Keys, Doors, and Windows

page. Select

“

Vehicle

”

to display the list of

available options and select

“

Remote Lock,

Unlock, Start

”

Sun Visors

Pull the sun visor down to block glare.
Detach the sun visor from the center mount
to pivot to the side window and,
if equipped, extend along the rod.

Roof

Sunroof

If equipped, the ignition must be on or in
ACC/ACCESSORY, or Retained Accessory
Power (RAP) must be active to operate the
sunroof. See

Ignition Positions

204

and

Retained Accessory Power (RAP)

208

1. Sunroof Switch (SLIDE)
2. Vent Switch (TILT)

Slide Switch

Express-Open/Express-Close :

Press

and release

(1) to express-open the

sunroof. The sunshade will not open
automatically. Press and release

(1) to

express-close the sunroof.

Open/Close (Manual Mode) :

Fully

press

(1) to open the sunroof. The

sunshade will not automatically open with
the sunroof. Release to stop at the desired
position. Fully press

(1) to close the

sunroof. Release to stop at the desired
position.

Tilt Switch

Vent Feature :

Press

(2) to vent the

sunroof. Press again and hold to open the
sunroof. Release to stop at the desired
position. The sunshade will not open
automatically. Press

(2) to

express-close the sunroof. Press again to
stop the movement.

The front sunshade can only be opened and
closed manually. The sunshade can be
opened by pushing up on the handle, and
closed by pulling forward on the handle
until it latches. Do not try to close the
sunshade while the sunroof is fully opened
or in the vent position.

If equipped, the rear sunshade can only be
opened or closed manually. To open, press
the latch button (if equipped) on the handle
while pushing up to unlatch it. The
sunshade will retract to the open position.
To close the sunshade, pull the handle
forward until it latches.

The sunroof cannot be opened or closed if
the vehicle has an electrical failure.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Adjust the head restraint so that the top of
the restraint is at the same height as the
top of the occupant's head. This position
reduces the chance of a neck injury in a
crash.

The height of the head restraint can be
adjusted.

To raise or lower the head restraint, press
the button located on the side of the head
restraint, and pull up or push the head
restraint down, and release the button. Pull
and push on the head restraint after the
button is released to make sure that it is
locked in place.

The front seat outboard head restraints are
not removable.

Rear Seats

Second Row Seats

The vehicle

’

s rear second row seats have

adjustable head restraints in the outboard
seating positions.

The height of the head restraint can be
adjusted. Pull the head restraint up to raise
it. Try to move the head restraint to make
sure that it is locked in place.

To lower the head restraint, press the
button, located on the top of the seatback,
and push the head restraint down. Try to
move the head restraint after the button is
released to make sure that it is locked in
place.

The second row head restraints are not
removable.

Third Row Seats

The vehicle

’

s rear third row seats have head

restraints in the outboard seating positions
that cannot be adjusted up or down.

The rear third row outboard head restraints
are not removable.

The rear third row outboard head restraints
are designed to be folded.

The head restraint can be folded to allow for
better visibility when the rear seat is
unoccupied.

When folding the seatback down, the head
restraint will automatically fold out of the
way as the seat is folded down.

Return the lowered head restraint to the
upright position until it locks into place.
Push and pull on the head restraint to make
sure it is locked.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Front Seats

Seat Adjustment

{

Warning

You can lose control of the vehicle if you
try to adjust a driver seat while the
vehicle is moving. Adjust the driver seat
only when the vehicle is not moving.

To adjust a manual seat:

1. Lift the handle under the seat to

unlock it.

2. Move the seat forward or rearward to

adjust the seat position.

3. Release the handle to stop the seat from

moving.

4. Try to move the seat back and forth to

be sure it is locked in place.

Seat Height Adjuster

If equipped, move the lever up or down to
manually raise or lower the seat.

Power Seat Adjustment

{

Warning

The power seats will work with the
ignition off. Children could operate the
power seats and be injured. Never leave
children alone in the vehicle.

To adjust a power seat, if equipped:

Move the seat forward or rearward by
sliding the control forward or rearward.

Raise or lower the front part of the seat
cushion by moving the front of the
control up or down.

Raise or lower the entire seat by moving
the rear of the control up or down.

To adjust the seatback, see

Reclining

Seatbacks

To adjust the lumbar support, see

Lumbar

Adjustment

Some vehicles are equipped with a feature
that activates a vibration in the driver seat
to help the driver avoid crashes. See

Driver

Assistance Systems

231

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Reclining Seatbacks

{

Warning

Sitting in a reclined position when the
vehicle is in motion can be dangerous.
Even when buckled up, the seat belts
cannot do their job.

The shoulder belt will not be against
your body. Instead, it will be in front of
you. In a crash, you could go into it,
receiving neck or other injuries.

The lap belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.

For proper protection when the vehicle is
in motion, have the seatback upright.
Then sit well back in the seat and wear
the seat belt properly.

Do not have a seatback reclined if the
vehicle is moving.

Manual Reclining Seatbacks

{

Warning

If either seatback is not locked, it could
move forward in a sudden stop or crash.
That could cause injury to the person
sitting there. Always push and pull on
the seatbacks to be sure they are locked.

To recline the seatback:

1. Lift the lever.
2. Move the seatback to the desired

position, and then release the lever to
lock the seatback in place.

3. Push and pull on the seatback to make

sure it is locked.

To return the seatback to the upright
position:

1. Lift the lever fully without applying

pressure to the seatback, and the
seatback will return to the upright
position.

2. Push and pull on the seatback to make

sure it is locked.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Power Reclining Seatbacks

Tilt the top of the control rearward to
recline.

Tilt the top of the control forward to
raise.

Lumbar Adjustment

Press and hold the control forward to
increase or rearward to decrease support.

Memory Seats

Overview

If equipped, the memory seat feature allows
drivers to save their unique driving positions
and a shared exit position. See

“

Saving

Seating Positions

”

later in this section. The

saved positions can be recalled manually by
all drivers, see

“

Manually Recalling Seating

Positions

”

later in this section, and drivers

with remote key 1 and 2 can also recall
them automatically. See

“

Auto Seat Entry

Memory Recall

”

“

Auto Seat Exit Memory

Recall

”

later in this section. To enable

automatic recalls, turn on Seat Entry
Memory and/or Seat Exit Memory. See

“

Enabling Automatic Recalls

”

later in this

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

section. The memory recalls may be
canceled at any time during the recall. See

“

Cancel Memory Seating Recalls

”

later in this

section.

Identifying Driver Number

The vehicle identifies the current driver by
their remote key number 1

–

8. The current

remote key number may be identified by
Driver Information Center (DIC) welcome
message,

“

You are driver x for memory

recalls.

