6 Technical Specifications
6.10.4 OLP
Table 6-65 OLP board specifications
Parameters
Unit
Specifications
Insertion loss at the
TI-TO1
dB
< 4
receive end
TI-TO2
Insertion loss at the
RI1-RO
dB
< 1.5
receive end
RI2-RO
Range of the input optical power
dBm
-35 to 7
Alarm threshold of optical power
dB
3
difference
Switching threshold of optical power
dB
5
difference
6.10.5 SCS
Table 6-66 SCS board specifications
Parameters
Unit
Specifications
Single-mode insertion loss
dB
< 4
Multimode insertion loss
dB
< 4.5
6.10.6 GFU
The parameter specifications of the GFU board are listed in Table 6-67, Table
6-68 and Table 6-69.
Table 6-67 Parameter specifications of GFU01 and GFU02
Parameters
Unit
Specifications
Working wavelength range
nm
1529-1561
Channel insertion loss
dB
1.5-12
Polarization dependent loss (PDL)
dB
≤ 0.5
6-59
6 Technical Specifications
Table 6-68 Parameter specifications of GFU03
Parameters
Unit
Specifications
Working wavelength range
nm
1529-1561
Channel insertion loss
dB
1.0-5.0
Polarization dependent loss (PDL)
dB
≤ 0.5
Table 6-69 Parameter specifications of GFU04
Parameters
Unit
Specifications
Working wavelength range
nm
1529-1561
Channel insertion loss
dB
0.5-6.0
Polarization dependent loss (PDL)
dB
≤ 0.5
6.10.7 DGE
The parameter specifications of the DGE board are listed in Table 6-70.
Table 6-70 Parameter specifications of DGE
Parameters
Unit
Specifications
Working wavelength range
nm
1529-1561
Dynamic attenuation range
dB
6-21
Fixed insertion loss
dB
<6
6.10.8 DSE
The parameter specifications of the DSE board are listed in Table 6-71.
Table 6-71 Parameter specifications of DSE
Parameters
Unit
Specifications
Working wavelength range
nm
1529-1570
Fixed insertion loss
dB
<3.0
6-60
6 Technical Specifications
6.10.9 VOA
Table 6-72 VOA board specifications
Parameters
Unit
Specifications
Attenuation range
dB
2-20
Adjustment accuracy
dB
0.5
6.10.10 VA4
Table 6-73 VA4 board specifications
Parameters
Unit
Specifications
Attenuation range
dB
2-20
Adjustment accuracy
dB
0.5
6.10.11 MCA
The parameter specifications of the MCA board are listed in Table 6-74.
Table 6-74 Parameter specifications of MCA
Parameters
Unit
Specifications
Working wavelength range
nm
C-band: 1529-1561
L-band: 1570-1604
Detect range for single channel
dBm
-10 to -30
optical power
Detect accuracy for optical power
dBm
±1.5
OSNR accuracy
dB
±1.5 (OSNR detect range: 13 to 19)
±2 (OSNR detect range: 19 to 23)
Detect accuracy for central
nm
±0.1
wavelength
Note: The OSNR detection function of the MCA is supported by the NRZ/CRZ system with a channel
spacing of 100 GHz and the NRZ system with a channel spacing of 50 GHz. It is not supported by the CRZ
system with a channel spacing of 50 GHz. The MCA in the CRZ system with a channel spacing of 50 GHz
only supports the function to detect the power and the center wavelength..
