Snowmobile Ski Doo REV SERIES (2006 year). Manual - part 122
Section 13 WIRING DIAGRAMSubsection 01 (WIRING DIAGRAMS)
A00E1FA
1
2
TYPICAL1. Receptacle2. Housing
WARNING
Keep wires away from any rotating, moving,heating, vibrating or sharp edge. Use properfastening devices as required.
496
mmr2005-102
