing rear centre panel

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Locking electric plug connection for auxiliary stop light

1600
