9-129 9 ZJ269B ZJ268B 10. Secure the outer idler wheel mounting block with the cap screw and lock nut. Tighten to specifica- tions. ZJ288 NOTE: To obtain proper alignment for the idler MS997A 11. Secure the outer and inner idler wheels to the mounting blocks with existing hardware. Tighten to specifications. 12. Secure the rail supports with cap screws (coated with blue Loctite #243). Tighten to specifications. MS061 13. Secure the end cap onto the slide rail using a cap screw, flat washers, and a lock nut. Tighten to specifications. MS206A NOTE: Apply a light coat of grease to the slide |
