Snowmobile Polaris IQ (2007-2008 year). Manual - part 7

1.22

Model Specifications

2008 600 RMK 144 / 600 RMK Shift 155

Model Number:
600 RMK 144: S08PK6FS / S08PK6FE
600 RMK Shift 155: S08PM6FS

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S3467-6044-PU6F

Displacement / # Cylinders

599cc / 2

Bore (inches/mm)

3.04 / 77.25

Stroke (inches/mm)

2.52 / 64

Piston to Cylinder Clearance
(inches/mm)

.004 - .006 / .105 - .159

Installed Ring Gap
(inches / mm)

.014 - .020 / .0356 - .508

Operating RPM ±200

8100

Idle RPM

1500

Engagement RPM ±200

3800

Exhaust Valve Spring

Pink

Carburetor Settings

Type

Mikuni TM38

Main Jet

280

Pilot Jet (Pj)

50

Jet Needle/Clip position

9DGN6-57 / 2

Needle Jet

P-8

Throttle Gap (Under Cutaway) (in/mm)

.125 / 3.2

Cutaway

2.5

Valve Seat

1.5

Starter Jet

145

Pilot Air Jet

.9

Fuel screw (Turns Out)

.5

Recommended Fuel Octane (R+M/2)

91

(Non-Oxygenated)

Carburetor Jetting

Altitude

Meters

(feet)

Ambient Temperature

< -25

°F/<-35°

C

-30°

F to -10

°F/-34

°C

 to

 -23°

C

-1

5°F t

o

 +5°

F

/-

26°

C t

o

 -15°

C

0°

F to

+20

°F/-1

8°C

 t

o

 -7°

C

+15°

F t

o

 +35°

F/-9°

C

 to +2°

C

+3

0°F t

o

 +50°

F/-1°

C

 t

o

 +10°

C

+45°

F to

 +6

5°F/

+7°

C

 to

+1

8°C

>+60°F/

>+

16°

C

0-600

(0-2000)

440

#3

430

#3

420

#2

400

#2

390

#2

380

#2

370

#2

360

#1

600-1200

(2000-4000)

410

#3

400

#3

390

#2

370

#2

360

#2

350

#2

340

#2

330

#1

1200-1800

(4000-6000)

370

#3

360

#2

350

#2

340

#2

330

#2

320

#2

310

#1

300

#1

1800-2400

(6000-8000)

340

#3

320

#2

310

#2

300

#2

280

#2

280

#1

270

#1

260

#1

2400-3000

(8000-10,000)

310

55Pj

#2

300

55Pj

#2

290

55Pj

#2

280

55Pj

#2

270

55Pj

#2

260

55Pj

#1

250

55Pj

#1

240

55Pj

#1

3000-3700

(10,000-12,000)

290

55Pj

#2

280

55Pj

#2

270

55Pj

#2

250

55Pj

#1

240

55Pj

#1

230

55Pj

#1

220

55Pj

#1

210

55Pj

#1

When using non oxygenated fuel with a RON greater than 93,

decrease the main jet number in the above chart by 10 and raise the

E-clip one position. If the chart recommends clip #1, install washer on

top when using RON 93.

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-62

140 / 330

(7043342)

BLACK

(155 / 222)

56/42 - .36

LW ER

19:41-76

600-1200

(2000-4000)

10-60

1200-1800

(4000-6000)

10-58

1800-2400

(6000-8000)

10-56

2400-3000

(8000-10,000)

10-54

3000-3600

(10,000-12,000)

10-AL

Drive Clutch Bolt Torque: 50 lb.ft. (68Nm)

1.23

Model Specifications

1

General

Width (in/cm)

46.5 / 115.6

Length (in/cm)

124 / 315 (144)

129 / 327.7 (155)

Height (in/cm)

48 / 121.9

Estimated Dry Weight
(lb/kg)

472 / 214.3 (144)
478 / 216.8 (155)

Fuel (Gallons / Liters)

11.5 / 43.5

Oil (Quarts / Liters)

3 / 2.8

Cooling System Capacity
(Quarts / Liters)

144 = 6.25 / 6

155 = 6.5 / 6.1

Brake Fluid

DOT 4

Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)

3211115

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System

8.373

19
41
76

Polaris Synthetic

11 / 325.3

Perc

Electrical

Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)

13.5 - 14.5 Vdc

280

Ignition Timing

26_ @3500 RPM

(TPS Un-plugged)

Spark Plug Gap in.(mm)

.027 (.70)

Spark Plug

Champion RN57YCC

CDI Marking

4011033

Flywheel Marking

4010677

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

144 (365.7)
155 (393.7)

Lug Height - Inches (cm)

2.0 (5.08) (144)

2.4 (6) (155)

Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler
shaft

3/8

″

- 1/2

″

 (1 - 1.3cm)

Front Suspension

Suspension Type

IQ RMK

Shocks

Ryde FX

IFS Spring Rate
lbs/in (N/mm)