”

This message is displayed the first

few times the vehicle is turned on when a
different remote key is used. For Seat Entry
Memory to work properly, save positions to
the 1 or 2 memory button matching the
driver number of this welcome message. To
aid in identifying remote key IDs, it is
recommended to only carry one remote key
when entering the vehicle. Perform the
following if the welcome message is not
displayed:

1. Move all keys and remote keys away

from the vehicle.

2. Start the vehicle with another remote

key. A DIC welcome message should
display indicating the driver number of
the other remote key. Turn the vehicle
off and remove the other key or remote
key from the vehicle.

3. Start the vehicle with the initial key or

remote key. The DIC welcome message
should display the driver number of the
initial remote key.

Saving Seating Positions

Read these instructions completely before
saving memory positions.

To save preferred driving positions to
1 and 2:

1. Turn the vehicle on or to accessory

mode. A DIC welcome message may
indicate the driver number of the current
remote key. See

“

Identifying Driver

Number

”

previously in this section.

2. Adjust all available memory features to

the desired driving position.

3. Press and release SET; a beep will sound.
4. Immediately upon releasing SET, press

and hold memory button 1 or 2 matching
the current Driver

’

s remote key number

until two beeps sound. If too much time
passes between releasing SET and
pressing 1 or 2, the two beeps will not
sound indicating memory position were
not saved. Repeat Steps 3 and 4 to try
again.

5. Repeat Steps 1

–

4 for the other remote

key 1 or 2 using the other 1 or 2 memory
button.

It is recommended to save the preferred
driving positions to both 1 and 2 if you are
the only driver.

To save the common exit seating position to

that is used by all drivers for Manually

Recalling Seating Positions and Auto Seat
Exit Memory Recall features, repeat Steps 1

–

4 using

, the exit button.

Manually Recalling Seating Positions

Press and hold 1, 2, or

button until the

recall is complete, to recall the positions
previously saved to that button.

Manual Memory recall movement for 1, 2 or

buttons may be initiated and will

complete to the saved memory position if
the vehicle is in or out of P (Park).

Enabling Automatic Recalls

Seat Entry Memory moves the driver seat
to the selected 1 or 2 position when the
vehicle is started. Select Settings > Vehicle
> Seating Position > Seat Entry Memory >
ON or OFF. See

“

Auto Seat Entry Memory

Recall

”

later in this section.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Seat Exit Memory moves the driver seat
to the preferred exit position of the

button when the vehicle is turned off and
the door is opened. Select Settings >
Vehicle > Seating Position > Seat Exit
Memory > ON or OFF. See

“

Auto Seat Exit

Memory Recall

”

later in this section.

Auto Seat Entry Memory Recall

Seat Entry Memory will automatically begin
movement to the seating positions of the 1
or 2 button corresponding to the driver

’

remote key number 1 or 2 detected by the
vehicle when:

The vehicle is turned ON.

Seating positions have been previously
saved to the same 1 or 2 button. See

“

Saving Seating Positions

”

previously in

this section.

Seat Entry Memory is enabled. See

“

Enabling Automatic Recalls

”

previously in

this section.

The vehicle is in P (Park).

Seat Entry Memory Recall will continue if
the vehicle is shifted out of P (Park) prior to
reaching the saved memory position.

If the saved memory seat position does not
automatically recall, verify the recall is
enabled. See

“

Enabling Automatic Recalls

”

previously in this section.

If the memory seat recalls to the wrong
position, the driver

’

s remote key number 1

or 2 may not match the memory button
number positions they were saved to. Try
the other remote key or try saving the
positions to the other 1 or 2 memory
button. See

“

Saving Seating Positions

”

previously in this section.

Automatic Seat Entry Memory recalls are
only available for driver

’

s remote key

numbers 1 and 2. Remote keys 3

–

8 will not

provide Seat Entry Memory recalls.

Auto Seat Exit Memory Recall

Seat Exit Memory will begin movement to
the seating position of the

button when:

The vehicle is turned off and the driver
door is open or opened within a
short time.

A seating position has been previously
been saved to the

memory button.

See

“

Saving Seating Positions

”

previously

in this section.

Seat Exit Memory is enabled. See

“

Enabling Automatic Recalls

”

previously in

this section.

The vehicle is in P (Park).

Seat Exit Memory recall will continue if the
vehicle is shifted out of P (Park) prior to
reaching the saved memory position.

Seat Exit Memory is not linked to the
driver

’

s remote key. The seating position

saved to

is used for all drivers.

Cancel Memory Seating Recalls

During any memory recall:
Press a power seat control
Press SET memory button

During Manual memory recall:

Release 1, 2, or

memory button

During Auto Seat Entry Memory Recall:
Turn vehicle off

Press SET, 1, 2, or

memory buttons

During Auto Seat Exit Memory Recall:

Press SET, 1, 2, or

memory buttons

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Obstructions

If something has blocked the seat while
recalling a memory position, the recall may
stop. Remove the obstruction and try the
recall again. If the memory position still
does not recall, see your dealer.

Heated and Ventilated Front
Seats

{

Warning

If temperature change or pain to the skin
cannot be felt, the seat heater may cause
burns. To reduce the risk of burns, use
care when using the seat heater,
especially for long periods of time. Do
not place anything on the seat that
insulates against heat, such as a blanket,
cushion, cover, or similar item. This may
cause the seat heater to overheat. An
overheated seat heater may cause a burn
or may damage the seat.

Heated and Ventilated Seat Buttons Shown,

Heated Seat Buttons Similar

If equipped, the buttons are near the
climate controls on the center stack. To
operate, the engine must be running.

Press

, if available, to heat the

driver or passenger seatback only.

Press

to heat the driver or

passenger cushion and seatback.

Press

{

, if available, to ventilate the

driver or passenger seat. A ventilated seat
has a fan that pulls or pushes air through
the seat. The air is not cooled.

When a heated seat is turned on, the
indicator on button turns red. When a
ventilated seat is turned on, the indicator on
button turns blue.

Press the button once for the highest
setting. With each press of the button, the
seat will change to the next lower setting,
and then to the off setting. The indicator
lights next to the buttons indicate three for
the highest setting and one for the lowest.
If the front heated seats are on high, the
level may automatically be lowered after
approximately 30 minutes.

The passenger seat may take longer to
heat up.

Auto Heated and Ventilated Seats

If the vehicle is equipped with auto heated
or ventilated seats, and the engine is
running, this feature will automatically
activate the heated or ventilated seats at
the level required by the vehicle's interior
temperature.

