28

FEATURES

Detonation Elimination Technology (DET)

The DET system prevents damage to the engine from detonation by
going into an engine protection mode whenever the DET system is
active.

When excessive detonation is detected,
the check engine light will illuminate
and you may notice decreased engine
performance and RPM when the DET
system is activated. In most cases this
is temporary and the operator does not
need to take any action. The engine
will return to its normal performance
automatically.

If severe detonation occurs, the check engine light will begin to flash
steadily and the gauge indicator will read “dET” (see illustration). The
engine will enter a limp home mode and RPM will be limited to 6500
RPM. The engine will remain in this mode until it is shut down and
restarted.

Check Engine Light

Indicates

Solid or Flickering

Excessive detonation detected

Steady Flashing

Severe detonation detected, RPM will be limited

29

FEATURES

Detonation Elimination Technology (DET)

The most likely causes of severe detonation are outlined in the trouble-
shooting table below.
DET Troubleshooting

Security System (Ignition Lock System)

Your snowmobile has an optional security function that can be activated
by an authorized POLARIS dealer. If you have this feature activated,
you can lock the ignition to prevent unauthorized use when leaving the
snowmobile unattended. A locked system will limit engine speed to
3000 RPM, which prevents clutch engagement, and the snowmobile
will not move when throttle is applied.

If you wish to use this system, see page 37 of the Instrument Cluster
section for security system activation and operating instructions.

Cause of DET Activation

Solution

Poor quality fuel

Replace with higher quality fuel

Incorrect ethanol/non-ethanol fuel

type setting

Verify correct fuel type setting on

gauge

Low fuel/no fuel in tank

Refuel with recommended fuel

Water in fuel

Replace with recommended fuel

Plugged fuel filter or tank pick-up sock See your POLARIS dealer for service

Alcohol-based fuel additive used with

Ethanol fuel

Do not add deicers or additives that
contain any form of alcohol while
using up to 10% ethanol fuel

Improper engine modifications

Do not modify the engine

30

FEATURES

Instrument Cluster

The instrument cluster contains
indicator lights and the rider
information center. The information
center can be controlled by either
the MODE and SELECT buttons on
the instrument cluster or by the
MODE/SET switch on the left
handlebar.

NOTICE: Certain products will damage

the lens and other plastic sur-
faces. Do not use alcohol to
clean the instrument cluster.
Immediately clean off any
gasoline that splashes on the
instrument cluster.

Rider Information

Center

Check Engine

Indicator

High Beam

Indicator

Low Oil

Indicator

Over-

Temperature

Indicator

Park Brake

Indicator

Reverse

Indicator

MODE

Button

SELECT

Button

Mode/Set

Switch

SET

MOD

E

31

FEATURES

Instrument Cluster

Indicators

Check Engine Indicator

This indicator appears if an EFI-related fault occurs. Do not operate the
snowmobile if this warning appears. Serious engine damage could
result. See your dealer. See page 44 for diagnostic code definitions.

Over-Temperature Indicator

This indicator illuminates to alert the operator that the engine is over-
heating. The operator should take action to cool the engine. See page 92.
If the indicator flashes, continued operation could result in serious
engine damage. Stop the engine immediately.

Low Oil Indicator

The low oil indicator light may flicker at times due to oil movement in
the bottle, but when the light comes on and remains on, add the recom-
mended oil before further operation. See page 73.

High Beam Indicator

The high beam indicator illuminates when the lights are set to high
beam.

Parking Brake Indicator

This indicator illuminates when the parking brake is engaged. It will
also illuminate when the service brake is in use. See page 64.

Reverse Indicator

This indicator flashes when the snowmobile is in reverse. See page 78.
