34

THE PERFECT FIT

IQ Rear Suspension Adjustments

Suspension Coupling

On all POLARIS snowmobile rear suspensions, there are two torque
arms that control the movement of the rail beam. Prior to the advent of
suspension coupling, these torque arms could move independently of
each other. Rear suspension coupling links the movement of the front
and rear torque arms to each other.

There are two types of rear suspension coupling.

Front To Rear Coupling and the Front Rear Scissor Stop
(FRSS)

The front rear scissor stop (FRSS) couples the movement of the front
torque arm with the rear torque arm and limits the amount of indepen-
dence between the movement of the front torque arm and the rear torque
arm.

When hitting a bump, the front torque arm starts to compress. The FRSS
links that movement to the rear torque arm, causing it to compress and
raise the rear suspension up as one, allowing the suspension to hit the
bump only once and reducing kickback.

The factory setting is usually adequate for all riders and conditions.

35

THE PERFECT FIT

IQ Rear Suspension Adjustments

Suspension Coupling

Rear To Front Coupling and the Rear Rear Scissor Stop
(RRSS)

The rear rear scissor stop (RRSS) couples the movement of the rear
torque arm with the front torque arm and limits the amount of indepen-
dent movement between the rear torque and the front torque arm.

Adjusting the RRSS either allows more weight to transfer to the rear for
more traction, or allows less weight to transfer to the rear, resulting in
improved cornering performance. An adjustment dot is located on the
RRSS. This dot is on the longest end of the scissor stop.

Rear Rear Scissor Stop (RRSS) - Attributes

Moving the RRSS to a higher position will have the following effects on
the suspension:
• Reduced weight transfer
• Improved chatter bump ride
• Improved cornering performance

• Increased load carrying capacity (2-up)

36

THE PERFECT FIT

IQ Rear Suspension Adjustments

Weight Transfer During Acceleration

The preferred method for controlling
weight transfer during acceleration is
by adjusting the rear rear scissor stop
(RRSS). The factory setting is the
best for most trail riding conditions.

To decrease weight transfer under
acceleration (for improved corner-
ing), rotate the RRSS to a higher
position.

To increase weight transfer or ski lift
during acceleration, rotate the RRSS
to a lower position.

Tip: Your dealer can help you with initial

setup and additional setup instruc-
tions to help you achieve your opti-
mum ride. A scissor stop tool is also
available from your dealer.

HIGH

LOW

LOW

MEDIUM

FRSS

RRSS

37

THE PERFECT FIT

Traction Products

Carbide Skags

A skag is a replaceable bar attached to the underside of the ski to assist
in turning the snowmobile and to prevent ski wear caused by contact
with roads and other bare terrain. Use carbide skags with studded tracks
to help maintain proper vehicle steering and control. See page 93.

If your snowmobile has carbide skags, it may be necessary to add track
studs to maintain proper vehicle control. Maintain a proper balance
between the number of studs and the length of carbide on the skags (the
more studs you use, the longer the carbide on the skags should be). See
your dealer's track studding chart.

Inspect skags frequently. Worn skags may reduce steering and braking
control on hard-packed snow and ice. Replace worn skags to maintain
proper balance and vehicle control.

WARNING! Loss of control can result in serious personal injury or death.
Proper balance of traction products on the skis and track must be maintained to
obtain proper vehicle control on hard-packed snow or ice. See your dealer for
assistance.

Wear Strips

To avoid excessive tunnel wear, tunnel wear strips must be installed
whenever track studding is used.

Install the appropriate wear strip kit. See your dealer.

Wear strips are designed for a specific stud length. See your dealer's
studding chart for recommended traction accessories.

NOTICE: Whenever wear strips are relocated, be sure there's adequate stud

clearance to the tunnel. Lack of clearance may result in damage to
tunnel.