The active high, medium, low, or off heated
or ventilated seat level will be indicated by
the manual heated and ventilated seat
buttons on the center stack. Use the manual
heated and ventilated seat buttons on the
center stack to turn auto heated or

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

ventilated seats off. If the passenger seat is
unoccupied, the auto heated or ventilated
seats feature will not activate that seat. To
enable or disable auto heated or ventilated
seats, select Settings > Vehicle > Climate
and Air Quality > Auto Cooled or Auto
Heated Seats > ON or OFF. If equipped with
a heated steering wheel, the auto heated
steering wheel activation will follow the
heated seat auto activation and the heated
wheel indicator will follow the state of the
steering wheel heat.

Remote Start Heated and Ventilated Seats

During a remote start, the heated or
ventilated seats, if equipped, can be turned
on automatically. When it is cold outside,
the heated seats will turn on followed by
the heated steering wheel, if equipped.
When it is hot outside, the ventilated seats
turn on. The heated or ventilated seats are
canceled when the ignition is turned on.
Press the heated or ventilated seat button
to use the heated or ventilated seats after
the vehicle is started.

The heated or ventilated seat indicator lights
do not turn on during a remote start.

The temperature performance of an
unoccupied seat may be reduced. This is
normal.

To enable or disable remote start heated or
ventilated seats, select Settings > Vehicle >
Remote Lock, Unlock, and Start > Remote
Start Auto Heat Seats or Remote Start Auto
Cool Seats > ON or OFF. See

Remote Vehicle

Start

Rear Seats

Rear Seat Reminder

If equipped, the message REAR SEAT
REMINDER LOOK IN REAR SEAT displays
under certain conditions indicating there
may be an item or passenger in the rear
seat. Check before exiting the vehicle.

This feature will activate when a second row
door is opened while the vehicle is on or up
to 10 minutes before the vehicle is turned
on. There will be an alert when the vehicle
is turned off. The alert does not directly
detect objects in the rear seat; instead,
under certain conditions, it detects when a
rear door is opened and closed, indicating
that there may be something in the
rear seat.

The feature is active only once each time
the vehicle is turned on and off, and will
require reactivation by opening and closing
the second row doors. There may be an

alert even when there is nothing in the rear
seat; for example, if a child entered the
vehicle through the rear door and left the
vehicle without the vehicle being shut off.

The feature can be turned on or off. Select
Settings > Rear Seat Reminder > ON or OFF.

Rear Seat Adjustment

The second row seats slide forward for
more room.

To adjust the seat position:

1. Remove objects on the floor in front of

or on the second row seat, or in the seat
tracks on the floor.

2. Lift the lever below the seat cushion and

slide the seat forward or backward.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

3. Push and pull on the seatback to ensure

the seat is locked in place.

Entering and Exiting the Third Row

{

Warning

Using the third row seating position
while the second row is folded, or folded
and tumbled, could cause injury in a
sudden stop or crash. Be sure to return
the seat to the passenger seating
position. Push and pull on the seat to
make sure it is locked into place.

{

Warning

If the seatback and floor latches are not
locked, the seat could move forward in a
sudden stop or crash and injure the
occupant. Always push and pull on the
seatbacks to be sure the seatback and
floor latches are locked.

Caution

Folding a rear seat with the seat belts
still fastened may cause damage to the
seat or the seat belts. Always unbuckle

(Continued)

Caution (Continued)

the seat belts and return them to their
normal stowed position before folding a
rear seat.

To access the third row from the driver side:

1. Remove objects on the floor in front of

or on the second row seat, or in the seat
tracks on the floor.

2. Make sure that the seat belt is

unfastened and in the stowed position.

3. Pull the handle on top of the seat

forward and pull the seat forward.

To access the third row from the
passenger side:

Remove objects on the floor in front of the
second row seat, or in the seat tracks on the
floor.

The second row passenger side seat can be
easily moved for third row entry or exit
with a forward-facing child restraint installed
using the LATCH system. Remove a
rear-facing child restraint before moving the
seat for third row entry or exit.

{

Warning

Remove the child from the child restraint
before moving the seat forward for third
row entry or exit. Failure to do so may
result in injury to the child.

Pull the handle on top of the seat forward
and pull the seat forward.

Returning the Seat to the Seating
Position

To return the second row seat to its normal
seating position:

1. Remove objects on the floor behind the

second row seat or in the seat tracks on
the floor.

2. Push on the seatback until the seat is

locked into place.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

3. Push and pull on the seatback and seat

cushion to make sure they are locked in
place.

4. Check that the seat belt is not under the

seat cushion.

Reclining the Seatbacks

To recline the seatbacks:

1. Leaning rearward in the seat, pull the

reclining seatback handle.

2. Move the seatback to the desired

position, and then release the handle to
lock the seatback in place.

3. Push and pull on the seatback to make

sure it is locked.

Folding the Seatbacks

To fold the second row seatbacks:

1. Remove anything on or under the seat.
2. Fold the head restraint rearward. See

Head Restraints

3. Pull forward on the reclining seatback

handle.

To return the seatback to the seating
position, lift the seatback and push it
rearward until it locks into place. Push and
pull on the seatback to make sure it is
locked. Push on the head restraint to return
it to the upright, locked position.

The second row seatbacks can also be folded
forward by pulling the levers on the driver
side of the rear cargo area. The top lever
folds the driver side seatback and the
bottom lever folds the passenger side
seatback.

Heated Rear Seats

{

Warning

If temperature change or pain to the skin
cannot be felt, the seat heater may cause
burns. See the Warning under

Heated

and Ventilated Front Seats

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

If equipped, the buttons are on the rear of
the center console.

With the engine running, press

heat the left or right outboard seat cushion.
On vehicles with rear climate controls, an
indicator on the climate control display
appears when this feature is on.

Press the button again to turn this feature
off. The light on the button will turn off. On
vehicles with rear climate controls, this
feature turns on at the highest setting. With
each press of the button, the heated seat
changes to the next lower setting, and then
the off setting. Three lights indicate the
highest setting, and one light indicates the

lowest. If the heated seats are on high, the
level may automatically be lowered after
approximately 30 minutes.

Third Row Seats

{

Warning

Using the third row seating position
while the second row is folded, or pushed
forward in the entry position, could cause
injury in a sudden stop or crash. Be sure
to return the seat to the passenger
seating position. Push and pull on the
seat to make sure it is locked into place.

Folding the Seatback

Caution

Folding a rear seat with the seat belts
still fastened may cause damage to the
seat or the seat belts. Always unbuckle
the seat belts and return them to their
normal stowed position before folding a
rear seat.

To fold the third row seatback:

1. Remove objects on the floor in front of

or on the second row seat, or in the seat
tracks on the floor.

2. If the second row seat is in the full rear

position, adjust it forward to allow the
third row seat to fold fully flat.

