COMBINE HARVESTER AW70V, VNQ, AW82V, VNQ. Manual - part 1

Safety Instructions



5



● Be sure to abide by the following instructions which are very important for safety.
● Personal injury, death, other accidents and damages to the machine may be caused if the precautions

are not followed.



1. Precautions on operator’s physical condition and clothes















































2. Precautions before use

























Do not operate if you are:
● Overtired, sick, under the influence of medication or otherwise incapacitated
● Drunk
● Pregnant
● Under eighteen years of age

[If not]
It may result in an accident.



Wear the clothes appropriate for operation

Do not put the towel around your head, neck and waist. You may need
the safety helmet, safety shoes, coveralls, other protections and clothes
suitable for operation. Your hearing may be harmed or lost if working for
long time in noisy environments. So be sure to wear the earmuffs or
earplugs.

[If not]
You may fall, be rolled in the machine and injured.

IMPORTANT



Be sure to check the machine before working.
Check and correct any abnormalities before using the combine.
Additionally, check and repair if there is any abnormality after working.

[If not]
Accident or mechanical failure may be caused as a result of
poor maintenance.

Safety Instructions



6

















































































This manual must be accompanied when
the machine is transferred to others.
Explain the operating methods in details, and request the operator
to read the Operator’s Manual carefully before operation.

[If not]
It may cause death, irreparable injury or damages to the machine.

Study it seriously

Operator’s

Manual



Put the fire extinguishers in the designated places.



Check the fire extinguishers are under normal condition and
placed in the designated places before using the combine.

[If not]

It will be unavailable to extinguish the fire quickly if any.



Make ready the first-aid kit.



Keep ready the first-aid kit and write down the phone
numbers of doctor, medical aid station, hospital and fire
brigade nearby in advance.

[If not]
First aid may be delayed and personal injury be caused
in case of safety accident.

IMPORTANT



Be sure to perform the periodic inspection and maintenance.



Perform the periodic inspection, repair and maintenance of
all parts on a quarterly basis. In particular, the fuel channel
should be replaced every two years, and electrical wiring be
checked yearly.

[If not]
Accident, personal injury or mechanical failure may sometimes
be caused due to improper maintenance.

Safety Instructions



7





3. Precautions for checking before test run and operation











































































Refuel and lubricate the machine after the engine is cooled down.
Do not refuel or lubricate the machine while the engine is running or at a high temperature.
Be sure to refuel outdoors.

[If not]
Fuel or engine oil may be ignited and cause personal injury or fire.



Never use fires while refueling.



Do not smoke or use open fire for lighting while refueling.

[If not]
Fuel may be ignited and cause personal injury or fire.

Do not smoke.

FUEL



Checking on a stable and level ground.
Perform the pre-operation inspection on an even and stable ground
  to prevent the machine from turning over or sliding.

[If not]
Accident may be caused.



Fasten the fuel tank cap securely and wipe off the spilled fuel
after refueling.



Fuel may spill sometimes if the fuel tank cap is loose. Fasten the
fuel cap securely. In addition, be sure to wipe off the spilled fuel if any.

[If not]
Fire hazard or personal injury may be caused sometimes.

Safety Instructions



8





































































Be sure to check the fuel leakage.



Be sure to check whether the fuel line is damaged and there is
fuel leakage.

[If not]
Fire hazard or personal injury may be caused.


Fuel leaking

causes a fire.



Be sure to check the wiring of electrical parts.
Check whether the electrical wiring is in touch with the sharp tips of
other parts, falls off or is loosely connected, and its insulation has
peeled off.

[If not]
Short-circuit may be caused, resulting in fire or burning.


Short-circuit

causes a fire.



Pay full attention to exhaust emission.

Do not start up the engine in a closed room, but run it
outdoors with good ventilation. Ensure adequate ventilation
if you have to run it indoors.

[If not]
Poisoning or fatal accident may be caused due to exhaust emission.
