Section 07 ELECTRICAL SYSTEM Subsection 03 (STARTING SYSTEM) TROUBLESHOOTING When the ignition switch is turned on or the start In case of problems, first ensure the problem is Causes of problems are not necessarily related to Check these components before removing starter. Fuses Make sure the charging fuse (30 A) on battery and Battery Refer to CHARGING SYSTEM to check battery Start/RER Button Liquid-Cooled Engines Models Check if the start/RER button works perfectly. START/RER BUTTON ON VEHICLES WITH ELECTRIC STARTER All engines except SDI TEST Continuity from start/RER button to MPEM Voltage from voltage regulator/rectifier WIRE COLOR RED/GREY and BEIGE RED/GREY and BEIGE RESISTANCE 1.0 — VOLTAGE — Above battery voltage and below 15 volts NOTE — — SDI engines TEST Continuity from start/RER button to MPEM Voltage from voltage regulator/rectifier WIRE COLOR BLACK and BLACK/BLUE BLACK and BLACK/BLUE RESISTANCE 1.0 — VOLTAGE — Above battery voltage and below 15 volts NOTE — — If the switch functions correctly, continue with the Ignition Switch Fan-Cooled Engines Models Disconnect switch housing. Using the multimeter ) in off position. Engine Cut-Out Switch Check the condition of engine cut-out switch. mmr2005-084 301 |
