8.66

Steering and Suspensions

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

Rear Track Shock Service

1.

Raise the snowmobile off the ground with a
snowmobile lift.

NOTE:  Lifting at the bumper will compress the RTS.

2.

Remove the seat assembly.

3.

Remove the nut holding the fuel tank to the x-brace.

4.

Remove the nut securing the shock to the rear crank.

5.

Carefully lift up the rear of the fuel tank to access the
shock fasteners. Prop the tank with a block of wood.

6.

Remove the shock. To remove spring, turn preload
knob counter-clockwise. Remove spring retainer, and
then spring.

7.

To remove the reservoir, remove the two clamp
screws. Note the orientation of the reservoir hose.
route the hose as shown during installation.

8.

Assembly is the reverse of removal. Torque fasteners
to specification using new lock nuts.

= T

Rear Track Shock Fasteners: 33 ft-lb (45 Nm)



Reservoir Clamp Screws: 17 ft-lb (23 Nm)



Fuel Tank Screw: 7 ft-lb (10 Nm)



Seat Screws” 7 ft-lb (10 Nm)

8.67

Steering and Suspensions

8

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

RMK COIL-OVER REAR SUSPENSION

Suspension Adjustments

The primary tuning component on all RMK coil-over rear
suspensions is the rear track shock spring installed length.

All RMK coil-over rear suspensions are manufactured with
STANDARD rear track shock springs that will
accommodate rider weights (with gear) up to



340 lbs. (154kg).

Initially, the rear track shock spring should be set to the
rider’s weight (with gear). Reference the Rear Track
Shock Spring (RTSS) Setup Table below.

RMK Coil-Over Standard Springs

• RMK = 7043680-133 (210 Rate)

• PRO RMK = 7043714-133 (190 Rate)

• RMK Assault = 7043572-133 (210 Rate)

RTSS Setup-Standard Spring

(Measure spring length with suspension off the ground.)

RIDER



WEIGHT

(

WITH



GEAR

)

MODEL

INSTALLED



SPRING



LENGTH

(

REAR



SUSPENSION



OFF



THE



GROUND

)

LBS.

KG

INCHES

CM

<160

<73

RMK

PRO RMK 155/163

10 3/4

27.3

RMK ASSAULT

10 7/8

27.6

160-220

73-100

RMK

10 1/4

26

PRO RMK 155/163

10 3/8

26.3

RMK ASSAULT

10 1/4

26

220-280

100-127

RMK

PRO RMK 155/163

10 1/8

25.7

RMK ASSAULT

10

25.4

280-340

127-154

RMK

PRO RMK 155/163

9 3/4

24.8

RMK ASSAULT

9 1/2

24.1

NOTE: BOLD/SHADED CELLS = FACTORY SETTING.

CAUTION

CAUTION: Do not adjust STANDARD spring length

greater than (>) or less than (<):

RMK = >10 3/4" or <9 5/8"

PRO RMK = >11" or <9 3/4"

RMK Assault = >11" or <9 3/8"

8.68

Steering and Suspensions

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

Heavy Duty Rear Track Shock Spring-RMK

Coil-Over

An optional HEAVY DUTY spring is available if
adjustments to the factory-installed springs are not
sufficient for riders over 300 lbs. (136kg).

The part number for the HD spring is 7043741-067.
Reference the RTSS Setup-Heavy Duty Spring Table
below.

Measuring Rear Track Shock Spring Installed

Length

1.

Lift the rear of the snowmobile off the ground or tip
the snowmobile on to its side to remove the weight
from the rear suspension.

2.

Use a tape measure to measure the spring installed
length between the two spring retainers.

3.

To adjust, clear away any snow/ice that may be
trapped within the spring or threads. Rotate the spring
using a spanner wrench to change the length.
Regardless of spring type, do not adjust the spring
past the MAXIMUM or MINIMUM measurements.

Spring Retainer Spanner Wrench

Use the spanner wrench included in the tool kit to adjust
the rear track shock spring installed length.

RTSS Setup-Heavy Duty Spring

(Measure spring length with suspension off the ground.)

RIDER



WEIGHT

(

WITH



GEAR

)

MODEL

INSTALLED



SPRING



LENGTH

(

REAR



SUSPENSION



OFF



THE



GROUND

)

LBS.

KG

INCHES

CM

250-300

113-136

RMK

PRO RMK 155/163

RMK ASSAULT

10 1/8

25.7

300-350

136-159

10

25.4

CAUTION

CAUTION: Do not adjust HEAVY DUTY spring length

greater than (>) or less than (<):

ALL MODELS = >10 7/8" or < 9 7/8"

INSTALLED LENGTH

Spanner Wrench PN:

2871095-329

8.69

Steering and Suspensions

8

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

Fine Tuning Adjustments

Additional minor adjustments can be made to the spring
length to adjust the feel of the vehicle. Do not exceed the
minimum and maximum installed length requirements.

For more ski lift (transfer), reduce spring preload by
increasing the installed length. Rotate the spring 1-2 full
turns counter-clockwise (when viewed from bottom). This
will enhance maneuverability, making the snowmobile
more “flickable” although it may hinder climbing
performance.

For less ski lift (transfer), increase spring preload by
reducing the installed length. Rotate the spring 1-2 full
turns clockwise (when viewed from bottom). This will
improve climbing ability and rider control.

To control the overall balance of the vehicle use the
following guidelines:

• More rear track shock spring preload increases ski

pressure. Less preload decreases ski pressure.

• Spring preload can affect bottoming resistance.

More preload means less bottoming. Less preload
means a softer ride (and more bottoming).

Both adjustments will affect overall balance and ski
pressure.

After adjusting RTSS preload, the front track shock (FTS)
spring preload and independent front suspension (IFS)
spring preload can also be adjusted.

For a softer ride on rough, washboard surfaces, reduce
front track shock (FTS) spring preload by 1-2 turns.

To improve corner stability, increase front suspension
(IFS) spring preload by 1-2 turns on both sides of the
vehicle.

Shock Dampening

Compression damping adjustments can be made on 800
RMK and 800 RMK Assault models to control ride quality
and bottoming resistance.

600/800 RMK - Rear Track Shock

Make the adjustments in half-turn increments, then test
ride. To stop bottoming, turn the damping screw clockwise
one half-turn, then test ride. Repeat the adjustment until
bottoming stops and the desired ride quality is achieved.

800 RMK Assault - IFS and Rear Track Shocks

Compression damping can be adjusted at the front
suspension and at the rear track shock. Make adjustments
in 2-click increments, then test ride. When adjusting the
front suspension, always adjust both clickers equally.

To stop bottoming of the front or rear suspension (stiffer
ride), rotate the clicker(s) clockwise two clicks (as viewed
from the top of the clicker), then test ride. Repeat the
adjustment until bottoming stops and the desired ride
quality is achieved.

For a more plush ride at the front or rear suspension, rotate
the clicker(s) counterclockwise two clicks, then test ride.
Repeat the adjustment until the desired ride quality is
achieved.

COMPRESSION SCREW
