Section 10 STEERING/FRONT SUSPENSION GENERAL INSPECTION Check for looseness, bent, worn out, rusted or To check upper arm bushings and ball joint: – Let vehicle weight compress the suspension. sideways to feel the free-play. – If excessive play is felt, replace the faulty com- ponent. To check lower arm bushings and ball joint: – Raise front of vehicle off the ground from the frame to release the suspension. – Firmly grab lower part of ski leg and try to move sideways to feel the free-play. – If excessive play is felt, replace the faulty com- ponent. DISASSEMBLY Ski Lift front of vehicle and support it off the ground. Unscrew nut no. 1 then pull screw no. 2 out. Re- Unscrew nuts no. 4 and remove ski runners no. 5. 2 3 A33F1RA 1 3 PRECISION SKI A33G1QA 3 1 2 MOUNTAIN SKI 3 1 2 A33G1RA PLASTIC SKI Shock Absorber Open hood and remove side panels. Reduce spring preload by turning adjusting ring A33F1SA 450 mmr2005-098 |
