Yanmar diesel tractor EF494T. OPERATOR'S MANUAL - part 2





EF494T OM

STARTING

START THE ENGINE SAFELY

If you operate the engine inside a closed building, be
sure there is plenty of ventilation before starting the
engine. Exhaust fumes are poisonous. Carbon
monoxide is especially dangerous because it is odorless
and colorless. You can easily be overcome without
realizing it.
Always stay near the tractor and keep the parking brake
set securely while warming it up.







Only start the engine from the operator’s seat. Never
start the engine while standing on the ground.







Before you start the engine:
(1) Sit in the operator’s seat and adjust the seat position

if necessary.

(2) Make sure the ROPS is in working condition and

seat belt securely fastened.

(3) Lower any implement to the ground.
(4) Place speed shift lever and the PTO switch in

neutral.

(5) Set the parking brake.
(6) Disengage the PTO for the neutral position.
(7) Check all the instruments, gauges and indicator

lights.

(8) Be sure everyone is clear of the tractor and

implement.









EF494T OM

DURING OPERATION

OPERATE THE TRACTOR SAFELY

Keep people and pets a safe distance away when
starting and operating the tractor and implement.

Do not permit any person other than the operator to ride
or board the tractor or implements, including any
wagons.

Do not play games with the tractor.
Never allow children to ride on your lap.








Do not touch the muffler, radiator, engine or other high
temperature parts before they have cooled down
completely.





Do not try to get on or off a moving tractor or
implements. Always use the handrails and steps and
face the tractor when getting on and off.
Never use control levers as a handhold and never step
on foot controls when getting on and off.
Do not get on the tractor with wet or greasy hands, or
muddy shoes. Do not jump off the tractor. Be aware of
slippery conditions on the ground.





Make sure you check the connecting points on your
equipment.

Keep hands, feet and clothing away from power-driven
parts. Keep others away from articulated joints, hitches,
drawbar, lift arms, PTO drives, cylinders, and anything
else that moves.

Never stand, or allow anyone else to stand, between the
tractor and an implement, unless the engine is turned off
and the parking brake is engaged securely.









EF494T OM

OPERATE THE TRACTOR SAFELY (continued)

Oversized implements are dangerous for tractor
operation and are not safe for you. Refer to the
implement’s operator manual for the minimum and
maximum horsepower requirements and weights that
are allowed.
When using a heavy implement in front, always install
ballast or an implement on the rear for safe, stable
steering control.







When using a heavy implement on a rear 3-point hitch,
always install ballast or an implement on the front for
safe, stable steering control.





Slow the tractor down when crossing rough ground, tall
grass or weeds. Rocks, holes and stumps may be
hidden in the brush.

Do not let your tractor bounce. You may lose steering
control.

Never use the tractor to round up farm animals.





Do not allow the tractor to coast downhill with the clutch
in, or with the gear shift in neutral.





When operating the tractor on a slope, set the wheel
tread as wide as possible for maximum stability, reduce
the engine speed and avoid quick application of the
brakes or sharp turns.

Stay off hills and slopes which are too steep.







EF494T OM

AVOID TIPPING OVER

When starting the tractor on an uphill slope, shift to as
low a gear as possible and reduce the engine speed to
avoid tipping over backward.







Do not drive near the edge of a gully or a steep
embankment. Avoid holes, ditches, etc. which may
cause the tractor to tip over, especially on hillsides or
steep slopes.





When operating on slopes or rough uneven ground, it is
important to have as much distance as possible
between the wheels. Operate the tractor carefully at the
lowest speed.

Do not pull carts etc. from the top link or the top link
hinge, rear axle, or any point above the drawbar. Doing
so could cause the tractor to tip over backward. Only
attach items to be pulled to the drawbar.






Use care when pulling loads or installing a heavy
implement.
(1) Only use approved hitch points.
(2) Limit loads to those which you can control safely.
(3) Limit travel speeds so that you can control the tractor

safely.

(4) Do not turn too quickly.
(5) Use care when backing up.
(6) Install the amount of ballast recommended in the

operator’s manual.






Driving forward out of ditch or in muddy conditions, or up
a steep slope, could cause the tractor to tip over
backward. If the mud is deep enough it will keep the
wheels from turning. Then, the tractor will rotate up and
back around the axle very quickly. When stuck in muddy
conditions, do not remove the implement or ballast
weight. Always back out.
