Section 04 FUEL SYSTEM A06E2OA 1 2 1. Plastic seal Jet When installing jet in DPM, ensure to position the 1 A32C6WA 3 2 3 1. Vent jet Pay also attention not to mix jets. Refer to the INSIDE DIAMETER mm (in) MODEL VENT JET LEAN JET All 1.2 (.047) 2.0 (.079) Cap Prior to installing DPM cap, ensure O-ring is in DPM MANIFOLD TESTING All DPM Models Visual Inspection With DPM manifold removed from vehicle and all If there is no apparent breakage or missing part Leak Testing Required Items The following items will be required: – Water column with at least 350 mm (13-3/4 in) in height. – Engine leak test kit (P/N 529 021 800) . 529 021 800 – 4.8 mm (3/16 in) T-fitting. DPM Manifold Preparation Connect hoses as shown. 196 mmr2005-104 |
