108

MAINTENANCE

Air Filter

Always clean all dirt and debris away from the air box area before

servicing the air filter. Always change the air filter at the intervals

outlined in the Periodic Maintenance Chart beginning on page 85.
1. Remove the cargo box access panel.
2. Clean all dirt and debris from the air

box area BEFORE servicing the air

filter.

3. Unlatch the cover clips and carefully

remove the air box cover.

4. Loosen the air filter clamp and

remove the filter.

NOTICE: Dirt or debris in the air box could

result in severe engine damage.

Always clean all dirt and debris from

the air box before installing the filter.

5. Inspect the air box for dirt, debris, oil

or water. Compress the edges of the

air box drain to drain any water. Clean

the air box thoroughly and wipe it

well with a clean, dry cloth.

6. Reinstall the filter. Install a new filter

if needed. Do not attempt to clean the

air filter. Tighten the clamp.

7. Reinstall the air box cover and secure

the cover clips.

8. Reinstall the access panel.

Cover Clips (2)

Cover Hinges

Filter

Clamp

Air Box Drain

109

MAINTENANCE

Breather Hose Inspection

1. Remove the breather hose clamp at the engine (near the exhaust

outlet).

2. Pull the other end of the breather hose assembly away from the

airbox.

3. Remove the breather hose assembly from the vehicle.
4. Inspect the hoses for debris. Blow gently through the hoses to check

for clogging. Replace a damaged or clogged hose.

5. Check hoses for cracks, deterioration, abrasions or leaks. Replace as

needed.

6. Reinstall the hose assembly and secure the clamp at the engine.

Push the other end of the hose firmly into the airbox fitting.

NOTICE: Operation of the vehicle without breather hoses can cause engine

damage. Always reinstall a breather hose after removing it for

service.

Intake Pre-Filters

The engine intake pre-filter is located on

the right side of the cargo box. The PVT

intake pre-filter is located on the left side

of the cargo box.
Inspect both pre-filters before each use of

the vehicle to ensure adequate air flow. If

necessary, remove the pre-filters and

clean with soapy water. Dry with low

pressure compressed air.

NOTICE: When washing the vehicle, always

avoid spraying water directly

toward the PVT intake duct. See

page 127 for recommended

washing procedures.

Engine Intake

Pre-Filter

110

MAINTENANCE

Spark Arrester

Failure to heed the following warnings while servicing the spark arrester could

result in serious injury or death.
Never run the engine in an enclosed area. Remove any combustible materials

from the area. Wear eye protection and leather work gloves. Do not stand

behind or in front of the vehicle while purging. Never go under the vehicle while

it's inclined.
The exhaust system can get extremely hot. Do not perform service on the spark

arrester while the system is hot. Allow components to cool sufficiently before

proceeding.

Use the following procedure to periodically purge accumulated carbon

from the exhaust pipe/muffler.
1. Remove the arrester clean-out

plug from the bottom of the

muffler.

2. Place the transmission in PARK.
3. Start the engine.
4. Quickly press and release the

throttle pedal several times to

purge carbon from the system.

5. If carbon comes out of the

exhaust, cover or plug the

exhaust outlet. Wear protective

gloves.

6. Lightly tap on the exhaust pipe with a rubber mallet while repeating

step 4.

7. If particles are still suspected to be in the muffler, elevate the rear of

the vehicle one foot (30 cm) higher than the front. Block the wheels.

8. Place the transmission in PARK. Repeat steps 4 to 6 until no more

particles are expelled.

9. Stop the engine. Allow the arrester to cool.
10. Reinstall the arrester plug and remove the exhaust outlet cover or

plug.

WARNING

Exhaust Outlet

Clean-Out

Plug

111

MAINTENANCE

Brakes

The front and rear brakes are hydraulic disc type brakes activated by the

brake pedal. See page 35.
Always check brake pedal travel and the brake fluid reservoir level

before each use of the vehicle. When applied, the brake pedal should

feel firm. Any sponginess would indicate a possible fluid leak or low

brake fluid level, which must be corrected before riding. See page 112

for brake fluid information.
If you discover any irregularities in brake system operation, including

excessive pedal travel, contact your POLARIS dealer for proper

diagnosis and repairs.

WARNING! Operating the vehicle with a spongy brake pedal can result in loss

of braking, which could cause an accident resulting in severe injury or death.

Never operate the vehicle with a spongy-feeling brake pedal.
