31

FEATURES

Adjustable Headlights

Move the adjuster to the left to lower the
headlight beam.

Move the adjuster to the right to raise the
headlight beam.

Radiator Compartment
Access Panel

The access panel is provided for cleaning
debris from the radiator.

Cargo Bag

The cargo bag is secured to the rear
of the tunnel with straps. The cargo
bag and the passenger seat are
removable to provide open storage
for transporting larger items. The
maximum weight capacity for the
cargo area is 30 lbs. (14 kg). Always
secure cargo before operating. Do not
exceed the weight limit. Do not allow
a passenger to sit on the seat back or
the cargo area.

Seat Latch

1. Push down on the seat latch lever, which is located at the lower rear

of the passenger seat.

2. Lift up the seat and remove it from the chassis.

3. Reverse the procedure to reinstall the seat. Press down firmly on

both sides of the seat to engage the latch. Verify that the latch is
engaged by firmly pulling the seat upward.

X

X

Cargo

Bag

Seat Latch

32

FEATURES

Passenger Grab Handle

On some models the position of the passenger grab handles can be
adjusted for rider preference.

1. Unscrew and remove the knob assemblies that secure the grab han-

dles.

2. Reposition the grab handles to one of the three available positions

on the grab handle tube between the operator seat and the passenger
seat.

3. Reinstall the knob assemblies and tighten securely.

33

FEATURES

12-Volt DC Outlet

If equipped, use the outlet to power
a global positioning sensor (GPS),
heated helmet shield, utility light,
cell phone or other accessories.

The 12-volt DC outlet is installed
in the recoil pocket next to the
right hood hold-down. If you
install an accessory outlet on your
model, always install it in the
recoil pocket. The fuel filter is
installed in the upper console area.
Do not install an outlet on the
upper console.

WARNING! Serious injury could occur if sparks ignite a fuel supply. Do not
install an accessory 12-volt DC outlet on the upper console. Install the outlet in
the recoil pocket.

12-Volt DC Outlet

34

FEATURES

RIDER SELECT Adjustable Steering System

The RIDER SELECT adjustable steering system (if equipped) allows
you to adjust the handlebar position to fit your style of riding. Some
models have five (5) adjustment positions. Other models have seven (7)
positions.

WARNING! If your snowmobile has five adjustment positions, do not remove
the RIDER SELECT lockout. Your POLARIS snowmobile has been engineered
for this range of adjustability. Removing this lockout and using RIDER SELECT
position 6 or 7 will result in the handlebars and brake lever contacting other
components and interfering with steering and braking. This could lead to loss of
control resulting in serious injury or death. Always be sure that the handlebars
and brake lever do not contact any other snowmobile components at any
steering position AND at any RIDER SELECT position.

Do not use RIDER SELECT positions 6 or 7 unless riding conditions require it.
Operation in position 6 or 7 can reduce vehicle handling for other types of riding
and result in serious injury or death.