6-61
6 Technical Specifications
6.10.12 OSC
Table 6-75 Optical interface parameter specifications of OSC
Parameters
Specifications
Type
Normal power
High power
Working wavelength range (nm)
C band: 1500-1520 or
C band: 1500-1520
L band: 1615-1635
Signal rate (Mbit/s)
SC1/SC2
2.048
2.048
TC1/TC2
8.192
8.192
Line code format
CMI
CMI
Launched power (dBm)
-7 to 0
5 to 10
Optical source type
MLM LD
MLM LD
Minimum receiver
SC1/SC2
-48
-48
sensitivity (dBm)
TC1/TC2
-48
-48
(BER=1×10-12)
6.10.13 FMU
Table 6-76 Parameter specifications of FMU
Item
Unit
Index
Online monitor
Standby fibre monitor
Test wavelength
nm
1310 ±25
1550 ±25
OTDR dynamic range
dB
39.5 (Note1)
38.5 (Note 1)
Event dead zone
m
10 (Note 2)
Attenuation dead zone
m
30 (Note 3)
Pulse width
10ns, 30ns, 100ns,
10ns, 30ns, 100ns, 300ns,
300ns, 1μs, 3μs,
1μs, 3μs, 10μs, 20μs
10μs, 20μs
Pulse output power
dBm
≤ 20
Distance accuracy
m
±1m±5 x 10-5 x test distance ± spacing between
the sample points (not including the group index
error)
Readout resolution
dB
0.001
Reflection measurement
dB
±2.0
resolution
6-62
6 Technical Specifications
Item
Unit
Index
Online monitor
Standby fibre monitor
Linearity
dB/dB
±0.05
Group index
1.400-1.700
Working temperature
°C
-5 to +55
Note1: The loss brought by online optical switch and the coupler is considered for the FMU. The dynamic
value is 1-2 dB smaller than the value of the OTDR component. Besides, the OTDR effective dynamic range
in online monitor mode is different from that in standby fibre monitor mode.
Note2: Test conditions: The pulse width of the test signal is 10 ns; the return loss is not more than -35 dB.
Note3: Test conditions: The pulse width of the test signal is 10 ns; the return loss is not more than -35 dB.
6.10.14 MWF
Table 6-77 Parameter specifications of MWF
Item
Unit
Index
Passband wavelength range
nm
1500-1635
Stopband wavelength range
nm
1280-1340
Passband insertion loss (including that of the
dB
1.2
connector)
Flatness (whole working wavelength range)
dB
0.4
Isolation (passband versus stopband)
dB
≥ 40
Return loss
dB
≥ 40
Polarization dependent loss
dB
≤ 0.1
Polarization mode dispersion
ps
≤ 0.1
Maximum input power
dBm
27
Working temperature
°C
-5 to +55
6.10.15 MWA
Table 6-78 Index requirement of the MWA
Item
Unit
Index
Wavelength range of the transmission channel
nm
1500-1635
Wavelength range of the reflection channel
nm
1280-1340
6-63
6 Technical Specifications
Item
Unit
Index
Insertion loss of the transmission channel (including that
dB
1.2
of the connector)
Insertion loss of the reflection channel (including that of
dB
1.0
the connector)
Flatness (whole working wavelength range)
dB
0.4
Isolation (transmission channel vs reflection channel)
dB
≥ 40
Isolation (reflection channel vs transmission channel)
dB
≥ 40
Return loss
dB
≥ 45
Directivity
dB
≥ 55
Polarization dependent loss
dB
≤ 0.1
Polarization mode dispersion
ps
≤ 0.1
Maximum input power
dBm
27
Working temperature
°C
-5 to +55
6.11 DCM
Currently, different DCM types are available for both C and L bands. Their
parameter specifications are listed in Table 6-79, Table 6-80 and Table 6-81.
Table 6-79 Performance requirement of dispersion compensation optical fibre of C-band
(G.652 fibre)
Item
Distance
Max.
DSCR
PMD
PDL
Max. allow
Operation
(km)
insertion
(ps)
(dB)
power
wavelength
Type
loss(dB)
(dBm)
(nm)
DCM(A)
20
4
90%-110%
0.4
0.1
20
1525-1565
DCM(B)
40
5
0.5
0.1
20
DCM(C)
60
7
0.6
0.1
20
DCM(D)
80
8
0.7
0.1
20
DCM(E)
100
9
0.8
0.1
20
DCM(F)
120
10
0.8
0.1
20
DCM(S)
5
2.5
0.3
0.1
20
The DCM(S) is only used in a system with Super CRZ line encoding.
