76

WINCH GUIDE

Winch Operation

Read the Winch Safety Precautions in the preceding pages before using

your winch.

Tip: Consider practicing the operation and use of your winch before you actually

need to use it in the field.

Improper winch use can result in SEVERE INJURY or DEATH. Always

follow all winch instructions and warnings in this manual.

Each winching situation is unique.

• Take your time to think through the winching you are about to do.
• Proceed slowly and deliberately.
• Never hurry or rush during winching.
• Always pay attention to your surroundings.
• You may need to change your winching strategy if it is not working.
• Always remember that your winch is very powerful.
• There are simply some situations that you and your winch will not be able

to deal with. Do not be afraid to ask others to help when this happens.

1. Always inspect the vehicle, winch, winch cable and winch controls

for any signs of damage or parts in need of repair or replacement

before each use. Pay particular attention to the first 3 feet (1 meter)

of winch cable if the winch is being used (or has been used) for lift-

ing an accessory plow assembly. Promptly replace any worn or

damaged cable.

2. Never operate a winch or a vehicle in need of repair or service.
3. Always apply your

vehicle’s park brake and/or

park mechanism to hold

the vehicle in place during

winching. Use wheel

chocks if needed.

WARNING

Hook Strap

77

WINCH GUIDE

Winch Operation

4. Always use the hook strap when

handling the hook.

WARNING! Never put your fingers into

the hook. This could lead to SEVERE

INJURY.

A. Attach the hook itself onto the

load or use a tow strap or chain

to secure the load to the winch

cable.

Tip: A “tow strap” is NOT intended to stretch. A “recovery strap” is designed to

stretch.

WARNING! Never use a recovery strap when winching due to the excessive

energy that can be released if the winch cable breaks. This can result in

SEVERE INJURY or DEATH. See the Shock Loading section on page 82.

B. Never hook the winch cable back onto itself. This will damage the

winch cable and may result in winch cable failure.

WARNING! Replace the winch cable at the first sign of damage to prevent

SEVERE INJURY or DEATH in the event of failure. For your safety, always

replace POLARIS winch parts (including the cable) with genuine POLARIS

replacement parts available at your authorized POLARIS dealer.

C. If possible, keep the winch cable aligned with the centerline of the

winching vehicle. This will help the spooling of the winch cable and

reduce the load on the fairlead.

D. If freeing a stuck vehicle by attaching to a tree, use an item such as a

tow strap to avoid damaging the tree during winch operation. Sharp

cables and chains can damage and even kill trees. Please remember

to TreadLightly® (treadlightly.org).

E. Before operating the winch, be sure

that the safety latch on the winch

cable hook is fully seated when the

load is attached.

F.

Never operate your winch with a

damaged hook or latch. Always

replace damaged parts before using

the winch.

NO

YES

NO

YES

78

WINCH GUIDE

Winch Operation

5. Never remove the hook strap from the hook.
6. Release the winch clutch and pull out the winch cable.
7. Pulling out as much cable as possible maximizes the winch’s pulling

capacity. Always be sure that at least five (5) full turns of winch

cable are wrapped around the winch drum at all times. The friction

provided by this wrapped cable allows the drum to pull on the

winch cable and move the load.

8. Read and adhere to the following information for winch damping to

ensure safe winch use.

A. In order to absorb energy that could be released by a winch cable

failure, always place a “damper” on the winch cable. A damper can be

a heavy jacket, tarp, or other soft, dense object. A damper can absorb

much of the energy released if a winch cable breaks when winching.

Even a tree limb can help as a damper if no other items are available to

you.

B. Lay the damper on top of the mid-point of the winch cable length that is

spooled out.

C. On a long pull, it may be necessary to stop winching so that the

damper can be repositioned to the new mid-point of the winch cable.

Always release the tension on the winch cable before repositioning the

damper.

D. Avoid being directly in line with the winch cable whenever possible.

Also, never permit others to stand near or in line with the winch cable

during winch operation.

9. Never hook the winch cable back onto itself. This will damage the

winch cable and may result in winch cable failure.

10. Never use straps, chains or other rigging items that are damaged or

worn.

79

WINCH GUIDE

Winch Operation

11. The ONLY time a winch-equipped vehicle should be moving when

using the winch is when that vehicle itself is stuck. The winch-

equipped vehicle should NEVER be in motion to “shock” load the

winch cable in an attempt to move a second stuck vehicle. See the

Shock Loading section on page 82. For your safety, always follow

these guidelines when winching a vehicle free:

A. Release the winch clutch and spool out the necessary length of winch

cable.

B. Align the winch cable as close as possible to the winching vehicle’s

centerline.

C. Attach the winch cable hook to the anchor point or the stuck vehicle’s

frame following instructions in this manual.

D. Re-engage the clutch on the winch.
E. Slowly winch in the slack in the winch cable.
F.

Select the proper vehicle gear to propel the stuck vehicle in the

direction of winching.

G. Shift to the lowest gear available on the stuck vehicle.
H. Slowly and carefully apply vehicle throttle and winch together to free

the vehicle.

I.

Stop winching as soon as the stuck vehicle is able to propel itself

without the help of the winch.

J.

Detach the winch cable hook.

K. Rewind the winch cable evenly back onto the winch drum following the

instructions in this manual.

12. Never attempt to winch another stuck vehicle by attaching the

winch cable to a suspension component, brush guard, bumper or

cargo rack. Vehicle damage may result. Instead, attach the winch to

a strong portion of the vehicle frame or hitch.

13. Extensive winching will run down the battery on the winching

vehicle. Let the winching vehicle’s engine run while operating the

winch to prevent the battery from running low if winching for long

periods.
