9.8.6 M40V Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-188 lists the optical specifications of the M40V board.
Table 9-188 Optical specifications of the M40V board
Item
Unit
Value
Adjacent channel spacing
GHz
100
Insertion loss
dB
≤ 8a
Reflectance
dB
< -40
Operating wavelength range
nm
1529-1561
Adjacent channel isolation
dB
> 22
Non-adjacent channel isolation
dB
> 25
Attenuation range
dB
0-15
Loss accuracy
dB
≤ 1 (0 to 10 dB)
≤ 1.5 (>10 dB)
Polarization dependent loss
dB
≤ 0.5
Maximum channel insertion loss difference
dB
≤ 3a
NOTE
a: This value can be reached when the attenuation of the VOA is set to 0 dB.
Mechanical Specifications
l Dimensions of front panel:
- TN11M40V: 76.2 mm (W) x 220 mm (D) x 264.6 mm (H) (3.0 in. (W) x 8.7 in. (D) x
10.4 in. (H))
- TN12M40V: 50.8 mm (W) x 220 mm (D) x 264.6 mm (H) (2.0 in. (W) x 8.7 in. (D) x
10.4 in. (H))
l Weight:
- TN11M40V: 2.3 kg (5.1 lb.)
- TN12M40V: 2.3 kg (5.1 lb.)
609
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
TN11M40V
20.0
25.0
TN12M40V
16.0
26.0
9.8.7 SFIU Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-189 Optical specifications of the SFIU board
Interface
Item
Uni
Value
t
-
Operating wavelength range (C band)
nm
1528-1561
-
Operating wavelength range of optical
nm
1480 to 1520
supervisory channel
LINE1-
Insertion loss
dB
≤ 1.0
SYS1
LINE2-
SYS2
LINE1-
Insertion loss
dB
≤ 1.5
OSC1
LINE1-
OSC2
LINE1-
Isolation
dB
≥ 65
OSC1 @λc
LINE1-
Isolation
dB
≥ 40
OSC2 @λc
OSC1-
Directivity
dB
≥ 45
SYS1
SYS1-
OSC1
OSC1-
Directivity
dB
≥ 55
OSC2
610
Interface
Item
Uni
Value
t
OSC2-
OSC1
-
Optical return loss
dB
> 40
-
Polarization
C band
dB
< 0.1
dependent loss
OSC channel
dB
< 0.15
Mechanical Specifications
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 1.0 kg (2.2 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F)(W)
(131°F)(W)
TN11SFIU
0.2
0.3
9.9 Fixed Optical Add and Drop Multiplexer Unit
Specifications
9.9.1 CMR2 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-190 lists the optical specifications of the CMR2 board.
Table 9-190 Optical specifications of the CMR2 board
Correspondin
Item
Unit
Value
g interfaces
-
Operating wavelength
nm
1271-1611
range
-
Adjacent channel spacing
nm
20
IN-D1
0.5 dB spectral width
nm
≥ ±6.5
611
Correspondin
Item
Unit
Value
g interfaces
IN-D2
Drop channel insertion
dB
≤ 1.5
loss
Adjacent channel
dB
> 25
isolation
Non-adjacent channel
dB
> 35
isolation
A1-OUT
0.5 dB spectral width
nm
≥ ±6.5
A2-OUT
Add channel insertion
dB
≤ 1.5
loss
IN-MO
Insertion loss
dB
≤ 1.0
MI-OUT
Isolation
dB
≥ 13
-
Maximum reflectance
dB
-40
NOTE
The equipment can transmit the 1271 nm wavelength by connecting the CMR2 board to corresponding
third-party equipment, though the equipment does not provide the 1271 nm OTU board and line board.
Rules for Adding/Dropping Wavelength
The CMR2 adds/drops and multiplexes two random channels of signals to/from the multiplexed
signals. There are no rules for adding/dropping signals.
Mechanical Specifications
The mechanical specifications of TN11CMR2 are as follows.
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 0.8 kg (1.8 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
CMR2
0.2
0.3
9.9.2 CMR4 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
612
Optical Specifications
Table 9-191 lists the optical specifications of the CMR4 board.
