HUAWEI OptiX OSN 8800 T64/T32 Intelligent Optical Transport Platform. Product Description - part 35

9.1 General Specifications

9.1.1 Cabinet Specifications

Table 9-1 lists the typical configurations of the N63B cabinet.

Table 9-1 Technical specifications of the N63B cabinet

Item

Specification

Dimensions

600 mm (W) x 300 mm (D) x 2200 mm (H)

Weight (kg)

60 kg

Standard working voltage

-48 V DC or -60 V DC

Working voltage range

-40 V DC to -72 V DC

Table 9-2 lists the typical configurations of the N66B cabinet.

Table 9-2 Technical specifications of the N66B cabinet

Item

Specification

Dimensions

600 mm (W) x 600 mm (D) x 2200 mm (H)

Weight (kg)

85 kg

Standard working voltage

-48 V DC or -60 V DC

Working voltage range

-40 V DC to -72 V DC

9.1.2 Subrack Specifications

NOTE

The predicted reliability specifications vary according to system configurations.

OptiX OSN 8800 T64

Table 9-3 Mechanical specifications of the OptiX OSN 8800 T64

Item

Specification

Dimensions

498 mm (W) × 580 mm (D) × 900 mm (H)

(19.6 in. (W) × 22.8 in. (D) × 35.4 in. (H))

368

Item

Specification

Weight (empty subracka)

65 kg (143 lb.)

a: An empty subrack means no boards are installed in the board area, and no fan tray assembly

or air filter is installed.

Table 9-4 Requirements on voltage and current of an OptiX OSN 8800 T64

Item

Requirement

Rated working current

200 A (Independent power supplies to four

sections of each subrack, with 50A for each

section)

Nominal working voltage

-48V DC/-60V DC

Working voltage range

-40V DC to -72V DC

Table 9-5 Power consumption of an OptiX OSN 8800 T64

Item

Value

Maximum subrack power consumptiona

6500 W

Typical configuration power consumption

less than 3700 W

(OTN)

Typical configuration power consumption

less than 2700 W

(OCS)

a: The maximum subrack power consumption refers to the theoretical power consumption

obtained when boards with the highest power consumption are installed in every slot on the

subrack.

Table 9-6 Power consumption of the common units in an OptiX OSN 8800 T64

Unit Name

Typical

Maximum

Remarks

Power

Power

Consumptio

Consumptio

n at 25°C (77°

n at 55°C

F) (W)a

(131°F) (W)a

Subrack

OTU

1804.6

2827.9

32 x LDX, 1 x SCC, 8 x PIU, 2

subrack

x AUX, 1 x EFI1, 1 x EFI2, 1 x

ATE, and 4 x fan tray assembly

369

Unit Name

Typical

Maximum

Remarks

Power

Power

Consumptio

Consumptio

n at 25°C (77°

n at 55°C

F) (W)a

(131°F) (W)a

OTU

1839.1

2776.7

2 x XCT, 2 x SXM, 20 x NQ2,

electrical

1 x SCC, 8 x PIU, 5 x TOA, 5 x

cross-

TQX, 2 x AUX, 1 x EFI1, 1 x

connect

EFI2, 1 x ATE, and 4 x fan tray

subrack

assembly

OTM

963.8

1860.3

1 x M40V, 1 x D40, 1 x OAU1,

subrack

1 x OBU1, 20 x LDX, 1 x SCC,

1 x SC2, 8 x PIU, 8 x AUX, 1 x

EFI1, 1 x EFI2, 1 x ATE, and 4

x fan tray assembly

OCS System

1920

2830

2 x SXM, 20 x SLD64, 8 x

SLO16, 4 x SLQ16, 4 x SLH41,

4 x EGSH, 2 x STG, 1 x STI, 2

x SCC, 8 x PIU, 2 x AUX, 1 x

EFI1, 1 x EFI2, 1 x ATE, and 4

x fan tray assembly

a: Indicates that the power consumption of the subrack and cabinet is the value in a certain

configuration. The value is for reference only. The actual power consumed by the chassis and

cabinet is a calculation based on the power consumption of each module.