100 (17.5)

Spring Installed Length
Inches (cm)

10.35 (26.2)

Front Vertical Travel
Inches (cm)

9 (22.9)

Ski Center Distance
Inches (cm)
Setup Width

39 - 40 - 41 (99.1 - 101.6 - 104.1)

38.67 (98.2)

Camber Inches (cm)

2.17

± 0.31 (55 ± 7.9)

Toe Out Inches (cm)

0 - 0.12 (0 - 0.31)

Rear Suspension

Suspension Type

IQ RMK 144 / 155

Front Track Shock (FTS)

Ryde FX

FTS Spring Rate
lbs/in (N/mm)

190 (33)

Rear Track Shock (RTS)

Ryde AFX

Compression Adjustable

Torsion Springs

.359 Square / 77_ (Stock)
.347 / 77_ / (Soft)
 - PN 7041627 - 067
 - PN 7041628 - 067
.375 / 77_ / (Firm)
 - PN 7041942 - 067
 - PN 7041943 - 067

Rear Travel Inches (cm)

14.5 (36.8) (144)
15.5 (39.4) (155)

1.24

Model Specifications

2008 600 Dragon IQ

Model Number:
S08PP6HS / S08PP6HE

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S3468-6044-PU6H

Displacement / # Cylinders

599cc / 2

Bore (inches/mm)

3.04 / 77.25

Stroke (inches/mm)

2.52 / 64

Piston to Cylinder Clearance
(inches/mm)

.004 - .006 / .105 - .159

Installed Ring Gap
(inches / mm)

.014 - .020 / .356 - .508

Operating RPM ±200

8250

Idle RPM

1700

Engagement RPM ±200

3800

Exhaust Valve Spring

Purple

Fuel Delivery

Type

Cleanfire Direct Injection

Throttle Body Marking

1203213

Throttle Body Bore

46mm

TPS Voltage @ Idle

0.95 +/- 0.01 Vdc

Fuel Pressure - PSI (bar)

58 (4.0)

Recommended Fuel Octane
(R+M/2)

91 Non-Oxygenated

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-64

BLK / GRN

(120 / 340)

(7042083)

RED/BLK

(140 / 240)

(7043058)

56/42 - .36

LW-ER

23:39-76

600-1200

(2000-4000)

10-62

22:39-76

1200-1800

(4000-6000)

10-60

22:40-76

1800-2400

(6000-8000)

10-58

2400-3000

(8000-10000)

10-56

20:41-76

3000-3600

(10000-12000)

10-AL

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

General

Width (in/cm)

48 / 121.9

Length (in/cm)

115 / 292.1

Height (in/cm)

48.5 / 123.2

Estimated Dry Weight
(lb/kg)

476 / 216.1

Fuel (Gallons / Liters)

11.7 / 44.3

Oil qts/l

3/2.8

Cooling System Capacity
(Quarts / Liters)

8.5 / 8

Brake Fluid

DOT 4

Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)

3211122

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System

8.373

23
39
76

Polaris Synthetic

11 / 325.3

Perc

Electrical

Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)

13.5 - 14.5 Vdc

400

Ignition Timing

18_ @1700 RPM

Coolant Temp = 120_F (49_C)

Spark Plug Gap in.(mm)

.027 (.70)

Spark Plug

Champion RN57YCC

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

121 (307.3)

Lug Height - Inches (cm)

1.25 (3.175)

Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler
shaft

7/8

″

- 1-1/8

″

(2.2 - 2.9cm)

1.25

Model Specifications

1

Front Suspension

Suspension Type

IQ 42.5

Shocks

Ryde FX Air 2.0

Air 2.0 Nitrogen Pressure
36mm Cylinder
47mm Cylinder

145 psi

60 psi

Front Vertical Travel
Inches (cm)

10 (25.4)

Ski Center Distance
Inches (cm)
Setup Width

42.5 (108)

41.16 (104.5)

Camber Inches (cm)

2.25

± 0.31 (57 ± 7.9)

Toe Out Inches (cm)

0 - 0.12 (0 - 0.31)

Rear Suspension

Suspension Type

IQ 121

Front Track Shock (FTS)

Ryde FX HPG w/IFP

FTS Spring Rate
lbs/in (N/mm)

130 - 270 (23 - 47)

FTS Spring  Installed
Length (inches / cm)

7.97

Rear Track Shock (RTS)

Ryde FX Compression

Adjustable w/Remote Res.

Torsion Springs

.347 Square / 80_ (Soft)
 - PN 7043070 - 067
 - PN 7043071 - 067
.347 Square / 77_ (Softest)
 - PN 7043240 - 067
 - PN 7043241 - 067
.359 Square / 12.5# (Stock)
 - PN 7043079 - 067
 - PN 7043080 - 067

Rear Travel Inches (cm)

13.9 (35.3)