6-64
6 Technical Specifications
Table 6-80 Performance requirement of dispersion compensation optical fibre of L-band
(G.652 fibre)
Item
Distance
Max.
DSCR
PMD
PDL
Max. allow
Operation
(km)
insertion
(ps)
(dB)
power (dBm)
wavelength
Type
loss(dB)
(nm)
DCM(A)
20
4
90%-110
0.6
0.1
20
1570-1605
%
DCM(B)
40
5.3
0.9
0.1
20
DCM(C)
60
7
1.0
0.1
20
DCM(D)
80
8.4
1.0
0.1
20
Table 6-81 Performance requirement of dispersion compensation optical fibre of C-band
(G.655 LEAF fibre)
Item
Distance
Max.
DSCR
PMD (ps)
PDL (dB)
Max. allow
Operation
(km)
insertion
power (dBm)
wavelength
Type
loss(dB)
(nm)
DCM(A)
20
4
90%-
0.4
0.3
24
1525-1565
110%
DCM(B)
40
5
0.5
0.3
24
DCM(C)
60
6
0.6
0.3
24
DCM(D)
80
7
0.7
0.3
24
DCM(E)
100
8
0.8
0.3
24
6.12 Channel Allocation
Table 6-82 C-band channel allocation (80 channels with 50GHz spacing)
Central frequency
Central wavelength
Central frequency
Central
(THz)
(nm)
(THz)
wavelength (nm)
196.05
1529.16
194.05
1544.92
196.00
1529.55
194.00
1545.32
195.95
1529.94
193.95
1545.72
195.90
1530.33
193.90
1546.12
195.85
1530.72
193.85
1546.52
195.80
1531.12
193.80
1546.92
195.75
1531.51
193.75
1547.32
195.70
1531.90
193.70
1547.72
6-65
6 Technical Specifications
Central frequency
Central wavelength
Central frequency
Central
(THz)
(nm)
(THz)
wavelength (nm)
195.65
1532.29
193.65
1548.11
195.60
1532.68
193.60
1548.51
195.55
1533.07
193.55
1548.91
195.50
1533.47
193.50
1549.32
195.45
1533.86
193.45
1549.72
195.40
1534.25
193.40
1550.12
195.35
1534.64
193.35
1550.52
195.30
1535.04
193.30
1550.92
195.25
1535.43
193.25
1551.32
195.20
1535.82
193.20
1551.72
195.15
1536.22
193.15
1552.12
195.10
1536.61
193.10
1552.52
195.05
1537.00
193.05
1552.93
195.00
1537.40
193.00
1553.33
194.95
1537.79
192.95
1553.73
194.90
1538.19
192.90
1554.13
194.85
1538.58
192.85
1554.54
194.80
1538.98
192.80
1554.94
194.75
1539.37
192.75
1555.34
194.70
1539.77
192.70
1555.75
194.65
1540.16
192.65
1556.15
194.60
1540.56
192.60
1556.55
194.55
1540.95
192.55
1556.96
194.50
1541.35
192.50
1557.36
194.45
1541.75
192.45
1557.77
194.40
1542.14
192.40
1558.17
194.35
1542.54
192.35
1558.58
194.30
1542.94
192.30
1558.98
194.25
1543.33
192.25
1559.39
6-66
6 Technical Specifications
Central frequency
Central wavelength
Central frequency
Central
(THz)
(nm)
(THz)
wavelength (nm)
194.20
1543.73
192.20
1559.79
194.15
1544.13
192.15
1560.20
194.10
1544.53
192.10
1560.61
The odd number wavelengths belong to the C-ODD band and the even number wavelengths belong to the
C-EVEN band.
