9-49

SPEC

CABLE ROUTING

F

D

G

H

I

J

K

8

9

0

A

B

C

E

1 2

3 4

5

6

7

L

M

N

N

O

O

O

P

Q

Q

R

R

T

S

U

T

V

W

X

Y

Z

[

\

\

]

^

a

b

c

d

e

f

g

g

g

h

h

h

i

i

i

j

j

k

k

l

l

m

m

n

PZ50

PZ50VT/PZ50MP

PZ50GT/PZ50FX/PZ50M

9-50

SPEC

CABLE ROUTING

[ Fasten the tail/brake light lead

and brake hose to the frame rear
cross member with the plastic
band. Install the plastic band with
its buckle positioned towards the
front of the machine and its end
facing to the right.

\ 40 ~ 50 mm (1.6 ~ 2.0 in)
] Parking brake cable
_ Gear motor lead coupler

(PZ50GT/PZ50FX/PZ50M/
PZ50VT/PZ50MP)

a Fasten the wire harness, brake

hose, and parking brake cable
with the plastic band.

b Battery
c Fuse box
d Main fuse
e Starter relay
f Starter relay lead
g Load control relay
h Fuel injection system relay
i Headlight relay
j Radiator fan motor relay

(PZ50GT/PZ50FX/PZ50M/
PZ50VT/PZ50MP)

k Gear motor relay 1 (PZ50GT/

PZ50FX/PZ50M/PZ50VT/
PZ50MP)

l Gear motor relay 2 (PZ50GT/

PZ50FX/PZ50M/PZ50VT/
PZ50MP)

m Gear motor relay 3 (PZ50GT/

PZ50FX/PZ50M/PZ50VT/
PZ50MP)

n Passenger grip warmer relay

(PZ50VT/PZ50MP)

9-51

SPEC

CABLE ROUTING

C

F

G

H

I

I

J

K
L

9

0

A

B

C

C

C

D

E

1

1

1

2

3

4

5

5

5

6

6

6

7

M
N
O

P
Q
R

S

T

U

V

W

X

Y

Z

[

\

]

^

a

b

b

b

c

c

c

c

d

e

f

g

h

i

A

A

B

B

C

A-A

B-B

8

9-52

SPEC

CABLE ROUTING

PZ50/PZ50GT/PZ50FX/PZ50M

1 Corrugated tube (engine stop

switch lead, throttle switch lead,
right grip warmer lead, and
thumb warmer lead)

2 Right grip warmer lead
3 Right handlebar switch
4 Route the throttle cable over the

handlebar.

5 Multi-function meter unit lead
6 Parking brake cable
7 Route the brake hose over the

top rod of the windshield bracket.
(Except for PZ50)

8 Route the parking  brake cable

between the top and bottom rods
of the windshield bracket.
(Except for PZ50)

9 Route the left handlebar switch

leads behind the handlebar.

0 Brake master cylinder
A Left grip warmer
B Brake light switch
C Corrugated tube (left grip warmer

lead, grip/thumb warmer adjust-
ment switch lead, brake light
switch lead, and headlight beam
switch lead)

D Auxiliary DC jack (PZ50GT/

PZ50FX/PZ50M)

E Rectifier/regulator
F Cylinder identification sensor

coupler

G A.C. magneto coupler
H Speed sensor lead
I Pressure regulator hose
J Fuel tank breather hose
K Throttle body heater hose
L Throttle position sensor
M Fasten the A.C. magneto lead,

oil pressure switch lead, and
pressure regulator hose with the
holder.

N Knock sensor
O Fasten the A.C. magneto lead,

water pump outlet hose, and
knock sensor lead with the plas-
tic band.