3. Remove anything on or under the seat.

4. Pull the strap on the seatback.
5. Push the seatback forward to lay flat.
6. Repeat for the other seatback,

if necessary.

Returning the Seat to the Seating
Position

To return the seatback to the seating
position:

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

1. From the rear of the vehicle, raise the

seatback to the upright position using
the strap on the back of the third row
seat, or lift the seatback and push it into
place from inside the vehicle.

{

Warning

2. Push and pull on the seatback to make

sure it is locked in place.

{

Warning

A seat belt that is improperly routed, not
properly attached, or twisted will not
provide the protection needed in a crash.
The person wearing the belt could be
seriously injured. After raising the rear
seatback, always check to be sure that
the seat belts are properly routed and
attached, and are not twisted.

Seat Belts

This section describes how to use seat belts
properly, and some things not to do.

{

Warning

Do not let anyone ride where a seat belt
cannot be worn properly. In a crash,
if you or your passenger(s) are not
wearing seat belts, injuries can be much
worse than if you are wearing seat belts.
You can be seriously injured or killed by
hitting things inside the vehicle harder or
by being ejected from the vehicle. In
addition, anyone who is not buckled up
can strike other passengers in the vehicle.

It is extremely dangerous to ride in a
cargo area, inside or outside of a vehicle.
In a collision, passengers riding in these
areas are more likely to be seriously
injured or killed. Do not allow passengers
to ride in any area of the vehicle that is
not equipped with seats and seat belts.

Always wear a seat belt, and check that
all passenger(s) are restrained
properly too.

This vehicle has indicators as a reminder to
buckle the seat belts. See

Seat Belt

Reminders

104

Why Seat Belts Work

When riding in a vehicle, you travel as fast
as the vehicle does. If the vehicle stops
suddenly, you keep going until something
stops you. It could be the windshield, the
instrument panel, or the seat belts!

When you wear a seat belt, you and the
vehicle slow down together. There is more
time to stop because you stop over a longer
distance and, when worn properly, your
strongest bones take the forces from the
seat belts. That is why wearing seat belts
makes such good sense.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Questions and Answers About Seat Belts

Q: Will I be trapped in the vehicle after a

crash if I am wearing a seat belt?

You

could

—

whether you are

wearing a seat belt or not. Your chance
of being conscious during and after a
crash, so you

can

unbuckle and get out,

much

greater if you are belted.

Q: If my vehicle has airbags, why should I

have to wear seat belts?

Airbags are supplemental systems only.
They work

with

seat belts

—

not instead

of them. Whether or not an airbag is
provided, all occupants still have to
buckle up to get the most protection.

Also, in nearly all states and in all
Canadian provinces, the law requires
wearing seat belts.

How to Wear Seat Belts Properly

Follow these rules for everyone's protection.

There are additional things to know about
seat belts and children, including smaller
children and infants. If a child will be riding
in the vehicle, see

Older Children

Infants and Young Children

. Review

and follow the rules for children in addition
to the following rules.

It is very important for all occupants to
buckle up. Statistics show that unbelted
people are hurt more often in crashes than
those who are wearing seat belts.

There are important things to know about
wearing a seat belt properly.

Sit up straight and always keep your feet
on the floor in front of you (if possible).

Wear the lap part of the belt low and
snug on the hips, just touching the
thighs. In a crash, this applies force to the
strong pelvic bones and you would be
less likely to slide under the lap belt.

If you slid under it, the belt would apply
force on your abdomen. This could cause
serious or even fatal injuries.

Wear the shoulder belt over the shoulder
and across the chest. These parts of the
body are best able to take belt
restraining forces. The shoulder belt locks
if there is a sudden stop or crash.

{

Warning

You can be seriously injured, or even
killed, by not wearing your seat belt
properly.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

{

Warning

You can be seriously injured or killed if
the shoulder belt is worn behind your
back, under your legs, or wrapped around
your neck. The shoulder belt can tighten
but cannot be loosened if it is locked. The
shoulder belt locks when it is pulled all
the way out of the retractor. It unlocks
when the shoulder belt is allowed to go
all the way back into the retractor, but it
cannot do this if it is wrapped around
you. You may have to cut the seat belt if
it is locked and tightened around you.

Lap-Shoulder Belt

All seating positions in the vehicle have a
lap-shoulder belt.

The following instructions explain how to
wear a lap-shoulder belt properly.

1. Adjust the seat, if the seat is adjustable,

so you can sit up straight. To see how,
see

“

Seats

”

in the Index.

2. Pick up the latch plate and pull the belt

across you. Do not let it get twisted.
The lap-shoulder belt may lock if you
pull the belt across you very quickly.
If this happens, let the belt go back
slightly to unlock it. Then pull the belt
across you more slowly.
If the shoulder portion of a passenger
belt is pulled out all the way, the child
restraint locking feature may be
engaged. See

Child Restraint Systems

. If this occurs, let the belt go back

all the way and start again. If the
locking feature stays engaged after
letting the belt go back to stowed

position on the seat, move the seat
rearward or recline the seat until the
shoulder belt retractor lock releases.
Engaging the child restraint locking
feature in the front outboard seating
position may affect the passenger
sensing system. See

Passenger Sensing

System

If the webbing locks in the latch plate
before it reaches the buckle, tilt the latch
plate flat to unlock.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

3. Push the latch plate into the buckle until

it clicks.
Pull up on the latch plate to make sure
it is secure. If the belt is not long
enough, see

Seat Belt Extender

Position the release button on the buckle
so that the seat belt could be quickly
unbuckled if necessary.

4. If equipped with a shoulder belt height

adjuster, move it to the height that is
right for you. See

“

Shoulder Belt Height

Adjuster

”

later in this section for

instructions on use and important safety
information.

5. To make the lap part tight, pull up on

the shoulder belt.

To unlatch the belt, push the button on the
buckle. The belt should return to its stowed
position.

Always stow the seat belt slowly. If the seat
belt webbing returns quickly to the stowed
position, the retractor may lock and cannot
be pulled out. If this happens, pull the seat
belt straight out firmly to unlock the
webbing, and then release it. If the webbing
is still locked in the retractor, see your
dealer.

Before a door is closed, be sure the seat belt
is out of the way. If a door is slammed
against a seat belt, damage can occur to
both the seat belt and the vehicle.

Shoulder Belt Height Adjuster

The vehicle has a shoulder belt height
adjuster for the driver and front outboard
passenger seating positions.

Adjust the height so that the shoulder
portion of the belt is on the shoulder and
not falling off of it. The belt should be close
to, but not contacting, the neck. Improper
shoulder belt height adjustment could
reduce the effectiveness of the seat belt in a
crash. See

How to Wear Seat Belts Properly

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Press and hold the release button while
raising or lowering the height adjuster to
the desired position.

