Caterpillar. Dealer service tools catalog (2018)

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Accumulator Charging Group

Warranty: Manufacturer's

• Used only on high pressure nitrogen bottles

• An additional 6V-7879 Adapter (not shown)

must be ordered separately to provide a

For repair information, contact Hydac. (Refer to

• Used to charge various accumulators on 206B,

method of connecting to English nitrogen

Tool Repair section of this catalog

212B, 214B, 224B Wheel-Type Excavators;

charging cylinders having a female 5/8-14

CB314, CS551, CP323, CS323 Compactors;

BSP thd (BSP #341 nitrogen); the 6V-7879

and all Excavators and Backhoe Loaders using

Adapter is used along with the 9U-6741

hydraulic hammer attachment; Challenger 35,

Adapter

45 and 55

• 151-8856 Charging Seal is required on

• Packaged in protective carrying case for

130-7623 Accumulators (130-7623 used only

convenience and to reduce damage

on Challenger 35 S/N 8DM00201 and Up,

• Hose assembly connects directly to nitrogen

Challenger 45 S/N 1DR00201 and Up, and

bottle with DIN specifications

Challenger 55 S/N 7DM00201 and Up); the

• 334-1071 Adapter, 9U-6741 Adapter and

151-8856 needs to be ordered separately

9U-6739 Hose Assembly required to connect

hose to U.S. nitrogen bottles (low pressure)

Dry nitrogen is the only gas approved for use in the accumulator. Charging the accumulator with oxygen gas will cause an explosion. This danger will

not happen if nitrogen cylinders with standard CGA (Compressed Gas Association, Inc.) number 580 connections are used. When you order nitrogen gas,

be sure that the cylinders are equipped with CGA No. 580 connections. Do not use color codes or other methods of identification to tell the difference

between nitrogen and oxygen cylinders.

• When charging the accumulators on machines

199-9040 Hose Assembly

equipped with hydraulic hammers, some

• Length: 250 cm (8 ft.)

additional tools will be required. The parts

• Diameter: 10.0 mm (0.394 in)

listed below may be required with the

• Swivel connection (male): CGA 680

9U-6740 or 152-2023 Accumulator Charging

• Swivel nut connection (female): M14 x 1.5 thd

Group.

• Working pressure: 385 bar (5500 PSI)

Includes:

152-2024 O-ring Seal

- 186-6225 Charging Adapter Assembly

• Plastic seal:

- Charging valve, with bleed-off and Gauge

- OD 20 mm (0.787 in)

- 199-9040 Hose

- ID 11.5 mm (0.453 in)

- 152-2024 Seal

- thickness 2.0 mm (0.079 in)

- Protective Case

• It is recommended that a 175-5507 Nitrogen

• Weight: 2.3 kg (5.0 lb)

Charging Group be connected between the

9U-7640 or 152-2023 Accumulator Charging

Group and the nitrogen bottle. This will allow

the pressure to be controlled and regulated.

See NEHS0598 Tool Operating Manual for

additional instructions.

Part Number

Description

152-2023

Accumulator Charging Group

Additional Tooling

Additional Tooling Required for Hydraulic Hammers

Item

Part Number

Description

7Q-8501

Adapter

7Q-8498

Adapter

7Q-8502

7Q-8499

Not Shown

2M-9780

Seal- O-ring-STOR(SAE 7/8- 14)

—

3K-0360

Seal- O-ring-STOR(SAE 3/4- 16)

7-168 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Nitrogen Adapter

Model Usage: MT735, MT745, MT765, MT835,

• Used to provide required connection between

• Used with 152-2023 Nitrogen Charge Kit

MT855, and MT865 GEN 111 Challenger Tractor

charging kit and accumulator

• Male M28 x 1.5 thd x female M16 x 2 thd

Warranty: Caterpillar ^®Six Months

Part Number

Description

209-2112

Nitrogen Adapter

Adapter

• Used to adapt threads of accumulator filling

• Hose from 175-5507 Nitrogen Charging Group

valve neck to 5P-2963 Adapter and 1S-8938

is then connected to fitting on 1S-8938 Chuck

Chuck

• 1/2 -20-2B thd x female 5/8 -18-2B thd

Item

Part Number

Description

1S-8938

AirChuck

4C-4321

Adapter (Includes 247-2708 Gasket)

094-1043

Accumulator

Gasket (part of 4C-4321 Adapter Group; also part of

247-2708

accumulator cap or available as separate part)

5P-2963

ChargingAdapter

Nitrogen Adapter Group

Essential Tool

• Used to connect nitrogen charging kits to

• Male M28 x 1.5-6g thd x female ISO 228-G

Leduc accumulators

3/4 thd

Model Usage: M313C, M315C, M316C, M318C,

M322C, M312C, M315, M318 and M320 Wheel

• Used with 9U-6740 or 152-2023 Accumulator

References

Excavators

Charging Group

• RENR6984

Warranty: Caterpillar ^®Six Months

• Connects to accumulators on feeder housing

• RENR6999

hydraulic system

Part Number

Description

185-4458

Nitrogen Adapter Group

Nipple Assembly

Essential Tool

• Used with 338-0500 Pressure Regulator and

• 1/4 inch NPT male end connects to 41,368 kPa

high pressure nitrogen gas bottle

(6000 PSI) pressure regulator CGA677 female

Model Usage: Cat^®Excavators and Track-Type

end connects to 41,368 kPa (6000 PSI) high

Tractors

• Durable stainless steel construction

pressure nitrogen gas bottle

Warranty: Caterpillar ^®Six Months

Part Number

Description

334-0802

Nipple Assembly

7-170 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Accumulator Piston Installer, Accumulator Seal Installer

Essential Tool

• Used to assemble piston into steering

• Seal installer makes seal installation onto

accumulator without damaging new seals

piston much easier and prevents damage

Model Usage: 797B Off Highway Truck

• Piston installer is placed into accumulator and

Warranty: Caterpillar ^®Six Months

Reference

piston is pressed through installer—

• SEPD0740-00

prevents seal damage by accumulator threads

247-3359

Part Number

Description

247-3359

Accumulator Piston Installer

247-3361

Accumulator Seal Installer

247-3361

Accumulator Tools for Hydraulic Hammer

Essential Tool

• Used with 121-6583 Accumulator Charging Kit Reference

Model Usage: PH 126 Hydraulic Hammer

• RENR6996, Hydraulic Hammer

• Disassembly and Assembly

Warranty: Caterpillar ^®Six Months

Part No.

Description

Use

281-2587

Spanner Wrench

Remove and install top cover of accumulator for servicing

282-8718

ChargingAdapter

Recharge nitrogen-filled accumulator

JULY 2018 Vehicle System Tools

7-171

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Strut Charging Cart / Nitrogen Fill Cart

Model Usage: LMT

• Tool group 520-1415 supplies all the loose

Reference

piece parts and service repair items (including

Warranty: See Individual Part Numbers

• SEHS9411 - Special Instruction for Servicing

but not limited to valves, gauges, adapters,

Suspension Cylinders

casters, pump and toolbox) needed to

fabricate FT3315 which is a dealer-fabricated

Specifications

mobile cart used to charge/adjust the entire

• Reservoir Capacity of Each Oil Tank Assembly

suspension system on large mining trucks in a

on Strut Charging Cart: 98 L (26 gal.)

timely manner.

• Hydraulic Pressure of Pump on Strut Charging

Cart: 8200 kPa (1200 psi) with 820 kPa (120

psi) air pressure

Part No.

Description

520-1415

Strut-Charging Cart Tool Group

Note: Images of FT3315 Dealer-

Fabricated Cart are for visual

reference only.

7-172 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Oil Refill Unit

Model Usage: 769, 773, 777, 785, 789, and 793

• Refills suspension cylinder with oil without

• Reservoir: 38 liters (10 gal)

Trucks

the need of circulating oil to remove trapped

• Hydraulic pressure: 8200 kPa (1200 PSI) with

nitrogen

Warranty: Caterpillar ^®Six Months

820 kPa (120 PSI) air pressure

• No need to evacuate old suspension cylinder

Reference

oil

• SEHS9411, Special Instruction, Suspension

• System will compress nitrogen remaining in

Cylinder Servicing

suspension cylinder oil

Part Number

Description

7S-5106

AirChuck

9U-5618

Bracket

9U-5619

Block

9U-5672

Barrel Assembly

9U-5675

Valve

9U-5676

Coupler

9U-5677

Nipple (Valved)

9U-5679

Strainer

9U-5680

CheckValve

9U-5682

Nipple

9U-5683

Coupler Valve

9U-5684

Breather

JULY 2018 Vehicle System Tools

7-173

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

H-Link Bore Rework Tools for Cushion Hitch Tractors-Scrapers

Model Usage: 621, 623, 627, 631, 633, 637, 641,

• Fabricated tools used with parts of 1P-4000

• Standard and oversized bushings available

651 and 657 Cushion Hitch Tractors-Scrapers

Line Boring Tool Group and other tools to

Reference

remove bushings, rebore, and install oversized

Warranty: Caterpillar ^®Six Months

bushings in H-Link bores in bracket and hitch

• SMHS6872, Special Instruction

castings of cushion hitch tractor-scrapers

Part Number

Description

Qty.

Remove

Rebore

Install

1P-1838

Adapter

1P-2344

Centering Ring

1P-2366

Holder Assembly a

5B-0637

Nut

5F-7353

Thrust Washer

5F-7366

Screw - Forcing

5P-1630

Drive Adapter a

5P-2981

Feed Assembly a

6V-3160

Cylinder Group

7F-5283

Head

8S-6587

Adapter,11/4in

a. Part of 1P-4000 Line Boring Tool Group

Strut Gauge

Model Usage: 785 and 789 Off-Highway Trucks

• Used to measure/check for proper oil/nitrogen

References

charge in front suspension cylinders

Warranty: Caterpillar ^®Six Months

• SENR4016; Service Manual; 785 Suspension

• Hold strut and spindle a specific distance

Cylinders, Systems Operation, Testing and

apart, 265 mm (10.43 in), during nitrogen

Adjusting

charging process (used with 175-5507

• SENR3436; Service Manual; 789 Suspension

Nitrogen Charging Group)

Cylinders, Systems Operation, Testing and

• Weight: 5.1 kg (11.2 lb)

Adjusting

Part Number

Description

1U-9364

Strut Gauge

Chain Clamp Assembly

Model Usage: Elevating Scraper

• Elevating scraper chain disassembly and

• Usable on the heaviest current elevator chain

assembly is simplified with the use of this

Warranty: Caterpillar ^®Six Months

Specifications

tool

• Chain clamp jaws width: 34.1 mm (1.38 in)

• Chain clamp jaws are applicable to the

narrowest elevator chain currently in the Cat^®

• Load capacity: 2 ton

products line

Part Number

Description

5P-2706

Chain Clamp Assembly

Service/Repair Parts

1A-1935

Nut

1B-7411

Nut

2J-3507

Nut

3K-8282

7-174 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Wear Gauge

Model Usage: TH350B (SLD1-Up), TH355B

• Used to measure chain elongation on

Reference

(JRK1-Up), TH360B (SLE1-Up), TH460B (SLF1-Up),

telescoping boom chain

• RENR5188-03; Service Manual; Testing and

TH560B (SLG1-Up)

Adjusting TH350B, TH355B, TH360B, TH460B

Warranty: Caterpillar ^®Six Months

and TH560B Telehandlers Hydraulic System

Part Number

Description

6V-0028

Wear Gauge

Hex Bit Sockets

Model Usage: General Usage and 5000 Series

• Used to remove and install metric socket head

• 129-4552 Hex Bit Socket replaces

Mining Excavators

cap screws from pumps

discontinued 1U-9475

Warranty: Caterpillar ^®Six Months

• Used with 3/4 inch and 1 inch drive ratchet

Reference

and breaker bar

• SENR6058, Service Manual

Part No.

Drive

Hex Size Bit

Max. Torque

Capscrew Size

3075 N·m

1U-9474

1in

22 mm

M30

(2275 ft-lb)

Adapter Assembly

Model Usage: 793 Off-Highway Trucks (4AR246-

• Removes/installs the six 7Y-5217 Socket Head

• Heat treated for added strength

UP, 4GZ, ATY, CBR)

Bolts used on rear suspension cylinder pins

• Equipped with retention pin to stay

(3/4 inch Square Drive x 17 mm Hex)

Warranty: Caterpillar ^®Six Months

engaged in square drive adapter

• Used with 162-8718 torque wrench and the

References

6V-4170 3/4 inch female square drive adapter

• 793 Off-Highway Truck Disassembly and

• Required to access bolts in confined area with

Assembly Manual, Rear Suspension Cylinder

limited clearance between bolt head and tire

Remove and Install

• Works on any 793 Off-Highway Truck starting

• SEPD0774, Service Magazine Article

with 4AR246, or any 793 Off-Highway Truck

earlier models that have been retrofitted with

the anti-rotation flag plate

Part Number

Description

251-8155

Adapter Assembly

Rotary Axle Pinion and Bevel Gear Tooling

Model Usage: RM350 Reclaimer/Mixer

Pinion Bevel Gear Tooling

• When completely assembled in differential

housing, tools provide stackup dimension of

Warranty: Caterpillar ^®Six Months

• Used to measure and align pinion to bevel

gear set and provide method to obtain shim

gear (1U-5847, 129-7156, 129-7157, and

pack measurement

129-1758)

• Tools are precisely machined to provide

correct and accurate assembly adjustment

using procedures provided in Service Manual

Item

Part Number

Description

129-7158

Measuring Pin

129-7157

Thrust Washer

129-7156

Shim

1U-5847

Measuring Shaft

JULY 2018 Vehicle System Tools

7-175

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Locknut Spanner Wrench

Model Usage: AP-1050, AP-1000 and AP-800C

• Used to quickly and easily remove and install

• Pilot also keeps wrench teeth engaged in

Asphalt Pavers

both 2H-3778 Spanner Nuts, the locknuts for

spanner nut when removing and installing

Extend-A-Mat^®B Screed extender sloper pivot

outer locknut (helps prevent slippage,

Warranty: Caterpillar ^®Six Months

pins (assembly requires an inner spanner nut,

resulting in damage to nut or injury to

star washer, and outer spanner locknut)

mechanic)

