1.18

Model Specifications

2007 700 HO RMK Dragon

Model Number: S07PL7JS / S07PL7JE

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S3322-7044-PF7J

Displacement / # Cylinders

700cc / 2

Bore (inches/mm)

3.19 / 81

Stroke (inches/mm)

2.68 / 68

Piston to Cylinder Clearance
(inches/mm)

.0042 - .006 / .109 - .163

Installed Ring Gap
(inches / mm)

Upper: .010 - .018 / .25 - .45

Lower: .014 - .020 / .35 - .50

Operating RPM ±200

8250

Idle RPM

1700

Engagement RPM ±200

3800

VES Spring Color

Purple

Fuel Delivery

Type

Cleanfire Direct Injection

Throttle Body Marking

1203213

Throttle Body Bore

46mm

TPS Voltage @ Idle

0.95 +/- 0.01 Vdc

Fuel Pressure - PSI (bar)

58 (4.0)

Recommended Fuel Octane
(R+M/2)

91 Non-Oxygenated

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

DRIVEN CLUTCH

Shift

Weight

Clutch Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-66

BLK / GRN

(120 / 340)

(7042083)

BLACK

(155 / 222)

56/42 .36

LWT ER

20:41-76

600-1200

(2000-4000)

10-64

1200-1800

(4000-6000)

10-62

1800-2400

(6000-8000)

10-60

2400-3000

(8000-10000)

10-58

3000-3600

(10000-12000)

10-56

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

General

Width (in/cm)

46.5 / 118.1

Length (in/cm)

130 / 330.2

Height (in/cm)

49 / 124.5

Estimated Dry Weight
(lb/kg)

478 / 217

Fuel (Gallons / Liters)

12 / 45.4

Oil (Quarts / Liters)

3.4 / 3.2

Cooling System Capacity
(Quarts / Liters)

6.3 / 6

Brake Fluid

DOT 4

Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)

3211115

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System

8.373

20
41
76

Polaris Synthetic

11 / 325.3

Perc

Electrical

Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)

13.5 - 14.5 Vdc

400

Ignition Timing

18_ @1700 RPM

Coolant Temp = 120_F (49_C)

Spark Plug Gap in.(mm)

.027 (.70)

Spark Plug

Champion RN57YCC

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

155 (393.7)

Lug Height - Inches (cm)

2.4 (6.1)

Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler shaft

3/8

″

- 1/2

″

 (1 - 1.3cm)

1.19

Model Specifications

1

Front Suspension

Suspension Type

IQ RMK

Shocks

Walker Evans Air

Oil Volume

95cc

Nitrogen Charge
Stock
Optional

215 psi

220 - 225 psi

Front Vertical Travel
Inches (cm)

9 (22.9)

Ski Center Distance
Inches (cm)
Setup Width

39(99.1) / 40(101.6) / 41(104.1)

38.67 (98.2)

Camber Inches (cm)

2.17

± 0.31 (55 ± 0.79)

Toe Out Inches (cm)

0 - 0.12 (0 - 0.31)

Rear Suspension

Suspension Type

IQ RMK 155

Front Track Shock (FTS)

Walker Evans Air

Oil Volume

70cc

FTS Nitrogen Charge
Stock
Optional

215 psi

210 - 220 psi

Rear Track Shock (RTS)

Walker Evans w/IFP

RTS Nitrogen Charge

200 psi

Torsion Springs

.359 Square / 77_ (Stock)
.347 / 77_ / (Soft)
 - PN 7041627 - 067
 - PN 7041628 - 067
.375 / 77_ / (Firm)
 - PN 7041942 - 067
 - PN 7041943 - 067

Rear Travel Inches (cm)

15.5 (39.4)

1.20

Model Specifications

2008 IQ Shift

Model Number: S08PB6FS / S08PB6FE

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S3466-6044-PU6F

Displacement / # Cylinders

599cc / 2

Bore (inches/mm)

3.04 / 77.25

Stroke (inches/mm)

2.52 / 64

Piston to Cylinder Clearance
(inches/mm)

.004 - .006 / .105 - .159

Installed Ring Gap
(inches / mm)

.014 - .020 / .0356 - .508

Operating RPM ±200

8100

Idle RPM

1700

Engagement RPM ±200

3800

Exhaust Valve Spring

Pink

Carburetor Settings

Type

Mikuni TM38

Main Jet

400

Pilot Jet

45

Jet Needle/Clip position

9DGN6-57 / 3

Needle Jet

P-8

Throttle Gap (Under Cutaway) (in/mm)

.082 / 2.1

Cutaway

2.0

Valve Seat

1.5

Starter Jet

145

Pilot Air Jet

1.0

Fuel screw (Turns Out)