After the height adjuster is set to the
desired position, try to move it down
without pressing the release button to make
sure it has locked into position.

Seat Belt Pretensioners

This vehicle has seat belt pretensioners for
the front outboard occupants. Although the
seat belt pretensioners cannot be seen, they
are part of the seat belt assembly. They can
help tighten the seat belts during the early
stages of a moderate to severe frontal, near
frontal, or rear crash if the threshold
conditions for pretensioner activation are

met. Seat belt pretensioners can also help
tighten the seat belts in a side crash or a
rollover event.

Pretensioners work only once. If the
pretensioners activate in a crash, the
pretensioners and probably other parts of
the vehicle

’

s seat belt system will need to

be replaced. See

Replacing Seat Belt System

Parts after a Crash

Do not sit on the outboard seat belt while
entering or exiting the vehicle or at any
time while sitting in the seat. Sitting on the
seat belt can damage the webbing and
hardware.

Rear Seat Belt Comfort Guides

Rear seat belt comfort guides may provide
added seat belt comfort for older children
who have outgrown booster seats and for
some adults. When installed on a shoulder
belt, the comfort guide positions the
shoulder belt away from the neck and head.

Comfort guides are available through your
dealer for the rear outboard seating
positions. Instructions are included with the
guides.

Seat Belt Use During Pregnancy

Seat belts work for everyone, including
pregnant women. Like all occupants, they
are more likely to be seriously injured if
they do not wear seat belts.

A pregnant woman should wear a
lap-shoulder belt, and the lap portion should
be worn as low as possible, below the
rounding, throughout the pregnancy.

The best way to protect the fetus is to
protect the mother. When a seat belt is
worn properly, it is more likely that the
fetus will not be hurt in a crash. For
pregnant women, as for anyone, the key to
making seat belts effective is wearing them
properly.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Seat Belt Extender

If the vehicle's seat belt will fasten around
you, you should use it.

But if a seat belt is not long enough, your
dealer will order you an extender. Only a
GM dealer issued extender should be used.
When you go in to order it, take the
heaviest coat you will wear, so the extender
will be long enough for you. To help avoid
personal injury, do not let someone else use
it, and use it only for the seat it is made to
fit. The extender has been designed for
adults. Never use it for securing child
restraints. For more information on the
proper use and fit of seat belt extenders see
the instruction sheet that comes with the
extender.

Safety System Check

Periodically check the seat belt reminder,
seat belts, buckles, latch plates, retractors,
shoulder belt height adjusters (if equipped),
and seat belt anchorages to make sure they
are all in working order. Look for any other
loose or damaged seat belt system parts
that might keep a seat belt system from
performing properly. See your dealer to
have it repaired. Torn, frayed, or twisted
seat belts may not protect you in a crash.

Torn or frayed seat belts can rip apart under
impact forces. If a belt is torn or frayed,
have it replaced immediately. If a belt is
twisted, it may be possible to untwist by
reversing the latch plate on the webbing.
If the twist cannot be corrected, ask your
dealer to fix it.

Make sure the seat belt reminder light is
working. See

Seat Belt Reminders

104

Keep seat belts clean and dry. See

Seat Belt

Care

Seat Belt Care

Keep belts clean and dry.

Seat belts should be properly cared for and
maintained.

Seat belt hardware should be kept dry and
free of dust or debris. As necessary, exterior
hard surfaces and seat belt webbing may be
lightly cleaned with mild soap and water.
Ensure there is not excessive dust or debris
in the mechanism. If dust or debris exists in
the system please see the dealer. Parts may
need to be replaced to ensure proper
functionality of the system.

{

Warning

Do not bleach or dye seat belt webbing.
It may severely weaken the webbing. In
a crash, they might not be able to
provide adequate protection. Clean and
rinse seat belt webbing only with mild
soap and lukewarm water. Allow the
webbing to dry.

Replacing Seat Belt System Parts
after a Crash

{

Warning

A crash can damage the seat belt system
in the vehicle. A damaged seat belt
system may not properly protect the
person using it, resulting in serious injury
or even death in a crash. To help make
sure the seat belt systems are working
properly after a crash, have them
inspected and any necessary
replacements made as soon as possible.

After a minor crash, replacement of seat
belts may not be necessary. But the seat
belt assemblies that were used during any

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

crash may have been stressed or damaged.
See your dealer to have the seat belt
assemblies inspected or replaced.

New parts and repairs may be necessary
even if the seat belt system was not being
used at the time of the crash.

Have the seat belt pretensioners checked if
the vehicle has been in a crash, or if the
airbag readiness light stays on after you
start the vehicle or while you are driving.
See

Airbag Readiness Light

104

Airbag System

The vehicle has the following airbags:

A frontal airbag for the driver

A frontal airbag for the front outboard
passenger

A knee airbag for the driver

A front center airbag for the driver and
front outboard passenger

A seat-mounted side impact airbag for the
driver

A seat-mounted side impact airbag for the
front outboard passenger

A roof-rail airbag for the driver and for
the second and third row passengers
seated directly behind the driver

A roof-rail airbag for the front outboard
passenger and the second and third row
passengers seated directly behind the
front outboard passenger

All vehicle airbags have the word AIRBAG on
the trim or on a label near the deployment
opening.

For frontal airbags, the word AIRBAG is on
the center of the steering wheel for the
driver and on the instrument panel for the
front outboard passenger.

For knee airbags, the word AIRBAG is on the
lower part of the instrument panel.

For the front center airbag, the word AIRBAG
is on the inboard side of the driver seatback.

For seat-mounted side impact airbags, the
word AIRBAG is on the side of the seatback
or side of the seat closest to the door.

For roof-rail airbags, the word AIRBAG is on
the ceiling or trim.

Airbags are designed to supplement the
protection provided by seat belts. Even
though today's airbags are also designed to
help reduce the risk of injury from the force
of an inflating bag, all airbags must inflate
very quickly to do their job.

Here are the most important things to know
about the airbag system:

{

Warning

You can be severely injured or killed in a
crash if you are not wearing your seat
belt, even with airbags. Airbags are
designed to work with seat belts, not
replace them. Also, airbags are not
designed to inflate in every crash. In
some crashes seat belts are the only
restraint. See

When Should an Airbag

Inflate?

Wearing your seat belt during a crash
helps reduce your chance of hitting
things inside the vehicle or being ejected
from it. Airbags are

“

supplemental

restraints

”

to the seat belts. Everyone in

the vehicle should wear a seat belt
properly, whether or not there is an
airbag for that person.