Table 9-7 OptiX OSN 8800 T64 equipment predicted reliability

System Availability

Mean Time to Repair

Mean Time Between

(MTTR)

Failures (MTBF)

0.9999922

4 hours

58.68 years

OptiX OSN 8800 T32

Table 9-8 Mechanical specifications of the OptiX OSN 8800 T32

Item

Specification

Dimensions

498 mm (W) × 295 mm (D) × 900 mm (H)

(19.6 in. (W) × 11.6 in. (D) × 35.4 in. (H))

Weight (empty subracka)

35 kg (77.1 lb.)

a: An empty subrack means no boards are installed in the board area, and no fan tray assembly

or air filter is installed.

370

Table 9-9 Requirements on voltage and current of an OptiX OSN 8800 T32

Item

Requirement

Rated working current

100 A (Independent power supplies to two

sections of each subrack, with 50A for each

section)

Nominal working voltage

-48V DC/-60V DC

Working voltage range

-40V DC to -72V DC

Table 9-10 Power consumption of an OptiX OSN 8800 T32

Item

Value

Maximum subrack power consumptiona

3500 W

Recommended typical configuration power

less than 2000 W

consumption (OTN)

Recommended typical configuration power

less than 2250 W

consumption (OCS)

a: The maximum subrack power consumption refers to the theoretical power consumption

obtained when boards with the highest power consumption are installed in every slot on the

subrack.

Table 9-11 Power consumption of the subrack in typical configuration in an OptiX OSN 8800

T32

Unit Name

Typical

Maximum

Remarks

Power

Power

Consumptio

Consumptio

n at 25°C (77°

n at 55°C

F) (W)a

(131°F) (W)a

Subrack

OTU

1633.4

2254.6

32 x LDX, 1 x SCC, 4 x PIU, 1

subrack

x AUX, 1 x EFI1, 1 x EFI2, 1 x

ATE, and 2 x fan tray assembly

OTU

1641.6

2166.5

2 x XCH, 20 x NQ2, 1 x SCC,

electrical

4 x PIU, 5 x TQX, 5 x TOA, 1

cross-

x AUX, 1 x EFI1, 1 x EFI2, 1 x

connect

ATE, and 2 x fan tray assembly

subrack

OTM

792.5

1287.1

1 x M40V, 1 x D40, 1 x OAU1,

subrack

1 x OBU1, 12 x LDX, 1 x SCC,

4 x PIU, 1 x AUX, 1 x EFI1, 1

x EFI2, 1 x ATE, and 2 x fan

tray assembly

371

Unit Name

Typical

Maximum

Remarks

Power

Power

Consumptio

Consumptio

n at 25°C (77°

n at 55°C

F) (W)a

(131°F) (W)a

OLA

290.3

706

4 x OBU1, 4 x VA1, 1 x SC2, 1

subrack

x SCC, 4 x PIU, 1 x AUX, 1 x

EFI1, 1 x EFI2, 1 x ATE, and 2

x fan tray assembly

OADM

974

1497.2

2 x OAU1, 2 x MR8V, 16 x

subrack

LDX, 1 x SC2, 1 x SCC, 4 x

PIU, 1 x AUX, 1 x EFI1, 1 x

EFI2, 1 x ATE, and 2 x fan tray

assembly

378.2

811

2 x M40V, 2 x D40, 2 x FIU, 1

x SC2, 2 x RMU9, 2 x WSM9,

2 x OAU1, 2 x OBU1, 1 x SCC,

4 x PIU, 1 x AUX, 1 x EFI1, 1

x EFI2, 1 x ATE, and 2 x fan

tray assembly

373.1

306.6

2 x M40, 2 x D40, 2 x WSMD9,

2 x DAS1, 1 x SCC, 4 x PIU, 1

x AUX, 1 x EFI1, 1 x EFI2, 1 x

ATE, and 2 x fan tray assembly

OCS System

1281

1757

2 x XCMs, 10 x SLQ64, 8 x

SLO16, 2 x SLH41, 2 x EGSH,

2 x STG, 1 x STI, 2 x SCC, 4 x

PIU, 1 x AUX, 1 x EFI1, 1 x

EFI2, 1 x ATE, and 2 x fan tray

assembly

a: Indicates that the power consumption of the subrack and cabinet is the value in a certain

configuration. The value is for reference only. The actual power consumed by the chassis and

cabinet is a calculation based on the power consumption of each module.

