Model MA TOW Tractor. Manual - part 74
Chapter 4: Illustrated Parts List
Jan. 1997
Section 4-2
p. 181
50-
375 390908031
T6-3002-101-14
brake, 8-1/2"x2-1/4"
1
As Req’d
50-1
60 16559
T6-3002-501
back plate assembly (includes bolts)
1
“
50-
375 390908030
T6-3002-101-13
brake drum
1
“
50-2
60 6817
T6-3002-505
wheel cylinder assembly
1
“
50-
60 16617
T6-3002-526
wheel cylinder repair kit
1
“
50-3
60 12365
T6-3002-508
push rod
2
“
50-4
60 12359
T6-3002-514
brake shoe with lining
2
“
50-5
60 16658
T6-3002-512
shoe lever
2
“
50-6
60 12560
T6-3002-515
anchor pin
2
“
50-7
60 7778
T6-3002-516
retaining ring
2
“
50-8
60 23320
T6-3002-518
adjusting screw assembly
2
“
50-9
60 8785
T6-3002-509
spring, brake shoe lever
2
“
50-10 —— ----------------
1/4-20NCX1-1/2"
hex head bolt
2
“
50-11 —— ----------------
1/4
lock washer
2
“
50-12
60 8798
T6-3002-502
hex head bolt (included with back plate)
4
“
50-13 —— ----------------
7/16
lock washer
4
“
50-
60 9958
T6-3002-103
bolt, brake line
2
“
50-
60 9959
T6-3002-105
connector, brake line
2
“
50-
60 7761
T6-3002-107
washer, brake line
4
“
Fig &
Co Vendor Part
Tug Part Number
Description
Qty
Effective
Ind#
de Number