{

Warning

Because airbags inflate with great force
and faster than the blink of an eye,
anyone who is up against, or very close

(Continued)

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Warning (Continued)

to any airbag when it inflates can be
seriously injured or killed. Do not sit
unnecessarily close to any airbag, as you
would be if sitting on the edge of the
seat or leaning forward. Seat belts help
keep you in position before and during a
crash. Always wear a seat belt, even with
airbags. The driver should sit as far back
as possible while still maintaining control
of the vehicle. The seat belts and the
front outboard passenger airbags are
most effective when you are sitting well
back and upright in the seat with both
feet on the floor.

Occupants should not lean on or sleep
against the front center armrest or
console in vehicles with a front center
airbag.

Occupants should not lean on or sleep
against the door or side windows in
seating positions with seat-mounted side
impact airbags and/or roof-rail airbags.

{

Warning

Children who are up against, or very
close to, any airbag when it inflates can
be seriously injured or killed. Always
secure children properly in the vehicle. To
read how, see

Older Children

Infants and Young Children

There is an airbag readiness light on the
instrument cluster, which shows the airbag
symbol.

The system checks the airbag electrical
system for malfunctions. The light tells you
if there is an electrical problem. See

Airbag

Readiness Light

104

Where Are the Airbags?

The driver frontal airbag is in the center of
the steering wheel.

The front outboard passenger frontal airbag
is in the passenger side instrument panel.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

The driver knee airbag is below the steering
column.

The front center airbag is in the inboard side
of the driver seatback.

Driver Side Shown, Passenger Side Similar

The seat-mounted side impact airbags for
the driver and front outboard passenger are
in the sides of the seatbacks closest to
the door.

Driver Side Shown, Passenger Side Similar

The roof-rail airbags for the driver, front
outboard passenger, and second and third
row outboard passengers are in the ceiling
above the side windows.

{

Warning

If something is between an occupant and
an airbag, the airbag might not inflate
properly or it might force the object into
that person causing severe injury or even
death. The path of an inflating airbag
must be kept clear. Do not put anything
between an occupant and an airbag, and

(Continued)

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Warning (Continued)

do not attach or put anything on the
steering wheel hub or on or near any
other airbag covering.

Do not use seat or console accessories
that block the inflation path of a
seat-mounted side impact airbag or the
front center airbag.

Never secure anything to the roof of a
vehicle with roof-rail airbags by routing a
rope or tie-down through any door or
window opening. If you do, the path of
an inflating roof-rail airbag will be
blocked.

When Should an Airbag Inflate?

This vehicle is equipped with airbags. See

Airbag System

. Airbags are designed to

inflate if the impact exceeds the specific
airbag system's deployment threshold.
Deployment thresholds are used to predict
how severe a crash is likely to be in time
for the airbags to inflate and help restrain
the occupants. The vehicle has electronic
sensors that help the airbag system

determine the severity of the impact.
Deployment thresholds can vary with
specific vehicle design.

Frontal airbags are designed to inflate in
moderate to severe frontal crashes to help
reduce the potential for severe injuries,
mainly to the driver's or front outboard
passenger's head and chest.

Whether the frontal airbags will or should
inflate is not based primarily on how fast
the vehicle is traveling. It depends on what
is hit, the direction of the impact, and how
quickly the vehicle slows down.

Frontal airbags may inflate at different crash
speeds depending on whether the vehicle
hits an object straight on or at an angle,
and whether the object is fixed or moving,
rigid or deformable, narrow or wide.

Frontal airbags are not intended to inflate
during vehicle rollovers, in rear impacts,
or in many side impacts.

In addition, the vehicle has advanced
technology frontal airbags. Advanced
technology frontal airbags adjust the
restraint according to crash severity.

Knee airbags are designed to inflate in
moderate to severe frontal impacts. Knee
airbags are not designed to inflate during
vehicle rollovers, in rear impacts, or in many
side impacts.

The front center airbag is designed to inflate
in moderate to severe side crashes
depending on the location of the impact,
when either side of the vehicle is struck. In
addition, the front center airbag is designed
to inflate when the sensing system predicts
that the vehicle is about to roll over on its
side. The front center airbag is not designed
to inflate in frontal impacts, near frontal
impacts, or rear impacts.

Seat-mounted side impact airbags are
designed to inflate in moderate to severe
side crashes depending on the location of
the impact. These airbags may also inflate
in some moderate to severe frontal impacts.
Seat-mounted side impact airbags are not
designed to inflate in rollovers or rear
impacts. A seat-mounted side impact airbag
is designed to inflate on the side of the
vehicle that is struck.

Roof-rail airbags are designed to inflate in
moderate to severe side crashes depending
on the location of the impact. In addition,
these roof-rail airbags may inflate during a

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

rollover or in a severe frontal impact.
Roof-rail airbags are not designed to inflate
in rear impacts. Both roof-rail airbags may
inflate when either side of the vehicle is
struck or if the sensing system predicts that
the vehicle is about to roll over on its side,
or in a severe frontal impact.

In any particular crash, no one can say
whether an airbag should have inflated
simply because of the vehicle damage or
repair costs.

What Makes an Airbag Inflate?

In a deployment event, the sensing system
sends an electrical signal triggering a release
of gas from the inflator. Gas from the
inflator fills the airbag causing the bag to
break out of the cover. The inflator, the
airbag, and related hardware are all part of
the airbag module.

For airbag locations, see

Where Are the

Airbags?

How Does an Airbag Restrain?

In moderate to severe frontal or near frontal
collisions, even belted occupants can contact
the steering wheel or the instrument panel.

In moderate to severe side collisions, even
belted occupants can contact the inside of
the vehicle.

Airbags supplement the protection provided
by seat belts by distributing the force of the
impact more evenly over the
occupant's body.

Rollover capable roof-rail airbags are
designed to help contain the head and chest
of occupants in the outboard seating
positions in the first, second, and third rows.
The rollover capable roof-rail airbags are
designed to help reduce the risk of full or
partial ejection in rollover events, although
no system can prevent all such ejections.

But airbags would not help in many types
of collisions, primarily because the
occupant's motion is not toward those
airbags. See

When Should an Airbag Inflate?

Airbags should never be regarded as
anything more than a supplement to seat
belts.

What Will You See after an
Airbag Inflates?

After frontal, knee, and seat-mounted side
impact airbags inflate, they quickly deflate,
so quickly that some people may not even
realize the airbags inflated. The front center
airbag and roof-rail airbags may still be at
least partially inflated for some time after
they inflate. Some components of the airbag
module may be hot for several minutes. For
location of the airbags, see

Where Are the

Airbags?

The parts of the airbag that come into
contact with you may be warm, but not too
hot to touch. There may be some smoke
and dust coming from the vents in the
deflated airbags. Airbag inflation does not
prevent the driver from seeing out of the
windshield or being able to steer the
vehicle, nor does it prevent people from
leaving the vehicle.

