89

MAINTENANCE

Lubrication Recommendations

Front Stabilizer

Bar Bushings

Rear Control

Arm Pivot

Bushings

Front Control

Arm Pivot

Bushings

90

MAINTENANCE

Engine Oil

Oil Recommendations

POLARIS recommends the use of POLARIS PS-4 Full Synthetic 5W-
50 4-cycle oil for this engine.

WARNING! Vehicle operation with insufficient, deteriorated, or contaminated
engine oil will cause accelerated wear and may result in engine seizure,
accident, and injury. Always perform the maintenance procedures as outlined in
the Periodic Maintenance Chart.

Oil may need to be changed more frequently if POLARIS PS-4 engine
oil is not used. Follow the manufacturer's recommendations for ambient
temperature operation. See page 132 for the part numbers of POLARIS
products.

NOTICE: Mixing brands or using a non-recommended oil may cause serious

engine damage. Always use the recommended oil. Never substitute
or mix oil brands.

91

MAINTENANCE

Engine Oil

Always check and change the oil at the intervals outlined in the Periodic
Maintenance Chart beginning on page 83. Always use the recommended
engine oil.

NOTICE: Allowing dirt or debris to enter the engine can result in serious engine

damage. Always clean away all dirt and debris from the dipstick area
before removing the dipstick.

Oil Check

The oil dipstick and fill tube is located
on the engine, behind the passenger
seat. Access the dipstick through the
right rear wheel well.

1. Position the vehicle on a level

surface.

2. Place the transmission in PARK.

3. Always clean away all dirt and

debris from the dipstick area
before removing the dipstick.
Remove the dipstick. Wipe it dry
with a clean cloth.

4. Reinstall and tighten the dipstick.

5. Remove the dipstick and

check the oil level.

6. Add the recommended fluid as

needed. Maintain the oil level
in the safe range between the
FULL and ADD marks. Do
not overfill.

7. Reinstall and tighten the

dipstick.

Dipstick

Full

Add

92

MAINTENANCE

Engine Oil

Oil and Filter Change

Always check and change the oil at the intervals outlined in the Periodic
Maintenance Chart beginning on page 83. Always change the oil filter
whenever changing oil.

The engine drain plug is located on the
bottom of the crankcase.

1. Position the vehicle on a level surface.

Place the transmission in PARK.
Apply the brakes.

2. Start the engine. Allow it to idle for

two to three minutes. Stop the engine.

3. Clean the area around the drain plug.

CAUTION! Hot oil can cause burns to skin. Do
not allow hot oil to contact skin.

4. Place a drain pan beneath engine

crankcase and remove the drain plug.

5. Allow the oil to drain completely.

6. Reinstall the sealing washer on the

drain plug.

Tip: The sealing surfaces on drain plug and crankcase should be clean and free

of burrs, nicks or scratches.

7. Reinstall the drain plug. Torque to 12 ft. lbs. (16 Nm).

Drain Plug Access