Table 9-191 Optical specifications of the CMR4 board
Correspondin
Item
Unit
Value
g interfaces
-
Operating wavelength
nm
1271-1611 (1371 nm excluded)
range
-
Adjacent channel spacing
nm
20
IN-D1
0.5 dB spectral width
nm
≥ ±6.5
IN-D2
Drop channel insertion
dB
≤ 2
IN-D3
loss
IN-D4
Adjacent channel
dB
> 25
isolation
Non-adjacent channel
dB
> 35
isolation
A1-OUT
0.5 dB spectral width
nm
≥ ±6.5
A2-OUT
Add channel insertion
dB
≤ 2
A3-OUT
loss
A4-OUT
IN-MO
Insertion loss
dB
≤ 1.5
MI-OUT
Isolation
dB
≥ 13
-
Maximum reflectance
dB
-40
NOTE
The equipment can transmit the 1291 nm wavelength by connecting the CMR4 board to corresponding
third-party equipment, though the equipment does not provide the 1291 nm OTU board and line board.
Rules for Adding/Dropping Wavelengths
The CMR4 board adds/drops and multiplexes four channels of signals to/from the multiplexed
signals. There are four wavelength groups.
Table 9-192 Rules for adding/dropping wavelengths on the CMR4 board
Group
Wavelength (nm)
A1/D1
A2/D2
A3/D3
A4/D4
1
1291
1311
1331
1351
613
Group
Wavelength (nm)
A1/D1
A2/D2
A3/D3
A4/D4
2
1391
1411
1431
1451
3
1471
1491
1591
1611
4
1511
1531
1551
1571
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
CMR4
0.2
0.3
9.9.3 DMR1 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-193 Optical specifications of the DMR1 board
Correspondin
Item
Unit
Value
g interfaces
EA/ED/WA/
Operating wavelength
nm
1260-1360
WD
range
EIN-ED
Drop channel insertion
dB
≤ 1
WIN-WD
loss
Isolation
dB
≥40
EA-EOUT
Add channel insertion
dB
≤ 1
WA-WOUT
loss
Isolation
dB
≥40
EIN-EMO
Insertion loss
dB
≤ 0.8
WIN-WMO
Isolation
dB
≥ 25
EMI-EOUT
Insertion loss
dB
≤ 0.8
WMI-WOUT
Isolation
dB
≥ 15
-
Maximum reflectance
dB
-40
614
Rules for Adding/Dropping Wavelength
The DMR1 board adds/drops and multiplexes a 1310 nm wavelength in the east and west
directions from the multiplexed signals.
Mechanical Specifications
Mechanical specifications of the TN11DMR1 board:
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 0.7 kg (1.5 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
DMR1
0.2
0.3
9.9.4 MR2 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-194 lists the optical specifications of the MR2 board.
Table 9-194 Optical specifications of the MR2 board
Correspondin
Item
Unit
Value
g interfaces
-
Operating wavelength
nm
1529-1561
range
-
Adjacent channel spacing
GHz
100
IN-D1
-1dB spectral width
nm
≥ 0.2
IN-D2
Drop channel insertion
dB
≤ 1.5
loss
Adjacent channel
dB
> 25
isolation
Non-adjacent channel
dB
> 35
isolation
A1-OUT
-1dB spectral width
nm
≥ 0.2
A2-OUT
615
Correspondin
Item
Unit
Value
g interfaces
Add channel insertion
dB
≤ 1.5
loss
IN-MO
Insertion loss
dB
≤ 1.0
MI-OUT
Isolation
dB
> 13
-
Polarization dependence
dB
< 0.2
loss
-
Maximum reflectance
dB
-40
Rules for Adding/Dropping Wavelength
The MR2 adds/drops and multiplexes random two channels of signals to/from the multiplexed
signals. There are no rules for adding/dropping wavelengths.
Mechanical Specifications
The mechanical specifications of TN11MR2 are as follows:
l Dimensions of front panel: 25.4 mm (W) x 220 mm (D) x 264.6 mm (H) (1.0 in. (W) x 8.7
in. (D) x 10.4 in. (H))
l Weight: 0.9 kg (2.0 lb.)
Power Consumption
Board
Typical Power
Maximum Power
Consumption at 25°C (77°
Consumption at 55°C
F) (W)
(131°F) (W)
MR2
0.2
0.3
9.9.5 MR4 Specifications
Specifications include optical specifications, dimensions, weight, and power consumption.