Table 9-12 OptiX OSN 8800 T32 equipment predicted reliability

System Availability

Mean Time to Repair

Mean Time Between

(MTTR)

Failures (MTBF)

0.99999244

4 hours

60.40 years

372

9.1.3 DCM Frame Specifications

Table 9-13 Technical specifications of the DCM frame

Item

Specification

Dimensions

48 mm (H) x 484 mm (W) x 270.5 mm (D) or

1.9 in. (H) x 19.1 in. (W) x 10.6 in. (D)

Weight

1.5 kg (3.3 lb.)

H = Height; W = Width; D = Depth

9.1.4 CRPC Frame Specification

Table 9-14 Mechanical specifications of the CRPC frame

Item

Value

Mechanical specifications

535 mm (W) x 257 mm (D) x 86 mm (H) or 21.1 in.

(W) x 10.1 in. (D) x 3.4 in. (H)

Weight

3 kg (6.6 lb)

9.1.5 Fan-Tray Assembly Specifications

Table 9-15 Technical specifications of the fan tray assembly

Item

Specification

Dimensions

493.7 mm (W) x 280.5 mm (D) x 64.0 mm (H) (19.4 in. (W) x

11.0 in. (D) x 2.5 in. (H))

Weight

3.6 kg (7.9 lb.)

Power Consumptiona

l Low Speed: 60 W

l Medium-Low Speed: 80 W

l Medium Speed: 110W

l Medium-High Speed: 170W

l High Speed: 270W

a: Rotating speed of fans is controlled intelligently. When the system is typically configured,

rotating speed of fans is automatically adjusted to a low level. When the system is fully

configured with boards of high power consumption, and the system is running in a high

ambient temperature, rotating speed of fans may be adjusted to a high level. When rotating

at the maximum speed, power consumption of fan tray assembly may reach 270 W.

373

9.2 Laser Class

Each type of boards of the product has a different laser class.

NOTE

The power shown in Table 9-16 refers to the reference output power of the laser. It is achieved when the

mode-field diameter of fiber is 10 um at the 1550 nm wavelength.

The laser class complies with IEC 60825-2 laser safety standards.

For the OptiX OSN 8800, the laser level of the equipment is HAZARD LEVEL 1M.

Table 9-16 Laser class

Reference Optical

Power Range

Laser Class

Board Type

Under 10 dBm

HAZARD

LDM, LDMD, LDMS, LDX, LEM24, LEX4,

LEVEL 1

LOA, LOG, LOM, LQM, LQMD, LQMS, LSQ,

LSX, LSXL, LSXLR, LSXR, LWXS, TMX, ND2,

NQ2, NS3, NS2, TDX, TOA, THA, TOM, TQX,

TOG, TSXL, D40, D40V, M40, M40V, RMU9,

WSM9(TN11, TN12), HSC1, SC1, SC2, ST2,

DCP, SCS, DCU, TDC

10 - 21.3 dBma

HAZARD

NPO2, NPO2E, SFIU, TN12FIU, ITL, CMR2,

LEVEL 1M

CMR4, DMR1, MR2, MR4, MR8, MR8V, SBM2,

RDU9, ROAM, WSMD2, WSD9, WSM9(TN13),

WSMD4, OAU100, OAU101, OAU102, OAU103,

OBU1, OLP, VA1, VA4, GFU, HBA, OAU105,

OBU2, TN13FIU01, TN13FIU02, CRPC, DAS1,

WSMD9

Under 10 dBm

Class 1

DCU, EGSH, SF64A, SF64, SFD64, SL64, SLD64,

SLH41, SLO16, SLQ16, SLQ64, EAS2

10 - 21.3 dBm

Class 1M

BPA

a: For the HBA, OAU105, OBU2, TN13FIU02, CRPC boards, after the IPA function is

enabled, the laser hazard level of the board is HAZARD LEVEL 1M, which indicates that

the maximum power output by the optical port on the board ranges 10 dBm (10 mW) to 21.3

dBm (136 mW).

9.3 Optical Transponder Unit Specifications

9.3.1 LDM Specifications

Specifications include optical specifications, dimensions, weight, and power consumption.

