Section 07 ELECTRICAL SYSTEM Subsection 04 (ACCESSORIES) ENGINE TYPE TAB LOCATION All carburetor equipped engines except Power Tek BEIGE/BLACK on positive tab BLACK on negative tab SDI engines RED/GREEN on positive tab BEIGE/BLACK on negative tab Power Tek RED/YELLOW on positive tab BEIGE/BLACK on negative tab A32E3RA 2 1 1. GREEN/RED wire on positive tab Using jumper wires, connect battery positive post Connect battery negative post to beeper negative CAUTION: To avoid beeper damage, ensure A32E3SA 1 2 TYPICAL — 12-VOLT BATTERY PLUGGED TO BEEPER A continuous sound should be heard. If not, re- If the beeper is good, check connectors, fuse and Installation To install beeper, reverse the removal procedure. ENGINE TEMPERATURE GAUGE Test Fan-cooled Models Check if the speedometer works properly. Check connector and wiring harness. Check the engine temperature sensor on engine. If all other parts work properly, replace the engine Liquid-cooled Models except SDI Check fuses, connectors and harness. Check condition of relay, refer to RELAY further in Check temperature sensor on engine. Replace temperature gauge. SDI Models Check fuse, connectors and harness. Check the condition of relay 2 by using the BUDS mmr2005-085 309 |