{

Warning

When an airbag inflates, there may be
dust in the air. This dust could cause
breathing problems for people with a
history of asthma or other breathing

(Continued)

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Warning (Continued)

trouble. To avoid this, everyone in the
vehicle should get out as soon as it is
safe to do so. If you have breathing
problems but cannot get out of the
vehicle after an airbag inflates, then get
fresh air by opening a window or a door.
If you experience breathing problems
following an airbag deployment, you
should seek medical attention.

The vehicle has a feature that may
automatically unlock the doors, turn on the
interior lamps and hazard warning flashers,
and shut off the fuel system after the
airbags inflate. The feature may also
activate, without airbag inflation, after an
event that exceeds a predetermined
threshold. After turning the ignition off and
then on again, the fuel system will return to
normal operation; the doors can be locked,
the interior lamps can be turned off, and
the hazard warning flashers can be turned
off using the controls for those features.
If any of these systems are damaged in the
crash they may not operate as normal.

{

Warning

A crash severe enough to inflate the
airbags may have also damaged
important functions in the vehicle, such
as the fuel system, brake and steering
systems, etc. Even if the vehicle appears
to be drivable after a moderate crash,
there may be concealed damage that
could make it difficult to safely operate
the vehicle.

Use caution if you should attempt to
restart the engine after a crash has
occurred.

In many crashes severe enough to inflate
the airbag, windshields are broken by
vehicle deformation. Additional windshield
breakage may also occur from the front
outboard passenger airbag.

Airbags are designed to inflate only once.
After an airbag inflates, you will need
some new parts for the airbag system.
If you do not get them, the airbag
system will not be there to help protect
you in another crash. A new system will
include airbag modules and possibly other
parts. The service manual for the vehicle
covers the need to replace other parts.

The vehicle has a crash sensing and
diagnostic module which records
information after a crash. See

Vehicle

Data Recording and Privacy

360

and

Event Data Recorders

361

Let only qualified technicians work on the
airbag systems. Improper service can
mean that an airbag system will not work
properly. See your dealer for service.

Passenger Sensing System

The vehicle has a passenger sensing system
for the front outboard passenger position.
The passenger airbag status indicator will
light on the overhead console when the
vehicle is started.

The words ON and OFF, and the symbols for
on and off, will be visible during the system
check. When the system check is complete,
either the word ON or OFF, and the symbol
for on or off, will be visible. See

Passenger

Airbag Status Indicator

105

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

The passenger sensing system turns off the
front outboard passenger frontal airbag
under certain conditions. No other airbag is
affected by the passenger sensing system.

The passenger sensing system works with
sensors that are part of the front outboard
passenger seat and seat belt. The sensors
are designed to detect the presence of a
properly seated occupant and determine if
the front outboard passenger frontal airbag
should be allowed to inflate or not.

According to accident statistics, children are
safer when properly secured in a rear seat
in the correct child restraint for their weight
and size.

Whenever possible, children aged 12 and
under should be secured in a rear seating
position.

Never put a rear-facing child seat in the
front. This is because the risk to the
rear-facing child is so great, if the airbag
inflates.

{

Warning

A child in a rear-facing child restraint can
be seriously injured or killed if the
passenger frontal airbag inflates. This is

(Continued)

Warning (Continued)

because the back of the rear-facing child
restraint would be very close to the
inflating airbag. A child in a
forward-facing child restraint can be
seriously injured or killed if the passenger
frontal airbag inflates and the passenger
seat is in a forward position.

Even if the passenger sensing system has
turned off the passenger frontal airbag,
no system is fail-safe. No one can
guarantee that an airbag will not deploy
under some unusual circumstance, even
though the airbag is turned off.

Never put a rear-facing child restraint in
the front seat, even if the airbag is off.
If securing a forward-facing child restraint
in the front outboard passenger seat,
always move the seat as far back as it
will go. It is better to secure child
restraints in the rear seat. Consider using
another vehicle to transport the child
when a rear seat is not available.

The passenger sensing system is designed to
turn off the front outboard passenger
frontal airbag if:

The front outboard passenger seat is
unoccupied.

The system determines an infant is
present in a child restraint.

A front outboard passenger takes his/her
weight off of the seat for a period
of time.

There is a critical problem with the airbag
system or the passenger sensing system.

When the passenger sensing system has
turned off the front outboard passenger
frontal airbag, the OFF indicator will light
and stay lit as a reminder that the airbag is
off. See

Passenger Airbag Status Indicator

105

The passenger sensing system is designed to
turn on the front outboard passenger frontal
airbag anytime the system senses that a
person of adult size is sitting properly in the
front outboard passenger seat.

When the passenger sensing system has
allowed the airbag to be enabled, the ON
indicator will light and stay lit as a reminder
that the airbag is active.

For some children, including children in child
restraints, and for very small adults, the
passenger sensing system may or may not
turn off the front outboard passenger

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

frontal airbag, depending upon the person's
seating posture and body build. Everyone in
the vehicle who has outgrown child
restraints should wear a seat belt
properly

—

whether or not there is an

airbag for that person.

{

Warning

If the airbag readiness light ever comes
on and stays on, it means that
something may be wrong with the airbag
system. To help avoid injury to yourself
or others, have the vehicle serviced right
away. See

Airbag Readiness Light

104

for more information, including important
safety information.

If the On Indicator Is Lit for a Child
Restraint

The passenger sensing system is designed to
turn off the front outboard passenger
frontal airbag if the system determines that
an infant is present in a child restraint. If a
child restraint has been installed and the ON
indicator is lit:

1. Turn the vehicle off.
2. Remove the child restraint from the

vehicle.

3. Remove any additional items from the

seat such as blankets, cushions, seat
covers, seat heaters, or seat massagers.

4. Reinstall the child restraint following the

directions provided by the child restraint
manufacturer and refer to

Securing Child

Restraints (With the Seat Belt in the Rear
Seat)

Securing Child Restraints (With the Seat
Belt in the Front Seat)

Make sure the seat belt retractor is
locked by pulling the shoulder belt all
the way out of the retractor when
installing the child restraint, even if the
child restraint is equipped with a seat
belt lock off. When the retractor lock is
set, the belt can be tightened but not
pulled out of the retractor.

5. If, after reinstalling the child restraint

and restarting the vehicle, the ON
indicator is still lit, turn the vehicle off.
Then slightly recline the vehicle seatback
and adjust the seat cushion,
if adjustable, to make sure that the
vehicle seatback is not pushing the child
restraint into the seat cushion.

Also make sure the child restraint is not
trapped under the vehicle head restraint.
If this happens, adjust the head restraint.
See

Head Restraints

6. Restart the vehicle.

The passenger sensing system may or may
not turn off the airbag for a child in a child
restraint depending upon the child

’

s size.

