9-57

SPEC

CABLE ROUTING

C

E

F

G

H

H

I

J
K

8

9

0

A

B

B

B

C

D

1

1

1

2

3

4

5

5

5

6

6

6

7

L
M
N
O
P
Q

R

S

T

U

V

W

X

Y

Z

[

\

]

_

a

a

a

b

b

b

b

c

d

e

e

f

g

A

A

B

B

C

A-A

B-B

9-58

SPEC

CABLE ROUTING

PZ50VT/PZ50MP

1 Corrugated tube (engine stop

switch lead, throttle switch lead,
right grip warmer lead, and
thumb warmer lead)

2 Right grip warmer lead
3 Right handlebar switch
4 Route the throttle cable over the

handlebar.

5 Multi-function meter unit lead
6 Parking brake cable
7 Route the brake hose in front of

the handlebar.

8 Route the left handlebar switch

leads behind the handlebar.

9 Brake master cylinder
0 Left grip warmer
A Brake light switch
B Corrugated tube (left grip warmer

lead, grip/thumb warmer adjust-
ment switch lead, brake light
switch lead, and headlight beam
switch lead)

C Auxiliary DC jack
D Rectifier/regulator
E Cylinder identification sensor

coupler

F A.C. magneto coupler
G Speed sensor lead
H Pressure regulator hose
I Fuel tank breather hose
J Throttle position sensor
K Throttle body heater hose
L Fasten the A.C. magneto lead,

oil pressure switch lead, and
pressure regulator hose with the
holder.

M Knock sensor
N Fasten the A.C. magneto lead,

water pump outlet hose, and
knock sensor lead with the plas-
tic band.

O Route the A.C. magneto lead

behind the idling adjusting screw
remote adjustment cable.

9-59

SPEC

CABLE ROUTING

C

E

F

G

H

H

I

J
K

8

9

0

A

B

B

B

C

D

1

1

1

2

3

4

5

5

5

6

6

6

7

L
M
N
O
P
Q

R

S

T

U

V

W

X

Y

Z

[

\

]

_

a

a

a

b

b

b

b

c

d

e

e

f

g

A

A

B

B

C

A-A

B-B

9-60

SPEC

CABLE ROUTING

P Fasten the idling adjusting screw

and oil pressure switch lead with
the plastic band. Install the plas-
tic band with its buckle posi-
tioned towards the rear of the
machine and its end facing to the
right.

Q Route the oil pressure switch

lead under the idling adjusting
screw, making sure that the lead
is not taut.

R Oil pressure switch coupler
S Starter motor
T Oil tank outlet hose
U Oil tank inlet hose
V Throttle body heater outlet hose
W Water pump inlet hose
X To the wire harness
Y Route the water pump outlet

hose and throttle body heater
outlet hose behind the engine
mounting bracket.

Z Coolant temperature sensor
[ Throttle body heater inlet hose
\ Thermostat cover
] To the parking brake
_ To the brake caliper
a Brake hose
b Throttle cable
c Main switch
d Pass the corrugated tube

(engine stop switch lead, throttle
switch lead, right grip warmer
lead, and thumb warmer lead),
corrugated tube (left grip warmer
lead, grip/thumb warmer adjust-
ment switch lead, brake light
switch lead, and headlight beam
switch lead), parking brake
cable, throttle cable, speedome-
ter unit lead, and brake hose with
the holder.
