PISTON SKIRT/CYLINDER CLEARANCE

1. Measure each cylinder front to back about 2.5 cm

(1 in.) from the bottom of each cylinder.

2. Measure the corresponding piston skirt diameter at

a point 1 cm (0.394 in.) above the piston skirt at a

right angle to the piston-pin bore. Subtract this

measurement from the measurement in step 1. The

difference (clearance) must be within

specifications.

AC091

PISTON-RING END GAP

1. Place each piston ring in the wear portion above

the exhaust port of its respective cylinder. Use the

piston to position each ring squarely in each

cylinder.

2. Using a feeler gauge, measure each piston-ring

end gap. Acceptable ring end gap must be within

specifications.

AN057

PISTON PIN AND PISTON-PIN BORE

1. Measure the piston pin diameter at each end and in

the center. Acceptable piston pin measurement

must be within specifications. If any measurement

varies by more than 0.02 mm (0.001 in.), the

piston pin and bearing must be replaced as a set.

AN056

2. Insert a snap gauge into each piston-pin bore; then

remove the gauge and measure it with a

micrometer. The diameter measurement must be

within specifications. Take two measurements to

ensure accuracy.

AC092

CONNECTING-ROD SMALL END BORE

1. Insert a snap gauge into each connecting-rod small

end bore; then remove the gauge and measure it

with a micrometer.

CYLINDER TRUENESS LIMIT (max)

mm

in.

0.10

0.004

2-64

AN061

2. The diameter measurement must be within

specifications.

CRANKSHAFT RUNOUT

1. Using the V Blocks (p/n 0644-022), support the

crankshaft on the surface plate.

„

NOTE: The V blocks should support the crank-

shaft on the outer bearings.

2. Mount a dial indicator and base on the surface

plate. Position the indicator contact point against

the crankshaft distance F (PTO-end) from the

crankshaft end. Zero the indicator and rotate the

crankshaft slowly. Note the amount of crankshaft

runout (total indicator reading).

„

NOTE: For runout distance specifications, see

Engine Information sub-section.

3. Position the indicator contact point against the

crankshaft distance D (MAG-end) from the

crankshaft end. Zero the indicator and rotate the

crankshaft slowly. Note the amount of crankshaft

runout (total indicator reading).

AQ042

4. Position the indicator contact point against the

crankshaft at point E (center). Zero the indicator

and rotate the crankshaft slowly. Note the amount

of crankshaft runout (total indicator reading).

5. If runout exceeds specifications at any of the

checkpoints, the crankshaft must be either

straightened or replaced.

CRANKSHAFT RUNOUT (max)

(total indicator reading)

mm

in.

0.05

0.002

2-65

2

NOTES

2-66