Table 6-83 L-band channel allocation (80 channels with
50GHz spacing)
Central frequency
Central wavelength
Central frequency
Central
(THz)
(nm)
(THz)
wavelength (nm)
190.90
1570.42
188.90
1587.04
190.85
1570.83
188.85
1587.46
190.80
1571.24
188.80
1587.88
190.75
1571.65
188.75
1588.30
190.70
1572.06
188.70
1588.73
190.65
1572.48
188.65
1589.15
190.60
1572.89
188.60
1589.57
190.55
1573.30
188.55
1589.99
190.50
1573.71
188.50
1590.41
190.45
1574.13
188.45
1590.83
190.40
1574.54
188.40
1591.26
190.35
1574.95
188.35
1591.68
190.30
1575.37
188.30
1592.10
190.25
1575.78
188.25
1592.52
190.20
1576.20
188.20
1592.95
190.15
1576.61
188.15
1593.37
190.10
1577.03
188.10
1593.79
190.05
1577.44
188.05
1594.22
190.00
1577.86
188.00
1594.64
189.95
1578.27
187.95
1595.06
189.90
1578.69
187.90
1595.49
6-67
6 Technical Specifications
Central frequency
Central wavelength
Central frequency
Central
(THz)
(nm)
(THz)
wavelength (nm)
189.85
1579.10
187.85
1595.91
189.80
1579.52
187.80
1596.34
189.75
1579.93
187.75
1596.76
189.70
1580.35
187.70
1597.19
189.65
1580.77
187.65
1597.62
189.60
1581.18
187.60
1598.04
189.55
1581.60
187.55
1598.47
189.50
1582.02
187.50
1598.89
189.45
1582.44
187.45
1599.32
189.40
1582.85
187.40
1599.75
189.35
1583.27
187.35
1600.17
189.30
1583.69
187.30
1600.60
189.25
1584.11
187.25
1601.03
189.20
1584.53
187.20
1601.46
189.15
1584.95
187.15
1601.88
189.10
1585.36
187.10
1602.31
189.05
1585.78
187.05
1602.74
189.00
1586.20
187.00
1603.17
188.95
1586.62
186.95
1603.57
The odd number wavelengths belong to L-ODD band and the even number wavelengths belong to L-EVEN
band.
Table 6-84 C-band channel allocation of 8-channel system (G.653 fibre)
Central frequency
Central
Central frequency
Central
(THz)
wavelength (nm)
(THz)
wavelength (nm)
192.10
1560.61
195.10
1536.61
192.30
1558.98
195.50
1533.47
192.60
1556.55
195.80
1531.12
193.00
1553.33
196.00
1529.55
6-68
6 Technical Specifications
Table 6-85 C-band channel allocation of 12-channel system (G.653 fibre)
Central frequency
Central wavelength
Central frequency
Central
(THz)
(nm)
(THz)
wavelength (nm)
192.10
1560.61
194.00
1545.32
192.20
1559.79
194.10
1544.53
192.40
1558.17
195.30
1535.04
192.80
1554.94
195.70
1531.90
193.00
1553.33
195.90
1530.33
193.10
1552.52
196.00
1529.55
Table 6-86 C-band channel allocation of 16-channel system (G.653 fibre)
Central frequency
Central wavelength
Central frequency
Central wavelength
(THz)
(nm)
(THz)
(nm)
192.10
1560.61
195.00
1537.40
192.20
1559.79
195.10
1536.61
192.30
1558.98
195.40
1534.25
192.40
1558.17
195.50
1533.47
192.60
1556.55
195.70
1531.90
192.70
1555.75
195.80
1531.12
193.00
1553.33
195.90
1530.33
193.10
1552.52
196.00
1529.55
6.13 Electromagnetic Compatibility (EMC)
Strictly followed international standards and EMC measures, the OptiX BWS
1600G is suitable for any kinds of telecommunication networks and markets.
Electromagnetic Safety Standards
CSA C22.2 No. 950
UL 1950
EN 60950, Safety of Information Technology Equipment
EN 60825-1 Safety of Laser Products - Part 1: Equipment Classification,
Requirements and User's Guide
6-69
