C6 CRANKCASE 600 PRO X S01NX6ES 2 3 4 12 13 14 16 1 11 6 7 8 9 10 4 5 15 Part numbers may have changed since this microfiche was issued. To ensure that correct parts are received, refer to the Electronic Catalog, which is updated monthly. Ref. Part No. Qty. Description Ref. Part No. Qty. Description 1 7080681 2 Clamp, Hose 2 5132196 4 Stud 3 5132197 4 Stud 4 2201931 1 Kit - Crankcase (Incl. 2,3,5-10) 5 7051529 2 Plug 6 7517785 2 Screw 7 7517784 8 Screw 8 7516825 1 Screw 9 7517786 4 Screw 10 7663001 2 Pin, Dowel 11 5411394 2 Seal 12 1201825 2 Asm., Reed Valve 13 5432852 4 Stuffer, Reed 14 1253414 2 Adaptor, Carb 15 7080683 1 Clamp 16 7516822 12 Screw 11/00 |
