Safety Instructions



21



















































































Keep the removed parts properly.



Keep the removed parts properly, and do not allow children or
any authorized persons to come close to the storage place.

[If not]
The parts may bruise their hands or feet or cause other accidents.



Dispose the wastes generated by the combine to avoid environmental pollution.



The wastes (oil, cooling water, filter and battery) generated by the combine during harvesting are hazardous
and may pollute the environment. Therefore, they should be handed over to relevant departments of
environmental protection for proper treatment, but not be discarded directly. In addition, no tableware should
be used for storage of waste to avoid being eaten by mistake.

[If not]
Environmental pollution or personal injury may be caused.



Wear heavy gloves while replacing the cutting blades.




[If not]
Your hands may be scratched.



Keep the removed parts properly.



Keep the removed parts properly, and do not allow children or
any authorized persons to come close to the storage place.

[If not]
The parts may bruise their hands or feet or cause other
accidents.



Do not touch by

bare-handed.

Do not

forget to put

the cover.

Service and Warranty



22




Warranty card



The warranty card is required for receiving after-sale
services. Therefore, keep it properly.


When the machine runs abnormally



Specify the following information and contact your
YANMAR dealer if the abnormality still exists after you
perform inspection and treatment as instructed in the
chapter “Trouble Shooting” on Page 94.


<Content of contact>





Model number and manufacture number of the
machine





Engine number







How do you use the machine?
(At what a speed you run the machine?)







How long have you used the machine?



(How much area or how long?)







Explain the problems as detail as possible























































Machine identification plate

Engine identification plate

Service and Warranty



23





Spare Parts Availability



Usually, spare parts for maintenance of this machine
will generally be available for five years after production
is discontinued. However, the delivery term of some
special parts should be determined through
consultation within the supply period. In principle,
supply of spare parts is to be suspended after expiry of
the above-mentioned period. If supply of spare parts is
requested after the specified period, the term and price
of delivery should be determined through consultation.


Genuine Parts and Oil



Genuine parts certified by us have been rigorously
tested and must pass a strict quality inspection. They
can be used with confidence. When replacing parts, be
sure to use the designated genuine parts.






























































Name of parts



24





























Rear

Front

Left

Right

Sunshade (optional)

Work lamp

Reel

Cutter blades

Reel tine

Crop divider

Feeder house

Crawler

Pre-cleaner

Threshing rotor

cover

Side cover of

threshing section

Platform auger