1.0

Recommended Fuel Octane (R+M/2)

91

(Non-Oxygenated)

Carburetor Jetting

Altitude

Meters (feet)

Ambient Temperature

< -25

°F/<-35°

C

-30°

F to -10

°F/-34

°C

 to

 -23°

C

-1

5°F t

o

 +5°

F

/-

26°

C t

o

 -15°

C

0°

F to

+20

°F/-1

8°C

 t

o

 -7°

C

+15°

F t

o

 +35°

F/-9°

C

 to +2°

C

+3

0°F t

o

 +50°

F/-1°

C

 t

o

 +10°

C

+45°

F to

 +6

5°F/

+7°

C

 to

+1

8°C

>+60°F/

>+

16°

C

0-600

(0-2000)

440

#3

430

#3

420

#3

400

#3

390

#3

380

#2

370

#2

360

#1

600-1200

(2000-4000)

410

#3

400

#3

390

#3

370

#3

360

#2

350

#2

340

#1

330

#1

1200-1800

(4000-6000)

370

#3

360

#2

350

#2

340

#2

330

#2

320

#1

310

#1

300

#1

1800-2400

(6000-8000)

340

#3

320

#2

310

#2

300

#2

280

#2

280

#1

270

#1

260

#1

2400-3000

(8000-10,000)

310

#2

300

#2

290

#2

280

#1

270

#1

260

#1

250

#1

240

#1

3000-3700

(10,000-12,000)

290

#2

280

#2

270

#1

250

#1

240

#1

230

#1

220

#1

210

#1

When using non oxygenated fuel with a RON greater than 93,

decrease the main jet number in the above chart by 10 and raise the
E-clip one position. If the chart recommends clip #1, install washer

on top when using RON 93.

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-62

BLK / GRN

(120 / 340)

(7042083)

RED/BLK

(140 / 240)

(7043058)

64/42.36

LW ER

23:39-76

600-1200

(2000-4000)

10-60

56/42 - .36

LW ER

22:39-76

1200-1800

(4000-6000)

10-58

22:40-76

1800-2400

(6000-8000)

10-56

2400-3000

(8000-10,000)

10-54

20:41-76

3000-3600

(10,000-12,000)

10-AL

Drive Clutch Bolt Torque: 50 lb.ft. (68Nm)

1.21

Model Specifications

1

General

Width (in/cm)

48.5 / 123.2

Length (in/cm)

115 / 292.1

Height (in/cm)

48 / 121.9

Estimated Dry Weight
(lb/kg)

466 / 211.6

Fuel (Gallons / Liters)

11.7 / 44.3

Oil (Quarts / Liters)

3 / 2.8

Cooling System Capacity
(Quarts / Liters)

8.5 / 8

Brake Fluid

DOT 4

Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)

3211122

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System

8.373

23
39
76

Polaris Synthetic

11 / 325.3

Perc

Electrical

Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)

13.5 - 14.5 Vdc

280

Ignition Timing

26_ @3500 RPM

(TPS Un-plugged)

Spark Plug Gap in.(mm)

.027 (.70)

Spark Plug

Champion RN57YCC

CDI Marking

4011033

Flywheel Marking

4010677

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

121 (307)

Lug Height - Inches (cm)

.91 / (2.3)

Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler
shaft

7/8

″

- 1-1/8

″

(2.2 - 2.9cm)

Front Suspension

Suspension Type

IQ 42.5

Shocks

Ryde FX MPV

IFS Spring Rate
lbs/in (N/mm)

100 (17.5)

Spring Installed Length
Inches (cm)

10.5 (26.67)

Front Vertical Travel
Inches (cm)

10 (25.4)

Ski Center Distance
Inches (cm)
Setup Width (cm)

42.5 (108)

41.16 (104.5)

Camber Inches (cm)

2.25

± 0.31 (57 ± 7.9)

Toe Out Inches (cm)

0 - 0.12 (0 - 0.31)

Rear Suspension

Suspension Type

IQ 121

Front Track Shock (FTS)

Ryde FX MPV

FTS Spring Rate
lbs/in (N/mm)

170 (29.75)

Rear Track Shock (RTS)

Ryde FX MPV

Torsion Springs

.347 Square / 80_ (Stock)
 - PN 7043070 - 067
 - PN 7043071 - 067
.347 Square / 77_ (Soft)
 - PN 7043240 - 067
 - PN 7043241 - 067
.359 Square / 12.5# (Firm)
 - PN 7043079 - 067
 - PN 7043080 - 067

Rear Travel Inches (cm)

13.9 (35.3)