• Used with 3/4 inch square drive torque

Reference

wrench— torque specification for 2 nuts is

• KENR2527, Service Manual, Disassembly and

545 ± 25 N·m (400 ± 20 ft-lb)

Assembly

• Due to its location, nut is extremely difficult to

access using any other tooling

Specifications

• Outside diameter: 88.9 mm (3.50 in)

• Wrench uses an inner pilot to prevent it from

• Overall length: 76.2 mm (3.00 in)

slipping off during removal and installation

• Spanner teeth: 4, equally spaced

of inner spanner nut (makes removal and

• Tooth width: 6.0 mm (0.24 in)

installation much easier)

• Square drive: 3/4 in

• Wrench is heat-treated for improved durability

• Approximate weight: 2 kg (5 lb)

Part Number

Description

4C-9416

Locknut Spanner Wrench

Hitch Bearing Puller Adapters

Model Usage: See Below

Step Plate

Part Number

Thread Size

Use

Model

Diameter

Warranty: Caterpillar ^®Six Months

95.3 x 101.6 mm

Removal and installation of

631D, 633D and 637D

5P-7398

1.25 in-12 thd

(3.75 x 4.0 in)

hitch lateral pitch bushings

Tractor-Scrapers

108 x 121 mm

Removal and installation of

631D, 633D and 637D

5P-7399

1.25 in-12 thd

(4.25 x 4.75 in)

vertical hitch bearings

Scrapers

Removal and installation of

82.6 x 88.9 mm

621B, 623B and 627B

5P-8601

1.25 in-12 thd

appropriate size bushings

(3.25 x 3.50 in)

Scraper hitches

and bearings

Socket

Essential Tool

• Used to disassemble and assemble rear

• 3/4 inch square drive

horizontal hitch

Model Usage: TS220 Towed Scraper

• Welded steel construction

• 4 3/8 inch, 6-point socket

Warranty: Caterpillar ^®Six Months

• Not recommended for use with impact wrench

Part Number

Description

336-6457

Socket

Socket Wrench

Essential Tool

• Used to make removal and installation of

Specifications

081-6212 Nut faster and easier

Model Usage: RT80, RT100, TH82, TH83, and

• Outside diameter: 88.9 mm (3.50 in)

TH103 Telehandler

• Provides adequate length to engage nut

• Inside diameter: 76.2 mm (3.00 in)

• Overall length: 114.3 mm (4.50 in)

Warranty: Caterpillar ^®Six Months

• Socket pilots around nut for positive

• Cross hole diameter: 27.0 mm (1.06 in)

engagement

• Distance across flats: 65.52 mm (2.580 in)

• Cross hole provided for bar or handle

Part Number

Description

147-3508

Socket Wrench

7-176 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Spacer

Model Usage: D6D Tractor

• 5P-7321 Spacers and two plates needed for

• Required to tilt/install semi-modular cab

positioning dash on tractor when tilting or

Warranty: Caterpillar ^®Six Months

Reference

removing cab or when installing new cab

• SMHS7062, Special Instruction

Item

Part Number

Description

5P-7321

Spacer

1A-1460

Bolt (1/2 - 13) (fork mounting hardware)

Offset Wrench

Essential Tool

• Used to remove and install cab bolts without

• Durable welded construction

removing fuel tank

Model Usage: 140M and 160M Monarch Series

• 3/4 inch square drive x 36 mm, 12 point, box-

Motor Graders

• Reduces service time by eliminating fuel tank

end wrench

removal

Warranty: Caterpillar ^®Six Months

Reference

• Required to properly tighten cab bolts to

• Service Manual, 140M and 160M

required 635 N·m of torque during installation

Disassembly and Assembly

Part Number

Description

318-1491

Offset Wrench

Impact Socket

Essential Tool

• Removes/installs bolts securing cab support

• 1 inch square drive with 1 1/2 inch 6-point

assemblies (outriggers) to frame assembly

socket opening

Model Usage: 789A (9ZC1-UP), 789B (7EK1-UP),

and 789C (2BW1-UP) Off- Highway Trucks

• Used with 222-3054 impact wrench or other

Reference

similar tool

Warranty: Caterpillar ^®Six Months

• SEBE9071, Service Letter, Product

• 2-step outside dia provides required clearance

Improvement Program for Inspecting and/or

• Industrial finish prevents rust and corrosion

Replacing the Rear Cab Support on Certain

789 Off-Highway Trucks

Part Number

Description

258-5686

Impact Socket

Warranty: Caterpillar ^®Lifetime

• Socketfor tightening engine mount bolts in

OHT using 3500 and C175 engines

• Applications include repair of heavy duty

trucks and off-road equipment

Part Number

Description

432-8907

¾ Inch Drive 1-inch, Shallow, 12 Point , Black

JULY 2018 Vehicle System Tools

7-177

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Measuring Ring and Seal Driver

129-7159 Measuring Ring

• Driver ensures seal is installed to correct

depth (also ensures seal is installed exactly

• Used to determine thickness of shim required

perpendicular to shaft; eliminates cocked

for correct assembly of pinion input shaft

seals)

• No other measuring method will provide

• Eliminates seal damage which can be caused

results as fast and accurately as using this

during seal installation using conventional

tool

tooling

• Heat-treated for durability

129-7160 Seal Driver

References

• Used to install differential oil seal after pinion

and bevel gear have been assembled

• KENR2560, Service Manual KENR2573,

Service Manual

Item

Part Number

Description

129-7159

Measuring Ring

129-7160

Seal Driver

Bearing Nut Spanner Wrench

Model Usage: 988B

• Used to remove and install spanner nut which

retains bearing in implement pump drive on

Warranty: Caterpillar ^®Six Months

988B Wheel Loaders

Part Number

Description

5P-7323

Bearing Nut Spanner Wrench

Spanner Wrench Assembly

Model Usage: SE60 Screed Pavers

• Removes and installs bearing locknuts

• Used to remove and install the bearing

5P-8513 on the power sloper for SE60 screeds

locknut 5P-5813

Warranty: Caterpillar ^®Six Months

• Low profile spanner wrench

• ½ inch square drive ratchet

Part No.

Description

Dimensions

Weight

Spanner Wrench

92.25mm (3.6”) I.D., 4 equally spaced spanner teeth,

472-4269

1.23Kg (2.7lb)

Assembly

12.7mm (0.5”) length of ring to grip the locknut

7-178 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Pin Driver Caps

Essential Tool

• Used to protect linkage pins from damage

• Side holes in head allow pins to be installed

during installation

or removed using a spanner wrench

Model Usage: 345C, 365C, 385C Hydraulic

Excavators

• Longer thread engagement for thicker flag

Reference

pins

Warranty: Caterpillar ^®Six Months

• Disassembly and Assembly Service Manual

• Heat-treated for added durability

for 345C, 365C, and 385C

Part Number

Thread Size

Thread Length

276-8831

M30 x 3.5

51.1mm (2.01in)

276-8833

M36 x 4.0

58.5mm (2.30in)

276-8834

M48 x 5.0

71.5mm (2.81in)

Receiving Sleeves, Adapter Plates, Pin Driver Caps

Receiving Sleeves

Part

(A)MaximumPin

(B) Maximum Pin

Description

Number

Diameter

Length

Diameter

SleeveAssembly—

124-4640

254 mm (10in)

450mm(17.72in)

Receiving

124-4641

Sleeve - Receiving

263mm(10.35in)

216mm(8.50in)

Open end (9U-6501)

SleeveAssembly—

134-8466

200mm(7.87in)

1,322 mm (52.05 in)

68.0mm (2.68in)

Receiving

ReceivingSleeve

134-8470

160mm(6.30in)

Open end

(Accessories)

1M-6756

Sleeve Assembly

166mm(6.54in)

202mm(7.95in)

33.0mm (1.30in)

4C-8163

Sleeve Assembly

163mm(6.42in)

890mm(35.04in)

70.0mm (2.76in)

4C-9491

ReceivingSleeve

227mm(8.94in)

300mm(11.81in)

52.5mm (2.07in)

4C-9493

Sleeve

227mm(8.94in)

160mm(6.30in)

52.5mm (2.07in)

5P-7370

Sleeve Assembly

198mm(7.80in)

180mm(7.09in)

101.0 mm (3.98 in)

6V-2072

Sleeve Assembly

176mm(6.93in)

240mm(9.45in)

40.0mm (1.58in)

6V-2097

ReceivingSleeve

130mm(5.12in)

75mm (2.95in)

39.0mm (1.54in)

6V-2098

Sleeve

112mm(4.41in)

76mm (2.99in)

39.0mm (1.54in)

Open end

6V-2108

ReceivingSleeve

106mm(4.17in)

74mm (2.91in)

(129-6672)

Approx. 25.0 mm

6V-6982

Sleeve Assembly

28 mm (1.10 in) a

125 mm (4.92 in) a

(0.98 in)

7F-6068

Sleeve Assembly

100mm(3.94in)

215mm(8.46in)

Open end (5P-8713)

9S-5431

Sleeve Assembly

149mm(5.87in)

187mm(7.36in)

101.6 mm (4.00 in)

9S-5564

Sleeve Assembly

115mm(4.53in)

431mm(16.97in)

33.0mm (1.30in)

9S-5565

Sleeve Assembly

74mm (2.91in)

355mm(13.98in)

33.0mm (1.30in)

Receiver Sleeve

9U-5671

36mm (1.42in)

98mm (3.86in)

Open end

Adapter b

Puller Assembly

9U-6706

182mm(7.17in)

438mm(17.24in)

83.0mm (3.27in)

(Cylinder Pins)

9U-6792

Puller Assembly - Pin

201mm(7.91in)

1,825 mm (71.85 in)

83.0mm (3.27in)

9U-7765

ReceivingSleeve

284mm(11.18in)

762 mm (30in)

Open end (9U-6501)

a. Approximate Size.

b. 9U-5671 Sleeve 36.0 mm (1.42 in) 98.0 mm (3.86 in) Open end.

JULY 2018 Vehicle System Tools

7-179

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Receiving Flag Sleeves

Maximum Pin

Stud Hole

Flag Clearance

Part Number

Description

Diameter

Length

Diameter

Size

Receiving

214.0 mm

1143.0 mm

70.0 mm

164.0 mm

9U-6752

Sleeve

(8.43 in)

(45.00 in)

(2.76 in)

(6.46 in)

Maximum Pin

Stud Hole

Flag Clearance

Part Number

Description

Diameter

Length

Diameter

Size

Sleeve

305 mm

68.0 mm

135.0 mm

137-8792

Assembly -

238mm(9.37in)

(12.01 in)

(2.68 in)

(5.31 in)

Bearing

Sleeve

1,140 mm

68.0 mm

146.0 mm

141-1785

Assembly -

144mm(5.67in)

(44.88 in)

(2.68 in)

(5.75 in)

Receiving

Sleeve Group

313 mm

1,473.8 mm

68.0 mm

234.0 mm

155-8191

(992G)

(12.32 in)

(58.02 in)

(2.68 in)

(9.21 in)

Receiving

247.7 mm

545 mm

68.0 mm

165.0 mm

237-9180

Sleeve

(9.75 in)

(21.46 in)

(2.68 in)

(6.50 in)

Assembly

Sleeve

812 mm

36.0 mm

152.0 mm

287-2153

152mm(5.98in)

Assembly

(31.97 in)

(1.40 in)

(6.00 in)

Sleeve

298 mm

660 mm

70.0 mm

203.2 mm

323-7335

Assembly

(11.73 in)

(25.98 in)

(2.76 in)

(8.00 in)

Sleeve

298 mm

660 mm

70.0 mm

203.2 mm

4C-8149

Assembly

(11.73 in)

(25.98 in)

(2.76 in)

(8.00 in)

Sleeve

419 mm

32.5 mm

95.0 mm

5P-7288

Assembly, 215

106mm(4.17in)

(16.50 in)

(1.28 in)

(3.74 in)

Excavator

Sleeve

35.0 mm

118.57 mm

6V-4035

125mm(4.92in)

250mm(9.84in)

Assembly

(1.38 in)

(4.67 in)

Sleeve

42.5 mm

17.5 mm

28.0 mm

8T-3198

190mm(7.48in)

Assembly

(1.67 in)

(0.69 in)

(1.10 in)

150.9 mm

158.8 mm

147.3 mm

9S-5433

Puller Adapter

Open end

(5.94 in)

(6.25 in)

(5.80 in)

Sleeve

415 mm

35.0 mm

138.6 mm

9U-5266

125mm(4.92in)

Assembly

(16.34 in)

(1.38 in)

(5.46 in)

Receiver

300 mm

138.6 mm

9U-5340

125mm(4.92in)

Open end

Sleeve

(11.81 in)

(5.46 in)

Sleeve

330 mm

52.0 mm

164.0 mm

9U-6751

214mm(8.43in)

Assembly

(12.99 in)

(2.05 in)

(6.46 in)

Sleeve

52.0 mm

164.0 mm

9U-6752

214mm(8.43in)

1,143mm (45in)

Assembly

(2.05 in)

(6.46 in)

Pin Driver Cap Specifications

Part Number

Description

Thread Size

Head Diameter

Thread Length

276-8831

Pin Driver Caps

M30 x 3.5

63.5mm (2.50in)

51.1mm (2.01in)

276-8833

Pin Driver Caps

M36 x 4.0

88.9mm (3.50in)

58.5mm (2.30in)

276-8834

Pin Driver Caps

M48 x 5.0

101.6mm (4in)

71.5mm (2.81in)

4C-9485

Pin Driver Caps

M30 x 3.5

63.5mm (2.50in)

29.5mm (1.16in)

9S-5561

Pin Driver Caps

1 1/2-12

88.9mm (3.50in)

35.8mm (1.41in)

9S-5562

Pin Driver Caps

1 1/4-12

63.5mm (2.50in)

29.5mm (1.16in)

9S-5563

Pin Driver Caps

1-14

50.8 mm (2 in)

23.1mm (0.91in)

9U-5342

Pin Driver Caps

M24 x 3.0

50.8 mm (2 in)

31.8mm (1.25in)

9U-6225

Pin Driver Caps

M36 x 4.0

88.9mm (3.50in)

38.6mm (1.52in)

Pin Driver Cap

9U-6758

M48 x 5.0

101.6mm (4in)

51.6mm (2.03in)

(installation only)

7-180 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Adapter Plates

Part Number

Description

Maximum Pin Diameter

124-4637

Adapter Plate

102mm(4.02in)

9U-5341

Adapter Plate Assembly

104mm(4.09in)

9U-6501

Plate - Head Puller

276mm(10.87in)

9U-6755

Adapter Plates

235mm(9.25in)

Adapter Flag Plates

Part Number

Description

Maximum Pin Diameter

Flag Clearance Size

162-7189

AdapterGroup-Plate

93mm (3.66in)

192-5510

Adapter Plate

260mm(10.24in)

234.0 mm (9.21 in)

1U-6150

Adapter Plates

156mm(6.14in)

130.0 mm (5.12 in)

9U-6754

Adapter Plates

187mm(7.36in)

130.0 mm (5.12 in)

9U-6757

Adapter Plates

196mm(7.72in)

164.0 mm (6.46 in)

Receiving Sleeves with Adapters

Adapter Plate Part No.

