Spare Parts Catalogue

Page

010  Crankcase

02 Front Cover

*  See Chapter Engine Management System

Pos. Part No Description

QTY

1

103635 Front Cover

1

2

100280 Sleeve

4

3

*

Sensor Crankshaft

1

4

*

Bolt

M6x12

1

5

*

Conduit

1

6

100501 Bolt

M6x20 8.8

10

7

101525 Oil Seal

1

8

102476 Generator Cover

1

9

100549 Bolt

M6x65 8.8

4

10

400661 Engine Bracket

1

Pos. Part No Description

QTY

11

100228 Sleeve

1

12

102475 Bolt

M10x90 8.8

3

10055_abMJ07_ETK_Rev1.4_090128

MPE 750 HO Snow

1

3

4

5

6

7

8

(10)

10

(10)

10

11

13

14

15

17

16

Spare Parts Catalogue

Page 4

020  Crank Drive

Pos. Part No Description

QTY

1

102868 Balance Shaft incl. Pos. 3, 4, 5

1

2

100017 Bearing Shell Balance Shaft

8

3

100463 Key

1

4

100112 Gear Balance Shaft

1

5

100164 Nut

M10 8.8

1

6

103974 Con Rod incl. Pos. 10

2

7

102660 Piston incl. Pos. 8

2

8

100361 Circlip

4

9

or

or

or

or

100008

100007

100009

100010

100011

Con Rod Bearing Red

Con Rod Bearing Yellow

Con Rod Bearing Blue

Con Rod Bearing Green

Con Rod Bearing Brown

1.721 mm

1.726 mm

1.731 mm

1.736 mm

1.741 mm

4







Pos. Part No Description

QTY

10

103694 2x Con-Rod Bolt

M10x1x38

2

11

100338 Crankshaft

1

16

or

or

or

or

100013

100012

100014

100015

100016

Main Bearing Red

Main Bearing Yellow

Main Bearing Blue

Main Bearing Green

Main Bearing Brown

1.990 mm

1.995 mm

2.000 mm

2.005 mm

2.010 mm

8







13

103105 Parallel Pin

1

14

103111 Washer

1

15

102949 Pulley

1

16

103028 Washer

1

17

103042 Bolt

M12x80 10.9

1

2

order in pairs

9

order

in pairs

12

order in pairs

10055_abMJ07_ETK_Rev1.4_090128

MPE 750 HO Snow

1

2

3

4

5

6

7

(7)

(7)

8

9

10

Spare Parts Catalogue

Page 5

030  Cylinder Head

*  See Chapter Engine Management System

01 Valve Cover

Pos. Part No Description

QTY

1

*

Bolt

M6x20 8.8

4

2

*

Washer

4

3

*

Ignition Coil

2

4

100446 Bolt

M6x45

10

5

100448 Washer

10

6

102941 Valve Cover Black incl. Pos. 7, 8, 9

1

7

102134 Valve Cover Seal

1

8

*

Sensor Camshaft

1

9

*

Bolt

6x18

1

10

402159 Engine Badge

1

10055_abMJ07_ETK_Rev1.4_090128

MPE 750 HO Snow

1

2

3

4

5

6

7

7

8

8

3

4

Spare Parts Catalogue

Page

030  Cylinder Head

02 Rocker Arms

Pos. Part No Description

QTY

1

101034 Nut

M10x1.25 10.9

8

2

103099 Washer

8

3

102023 Rocker Arm Short

2

4

102024 Rocker Arm Long

2

5

100605 Bolt

M6x20 10.9

4

6

100080 Rocker Axle

4

7

101973 Rocker Arm Support 1

2

8

101974 Rocker Arm Support 2

2
