Snowmobile Arctic Cat (2002 year). Manual - part 71





5-3

5

Electrical

Specifications

(120 cc)

„

NOTE: The ignition system is transistorized.

Description

Resistance Test

Test Value

 + Test Connections -

Lighting Coil

0.46-0.68 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

+ Test Connections -

Voltage Regulator

11-13 AC volts

@ 2500-2700 RPM

yellow

brown

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Standard

Ignition Timing

Fixed

Lighting Coil Output

12V/55W

Ignition Type

Transistorized

Spark Plug

NGKBPR6ES

Spark-Plug Gap

0.7-0.8 mm

(0.028-0.031 in.)

5-4

Electrical

Specifications

(370 cc/440 cc Panther)

„

NOTE: The ignition system is a Normally Open Ignition (NOI).

* Timing to be checked only with the engine at normal operating temperature.

** Engine RPM is approximate. Tests were made by pulling the recoil starter rope briskly, not with the engine

running.

„

NOTE: Lighting coil output is unregulated voltage.

Description

Resistance Test

Test Value

  + Test Connections -

Ignition Coil

Primary
Secondary

0.25-0.34 ohm

6800-10,200 ohms

orange

high tension wire

black

high tension wire

Stator Coil (Charge)

128-192 ohms

red/white

black/red

Lighting Coil

0.17-0.26 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

+ Test Connections -

Voltage Regulator

11-13 AC volts

@ 2500-2700 RPM

yellow

brown

Low Oil-Light Sending

Unit

Less than 1 ohm

(float end down)

terminal

terminal

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Peak Voltage Test

RPM**

2000**

Primary Coil

170-187V

Secondary Coil

150-165V

Stator Coil (Charge)

200-220V

Lighting Coil

9.0-9.9V

Description

Standard

Ignition Timing*

18° BTDC @ 2000 RPM

2.012 mm (0.079 in.)

Lighting Coil Output

12V/185W

Ignition Type

CDI/NOI

(Normally Open Ignition)

Spark Plug

NGKBR9EYA

Spark-Plug Gap

0.7-0.8 mm

(0.028-0.031 in.)

5-5

5

Electrical

Specifications

(500 cc)

„

NOTE: The ignition system is a Normally Open Ignition (NOI).

* Engine RPM is approximate. Tests were made by pulling the recoil starter rope briskly, not with the engine

running.

„

NOTE: Lighting coil output is unregulated voltage.

Description

Resistance Test

Test Value

 + Test Connections -

Ignition Coil

Primary
Secondary

0.27-0.41 ohm

6800-10,200 ohms

orange

high tension wire

black

high tension wire

DC Power Coil

0.71-1.07 ohms

red/yellow

yellow/red

Ignition Timing Sensor

152-228 ohms

green/white

brown

Lighting Coil

0.12-0.18 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

 + Test Connections -

Voltage Regulator

11-13 AC volts

@ 2500-2700 RPM

red

brown

Low Oil-Light Sending

Unit

Less than 1 ohm

(float end down)

terminal

terminal

High Temperature

Sensor

Open (water temperature

lower than 190°F)

terminal

ground

Up to 20 ohms

(water temperature

higher than 230°F)

terminal

ground

High Temperature

Warning Light

Less than 10 ohms

terminal

terminal

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Peak Voltage Test

RPM*

2000*

Primary Coil

170-187V

Secondary Coil

105-116V

DC Power Coil

14.0-15.5V

Lighting Coil

7.0-7.7V

Description

Standard

Ignition Timing

25° BTDC @ 2000 RPM

3.671 mm (0.145 in.)

Lighting Coil Output

12V/210W

Ignition Type

CDI/NOI

(Normally Open Ignition)

Spark Plug

NGKBR9EYA

Spark-Plug Gap

0.7-0.8 mm

(0.028-0.031 in.)

5-6

Electrical

Specifications

(440 cc Z/550 cc)

„

NOTE: The ignition system is a Normally Open Ignition (NOI).

* Timing to be checked only with the engine at normal operating temperature.

        ** Engine RPM is approximate. Tests were made by pulling the recoil starter rope briskly, not with the engine

   running.

„

NOTE: Lighting coil output is unregulated voltage.

Description

Resistance Test

Test Value

+ Test Connections -

Ignition Coil

Primary
Secondary

0.25-0.34 ohm

6800-10,200 ohms

orange

high tension wire

black

high tension wire

Charge Coil (1)

128-192 ohms

red/white

black/white

Charge Coil (2)

13.6-20.4 ohms

black/red

red/white

Lighting Coil

0.17-0.26 ohm

yellow

yellow

Spark-Plug Cap

4000-6000 ohms

cap end

cap end

Description

Test Value

 + Test Connections -

Voltage Regulator

11-13 AC volts

@ 2500-2700 RPM

yellow

brown

Low Oil-Light Sending

Unit

Less than 1 ohm

(float end down)

terminal

terminal

High Temperature

Sensor

Open (water temperature

lower than 190°F)

terminal

ground

Up to 20 ohms

(water temperature

higher than 230°F)

terminal

ground

High Temperature

Warning Light

Less than 10 ohms

terminal

terminal

Ignition Switch

Less than 1 ohm

(key in OFF position)

terminal

terminal

Description

Peak Voltage Test

Description

Standard

RPM**

2000**

Ignition Timing*
(440 cc Z)

18° BTDC @2000 RPM

2.012 mm (0.079 in.)

Primary Coil

177-195V

Ignition Timing*
(550 cc)

33° BTDC @ 2000 RPM

6.556 mm (0.258 in.)

Secondary Coil

170-187V

Lighting Coil Output
(440 cc Z)

12V/185W

Charge Coil (1)

9.0-9.9V

Lighting Coil Output
(550 cc)

12V/180W

Charge Coil (2)

9.0-9.9V

Ignition Type

CDI/NOI

(Normally Open Ignition)

Lighting Coil

10-11V

Spark Plug

NGKBR9EYA

Spark-Plug Gap

0.7-0.8 mm

(0.028-0.031 in.)