Used with Receiving Sleeve Part No.

124-4637

124-4640, 124-4641

154-7387

9U-6751, 9U-6752

192-5510

155-8191

1U-6150

9U-6751, 9U-6752

9U-5341

9U-5266

9U-6501

9U-7765

9U-6754

9U-6751, 9U-6752

9U-6755

9U-6751, 9U-6752

9U-6757

9U-6752

Linkage Pin and Bearing Removal Tools

Model Usage: 5110 Excavator

• Used to remove all linkage pins and bearings

• Used with general tooling listed in “General

Tooling Used for All Pins”

Warranty: Caterpillar ^®Six Months

• Receiving sleeve assembly is easily

suspended with lifting link brackets (supplied

• Only 1 receiving sleeve is required for this

with receiving sleeve)

operation (sleeve is adapted for other pin

diameters by using appropriate receiving

sleeve adapter assembly)

Items with no Part Number

Item

Description

Linkage Pin

Item

Part Number

Description

1 a

134-8466

Sleeve Assembly - Receiving

316-1491

Cylinder Group (100T) 6 in stroke

136-5747

Stud-Puller (M48x 5)

9U-6810

Nut - Fast Runner (M48 x 5.0)

General Tooling Used for All Pins

350-7768

Pump Group-Hydraulic (115V)

—

6D-7726

Hydraulic Hose (2)

—

350-7769

Pump Grp - Hydraulic (230V)

a. Item 1 and 2

JULY 2018 Vehicle System Tools

7-181

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Typical Pin Locations

Item

Description

Cylinder pin

Stick-to-Boom Pin

Bucket Pin

Bucket Linkage Pin

Boom-to-Swing Frame Pin

Cylinder Pin

Bucket Linkage Pin

Included in Pin Specific tooling:

Hydraulic Cylinder (150 ton), used with Pin No. 2, No. 3, No. 4, and No. 6

Pin-Specific Tooling

Part Number

Description

Pin No. 1

316-1491

Cylinder Group (100T) 6 in stroke

9U-6810

Nut - Fast Runner (M48 x 5.0)

9U-6814

Stud-Puller (M48x 5)

Pin No. 2

134-8466

Sleeve Assembly - Receiving

134-8470

Receiving Sleeve (Accessories)

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Pin No. 3

134-8466

Sleeve Assembly - Receiving

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Pin No. 4

134-8466

Sleeve Assembly - Receiving

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Pin No. 5

134-8466

Sleeve Assembly - Receiving

136-5747

Stud-Puller (M48x 5)

316-1491

Cylinder Group (100T) 6 in stroke

9U-6810

Nut - Fast Runner (M48 x 5.0)

Pin No. 6

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Pin No. 7

136-5747

Stud-Puller (M48x 5)

316-1491

Cylinder Group (100T) 6 in stroke

9U-6810

Nut - Fast Runner (M48 x 5.0)

9U-6814

Stud-Puller (M48x 5)

Pin No. 8

134-8466

Sleeve Assembly - Receiving

136-5747

Stud-Puller (M48x 5)

316-1491

Cylinder Group (100T) 6 in stroke

9U-6810

Nut - Fast Runner (M48 x 5.0)

Maximum Pin

Maximum

Thread

Part No.

Description

Use

Diameter

Length

Rod Diameter

Capacity (Tons)

Size

Length

As a receiving sleeve for

SleeveAssembly—

134-8466

200mm(7.87in)

1,322mm (52in)

64 mm (2.5 in)

136 t (150 ton)

alllong pins on vehicle. By

Receiving

itself for boom-to-stick pin

ReceivingSleeve

With 134-8466 to accept a

134-8470

160mm(6.30in)

136 t (150 ton)

(Accessories)

160 mm(6.3in) diameter pin

136-5747

Stud-Puller (M48x 5)

2,415 mm (95.1 in)

M48 x 5

2415mm(8 ft)

7-182 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Adapter Plate and Receiving Sleeve Assembly

Essential Tool

• Used to remove boom to frame pin, stick to

• Adapter plates attach to 155-8191 Receiving

boom pin, bucket to stick pin, and all related

Sleeves allowing the removal of smaller

Model Usage: 5110B Excavator

hydraulic cylinder mounting pins

diameter linkage pins with larger diameter

Warranty: Caterpillar®Six Months

receiving sleeves, thus eliminating the need

Used with 350-7768 Hydraulic Pump

•

for many additional sleeves.

(115 VAC) or 350-7769 Hydraulic Pump

(230 VAC) and 6D-7726 Hydraulic Hose

Maximum Pin

Item

Part Number

Description

Maximum Capacity

Diameter

192-5510

Adapter Plate

260mm(10.2in)

150 tons

Item

Description

Receiving Sleeve Assembly

Adapter Plate

Linkage Pin

Hydraulic Cylinder

Puller Stud

Fast Runner Nut

Retaining Plate

Rod

Nut

Socket Head Bolt

Washer

Front Strut Bearing Seal Installation Tools

Model Usage: 735, 735B, 740, 740 Ejector, 740B,

• Used to install front suspension cylinder seals

• 456-9452 (#6 Nylon) supports the seal during

740B Ejector

installation

• 456-9453 (#6 Nylon) is used to initially place

Warranty: Caterpillar ^®Six Months

the seals. It is also used with 456-9450 (steel)

• 456-9451 (#6 Nylon) is used as a guide during

456-9453 (#6 Nylon) as the driver

the seal installation process

Part Number

Dimensions

Weight

456-9450

24 X 100 mm (0.9 X 3.9in)

0.307 kg (0.7lb)

456-9451

88 X 74 mm (3.5 X 2.9 in)

0.535 kg (1.2lb)

456-9452

78 X 88 mm (3.1 X 3.5 in)

0.467 kg (1.0lb)

456-9450

456-9453

69 X 150 mm (2.7 x 5.9in)

0.759 kg (1.7lb)

456-9451

456-9452

456-9453

JULY 2018 Vehicle System Tools

7-183

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Pin Specific Tooling No. 1-5 (Continued)

Part Number

Description

Qty.

Pin No. 1

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6800

Nut - Speed (M64)

Pin No. 2

316-1491

Cylinder Group (100T) 6 in stroke

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6815

Puller Stud (M48) 62 in

9U-6903

Nut - Speed (M48)

Pin No. 3

192-5510

Adapter Plate

316-1491

Cylinder Group (100T) 6 in stroke

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6815

Puller Stud (M48) 62 in

9U-6903

Nut - Speed (M48)

Pin No. 4

155-8191

Sleeve Group (992G)

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6702

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Pin No. 5

155-8191

Sleeve Group (992G)

192-5510

Adapter Plate

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6702

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

7-184 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Pin Specific Tooling No. 6-11

Part Number

Description

Qty.

Pin No. 6

192-5510

Adapter Plate

316-1491

Cylinder Group (100T) 6 in stroke

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6815

Puller Stud (M48) 62 in

9U-6903

Nut - Speed (M48)

Pin No. 7

192-5510

Adapter Plate

316-1491

Cylinder Group (100T) 6 in stroke

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6815

Puller Stud (M48) 62 in

9U-6903

Nut - Speed (M48)

Pin No. 8

155-8191

Sleeve Group (992G)

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6702

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Pin No. 9

155-8191

Sleeve Group (992G)

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6702

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Pin No. 10

136-5747

Stud-Puller (M48x 5)

155-8191

Sleeve Group (992G)

316-1491

Cylinder Group (100T) 6 in stroke

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6903

Nut - Speed (M48)

Pin No. 11

155-8191

Sleeve Group (992G)

4C-8152

Retaining Plate

8T-0271

Bolt - Hex Socket Head (M10 x 1.5)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6702

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

JULY 2018 Vehicle System Tools

7-185

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Linkage Bearing Locations (Continued)

Removal Tooling

Part Number

Description

Qty.

Bearing No. 8

137-8792

Sleeve Assembly - Bearing

197-6682

Bearing Puller Adapter

4C-8152

Retaining Plate

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6800

Nut - Speed (M64)

Bearing No. 10

137-8792

Sleeve Assembly - Bearing

138-1135

Bearing Puller Plate

4C-8152

Retaining Plate

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6800

Nut - Speed (M64)

Bearing No. 11

197-6683

Bearing Puller Adapter

316-1491

Cylinder Group (100T) 6 in stroke

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6751

Sleeve Assembly

9U-6753

Retaining Plate

9U-6815

Puller Stud (M48) 62 in

9U-6903

Nut - Speed (M48)

7-186 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Installation Tooling

Part Number

Description

Qty.

Bearing No. 1, 5, 9, and 10

138-1135

Bearing Puller Plate

197-6685

Bearing Installer Plate

4C-6504

Puller Stud (M64) 48 in

9U-6800

Nut - Speed (M64)

Bearing No. 2 and 3

197-6681

Bearing Puller Adapter

197-6687

Bearing Installer Plate

9U-6800

Nut - Speed (M64)

Bearing No. 4

197-6685

Bearing Installer Plate

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Bearing No. 6

197-6687

Bearing Installer Plate

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Bearing No. 7 and 8

197-6686

Bearing Installer Plate

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Bearing No. 11

197-6687

Bearing Installer Plate

4C-8150

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

Block Assemblies

Model Usage: 621B, 623B, 627B, 631D, 633D

• Used for supporting hitch when separating

• Blocks tapped for 3/4 inch-10 bolts which are

and 637D Tractors

tractor from scraper

adjusted out against hitch to support it firmly

Warranty: Caterpillar ^®Six Months

• Two blocks required, one for each hitch stop

on tractor differential case

Part Number

Description

2G-2827

Block Assemblies

Support Stand Assembly

Essential Tool

• Used to support upper structure of machine

during removal and installation of forward tilt

Model Usage: TK722 (TKC1-UP and 1031-UP);

cylinder

TK732 (T1041-UP); TK752 (3021-UP) Track Feller

Buncher

Part Number

Description

245-9130

Support Stand Assembly

Warranty: Caterpillar ^®Six Months

JULY 2018 Vehicle System Tools

7-187

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Main Frame Assembly Tools (994)

Model Usage: 994 Wheel Loader

• Used in assembly of 994 Wheel Loader main

• Align and hold 994 center hitch pin bores prior

frames

to pin installation

Warranty: Caterpillar ^®Six Months

• Bore alignment very important but difficult

Reference

because of large pin size, close tolerances,

• SEHS9272, Special Instruction, 994 Field

mass of 2 loader frames, speed required to

AssemblyInstructions

install cold (shrunk) pins before they warm

and expand

• SENR4755, Service Manual, 994 Vehicle

Systems Disassembly and Assembly Module

Item

Part Number

Description

Dimensions

Weight

236 mm (9.3 in) diameter

9U-5234

Collet Assembly

89 kg (196.21lb)

670mm(26.4in)long

750 x 174 x 178 mm

9U-5235

Fixture Assembly

22.7 kg (50.04lb)

(29.5 x 6.9 x 7 in)

Pin Collet Assembly and Fixture Assembly

Model Usage: 994K Wheel Loader

Warranty: Caterpillar ^®Six Months

• Used to aid in the assembly of the hitch pins

on the new 994K Wheel Loader by providing

initial alignment tool for both upper joint and

460-0955

441-8318

lower joint

Reference

Part Number

441-8318

460-0955

994K Main Frame Assembly Tools

Length

738mm(29.1in)

991 mm (39in)

Diameter

225mm (8.9in)

Width

388mm(15.3in)

Height

256mm(10.1in)

Weight

70 kg (154.3lb)

59 kg (130.1lb)

7-188 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Hitch Pin Pulling Tools (994)

Model Usage: 994 Wheel Loader

• Used to pull hitch pin or pull any pin with

9U-6489 Eyebolt (with shoulder)

a 2 inch-12 puller hole - saves time and

Warranty: Caterpillar ^®Six Months

• Provides quick and convenient lifting point

eliminates destruction of pin

•

Used for general lifting applications of

• Used with 8T-7781 Nut

14,755 kg (32,500 lb) or less [upper hitch pin

• Hydraulic removal of pin is preferred over

weighs 116 kg (255 lb) and lower hitch pin

other methods, such as burning, cutting, or

185 kg (407 lb)]

drilling

9U-6501 Plate

• 2 inch stud provides a maximum 1335 kN

• Heat treated to Rockwell C32-38

(150 tons) hydraulic pulling force

• 2-step diameter centers plate on end of

• 38.1 mm (1 1/2 in) stud provides a maximum

different ID receiving sleeves

890 kN (100 tons) of hydraulic pulling force

9U-6698 Puller Stud

• Most 994 hitch pin pulling operations require

the maximum force provided by these tools

• Used for any general pulling application

requiring 1 1/2 inch-12 threads

9U-7763 Puller Stud

• Rolled threads and heat treatment for added

strength

• Provides pulling capacity up to 890 kN (100

• Provides pulling capacity up to 1335 kN

tons)

(150 tons)

References

• Course threads, on cylinder end of stud,

provide for faster nut running during pulling

• SENR4755, Disassembly and Assembly, 994

Wheel Loader Vehicle Systems

9U-7764 Bushing

• Procedurefor 994Front Frame Replacement

• Used to reduce 63.5 mm (2.5 in) center hole

from Decatur Mining Vehicle Center (M.V.C.)

of cylinder to 51 mm (2.0 in) diameter for

9U-7763 Stud

• Heat treated for additional strength

Item

Part Number

Description

9U-6698

Stud—Puller, 1 1/2in

9U-7763

Stud - Puller, 2 in

9U-6489

Shoulder Eye Bolt

JULY 2018 Vehicle System Tools

7-189

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Assembly Diagram for 994 Hitch Pin Pulling Tools