It is better to secure the child restraint in a
rear seat. Never put a rear-facing child
restraint in the front seat, even if the ON
indicator is not lit.

If the Off Indicator Is Lit for an
Adult-Sized Occupant

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

If a person of adult size is sitting in the
front outboard passenger seat, but the OFF
indicator is lit, it could be because that
person is not sitting properly in the seat or
that the child restraint locking feature is
engaged. Use the following steps to allow
the system to detect that person and enable
the front outboard passenger frontal airbag:

1. Turn the vehicle off.
2. Remove any additional material from the

seat, such as blankets, cushions, seat
covers, seat heaters, or seat massagers.

3. Place the seatback in the fully upright

position.

4. Have the person sit upright in the seat,

centered on the seat cushion, with legs
comfortably extended.

5. If the shoulder portion of the belt is

pulled out all the way, the child restraint
locking feature will be engaged. This
may unintentionally cause the passenger
sensing system to turn the airbag off for
some adult-sized occupants. If this
happens, unbuckle the belt, let the belt
go back all the way, and then buckle the
belt again without pulling the belt out
all the way.

6. Restart the vehicle and have the person

remain in this position for two to
three minutes after the ON indicator
is lit.

{

Warning

If the front outboard passenger airbag is
turned off for an adult-sized occupant,
the airbag will not be able to inflate and
help protect that person in a crash,
resulting in an increased risk of serious
injury or even death. An adult-sized
occupant should not ride in the front
outboard passenger seat, if the passenger
airbag OFF indicator is lit.

Additional Factors Affecting System
Operation

Seat belts help keep the passenger in
position on the seat during vehicle
maneuvers and braking, which helps the
passenger sensing system maintain the
passenger airbag status. See

“

Seat Belts

”

and

“

Child Restraints

”

in the Index for

additional information about the importance
of proper restraint use.

A thick layer of additional material, such as
a blanket or cushion, or aftermarket
equipment such as seat covers, seat heaters,
and seat massagers can affect how well the
passenger sensing system operates. We
recommend that you not use seat covers or
other aftermarket equipment except when
approved by GM for your specific vehicle.
See

Adding Equipment to the

Airbag-Equipped Vehicle

for more

information about modifications that can
affect how the system operates.

The ON indicator may be lit if an object,
such as a briefcase, handbag, grocery bag,
laptop, or other electronic device, is put on
an unoccupied seat. If this is not desired,
remove the object from the seat.

{

Warning

Stowing articles under the passenger seat
or between the passenger seat cushion
and seatback may interfere with the
proper operation of the passenger
sensing system.

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

Servicing the Airbag-Equipped
Vehicle

Airbags affect how the vehicle should be
serviced. There are parts of the airbag
system in several places around the vehicle.
Your dealer and the service manual have
information about servicing the vehicle and
the airbag system. To purchase a service
manual, see

Publication Ordering

Information

358

{

Warning

For up to 10 seconds after the vehicle is
turned off and the battery is
disconnected, an airbag can still inflate
during improper service. You can be
injured if you are close to an airbag
when it inflates. Avoid yellow connectors.
They are probably part of the airbag
system. Be sure to follow proper service
procedures, and make sure the person
performing work for you is qualified to
do so.

Adding Equipment to the
Airbag-Equipped Vehicle

Adding accessories that change the vehicle's
frame, bumper system, height, front end,
or side sheet metal may keep the airbag
system from working properly.

The operation of the airbag system can also
be affected by changing, including
improperly repairing or replacing, any parts
of the following:

Airbag system, including airbag modules,
front or side impact sensors, sensing and
diagnostic module, airbag wiring, or front
center console

Front seats, including stitching, seams or
zippers

Seat belts

Steering wheel, instrument panel,
overhead console, ceiling trim, or pillar
garnish trim

Inner door seals, including speakers

Your dealer and the service manual have
information about the location of the airbag
modules and sensors, sensing and diagnostic
module, and airbag wiring along with the
proper replacement procedures.

In addition, the vehicle has a passenger
sensing system for the front outboard
passenger position, which includes sensors
that are part of the passenger's seat. The
passenger sensing system may not operate
properly if the original seat trim is replaced
with non-GM covers, upholstery, or trim,
or with GM covers, upholstery, or trim
designed for a different vehicle. Any object,
such as an aftermarket seat heater or a
comfort enhancing pad or device, installed
under or on top of the seat fabric, could
also interfere with the operation of the
passenger sensing system. This could either
prevent proper deployment of the passenger
airbag(s) or prevent the passenger sensing
system from properly turning off the
passenger airbag(s). See

Passenger Sensing

System

If the vehicle has rollover roof-rail airbags,
see

Different Size Tires and Wheels

308

for additional important information.

If the vehicle must be modified because you
have a disability and you have questions
about whether the modifications will affect
the vehicle's airbag system, or if you have
questions about whether the airbag system

GMC Acadia/Acadia Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-16402009) - 2023 - CRC - 3/28/22

Seats and Restraints

will be affected if the vehicle is modified for
any other reason, call Customer Assistance.
See

Customer Assistance Offices

353

Airbag System Check

The airbag system does not need regularly
scheduled maintenance or replacement.
Make sure the airbag readiness light is
working. See

Airbag Readiness Light

104

Caution

If an airbag covering is damaged, opened,
or broken, the airbag may not work
properly. Do not open or break the airbag
coverings. If there are any opened or
broken airbag coverings, have the airbag
covering and/or airbag module replaced.
For the location of the airbags, see

Where

Are the Airbags?

. See your dealer for

service.

Replacing Airbag System Parts
after a Crash

{

Warning

A crash can damage the airbag systems
in the vehicle. A damaged airbag system
may not properly protect you and your
passenger(s) in a crash, resulting in
serious injury or even death. To help
make sure the airbag systems are
working properly after a crash, have
them inspected and any necessary
replacements made as soon as possible.

If an airbag inflates, you will need to
replace airbag system parts. See your dealer
for service.

If the airbag readiness light stays on after
the vehicle is started or comes on when you
are driving, the airbag system may not work
properly. Have the vehicle serviced right
away. See

Airbag Readiness Light

104

Child Restraints

Older Children

Older children who have outgrown booster
seats should wear the vehicle

’

s seat belts.

Refer to

How to Wear Seat Belts Properly

The manufacturer instructions that come
with the booster seat state the weight and
height limitations for that booster. Use a
booster seat with a lap-shoulder belt until
the child passes the fit test below:

Sit all the way back on the seat. Do the
knees bend at the seat edge? If yes,
continue. If no, return to the booster seat.

MC Acadia Owner (2023 year). Manual in english - page 2