374

Bo

Client-Side

Client-Side

WDM-Side

WDM-Side

ard

Fixed

Pluggable Optical

Fixed Optical

Pluggable Optical

Optical

Module

Module

Module

Module

TN

N/A

I-16-2 km

N/A

2.67 Gbit/s Multirate

12L

(eSFP CWDM)-80 km

S-16.1-15 km

DM

2.67 Gbit/s Multirate

L-16.1-40 km

(eSFP DWDM)-120

L-16.2-80 km

km

2.125 Gbit/s

Multirate-0.5 km

1000 BASE-LX-10 km

1000 BASE-LX-40 km

1000 BASE-ZX-80 km

1.25 Gbit/s Multirate

(eSFP CWDM)-40 km

2.67 Gbit/s Multirate

(eSFP CWDM)-80 km

2.67 Gbit/s Multirate

(eSFP DWDM)-120 km

NOTE

There is a margin between the default input power low alarm threshold and the receiver sensitivity and a

margin between the default input power high alarm threshold and the overload point. This ensures that the

system can report an input power low alarm before the actual input power reaches the receiver sensitivity

or report an input power high alarm before the actual input power reaches the overload point.

Client-Side Pluggable Optical Module

NOTE

I-16 module, S-16.1 module, L-16.1 module and L-16.2 module can be used to access OTU1, STM-16, OC-48,

FC200, FC100, GE, STM-4, OC-12, ESCON, STM-1, OC-3, DVB-ASI, and FE signals.

Table 9-17 Specifications of client-side pluggable optical module for SDH services

Item

Unit

Value

Optical

I-16-2 km

S-16.1-15

L-16.1-40

L-16.2-80

Module

km

km

km

Type

Line code

-

NRZ

NRZ

NRZ

NRZ

format

Optical

-

MLM

SLM

SLM

SLM

source type

Target

-

2 km (1.2 mi.)

15 km (9.3

40 km (24.9

80 km (49.7

distance

mi.)

mi.)

mi.)

375

Item

Unit

Value

Optical

I-16-2 km

S-16.1-15

L-16.1-40

L-16.2-80

Module

km

km

km

Type

Transmitter parameter specifications at point S

Operating

nm

1266 to 1360

1260 to 1360

1280 to 1335

1500 to 1580

wavelength

range

Maximum

dBm

-3

0

3

3

mean

launched

power

Minimum

dBm

-10

-5

-2

-2

mean

launched

power

Minimum

dB

8.2

8.2

8.2

8.2

extinction

ratio

Maximum

nm

N/A

1

1

1

-20 dB

spectral

width

Minimum

dB

N/A

30

30

30

side mode

suppression

ratio

Eye pattern

-

G.957-compliant

mask

G.959.1-compliant

Receiver parameter specifications at point R

Receiver

-

PIN

PIN

APD

APD

type

Operating

nm

1270 to 1580

1270 to 1580

1280 to 1335

1500 to 1580

wavelength

range

Receiver

dBm

-18

-18

-27

-28

sensitivity

Minimum

dBm

-3

0

-9

-9

receiver

overload

376

Item

Unit

Value

Optical

I-16-2 km

S-16.1-15

L-16.1-40

L-16.2-80

Module

km

km

km

Type

Maximum

dB

-27

-27

-27

-27

reflectance

NOTE

The 2.125 Gbit/s multirate module can be used to access FC200, GE, FC100, and FE signals.

NOTE

The 1000 BASE-LX-10 km module, 1000 BASE-LX-40 km module, or 1000 BASE-ZX-80 km module can be

used to access GE, FC100, STM-4, ESCON, STM-1, FE and DVB-ASI signals.

Table 9-18 Specifications of client-side pluggable optical module for GE services

Item

Unit

Value

Optical

2.125 Gbit/s

1000 BASE-

1000 BASE-

1000 BASE-

Module

Multirate-0.

LX-10 km

LX-40 km

ZX-80 km

Type

5 km

Line code

-

NRZ

NRZ

NRZ

NRZ

format

Target

-

0.5 km (0.3

10 km (6.2

40 km (24.9

80 km (49.7

distance

mi.)

mi.)

mi.)

mi.)

Transmitter parameter specifications at point S

Operating

nm

830 to 860

1270 to 1355

1270 to 1355

1500 to 1580

wavelength

range

Maximum

dBm

-2.5

-3

0

5

mean

launched

power

Minimum

dBm

-9.5

-11.5

-4.5

-2

mean

launched

power

Minimum

dB

9

9

9

9

extinction

ratio

Eye pattern

-

IEEE802.3z-compliant

mask

Receiver parameter specifications at point R

377

Content   ..  33  34  35  36   ..