Item

Description

Hitch Pin

Hitch Pin Bushing

Item

Part Number

Description

8T-7781

Nut

9U-7764

Bushing

9U-6501

Plate - Head Puller

9U-7765

ReceivingSleeve

9U-7763

Stud - Puller, 2 in

Tool Specifications for 994 Hitch Pin

• 9U-7763 Puller Stud

Pulling Tools

- Overall length: 1220 mm (48.0 in)

- Short end thread: 2 in-12 thd (rolled)

• 9U-6489 Shoulder Eyebolt

- Length: 101 mm (4.0 in)

- Thread: 2 in-12 thd

- Long end thread: 2 in-8 (rolled)

- Length from bottom of shoulder to end of

- Length: 1016 mm (40.0 in)

thread: 51 mm (2.0 in)

- Heat treatment: Rockwell C41-45

- Capacity: 14,755 kg (32,500 lb)

- Pulling capacity (force): 1335 kN (150 tons)

- Eye diameter: 82.6 mm (3.25 in)

• 9U-7764 Bushing

• 9U-6501 Plate

- Outside diameter: 62.0 mm (2.44 in)

- Overall diameter: 305 mm (12.0 in)

- Inside diameter: 52.3 mm (2.06 in)

- Thickness: 38 mm (1.5 in)

- Center hole diameter: 53 mm (2.1 in)

• 9U-7765 Receiving Sleeve

- Heat treatment: Rockwell C32-38

- Outside diameter: 305 mm (12.0 in)

- Large step diameter: 276 mm (10.9 in)

- Inside diameter: 285 mm (11.2 in)

- Small step diameter: 201.5 mm (7.93 in)

- Overall length: 762 mm (30.0 in)

- Rated Pulling Capacity: 1335 kN (150 tons)

- Lifting eyes: 2

- Rated pulling capacity: 1335 kN (150 tons)

• 9U-6698 Puller Stud

- Threads: 1 1/2 in-12 thd (rolled)

- Thread length: 1220 mm (48.0 in)

- Pulling capacity (force): 890 kN (100 tons)

- Heat treatment: Rockwell C41-45

7-190 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Pin Pulling Tools, 990 Articulation Hitch

Model Usage: 990 Wheel Loader

• Used to pull articulation hitch pins and

124-4638 Bearing Puller Plate

bearings - saves time and eliminates

Warranty: Caterpillar ^®Six Months

• Used to remove the top articulation hitch pin

damage to pin

bearing

• Used with 316-1491 and 9U-6810 Speed Nut

124-4639 Bearing Puller Plate

• Hydraulic removal of pin is preferred over

• Used to remove the bottom articulation hitch

other methods, such as burning, cutting, or

pin bearing

drilling

124-4640 Receiving Sleeve Assembly

• M48 threads provide a maximum of 890 kN

(100 tons) of hydraulic pulling force

• Used to remove the top and bottom

articulation hitch pins

• All plates and sleeves serviced separately

124-4641Receiving Sleeve

464-4637 Adapter Plate

• Used to remove the top and bottom

• Used to remove 4E-8152 Top Hitch Pin on

articulation hitch pin bearings

early 990s (no puller hole for removing the pin

hydraulically)

• Later models, with pin puller hole, do not

require this adapter plate

Recess/Inside

Overall

Outside

Puller Hole

Rated

Overall

Item

Part No.

Description

Thickness

Diameter

Thread

Capacity

Length

177.8 mm

76.2 mm

890 kN

124-4637

Adapter Plate

M48 X 5

(7.00 in)

(3.00 in)

(100tons)

Bearing Puller Plate

214 mm

251 mm

124-4638

38 mm (1.5 in)

M48 X 5

(upper bearing)

(8.43 in)

(9.88 in)

Bearing Puller Plate

174.0 mm

193.5 mm

124-4639

38 mm (1.5 in)

M48 X 5

(lower bearing)

(6.85 in)

(7.62 in)

SleeveAssembly—

279.4 mm

890 kN

450 mm

124-4640

Receiving

(11.00 in)

(100tons)

(17.7 in)

Open end

279.4 mm

890 kN

216 mm

124-4641

Sleeve - Receiving

(9U-6501)

(11.00 in)

(100tons)

(8.5in)

Sleeve Assembly

Model Usage: 993K Wheel Loader

• Used to remove lower articulation flagged

Reference

hitch pin

Warranty: Caterpillar ^®Six Months

• KENR5832, 993K Wheel Loader Machine

• Used with 316-1491 or 6V-0014 Hydraulic

Systems, Disassembly and Assembly, Loader

Cylinder Group, 350-7768 Electric Hydraulic

Frame from Rear Frame - Separate

Pump Group, 9U-6815 Puller Stud, and

Specifications

9U-6810 Speed Nut

• Inside diameter: 298 mm (11.73 in)

• Hydraulic removal of pin is preferred over

other methods, such as burning, cutting, or

• Overall length: 736 mm (28.98 in)

drilling

• Flag opening: 220 mm (8.66 in)

• Heat-treated for added durability

• Hole for threaded rod: 70 mm (2.76 in)

Part Number

Description

332-7591

Sleeve Assembly

JULY 2018 Vehicle System Tools

7-191

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Bearing Puller Plate

Model Usage: 950G and 962G Series II, 950H,

• Used to remove both bearing cups and cones

Specifications

950K II, 962H, 962K II, IT62H

from lower and upper hitch articulation joints

• Threaded hole: M24 x 3.0

Warranty: Caterpillar ^®Six Months

• Used with 6V-3160 Double Acting Hydraulic

• Maximum pulling force: 267 kN (30 tons)

Cylinder and 9U-5345 Fast Runner Nut

• Outside diameter (428-9314): 136.0 mm

Assembly (M24 x 3.0)

(5.35 in)

• Use 428-9314 for lower hitch articulation joint

• Outside diameter (428-9315): 106.0 mm

and 428-9315 for upper joint

(4.17 in)

• Hydraulic removal of bearings is preferred

over other methods, such as burning, cutting,

or drilling

Part Number

Description

428-9314

Bearing Puller Plate

428-9315

Bearing Puller Plate

Tools for Tightening Horizontal Hitch Pins

Model Usage: 631, 633, 637, 641, 651, 657, 660

• Used with 2P-8285 Arm, 2P-8286 Drive

• 5P-1663 Extension Wrench discontinued and

and 666 Tractor-Scrapers

Adapter, 7S-4135 Torque Multiplier, 2P-0853

replaced by 5P-1661 Wrench

Ratchet Adapter, and 9S-7351 Torque Wrench

Warranty: Caterpillar ^®Six Months

to remove and install horizontal hitch pins

Item

Part Number

Description

Size

5P-1661

Sledge Wrench

4 1/4 in

5P-1662

Socket

4 1/4 in

Ratchet Wrench

Model Usage: AP500F

• Allows for manual extender height adjustment

• Ratcheting Box End with open end wrench to

of the SE50 Screed

fit in space constrained area

Warranty: Caterpillar ^®Six Months

• Fits 27mm hex

Part Number

Description

5P-1661

Ratchet Wrench

Puller Plate

Model Usage: See below

• Used with hydraulic cylinder of 55 tons or less

Reference

capacity to remove tubes and glands in truck

Warranty: Caterpillar ^®Six Months

• Service Magazine, January 19, 1981

front suspension groups

Part Number

Model

6V-3141

776 Tractors and 777 Trucks

6V-3142

768 and 772 Tractors and 769 and 773 Trucks

7-192 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Front Suspension Forcing Plates

Model Usage: 735 and 740 Articulated Trucks

• Used to separate front suspension “A-frame”

• Threaded hole: 1 1/2-12

from main frame assembly at lower hitch pin

Warranty: Caterpillar ^®Six Months

Reference

• Used with 5P-5264 Forcing Bolt (sold

• RENR5140, Service Manual, Front Suspension

separately)

Remove and Install, Disassembly and

• Reduces damage to front suspension and

Assembly Machine Systems

main frame/hitch pin

• Precision machined and heat-treated for long

durability

Part Number

Description

Used On

Serial No. used with

older 735 and 740 Articulated

217-5919

Forcing Plate

AWR and AXM

Trucks

new735and740Articulated

B1N00959-up, B1P02709-up, and

439-2598

Forcing Plate

Trucks

B1R00360-up

Puller Plate, Bar Assembly

Model Usage: 768, 769, 772, 773’s, 776 and 777

• Used to separate front suspension struts from

• Two 6V-6178 Plates and four 6V-6179 Bar

steer axle spindles on all Cat^®off-highway

Assemblies used with Cylinder Group to

Warranty: Caterpillar ^®Six Months

trucks and tractors; tools for this operation

provide heavy-duty tool arrangement with

cannot be used on all vehicles

16.5 kN (150 tons) capacity

• Eight 1D-4635 Bolts needed when used on

768, 769, 772 and 773s; four 3R-2299 Bolts

needed when used on 776 and 777s

Part Number

Description

6V-6178

Puller Plate

6V-6179

Bar Assembly

Pin Puller 2000™

Model Usage: 793F and 797F OHTs

• Tool is wedged between rear suspension

• Once pin is pulled, there is no need to remove

cylinder and pilots off the opposite pin bore

pin puller from machine. Simply replace

Warranty: Caterpillar ^®Six Months

suspension cylinder and install pins. Turn the

• Uses 25T cylinder pack to pull suspension pins

pin puller around and perform same task on

opposite side.

Part No.

Description

Dimensions

Weight

464-8536

Pin Puller 2000™

1436.1 x 521.6 x 270 mm (56.5 x 20.5 x 10.6 inch)

121 kg (266.2 lbs)

Attachments

464-8537

793F

Includes adapters for both ends of pin puller and rear suspension pin

464-8538

797F

JULY 2018 Vehicle System Tools

7-193

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Separation Group

Essential Tool

• Used to separate spindle/hub assembly from

• Bottom plate includes a V-shaped retainer

suspension cylinder rod

plate for positioning and holding hydraulic

Model Usage: 769D (BBB00069-UP), 771D

cylinder during use

(BCA00071-UP), 773D, 773E (BDA00073-UP),

• Used with dealer supplied 350-7768 Electric

775D, 775E (BEC00075-UP) Off-Highway Trucks

Hydraulic Pump (115 V) or 350-7769 Electric

References

Hydraulic Pump (230 V), 1U-5197 Hydraulic

Warranty: Caterpillar ^®Six Months

• NEHS0975 Tool Operating Manual; Using

Cylinder (80 Ton Capacity), and two 8F-0024

291-4194 Separation Group to Separate Front

High-Pressure Hoses or 6D-7726 High-

Spindle/Hub From Suspension Cylinder Rod

Pressure Hoses

• SENR1422; 769D, 771D Disassembly and

• Separation group consists of 2 interlocking

Assembly, Front Suspension Cylinders

top plates with bolts and nuts, a bottom plate,

and 2 threaded rod assemblies with nuts and

• SENR1584; 773D, 773E, 775D, and 775E

washers

Disassembly and Assembly, Front Wheel,

Bearing and Dual Cone Seal - Remove

• Procedure can be done with components on or

off-vehicle

Description

Qty.

Weight

Top plate

27 kg (50 lb)

Bottom plate assembly

34 kg (75 lb)

Rod assembly

16 kg (35 lb)

Hydraulic cylinder

29 kg (63 lb)

Separation Group Parts

Unnumbered Part

Item

Description

Qty

Washer

Item

Part Number

Description

Qty.

291-4196

Top Plate Assembly

9X-2475

M20 x 2.5 Bolt

8T-3282

Washer - Hard

6V-7742

Nut - Full

291-4195

RodAssembly

8C-7328

M48 x 5 Nut

291-4197

Bottom Plate Assembly

Not shown

224-0554

Warning Film

7-194 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Puller for 789

Model Usage: 789

• Used to separate front axle (spindle) from its

• Capacity: 6470 kN (727 Ton-Force) for

suspension cylinder strut (similar to 8T-2852

separating strut and spindle connection

Warranty: Caterpillar ^®Six Months

Puller for 785 Off-Highway Trucks)

Reference

• Used with 8T-2853 Handle Assembly

• SENR3404, 789 Truck Vehicle System

(2 required) to position puller on bottom of

Disassembly and Assembly Manual

front axle

• Support front axle before removing bolts that

• Puller weight: 58.7 kg (129 lb)

hold 5T-6303 Plate in position.

Part Number

Description

8T-9205

Puller for 789

To avoid possible personal injury from sudden release of the axle from the strut rod or the snapping of a bolt when removing the plate, loosen all bolts in a

circular pattern one-half turn. Do this again and again until the torque for the bolts is released.

