66

MAINTENANCE

Lubrication

Rear Suspension

Grease the rear suspension pivot shafts (raise the rear of unit). Locations
are shown below.

An (X) indicates a grease point or fitting.

x

x

x

x

x

67

MAINTENANCE

Lubrication

Driveshaft Bearing

Inject grease into the fitting on the
speedometer drive adaptor until
grease purges from inside or outside
the bearing seal (approximately two
pumps).

Throttle Cable

Lubricate the throttle cable lightly
with grease or oil. With the engine
off, turn the handlebars to the left
and lubricate liberally as shown.

Choke and Cable

Lubricate the choke slide and cables
lightly with oil or grease. Before
turning the engine off, operate the
choke intermittently to draw
moisture out of the choke plunger
area and reduce the possibility of
the choke becoming frozen.

Coupler Greasing

Grease the couplers on the
jackshaft (1) and driveshaft (2).

x

x

x

1

2

68

MAINTENANCE

Lubrication

Gearcase Oil Level

Check the gearcase oil level at the
intervals outlined in the maintenance
charts beginning on page 64. Change
the gearcase oil after the first 500 miles
(800 km), then every 1000 miles (1600
km) or seasonally.

To check the oil level, place the
snowmobile on a level surface. The oil
level should be between the “safe”
marks on the dipstick (1). Do not
overfill.

POLARIS recommends the use of
POLARIS Synthetic Chaincase Lube.
See page 106 for the part numbers of
POLARIS products.

Clean the magnetic plug (2) every 500
miles (800 km) and whenever checking
or changing lubricant.

NOTICE: Mixing brands or using non-recommended lubricants could result in

excessive wear to chain, sprockets and bearings. Always use
POLARIS-recommended products for your vehicle.

1

2

69

MAINTENANCE

Spark Plugs

It’s very important to use the correct spark plug for your snowmobile. A
spark plug with a heat range too high will cause engine damage. A spark
plug with a heat range too low will cause excessive fouling and engine
malfunctioning.

In selecting a spark plug heat range for production, a manufacturer
assumes that the engine will be operated under extreme heavy duty
conditions and selects a spark plug that will protect the engine from
internal damage if the purchaser actually does operate the engine in this
manner. This selection could cause the customer who normally operates
the engine under medium or light duty to have spark plug failure.

NOTICE: A spark plug with a heat range too high will always cause engine

damage if the engine is operated in conditions more severe than
intended for that plug. Always use the spark plugs recommended for
your snowmobile. Refer to the specifications section beginning on
page 104.

A new engine can cause temporary spark plug fouling due to the
preservative added during the assembly process. Avoid prolonged idle
speeds, which cause plug fouling and carbonization.
• Use recommended spark plugs with the proper gap. Refer to the

specifications section beginning on page 104.

• Spark plug torque is 18-22 ft. lbs. (24.4-29.8 Nm).
• Always carry spare spark plugs in case of an emergency.

NOTICE: Using non-recommended spark plugs can result in serious engine

damage. Always use POLARIS-recommended spark plugs.
