Model MA TOW Tractor. Manual - part 75
Chapter 4: Illustrated Parts List
Jan. 1997
Section 4-2
p. 185
51-1
—— ----------------
T6-6001-113
Master Cylinder, dual, Rear disc brakes only (note 1)
1
128 & Up
127 F36706
MD-CB1-121
master cylinder, single
1
001-127
51-2
92 7911
T6-600-112
adapter, master cylinder forward port
1
128 & Up
92 7910
T6-6011-127
adapter, master cylinder forward port
1
001-127
92 7909
T6-6001-129
adapter, master cylinder aft port
1
“
51-3
92 S320
T6-6011-141
BRAKE LINE, 20-INCH
4
001 & Up
51-4
92 302X3
T6-8011-121
brake line connector
2
“
51-5
92 S340
T6-6011-149
brake line, 40-inch
1
“
51-6
92 S330
T6-6011-161
brake line, 30-inch
1
“
51-7
92 252X3
T6-6011-153
connector, brake line flex hose
2
“
51-8
227 FA210169020404 T6-6016-103
brake hose, 14-inch,rear disc brakes, forward calipers
1
“
51-9
227 FA210128020404 T6-6016-105
brake hose, 14-inch,rear disc brakes, aft calipers 1
“
51-10
92 7812
T6-6011-111
tee, brake line
2
“
51-11 —— ----------------
T6-6011-113
support, brake line tee
2
“
51-12 —— ----------------
1/4-20NCX1"
hex head bolt
2
“
51-13 —— ----------------
1/4-20NC
locknut
2
“
51-14
92 S306
T6-6011-151
brake line, 6-inch
2
128 & Up
51-15
92 253-57121-017 T6-8013-143
brake hose
4
2117 & Up
92 1040U10260408T6-6011-155
brake hose
4
128-2116
51-16
364 14094948
T6-8013-145
bolt, brake hose
4
2117 & Up
227 C5551X4
T6-6011-159
elbow, 90°, caliper
4
128-2116
51-17
31 475660
T6-8013-147
washer, brake hose bolt
8
2117 & Up
51-18
92 7828
T6-600-110
ADAPTOR, BRAKE LINE
2
001 & Up
51-
HE 88684
----------------
p-clamp, plastic
Ref.
“
51-
HE 86080
----------------
p-clamp, metal
Ref.
“
Fig &
Co Vendor Part
Tug Part Number
Description
Qty
Effective
Ind#
de Number
1. Brake booster provided as original equipment on tractors prior to serial number 362 is no longer
available. Replacement of this booster requires replacement of single master cylinder MD-CB1-121 with
dual master cylinder T6-6001-113. See brake pedal, booster and master cylinder assembly.