Front Strut Handling Group

Essential Tool

European Union compliant, CE marked

References

Model Usage: 769 through 793 Construction

• Used to remove, disassemble, assemble, and

• SENR2944 (769C), Service Manual

Mining Trucks (CMT)

install front strut

• SENR2964 (773B), Service Manual

• SENR5616 (777C), Service Manual

Warranty: Caterpillar ^®Six Months

• Provides safe and efficient removal and

• SENR5678 (785B), Service Manual

installation without removing truck fenders

• SENR5687 (789B), Service Manual

• Canbe used as a platform for disassembly

• SENR5692 (793B), Service Manual

and assembly

Specifications

• Must be matched with appropriate size forklift

• Working load limit: 6,652 kg (14,667 lb)

to handle weight of front strut

• Inside dimension of fork spread: 105 cm

(41.5 in)

Part Number

Description

148-0357

Front Strut Handling Group

Group Includes:

457-5050

Supporting Bracket Group

1D-4709

Hex Head Bolt

5P-8250

Hard Washer

Tool Group (Support Brackets)

Model Usage: 769 through 793 Construction

• 457-6050 Tool Group (Support Brackets) is

• 457-6048 and 457-6049 are not serviced

Mining Trucks (CMT)

used to repair 148-0357 Tool Group (Front

separately

Strut)

Warranty: Caterpillar ^®Six Months

Part Number

Dimensions

Weight

457-6048

794 x 546 mm (31.3 x 21.5 in)

185mm (7.3in)

457-6049

794 x 546 mm (31.3 x 21.5 in)

40 mm (1.6 in)

457-6050

6.4 kg (14.1 lb)

JULY 2018 Vehicle System Tools

7-195

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Cutter Bit Removal Tooling

Model Usage: PR1000, PR750, PR450, PM565

• Used to remove cutter bits on Cat^®rotary

• Air hammer can be operated from machines

Pavement Profilers; RR/SS250 and RM/SM350

mills (cold planers) and other similar

air system eliminating need for service truck

Road Reclaimer/Soil Stabilizer

equipment

when changing cutters

Warranty: Caterpillar ^®Six Months

• 104-8591 Hammer Punch and 8T-4474 Bit

• Air hammer tools will work on

Puller are direct replacement parts for original

CP-4447-RUTAB or CP-717 Chicago Pneumatic

equipment tools

air hammers

• Using an air hammer and air hammer punches

(8T-4060 and 8T-4340) makes cutter removal

even easier and faster

Item

Part Number

Description

5P-8998

Nipple - Pipe

5R-5561

Nipple Assembly

9N-9094

Air Hose Assembly

104-8591

Hammer Punch

8T-4474

Bit Puller

Bit Holder Remover, Installer and Handle

Model Usage: PM200 & PM201 Cold Planers

• 372-7066 used to easily remove 241-4559

• Tools constructed of hardened steel with

cutter bit holder from rotor

black oxide finish

Warranty: Caterpillar ^®Six Months

• 372-7067 used to easily install 241-4559

cutter bit holder on rotor

Part Number

Description

Dimensions

372-7066

Bit Holder Removal Tool

267.4 x 155.6 mm (10.53 x 6.13 in)

372-7067

Bit Holder Install Tool

76.2 x 19.1 mm (3.0 x .75 in)

Service/Repair Parts

385-4009

Bit Holder Handle

157 x 60 mm (6.2 x 2.4in)

7-196 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Bit Extractor Tool, Wedge Removal Tool

Model Usage: PM200 & PM201 Cold Planners

• Used to easily remove broken 241-4559 cutter

bit holder from rotor

Warranty: Caterpillar ^®Six Months

Part Number

Dimensions

378-4294

250.3 x 90 mm(9.9 x3.5in)

392-3965

70 x 25.4 mm (2.8 x 1.0in)

Depth Adjuster

Essential Tool

• Used to quickly and easily adjust depth of cut

Reference

Model Usage: PC203/4 and PC404 Cold Planer

• SEBU7705, Service Manual

Worktools on Cat Skid Steer Loaders

Part Number

Description

Warranty: Caterpillar ^®Six Months

232-6299

Depth Adjuster

Cable Handled Pin Remover

Model Usage: 5130 Mining Excavators (Front

• Used to remove FLEXPIN from excavator

Specifications

Shovel and Backhoe Styles)

bucket teeth

• Overall length: 508 mm (20.0 in)

Warranty: Caterpillar ^®Six Months

• Used with a sledge hammer to remove pin

• Overall height: 257 mm (10.1 in)

References

• Oval pin size: 25 x 30 mm (1.0 x 1.2 in)

• SENR6058, 5130 Service Manual Module,

Disassembly and Assembly

• SEHS9721, Special Instruction, Assembly

Procedure for Hydraulic Excavator (5130 only)

Part Number

Description

1U-7184

Cable Handled Pin Remover

Pin Remover

Model Usage: Medium Wheel Loaders and

• Usedto remove and install “K SeriesTooth

• Urethane collars provide larger striking area,

Excavators or any K Series Tooth System G.E.T.

System” bucket teeth retaining pins

prevent damage to striking surface, and

absorb shock of hammer blow

Warranty: Caterpillar ^®Six Months

• Used with large hammer (installation) or

sledge hammer (removal)

• Urethane collars also keep hammer head from

sliding off of striking surface

• Easy to hold and wire rope handle reduces

shock

Part Number

Description

229-0287

Pin Remover

JULY 2018 Vehicle System Tools

7-197

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Tooth Pin Remover Group (Small Bucket)

Model Usage: J200 thru J450

• Used to remove pins as small as 15.5 mm

• 2 adapters available for correct alignment;

(0.61 in) from bucket teeth

one for J200-J400 Series, another for J450

Warranty: Caterpillar ^®Six Months

Series teeth

• Used with 8T-3130Wrench (7/8)— allows

removal of teeth as close as 13.2 cm (5.2 in)

Reference

apart

• NEHS0696, Tool Operating Manual

• Tool loosens pins so they can be removed

with pliers

Part Number

Description

149-2872

Tooth Pin Remover Group (Small Bucket)

Fabric Baskets

Model Usage: All Models with Ground Engaging

European Union compliant, CE marked

• Suitable nylon strap (sold separately) must be

Tools (GET)

used with 149-0174

• Used to help remove and install bucket teeth,

Warranty: Caterpillar ^®Six Months

cutting edges, and adapters

References

• Must be used with overhead lifting device

• NEHS0700, Tool Operating Manual, Using

• Provides an easy method of moving Ground

the Choker Style Fabric Basket to Install and

Engaging Tools (GET) products in and out of

Remove Bucket Teeth

service trucks or shop environment

• NEHS0701, Tool Operating Manual, Using

• Non-choker style baskets must be used in

Non-Choker Style Fabric Baskets to Install

pairs (securely holds cutting edge)

Bucket or Blade Cutting Edges

Part Number

Description

Maximum Capacity

Maximum Length

Weight Capacity

Choker Style Fabric

260mm(10.2in)

149-0173

450mm(17.7in)

104 kg (229lb)

Basket

square

Non-Choker Style

63.5 x 419 mm

149-0174

200mm (7.9in)

125 kg (276lb)

Fabric Basket

(2.5 x 16.5 in)

Shroud Position and Adapter Position Gauge Assembly

Model Usage: 7495, 7495HD, 7495HF, 495HRZ,

• Used to fit gauge up to bucket revealing worn

• Reduces chance of premature failure of

495HD, 495HFZ Electric Rope Shovels (ERS)

area to determine rebuild, repair or replace

bucket

options prior to replacing teeth adapters

Warranty: Manufacturer’s

• Work areas and position tooth adapters easily

• Used to locate weld on lip shroud mounting

visible

boss (398-3027)

Part Number

Description

399-5769

Shroud Position Gauge Assembly (Whisler 12)

399-5770

Adapter Position Gauge Assembly (Whisler 12)

399-5770

Pry Bar

Model Usage: Wheel Loaders, Track -Type

• Used to remove and install retainers on

• Ergonomic handle reduces hand fatigue

Loaders, Excavators, and Backhoe Loaders

K-series hammerless bucket teeth

• Long-life finish resists rust and wear

Warranty: Caterpillar ^®Six Months

Part Number

Description

263-0039

Pry Bar

7-198 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Tooth Pin Remover

Model Usage: 416, 420, and 430 Backhoe

European Union compliant, CE marked

• Works on Caterpillar^®Diagonal Retention

Loaders and All Models with Diagonal Retention

System (DRS) with 1-piece flex pins

• Used to remove and install flex pins from

System Pins

bucket teeth in a matter of minutes

• Also works on “23 Series” forged or cast

Warranty: Caterpillar ^®Six Months

teeth with horizontal flex pin retention

• Quick and easy (recommended over punch and

hammer method)

• Small enough to store in mechanic’s toolbox

Part Number

Description

207-0631

Tooth Pin Remover

Compression Retainer Pry Bar

Essential Tool

• Used to install and remove bucket tip spring

• Flat end is used to compress retainer which

retainers

allows for removal

Model Usage: 990, 992, 998 Wheel Loader; 345,

350, 375 Excavator; 5080 Mining Shovel

• Eliminates use of hammers or other devices

References

normally used for conventional pin removal

Warranty: Caterpillar ^®Six Months

• PEXT8026, New Caterpillar Compression

(using other tools could cause personal injury)

Retainer and Tip System

• Cut out end is used to remove plug and cap

• PEXT9034, Compression Retaining System

• Makes removal faster and easier

(CD-ROM)

Part Number

Description

175-0138

Compression Retainer Pry Bar

Cutting Edge Handling Bracket Assemblies

Model Usage: Machines with Cutting Edges

European Union compliant, CE marked

• Easy and quick attachment to cutting edge

having Rectangular Holes

• Used to lift cutting edges with rectangular

• Adjusts to different hole sizes

Warranty: Caterpillar ^®Six Months

mounting holes

• Provides positive locking

Part Number

Rectangular Hole Size

Maximum Weight Limit

152-2025

15.7, 19.1, and 22.1 mm (5/8, 3/4, and 7/8 in)

270 kg (595.25lb)

152-2026

25.4 and 31.8mm (1 and 1 1/4in)

392 kg (864.21lb)

Puller for 785

Model Usage: 785

• Used to separate front suspension strut from

Reference

front axle (spindle)

Warranty: Caterpillar ^®Six Months

• SENR4020, 785 Truck Vehicle Systems

• Used with 8T-2853 Handle Assembly

Disassembly and Assembly Manual

(2 required) to position 8T-2852 Puller on

• Support front axle before removing bolt that

bottom of front axle; install 6 bolts spaced

holds 6G-6534 Plate in position.

evenly around puller to hold it to front axle

• Puller ton-force capability: 654 tons

Part Number

Description

8T-2852

Puller for 785

To avoid possible personal injury from sudden release of the axle from the strut rod or the snapping of a bolt when removing plate, loosen all bolts in a

7-198 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Puller Plate

Model Usage: 789 and 793 Off-Highway Trucks

• Required for front axle removal on 793 Off-

References

Highway Truck

Warranty: Caterpillar ^®Six Months

• SENR4917, (793 Truck) SEN3404, (789 Truck)

• Used to separate front axle from front strut

Vehicle System Disassembly and Assembly

(two 8T-2853 Handles may be used with puller

Specifications

plate to help position it to bottom of front

axle)

- Diameter: 445 mm (17.5 in)

- Thickness: 130 mm (5.1 in)

• Similar to 8T-2852 Puller and 8T-9205 Puller

- Weight:68 kg (150 lb)

used on 785 and 789 Off-Highway Trucks

- Hardness: Rockwell C 42-47

• Support the front axle before removing the

bolts that hold the 8X-2608 Plate in position.

Part Number

Description

9U-5613

Puller Plate

To avoid possible personal injury from sudden release of the axle from the strut rod or the snapping of a bolt when removing the plate, loosen all bolts in a

circular pattern one-half turn. Do this again and again until the torque for the bolts is released.

Pusher Plate

Essential Tool

• Used to separate front axle from front

Reference

suspension cylinder

Model Usage: 793D Extended-Life Off-Highway

• RENR8332, Disassembly and Assembly, 793D

Truck, FDB1-Up

• Required for front axle removal

Extended-Life Off-Highway Truck, Machine

Systems, Spindle (Front) Remove

Warranty: Caterpillar ^®Six Months

• Similar to 9U-5613 Puller Plate, but utilizes

larger bolt diameter and front axle keyway

• Support the front axle before removing the

clearance

bolts that hold the 183-9580 Steering Arm in

Position.

• Heat treated to C42-47 for durability

• Weight: 70 kg (154.4 lb)

Part Number

Description

283-0811

Pusher Plate

To avoid possible personal injury from sudden release of the axle from the strut rod, or the snapping of a bolt when removing the plate, loosen all bolts in a

circular pattern one-half turn. Do this again and again until the torque for the bolts is released.

Puller Plate

Essential Tool

• Used to separate front axle from suspension

Specifications

strut rod

Model Usage: 797 Off-Highway Trucks

• Outside diameter: 533 mm (21.0 in)

• Can be used with a hoist attached to two

Warranty: Caterpillar ^®Six Months

• Overall thickness: 115 mm (4.5 in)

1/2-13 eye bolts

Bolt hole circle dimension: 445 mm (17.5 in)

•

• Attaches to rod with eighteen 7Y-5245 Hex

• 7Y-5245: M36 x 4.0, 150.0 mm (5.9 in) long

Head Bolts and 9X-8259 Flat Hard Washers

• 9X-8259: M36

• Heat-treated for added strength and durability

• Eye bolts not included

Part Number

Description

160-5493

Puller Plate

7-198 JULY 2018 Vehicle System Tools

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Hitch Pin Sprocket Wrench

Model Usage: 651E and 657E Tractor Scrapers

• Used for removing or installing 5P-9093 Hex

• 2 wrenches required for various stages of

Nut (5 3/8 inch) securing horizontal hitch pin;

tractor and hitch assembly

Warranty: Caterpillar ^®Six Months

hitch pin size increased to 3 1/2 inch-12-2B

thd and 5 3/8 inch hex nut size on 651E and

657E Series Tractor Scrapers from 4 1/4 inch

hex size on 651B and 657B Series

Part Number

Description

6V-9080

Hitch Pin Sprocket Wrench

Cylinder Spanner Wrench

Model Usage: Articulated Trucks D25C, D30C,

• Used to disassemble and assemble cylinder

• Services 4 different pistons— more

D25D, D30D, D350D, D35C, D35MP, D40D,

pistons from rods on suspension cylinders on

economical than 4 separate tools

D400D, D350C, D400

articulated trucks

• Has 1 1/4 inch hex for use with 1 1/4 inch

Warranty: Caterpillar ^®Six Months

• Is more versatile, faster and safer than

socket and torquing tool

universal-type spanners

Reference

• Designed to perform without damaging or

• SENR8203, Service Manual, Vehicle Systems

scratching piston OD or rod

Disassembly and Assembly (D400D)

Part Number

Description

9U-5131

Cylinder Spanner Wrench

Mining Excavator Pin Removal/Installation Tooling (5130)

Model Usage: 5130 Mining Excavators (Front

Pin Pullers

Threaded Puller Rods and Fast Runner Nuts

Shovel and Backhoe Styles)

• Used to remove and install boom-to-frame

• Threaded rods, in various lengths, used to pull

Warranty: Caterpillar ^®Six Months

pin, stick-to-boom pin, bucket-to-stick pin, and

pins into or out of pin bore

all related cylinder pins - tooling is essential

• Fast runner nuts are used with threaded rod to

to properly handle large pins without damage

make removal of pins faster and easier

• Used with general tooling listed below in

• Puller rods screw into threaded hole in pin

“General Tooling Used for All Pins”

References

• Alocking stud is designed into each pin

installer to lock pin inside installer (essential

• SENR6058, 5130 Service Manual Module,

when working overhead)

