Section 03 ENGINES Subsection 03 (ENGINE REMOVAL AND INSTALLATION) A33C2GA 1 LEFT SIDE OF VEHICLE A33C2HA 1 RIGHT SIDE OF VEHICLE Unscrew the engine stopper no. 2 completely. Lift the engine a little then unplug oil pump hoses On SDI models, disconnect all engine connectors Lift and slide out engine using the engine removal 529 035 829 Unscrew engine support nuts no. 3 then separate INSPECTION Check if engine support no. 4 is cracked, bent or Check rubber mounts no. 5 on engine support. INSTALLATION To install engine in vehicle, reverse the removal Install engine support under engine then torque Before installing engine support bolts no. 1, apply A33C2IA A B A. Do not apply Loctite in this area, ± 10 mm (.39 in) Torque engine support bolts to 48 N•m (35 lbf•ft). Hand torque engine stopper no. 2 then torque its Reinstall all removed parts by using the appropri- mmr2005-070 69 |