Optical Specifications
Table 9-195 lists the optical specifications of the MR4 board.
Table 9-195 Optical specifications of the MR4 board
Interface
Item
Unit
Value
-
Operating wavelength
nm
1529-1561
range
616
Interface
Item
Unit
Value
-
Adjacent channel spacing
GHz
100
IN-D1
-1dB spectral width
nm
≥ 0.2
IN-D2
Drop channel insertion
dB
≤ 2.2
IN-D3
loss
IN-D4
Adjacent channel
dB
> 25
isolation
Non-adjacent channel
dB
> 35
isolation
A1-OUT
-1dB spectral width
nm
≥ 0.2
A2-OUT
Add channel insertion
dB
≤ 2.2
A3-OUT
loss
A4-OUT
IN-MO
Insertion loss
dB
≤ 1.5
MI-OUT
Isolation
dB
> 13
-
Maximum reflectance
dB
-40
Rules for Adding/Dropping Wavelengths
The MR4 board adds/drops and multiplexes four consecutive channels of signals to/from the
multiplexed signals. There are ten groups of wavelengths.
617
Table 9-196 Rules for adding/dropping wavelengths of the MR4 board
G
C
A1/D1
A2/D2
A3/D3
A4/D4
r
h
Wa
Wav
Fre
W
Wa
Fre
W
Wa
Fre
W
Wave
Freq
o
ar
vel
elen
que
a
vele
qu
av
vele
que
av
lengt
uenc
u
a
en
gth
ncy
v
ngt
enc
el
ngt
ncy
el
h
y
p
ct
gth
(nm)
(T
el
h
y
en
h
(TH
en
(nm)
(THz
er
No
Hz)
e
(nm
(T
gt
(nm
z)
gt
)
is
n
)
Hz
h
)
h
ti
gt
)
N
N
c
h
o.
o.
C
N
o
o.
d
e
1
9
80
1560
192.
7
155
192
76
155
192.
74
1558.
192.4
2
.61
10
8
9.79
.20
8.98
30
17
0
1
0
9
2
4
0
2
9
72
1557
192.
7
155
192
68
155
192.
66
1554.
192.8
2
.36
50
0
6.55
.60
5.75
70
94
0
5
0
9
2
8
0
3
9
64
1554
192.
6
155
193
60
155
193.
58
1551.
193.2
2
.13
90
2
3.33
.00
2.52
10
72
0
9
0
9
3
2
0
4
9
56
1550
193.
5
155
193
52
154
193.
50
1548.
193.6
3
.92
30
4
0.12
.40
9.32
50
51
0
3
0
9
3
6
0
618
G
C
A1/D1
A2/D2
A3/D3
A4/D4
r
h
Wa
Wav
Fre
W
Wa
Fre
W
Wa
Fre
W
Wave
Freq
o
ar
vel
elen
que
a
vele
qu
av
vele
que
av
lengt
uenc
u
a
en
gth
ncy
v
ngt
enc
el
ngt
ncy
el
h
y
p
ct
gth
(nm)
(T
el
h
y
en
h
(TH
en
(nm)
(THz
er
No
Hz)
e
(nm
(T
gt
(nm
z)
gt
)
is
n
)
Hz
h
)
h
ti
gt
)
N
N
c
h
o.
o.
C
N
o
o.
d
e
5
9
48
1547
193.
4
154
193
44
154
193.
42
1545.
194.0
3
.72
70
6
6.92
.80
6.12
90
32
0
7
0
9
4
0
0
6
9
40
1544
194.
3
154
194
36
154
194.
34
1542.
194.4
4
.53
10
8
3.73
.20
2.94
30
14
0
1
0
9
4
4
0
7
9
32
1541
194.
3
154
194
28
153
194.
26
1538.
194.8
4
.35
50
0
0.56
.60
9.77
70
98
0
5
0
9
4
8
0
8
9
24
1538
194.
2
153
195
20
153
195.
18
1535.
195.2
4
.19
90
2
7.40
.00
6.61
10
82
0
9
0
9
5
2
0
619















Content   ..  55  56  57  58   ..