Disassembly and Assembly

• Each pin installer should be fitted with the

• SENR1472, 5130B Service Manual Module,

correct cradle assembly to hold hydraulic

Disassembly and Assembly

cylinder in place

• SEHS9721, Special Instruction, Assembly

Procedure for Hydraulic Excavator (5130 only)

Item

Description

Hydraulic Cylinder

Square Head Setscrew (Locking Stud)

Threaded Puller Rod

Cradle Assembly

Fast Runner Nut

Pin Installer

Bolt Washer Nut

JULY 2018 Vehicle System Tools

7-201

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

5130 Pin Driver Caps

• 2 sizes of pin driver caps are available to

• When installed, the caps can be hit with

protect ends from “mushrooming”

sledge hammer to drive pins into bore

• Used only when hydraulic force is not required

5130 Front Shovel Tooling Usage

Item

Description

Boom-to-Swing Frame Pin

Stick-to-Boom Pin

Bucket Pin

Cylinder Pins

Removal/Installation

Part Number

Description

Pin No. 1 (Boom-to-Swing Frame)

4C-9544

Pin Driver Cap (installation only)

Pin No. 3 (Bucket Pin)

9U-6792

Puller Assembly - Pin

Pin No. 4 (Cylinder Pin)

4C-9544

Pin Driver Cap (installation only)

9U-6706

Puller Assembly (Cylinder Pins)

Pin No. 5 (Cylinder Pin)

9U-6706

Puller Assembly (Cylinder Pins)

9U-6758

Pin Driver Cap (installation only)

9U-6814

Stud-Puller (M48x 5)

9U-6903

Nut - Speed (M48)

5130 Mass Excavator Tooling Usage

Warranty: Caterpillar ^®Six Months

Item

Description

Boom-to-Swing Frame Pin

Stick-to-Boom Pin

Bucket Pin

Cylinder Pins

Removal/Installation

Part Number

Description

4C-9544 (Pin No. 1 (Boom-to-Swing Frame))

Pin Driver Cap (installation only)

9U-6792 (Pin No. 3 (Bucket Pin))

Puller Assembly - Pin

4C-9544 (Pin No. 4 (Bucket Pin))

Pin Driver Cap (installation only)

9U-6792 (Pin No. 4 (Bucket Pin))

Puller Assembly - Pin

Pin No. 5 (Cylinder Pin)

4C-9544

Pin Driver Cap (installation only)

9U-6706

Puller Assembly (Cylinder Pins)

Pin No. 6 (Cylinder Pin)

9U-6706

Puller Assembly (Cylinder Pins)

9U-6758

Pin Driver Cap (installation only)

9U-6814

Stud-Puller (M48x 5)

9U-6903

Nut - Speed (M48)

JULY 2018 Vehicle System Tools

7-201

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

General Tooling

General Tooling Used for All Pins

Part Number

Description

350-7768

Pump Group-Hydraulic (115V)

6D-7726

Hydraulic Hose (2)

350-7769

Pump Grp - Hydraulic (230V)

9U-6702

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

5130 Part Specifications

Max. Pin

Max.Rod

Part No.

Description

Max. Capacity

Thread Size

Length

Diameter

Use

Diameter

Length

Diameter

General Tooling Used for All Pins

RodAssembly

136 t

Usedto removeand

4C-8150

M64 x 6

1.8 m (6.0 ft)

- Threaded

(150tons)

install pins

Pin Driver Cap

Used to install pins

127 mm

4C-9544

(installation

M64 x 6

70 mm (2.8 in)

when using sledge

(5.0in)

only)

hammer

RodAssembly

136 t

Usedto removeand

9U-6702

M64 x 6

2.6 m (8.5 ft)

- Threaded

(150tons)

install pins

Puller

182 mm

440 mm

136 t

Used to remove

9U-6706

Assembly

82 mm (3.2 in)

(7.2in)

(17.3 in)

(150tons)

cylinder pins

(Cylinder Pins)

Pin Driver Cap

Used to install pins

101 mm

9U-6758

(installation

M48 x 5.0

77 mm (3.0 in)

when using sledge

(4.0in)

only)

hammer

Holds pin during

removal (hydraulic

Puller

228 mm

1825 mm

136 t

cylinder cradle

9U-6792

Assembly -

82 mm (3.2 in)

(9.0in)

(71.9 in)

(150tons)

assembly part of

9U-6792) and during

installation

Usedwith threaded

Nut - Speed

9U-6800

M64 x 6

puller rods to remove

(M64)

and install pins

Stud— Puller

Usedto removeand

9U-6814

90 t (100 tons)

M48 x 5.0

0.9 m (3.0 ft)

(M48 x 5)

install pins

Puller Stud

Usedto removeand

9U-6815

90 t (100 tons)

M48 x 5

1.5 m 5.0 ft)

(M48) 62 in

install pins

Usedwith threaded

Nut - Speed

9U-6903

M48 x 5

puller rods to remove

(M48)

and install pins

7-202 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Mining Excavator Pin Removal/Installation Tooling (5230)

Model Usage: 5230 Mining Excavators (Front

Pin Pullers

Threaded Puller Rods and Fast Runner Nuts

Shovel)

• Used to remove and install boom-to-frame

• Threaded rods, in various lengths, used to pull

Warranty: Caterpillar ^®Six Months

pin, stick-to-boom pin, bucket-to-stick pin, and

pins into or out of pin bore

all related cylinder pins (tooling is essential to

• Fast runner nuts are used with threaded rod to

properly handle large pins without damage)

make removal of pins faster and easier

• Used with general tooling listed in “General

• Rods screw into threaded hole in each pin

Tooling Used for All Pins”

Reference

• Alocking stud is designed into each pin

installer to lock pin inside installer (essential

• SENR6108, 5230 Service Manual Module,

when working overhead)

Disassembly and Assembly

• Each pin installer should be fitted with the

correct cradle assembly to hold hydraulic

cylinder in place

Item

Description

Hydraulic Cylinder

Square Head Setscrew (Locking Stud)

Threaded Puller Rod

Cradle Assembly

Fast Runner Nut

Pin Installer

Bolt

Part Number

Description

6V-8237

Hard Washer

8T-4001

Nut

5230 Pin Driver Caps

• 2 sizes of pin driver caps are available

• When installed, the caps can be hit with

to protect ends of pin (keeps pin from

sledge hammer to drive pins into bore (used

mushrooming at the ends)

for installation only)

• Used only when hydraulic force is not required

to install pins

Part Number

Description

Qty.

350-7768

Pump Group-Hydraulic (115V)

6D-7726

Hydraulic Hose (2)

350-7769

Pump Grp - Hydraulic (230V)

9U-6702

Rod Assembly - Threaded

9U-6800

Nut - Speed (M64)

JULY 2018 Vehicle System Tools

7-203

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

5230 Front Shovel Tooling Usage

Item

Description

Cylinder Pins

Removal/Installation

Part Number

Description

Pin No. 4 (Cylinder Pin)

4C-9544

Pin Driver Cap (installation only)

9U-6814

Stud-Puller (M48x 5)

5230 Part Specifications

Warranty: Caterpillar ^®Six Months

General Tooling Used for All Pins

Max. Pin

Max.Rod

Capacity

Part No.

Description

Thread Size

Length

Diameter

Use

Diameter

Length

Diameter

(Tons)

RodAssembly

1829 mm

136 t

4C-8150

M64 x 6

1.8 m (6.0 ft)

Used to remove and install pins

- Threaded

(72.01 in)

(150tons)

Pin Driver Cap

127 mm

70 mm

101 mm

Used to install pins when using

4C-9544

(installation

M64 x 6

(5 in)

(2.8in)

(4.0in)

sledge hammer

only)

RodAssembly

2616 mm

136 t

9U-6702

M64 x 6

2.6 m (8.5 ft)

Used to remove and install pins

- Threaded

(102.99 in)

(150tons)

Nut - Speed

Used with threaded puller rods

9U-6800

M64 x 6

(M64)

to remove and install pins

7-204 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Mining Excavator Pin Removal/Installation Tooling (5230B)

Model Usage: 5230B Mining Excavators

Pin Pullers

Pin Driver Caps

Warranty: Caterpillar ^®Six Months

• Used to remove and install boom-to-frame

• 2 sizes of pin driver caps are available

pin, stick-to-boom pin, bucket-to-stick pin, and

to protect ends of pin (keeps pin from

all related cylinder pins (tooling is essential to

mushrooming at the ends)

properly handle large pins without damage)

• When installed, the caps can be hit with

• Used with general tooling listed in General

sledge hammer to drive pins into bore (used

Tooling Used for All Pins

for installation only)

• Alocking stud is designed into each pin

• Used only when hydraulic force is not required

installer to lock pin inside installer (essential

to install pins

when working overhead)

Reference

• Each pin installer should be fitted with the

• RENR3379, Service Manual

correct cradle assembly to hold hydraulic

cylinder in place

Threaded Puller Rods and Fast Runner Nuts

• Threaded rods, in various lengths, used to pull

pins into or out of pin bore

• Fast runner nuts are used with threaded rod to

make removal of pins faster and easier

• Rods screw into threaded hole in each pin

Part Number

Description

Qty.

General Tooling Used for All Pins

350-7768

Pump Group-Hydraulic (115V)

4C-8152

Retaining Plate

4C-9544

Pin Driver Cap (installation only)

350-7769

Pump Grp - Hydraulic (230V)

8T-4121

Washer (M10)

8T-4133

Nut (M10)

9T-2240

Rod (M10)

9U-6800

Nut - Speed (M64)

Requires the following

135-2532

Bushing

135-2533

Street Elbow

Coupler Assembly Quick Connective

1P-2376

(Female) (2)

1P-2377

Plug As - Dust

6D-7726

Hydraulic Hose (2)

8T-0820

Standard PressureGauge

JULY 2018 Vehicle System Tools

7-205

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

5230B Front Shovel Tooling Usage

Item

Description

Boom-to-Swing Frame Pin

Stick-to-Boom Pin

Cylinder Pins

Part Number

Description

Pin No. 1

9U-6702

Rod Assembly - Threaded

Pin No. 2 and 4

9U-6702

Rod Assembly - Threaded

5230B Mass Excavator Tooling Usage

Item

Description

Boom-to-Swing Frame Pin

Stick-to-Boom Pin

Bucket Pin

Cylinder Pins

Part Number

Description

Pin No. 1 and 2

9U-6702

Rod Assembly - Threaded

Pin No. 3, 4, 5 and 6

9U-6702

Rod Assembly - Threaded

7-206 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

5230B Part Specifications

Max.

Max. Pin

Max.

Part No.

Description

Max. Length

Capacity

Thread Size

Length

Diameter

Use

Diameter

(Tons)

1 Requires the following

Pin Driver Cap

127 mm

70 mm

101 mm

Used to install pins when using

4C-9544

(installation

M64 x 6

(5 in)

(2.8in)

(4.0in)

sledge hammer

only)

RodAssembly

2616 mm

136 t

9U-6702

M64 x 6

2.6 m (8.5 ft)

Used to remove and install pins

- Threaded

(102.99 in)

(150tons)

Nut - Speed

Used with threaded puller rods

9U-6800

M64 x 6

(M64)

to remove and install pins

Stud— Puller

920 mm

90 t

9U-6814

M48 x 5.0

0.9 m (3.0 ft)

Used to remove and install pins

(M48 x 5)

(.22in)

(100tons)

Bearing Puller Adapter

Model Usage: 300 and M300 Series Excavators;

• Used to remove sleeve bearings from boom

References

5000 Series Mining Excavators (Front Shovel and

and stick— essential to remove bearing

• 5000 Series Excavator Service Manual

Backhoe Styles)

sleeves used on 300,M300, and 5000 Series

Module, Disassembly and Assembly 00

Excavators

Warranty: Caterpillar ^®Six Months

Series Excavator Service Manual Module,

• Also used to pull any bearing with appropriate

Disassembly and Assembly

size inside diameter

• M300 Series Excavator Service Manual

• Bearing puller adapters allow easy removal of

Module, Disassembly and Assembly

sleeve bearings and reduce chance of damage

• SEHS9721, Special Instruction, Assembly

to bearing bore

Procedure for Hydraulic Excavator

• Sides are cut away to allow adapter to be put

(5130 Excavator only)

through bearing in a sideways position and

then turned up to engage against backside of

bearing

• A 1 1/4 inch hardened washer must be used

when using 1 1/4-12 threaded puller rods and

7H-7539 Nut

Used with the following tooling when adapter plate has M64 threaded holes

Part Number

Description

Not Listed

Hydraulic Cylinder

JULY 2018 Vehicle System Tools

7-207

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Bearing Puller Adapters (Continued)

Part Number

Description

Used with the following tooling when adapter plate has M64 threaded holes

350-7768

Pump Group-Hydraulic (115V)

6D-7726

Hydraulic Hose (2)

350-7769

Pump Grp - Hydraulic (230V)

9U-6800

Nut - Speed (M64)

Used with the following tooling when adapter plate has 1 1/4-12 threaded holes

350-7768

Pump Group-Hydraulic (115V)

4K-0684

Hardened Washer

6D-7726

Hydraulic Hose (2)

6V-3175

Hydraulic Cylinder

7H-7539

Nut— Full, 1 1/4 - 12

350-7769

Pump Grp - Hydraulic (230V)

9U-6832

Speed Nut

Bearing Puller Adapter Specifications

Adapter OD

Threaded Hole

Part Number

Description

Bearing I.D.

(Item 1)

(Item 2)

(Item 3)

Used with the following tooling when adapter plate has 1 1/4-12 threaded holes

Bearing Puller

123-3804

60.0

(2.36)

70.0

(2.76)

59.0

(2.32)

1 1/4 -12

Adapter

Bearing Puller

1U-6217

160.0

(6.30)

185.4

(7.30)

159.0

(6.26)

1 1/4 -12

Adapter

Bearing Puller

231-4349

65.0

(2.56)

75.0

(2.95)

64.0

(2.52)

1 1/4 -12

Adapter

Bearing Puller

246-2386

120.0

(4.72)

137.0

(5.39)

119.0

(4.69)

1 1/4 -12

Adapter

Bearing Puller

284-2368

100.5

(3.96)

115.0

(4.53)

99.5

(3.92)

1 1/4 -12

Adapter

Bearing Puller

9U-5336

70.0

(2.76)

81.0

(3.19)

69.0

(2.72)

1 1/4 -12

Adapter

Bearing Puller

9U-5337

80.0

(3.15)

91.0

(3.58)

79.0

(3.11)

1 1/4 -12

Adapter

Bearing Puller

9U-5338

90.0

(3.54)

102.0

(4.02)

89.0

(3.50)

1 1/4 -12

Adapter

Bearing Puller

9U-5339

100.0

(3.94)

112.0

(4.41)

99.0

(3.90)

1 1/4 -12

Adapter

Bearing Puller

9U-6227

110.0

(4.33)

126.0

(4.96)

109.0

(4.29)

1 1/4 -12

Adapter

Bearing Puller

9U-6260

130.0

(5.12)

150.0

(5.91)

129.0

(5.08)

1 1/4 -12

Adapter

Bearing Puller

9U-6261

140.0

(5.51)

160.00

(6.30)

139.0

(5.47)

1 1/4 -12

Adapter

Bearing Puller

9U-6904

200.0

(7.87)

225.4

(8.87)

199.0

(7.83)

M64 x 6

Adapter

Bearing Puller

9U-6906

220.0

(8.66)

245.4

(9.66)

219.0

(8.62)

M64 x 6

Adapter

Bearing Puller

9U-6907

120.0

(4.72)

145.4

(5.72)

119.0

(4.69)

1 1/4 -12

Adapter

7-208 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Bearing Puller Adapter

Essential Tool

• Used to remove 162-6471 Bushings

• Bearing inside diameter: 89.2 mm (3.51 in)

Model Usage: 539 Knuckleboom Loader

• Used with 4C-9634 Stud Puller, 9U-8632 Fast

• Adapter outside diameter: 87.4 mm (3.44 in)

Runner Nut and 316-1489 Cylinder Group

Warranty: Caterpillar ^®Six Months

Part Number

Description

185-5852

Bearing Puller Adapter

Essential Tool

• Used to remove stick nose sleeve bearings

Reference

Model Usage: 330D Hydraulic Excavator

• Heat-treated for added durability

• RENR8648, 330D Disassembly and Assembly

Machine Systems

Warranty: Caterpillar ^®Six Months

• Used with 316-1489 Cylinder Group and 4C-

9634 Puller Stud

Specifications

• Thread: 1 1/4-12

• Small outside diameter: 99.5 mm (3.92 in)

• Large outside diameter: 115.0 mm (4.53 in)

Part Number

Description

284-2368

Bearing Puller Adapter

Bearing Puller Plate (988G)

Model Usage: 988G Wheel Loader

• Used to remove sleeve bearings from Y and K

Specifications

pin locations

Warranty: Caterpillar ^®Six Months

• Inside diameter: 180 mm (7.1 in)

• Bearing puller adapter has center swivel point

• Overall outside diameter: 188 mm (7.4 in)

for easy installation

• Small outside diameter: 156 mm (6.1 in)

• Heat-treated for added durability

Part Number

Description

185-3542

Bearing Puller Plate (988G)

Sleeve Assembly, Bearing Puller Plate

Model Usage: 988K Wheel Loader

• Used to remove the two bearing cups and the

- Electric Hydraulic Pump

two bearing cones from the bore in the lower

- 9U-6814 Puller Stud

Warranty: Caterpillar ^®Six Months

hitch pin assembly

- 9U-6810 Nut

- 316-1491 or 6V-0014 Hydraulic Cylinder

• Requires additional tooling:

- 8T-1158 Bolt

- 350-7768 (115V) Electric Hydraulic Pump or

350-7769 (230V)

Part No.

Description

Diameter

Length

Weight

452-0331

Sleeve Assembly

265mm(10.4in)

425.5 mm (16.8 in)

40 kg (88.2 lb)

451-4588

Bearing Puller Plate

185mm (7.3in)

40 mm (1.6 in)

6.4 kg (14.1 lb)

454-6245

Bearing Puller Plate

208mm (8.2in)

40 mm (1.6 in)

8.5 kg (18.7 lb)

JULY 2018 Vehicle System Tools

7-209

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Extension Assembly Arm

Model Usage: 5230 Mining Excavators (Front

• Used to remove and install final drive

• Extra mounting holes allow final drive to be

Shovel)

assembly into track roller frame

rotated to any desired angle (30° increments)

during installation - helps to align final drive

Warranty: Caterpillar ^®Six Months

• Used with overhead hoist or equivalent to lift

mounting holes for assembly

extension arm and final drive assembly

• Bolts and washers are required to mount

• Extension arm is essential to correctly and

extension to final drive— 6V-3532 Bolt

quickly install the final drive - final drive

(M20 x 60 mm long) and 8T-3282 Washer

assembly must be held horizontal to allow

final drive installation due to close tolerances

• Overall length: 1168 mm (46.0 in)

between mounting diameters and track roller

• Approximate weight: 49.8 kg (110 lb)

frame bores

Reference

• Bolts directly onto final drive with standard

metric bolts

• SENR6108, 5230 Service Manual Module,

Disassembly and Assembly

Part Number

Description

4C-9695

Extension Assembly Arm

Strap Wrench

Model Usage: SE60 Screed

• Used to tighten wiring harness MS type

Specifications

connectors before applying lock wire

Warranty: Manufacturer’s

• Length: 165 mm (6.5 in)

• Square Drive: 9.5 mm (3/8 in)

• Weight: .11 kg (.25 lb)

Part Number

Description

459-0233

Strap Wrench

Articulation Sending Unit Alignment Gauge

Model Usage: All H Series Motor Graders

• Used to make sure 3E-5383 Articulation

• Allows quick and accurate positioning of

Sending Unit matches actual position of

sensor relative to 2 fixed points on machine

Warranty: Caterpillar ^®Six Months

vehicles articulation (if sensor is not aligned

• Sensor is properly positioned when bushing,

properly, operators display for articulation in

pin, and hole are all aligned

cab will be incorrect)

• Overall size: 25.0 x 89.0 x 16.0 mm (0.10 x

• Alignment gauge is required to realign

3.50 x 0.63 in)

replacement sensors, or if sensor moved

for any reason such as work to, or around

Reference

articulation joint area

• Service Manual Module

Part Number

Description

127-8073

Articulation Sending Unit Alignment Gauge

Adapter

Model Usage: Challenger 35, 45 and 55

• Used to provide connection to pump when

• Threads into port on top of steering pump

checking servo up-stroke pressure from inside

Warranty: Caterpillar ^®Six Months

• Thread specification: M8 x 1

port (there is insufficient clearance to attach

• Angle: 90°

pressure gauge onto top of pump)

• Uses quick disconnect end to easily and

Reference

quickly attach pressure gauge

• SENR8300 Service Manual

Part Number

Description

1U-9099

Adapter

7-210 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Hand Brake Tool

Model Usage: Challenger 35, 45 and 55

• Used to separate brake friction plates (makes

• With parking brake unit removed, tool is

it possible to separate and insert brake pads

easily installed to separate discs

Warranty: Caterpillar ^®Six Months

into friction plates)

• Once brake pads are between friction plates,

• Makes a difficult installation procedure quick

tool can be easily removed and parking brake

and easy

can be mounted to housing

• Tool is angled to allow parking brake to be

• Overall length: 218 mm (8.6 in)

almost completely installed before tool is

Reference

removed

• SENR8300 Service Manual

• Rubber coated handle makes it easy to hold

Part Number

Description

1U-9067

Hand Brake Tool

PTO Component Tools

Model Usage: Challenger 35, 45 and 55

• Used to remove, install, assemble, and

Reference

disassemble components of PTO

Warranty: Caterpillar ^®Six Months

• SENR8300 Service Manual

137-3482 PTO Installer

Specifications

• Used to install 112-8695 Seal for PTO output

• 137-3482 PTO Installer:

shaft and 112-8436 Seal for rock shaft

- Outside diameter: 92.0 mm (3.62 in)

• Handle can be attached to installer and seals

- Pilot diameter: 74.3 mm (2.93 in)

are then driven into place

- Diameter of center hole: 6.63 mm (0.26 in)

• Installer provides additional protection to seal

during installation

Part Number

Description

137-3482

PTO Installer

1U-9066

PTO Hub Puller

1U-9066 PTO Hub Puller

• Used to remove PTO clutch housing assembly

• Used with 8B-7548 Push/Puller Group

(hub)

JULY 2018 Vehicle System Tools

7-211

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Bearing Driver Plate

Model Usage: 785B, 789B, and 793B Off-

• Used to install bearings without damage

• SENR5687, 789B Vehicle Systems

Highway Trucks

Disassembly and Assembly

• Has 2 different pilots (1 for 8X-8654 Bearing

Warranty: Caterpillar ^®Six Months

used on 789B and 793B Off-Highway Trucks);

• SENR5692, 793B Vehicle Systems

1 for 7I-5494 Bearing used on 785B Off-

Disassembly and Assembly

Highway Trucks)

Specifications

• Used with either 1P-0531 Handle or 1P-0532

• Outside diameter: 139.7 mm (5.50 in)

Handle and 4L-7124 Bolt (handles and bolt

part of 1P-0520 Driver Group)

• Thickness: 19.05 mm (0.750 in)

• Driver plate heat-treated for durability

• Pilot diameters: 114.0 mm (4.49 in) and

126.7 mm (4.99 in)

Reference

• Attachment to handle: 4L-7124 Bolt, 1/4 in x

• SENR5678, 785B Vehicle Systems

20 x 1 1/4 in

Disassembly and Assembly

• Heat treat: Rockwell C 32-38

Item Part No.

Description

9U-7412

Bearing Driver Plate

Notincluded

1P-0531

Handle (Part of 1P-0520 Driver Group)

1P-0532

Handle (Part of 1P-0520 Driver Group)

4L-7124

Bolt - Hex Socket Head (Part of 1P-0520 Driver Group)

Rear Stand Group

Model Usage: Challenger 35, 45 and 55

• Used when splitting tractor to remove

1U-9073 Rear Stand Group

transmission or other driveline components

Warranty: Caterpillar ^®Six Months

• Rear supports bolt on with 0S-1626 Bolts

• Bolts directly to frame using counterweight

and 2J-3506 Nuts - front support uses

bolt holes

counterweight mounting bolts

• Support can be adjusted for height

Reference

• SENR8300 Service Manual

Item

Part Number

Description

1A-1935

Nut

5F-7366

Screw - Forcing

5F-7353

Thrust Washer

7-212 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Decal

Model Usage: All Vibratory Compactors

133-0963 Hand Held Tachometer

Reference

Warranty: Caterpillar ^®Six Months

• Check vibrations per minute by simply placing

• Instructions for using the 133-0963 Drum

the unit on a vibrating drum and reading

Vibration Tachometer and the 133-9905

the measurement (If vibration is too great

Frequency Meter are included with each unit.

to obtain a reading, simply place your hand

Specifications

on the drum and then place the tachometer

on top of your hand. This will dampen the

• Low range: 1000 - 2000 VPM in increments

vibration, but still provide an accurate

of 50

reading.)

• High range: 2000 - 4000 VPM in increments

• Small, lightweight, hand-held, and easily

of 100

carried into the field

• Overall size: 76 x 51 x 64 mm

• Completely sealed against contamination in

(3.0 x 2.0 x 2.5 in)

normal working environments

• Weight: 370 g (13 oz)

• Readings can be extrapolated to one-quarter

• Accuracy: 0.5% of rated frequency

increments (for example, 12 VPM/25 VPM

• Individual reed accuracy: 0.3% at room

temperature

Part Number

Description

133-0963

HandHeld Drum Vibration Tachometer

133-9905

Frequency Meter

133-9905 Frequency Meter

Specifications

• Used to measure vibrations per minute (VPM)

• Size: 85.0 x (3.4 in) diameter, 19.0 mm

of vibratory compactor drums

(0.75 in) thick

• Low-cost option to measure vibrations per

• RPM range: 800 - 50,000

minute (good choice when exact accuracy of

• Cycles per second range: 14 - 750

reading is not critical)

• Indicator can check RPM between 800 and

50,000 or cycles per second between 14 and

750

Vibration Amplitude Decal

NEEG2687 Vibration Amplitude Decal

• Amplitude readout ranges: 0.50 to 6.35 mm

(0.020 to 0.250 in)

• Used to quickly and easily indicate amplitude

of a vibrating surface

• Size: 51.0 x 210.0 mm (2.00 x 8.25 in)

• Magnetized and will stick on most metal

surfaces

• To obtain a reading, place decal on metal

surface, 90° to direction of travel, and read

wedge overlap

JULY 2018 Vehicle System Tools

7-213

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Brake Lifting Bracket (24H Motor Grader)

Model Usage: 24H Motor Grader

European Union compliant, CE marked

Reference

Warranty: Caterpillar ^®Six Months

• Used to remove and install brake group

• KENR6023 Disassembly and Assembly

(brakes do not have to be released prior to

Manual, 24M Motor Grader Power Train

installation when using this bracket)

• NEHS1095 Tool Operating Manual: 132-5136

• Used with overhead lifting device

Brake Lifting Bracket

• Bracket easily attaches to brake group and is

Specifications

held securely in place with one lug nut

• Length: 560 mm (22.0 in)

• Bracket can be installed without brake halves

• Height: 460 mm (18.1 in)

being oriented

• Weight: 12.25 kg (27 lb)

• Bracket holds brake group in a horizontal

position making removal and installation

• Working load limit: 998 kg (2200 lb)

much faster and easier

• Proof test load: 1996 kg (4400 lb)

• Each lifting bracket comes with a certificate

of proof testing

Part Number

Description

132-5136

Brake Lifting Bracket (24H Motor Grader)

Seal Driver

Model Usage: CB534, CB534B, CB534C, CB535,

• Used to properly install 140-8409 and

• Driver installs seals with housing in vehicle,

CB634, CB634C, and CS431 Compactors

140-8410 Seals into housing of the eccentric

getting around hard-to-reach areas

group

Warranty: Caterpillar ^®Six Months

Reference

• Eliminates possibility of seal damage caused

• Service Manual, Disassembly and Assembly

by hammer and punch (provides proper depth

of Eccentric Group

and uniform fit)

• Use one end of driver to install seal flush with

Specifications

housing, and other end of driver to install seal

• Outside diameter: 101.6 mm (4.00 in)

to a depth of 10.0 mm (0.39 in)

• Inside diameter: 55.6 mm (2.19 in)

• Length: 182.4 mm (7.18 in)

Part Number

Description

141-3028

Seal Driver

7-214 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Adapter Bracket Assembly

Essential Tool

European Union compliant, CE marked

Reference

(151-7537)

Model Usage: CS/CP 533C, CS/CP 563C, CS583C

• KENR7009 Service Manual, Compactor

Vibratory Compactors

• Used to safely remove and install compactor

Disassembly and Assembly

pods

Warranty: Caterpillar ^®Six Months

Specifications

Lifting Bracket

• 150-3978 Lifting Bracket Assembly:

• Uses different adapter plates for various

- Maximum capacity: 907 kg (2000 lb)

applications

- Height: 1014 mm(40.0 in)

- Maximum depth: 1089 mm (43.0 in)

• Adjustable center of gravity

- Minimum depth (without adapters):

• Adapter Plate

820 mm (32.0 in)

• Heat-treated for added strength and durability

- Adjustable center of gravity: 197.0 -

1089 mm (7.75 - 43.0 in) inside clearance

• Fits intricate profile of pods

• 151-7537 Adapter Bracket Assembly:

• Locking pads secure pod to adapter

- Overall dimensions: 500 x 630 x 229 mm

(20.0 x 25.0 x 9.0 in)

Part Number

Description

150-3978

Lifting Bracket

151-7537

Adapter Plate

Eccentric Weight Removal Tools for Vibratory Compactors

Essential Tool

European Union compliant, CE marked

306-9603 Adapter Assembly

Model Usage: CB-434D (CNH1-Up) Vibratory

• Used to remove and install various compactor

• Used on CB-434D, CS-563E, and CP-563E

Asphalt Compactor, CB-534D (CNH1-Up)

drum eccentric weight housings

Vibratory Compactors

Vibratory Compactor, CS-563E (CNG1-Up)

• Connects to 306-3351 C-frame Assembly with

306-3351 C-Frame Assembly

Vibratory Soil Compactor, CP-563E (CNT1-Up)

lock bolt

Vibratory Soil Compactor, CB-564D (C6D1-Up)

• Used with adapter assemblies for various

• Fits profile of eccentric weights

Vibratory Compactor

applications

• A 099-0169 Bolt secures eccentric weight to

Warranty: Caterpillar ^®Six Months

• Use with an approved shackle

adapter

• Adjustable center of gravity

Reference

• 7X-0328 Bolt, 5P-1076Washer, and 6V-8188

Nut are used to attach adapter assemblies

• KENR3614 Disassembly and Assembly

Manual, CB-534D, CB-534D Series XW,

306-3352 Adapter Assembly

and CB-564D Vibratory Compactor Machine

• Usedon CB534D, CB534D series XW,and

Systems

CB-564D Vibratory Compactors

• NEHS1019 Tool Operating Manual; 306-3351

• Connects to 306-3351 C-frame Assembly with

C-Frame Lifting Assembly

alock bolt

• NEHS1020 Tool Operating Manual; 306-3352

• Fits profile of eccentric weights

C-Frame Adapter, 306-9603 C-Frame Adapter

• An 8T-7338 M16 Bolt secures eccentric

weight to adapter

306-3351

306-3352

306-9603

Working load limit

454 kg (1000 lb)

Weight

84 kg (185 lb)

7.6 kg (16.8 lb)

6.9 kg (15.4 lb)

Part Number

Description

306-3351

C-Frame Assembly

306-3352

Adapter Assembly

306-9603

Adapter Assembly

JULY 2018 Vehicle System Tools

7-215

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Lifting Bracket Assembly

Essential Tool

European Union compliant, CE marked

• Overall size: 82.25 x 72.39 cm

Model Usage: CB-434D, CB-534D, CB-534D

• Used to remove and install compactor drum

• Adjustable center of gravity: 38.1 mm (1.50 in)

Series XW, CB-564D Compactor

support plates and final drive

to 68.58 cm (27.00 in)

Warranty: Caterpillar ^®Six Months

• Used with overhead lifting device, suitable

Reference

shackle, dealer-supplied grade 8 bolt/washer

• KENR3614 Disassembly and Assembly,

• Adjustable center of gravity to balance load

CB-534D, CB-534D Series XW, and CB-564D

for alignment during installation

Vibratory Compactors Machine Systems

Specifications

• Maximum capacity: 454 kg (1000 lb)

Part Number

Description

232-0228

Lifting Bracket Assembly

Essential Tool

European Union compliant, CE marked

• A three-hole shackle mounting plate allows

adjustable center of gravity, to balance load

Model Usage: CB54, CB54 Series XW, and CB64

• Used to remove and install compactor drum

during installation

Vibratory Compactor

support plates and final drive

Warranty: Caterpillar ^®Six Months

• Used with 7X-2581 Bolt - M30 x 100 mm

Reference

(4.0 in) long, 9X-8258 Washer - M30, and

• NEHS1088, Tool Operating Manual, 345-1236

two guide bolts (all dealer supplied)

Lifting Bracket

• Boltand washerare used toattach lifting

• KENR5997, CB54, CB54 Series XW, and CB64

bracket to compactor drum support plate

Vibratory Compactor

• A suitable overhead lifting device and

Specifications

189-0410 Screw Pin Shackle are required

• Working load limit: 567 kg (1250 lbs)

to support and raise lifting bracket and

• Overall size (L x H x W): 387.4 x 409.6 x

compactor drum support plate

95.2 mm (16.12 x 15.25 x 3.75 in)

• Durable welded steel construction

• Weight: 12 kg (26.0 lbs)

Item with no Part Number

Description

Qty.

Guide Bolt (Not shown)

Item

Part Number

Description

Qty.

345-1236

Lifting Bracket

Bolt,M30 x 100 mm

7X-2581

(3.94) length

9X-8258

Washer

Not shown

Required

189-0410

Shackle (4.75 ton)

Lifting Bracket Assembly

Model Usage: 320, 322, 325, 330, 336, 345, 349

European Union Compliant, CE marked

• NEHS1163 Tool Operating Manual

Warranty: Caterpillar ^®Six Months

• Used to aid in moving the cover (9Q-5696 and

• RENR8648 330D, 336D and 340D Excavators

149-3577) to and from final drive

and 336D MHPU Mobile Hydraulic Power Unit

• Easy to install

Machine

• Material: Steel

Specifications

References:

• Dimensions: 226.5 x 171.6 mm (8.91 x 6.75 in)

• KENR8182 325VM Variable Gauge

• Working Load Limit (WLL): 61.2 kg (135 lb)

Undercarriage

• Weight: 2.34 kg (5.18 lb)

Part Number

Description

417-6239

Lifting Bracket Assembly

7-216 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Lift Adapter Assembly

Essential Tool

European Union compliant, CE marked

• Overall size: 1066 x 228 x 370 mm (42.0 x 9.0

x 14.5 in)

Model Usage: CP434D and CS434D Compactor

• Used to remove eccentric weight housing

without removing drum

• Angle of lift arm: 80 degrees

Warranty: Caterpillar ^®Six Months

• Used with 150-3978 Lifting Bracket Assembly

• Maximum weight load limit: 200 kg (440 lb)

Specifications

• Maximum reach (with 150-3978): 187 cm

(74.0 in)

Part Number

Description

231-7699

Lift Adapter Assembly

Spanner Wrench

Essential Tool

• Used to remove and install 267-5641 Nut,

• Used with 206-8796 Torque Multiplier, 1 1/2

which is part of 303-8755 Eccentric Weight

inch square drive

Model Usage: CB-534D, CB-534DXW Vibratory

Group

Compactor

• Teeth are hardened to handle high torque

• 40.7 cm (16.0 in) diameter tool with six

from multiplier

Warranty: Caterpillar ^®Six Months

equally-spaced teeth to securely engage

• Made from durable, welded-steel construction

special nut

with black oxide coating for corrosion

resistance

Part Number

Description

347-1694

Spanner Wrench

Seal Installer, Seal Guide

Essential Tool

• Used to properly install 126-9339 Seals into

• Guide seals over shaft and wear sleeve to

housing of eccentric group

provide proper fit without damage to seal and

Model Usage: CS531, CS533, CS563, CS583,

prevents seal from rolling

CP533, and CP563 Compactors

• Eliminates seal damage caused by hammer

and punch installation method (provides even

Warranty: Caterpillar ^®Six Months

Reference

installation pressure and uniform fit)

• KENR7009 Compactor Machine Systems

• Guide centers housings for pod assembly to

Disassembly and Assembly Manual

ensure proper bearing alignment

Part Number

Description

Length

Outside Diameter

157-2378

Seal Installer

101.6 mm (4.00 in)

61 mm (2.4 in)

158-0511

Seal Guide

128mm (5.0in)

45 mm (1.7 in)

Spanner Socket

Essential Tool

• Used to remove and install pinion spanner nut

Specifications

without damage

Model Usage: PF290B, PS360B Pneumatic

• Length: 179 mm (7.0 in)

Compactors

• Used with 1 inch square drive impact or

• Outside diameter: 167 mm (6.6 in)

torque wrench

Warranty: Caterpillar ^®Six Months

Square drive: 1 in

•

• Heat-treated to increase durability and tool

• Between teeth: 131 mm (5.2 in)

life

• Tooth width: 11 mm (0.4 in)

Reference

• Tooth spacing: 4, equally spaced

• KENR7008 and KENR7018 Differential

Disassembly and Assembly Manuals

Part Number

Description

154-6179

Spanner Socket

JULY 2018 Vehicle System Tools

7-217

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Sleeve

Essential Tool

• Used to assemble fork assembly components

Reference

Model Usage: PS/PF300 and PS/PF300B

• Sleeve properly aligns guide on shaft

• KENR2705 Service Manual, PS300B/PF300B

Pneumatic Compactor Machine Systems

Warranty: Caterpillar ^®Six Months

Disassembly and Assembly

Part Number

Description

Overall Dimensions

163-1650

Sleeve

140.0 x 50.8 mm (5.51 x 2.00 in)

Bearing Puller Plate

Model Usage: D7R Track-Type Tractor

• Used to correctly remove old pivot shaft

• Hydraulic removal of bearings is preferred

bearings from tractor frame and install new

over other methods, such as burning, cutting,

Warranty: Caterpillar ^®Six Months

ones

or drilling

• Bearing puller plate has center swivel point

Specifications

for easy installation

• Overall outside diameter: 179.0 mm (7.05 in)

• Heat treated for added durability

• Small outside diameter: 170.9 mm (6.73 in)

• Hole diameter: 42.0 mm (1.65 in)

Part Number

Description

210-6670

Bearing Puller Plate

7-218 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Speed Sensor Gauge

Essential Tool

• Used to adjust travel motor speed sensor to

Reference

proper depth (refer to Special Instruction for

Model Usage: AP-1055B, BG-2455C Asphalt

• REHS0895 Special Instruction, Speed Sensor

specific procedure for using tool)

Pavers

Installation

• Faster and more accurate than other methods

Warranty: Caterpillar ^®Six Months

• REHS0894 Special Instruction, Speed Sensor

Installation

Part Number

Description

198-8732

Speed Sensor Gauge

Centering Spacer

Essential Tool

• Centering spacers are used to service tires in

Specifications

the field

Model Usage: CW34

• Diameter: 30 mm

• Spacers are required to help center the rim

Warranty: Caterpillar ^®Six Months

• Length: 19 mm

lugs to the hub during tire installation

• Weight: .06 kg

• Use 2 per package per machine

Part Number

Description

460-4918

Centering Spacer

JULY 2018 Vehicle System Tools

7-219

Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Puller Plate, Adapter Plate

Essential Tool

• Used to quickly and easily remove and install

Specifications

blade tip pins

Model Usage: 24H Motorgrader

• 154-7386 Puller Plate:

• Used with 9U-6751 Receiving Sleeve (33.0 cm

- Outside diameter: 97.5 mm (3.83 in)

Warranty: Caterpillar ^®Six Months

[12.99 in] long) or 9U-6752 Receiving Sleeve

- Thread: M30 x 3.5

(114.3 cm [45.0 in] long)

- Thickness: 40 mm (1.6 in)

- Bolt hole diameter: 18 mm (0.71 in)

• Saves time and eliminates destruction of pin

• 154-7387 Adapter Plate:

• Bolts directly onto pin in place of pin cap

- Outside diameter: 270 mm (10.6 in)

• Provides efficient means of pulling pin

- Inside diameter: 118 mm (4.6 in)

- Attaching bolts: 6V-5192 Socket Head Cap

• Chamfered end guides pin during installation

Screw

- Bolt quantity: 3

Part Number

Description

154-7386

Puller Plate

154-7387

Adapter Plate

Frame Bracket Assembly

Model Usage: MT735, MT745, MT755, MT765,

• Used to support front frame (in raised

• Used when:

MT835, MT845, MT855, and MT865 Gen 111

position)

- Changing rubber drive belts

Challenger Tractors

- Repositioning undercarriage row width

• Used with Twelve-Ton Support Stands

- Removing undercarriage from tractor

Warranty: Caterpillar ^®Six Months

• 2 required (bolts directly to front frame)

- During major service/repair work

Part Number

Description

203-5584

Frame Bracket Assembly

Service/Repair Parts

6V-8237

Hard Washer

8T-0664

Bolt, M24 x 3

8T-3282

Washer - Hard

8T-6430

Bolt, M20 x 2.5

Drill Fixture

Essential Tool

• Used to locate and repair damaged swing

Reference

drive mounting bolt holes and dowel holes

Model Usage: 345B and 345C Series II Excavator

• Technical Information Bulletin 4228-00

• Comes with two 16 mm (0.629 in) and two

Warranty: Caterpillar ^®Six Months

• REHS2415 Special Instruction

30 mm (1.181 in) pins (one set shown in the

storage position) and bushings

Part Number

Description

254-3424

Drill Fixture

Essential Tool

• Drill fixture is used to locate and repair

Specifications

damaged holes on the swing gear

Model Usage: 374D

• Diameter: 430 mm (16.9 in)

• Tool is used without removing the swing gear

Warranty: Caterpillar ^®Six Months

• Thickness: 45 mm (1.8 in)

- Tool kit includes the following hardwares:

- M24x3 bolts (qty-2), 6V-8198

- Eyebolt Assembly, 422-5471

- M8x1.25: Machine Screw, 095-7934

7-220 JULY 2018 Vehicle System Tools

IMPLEMENTS, FRAME, HITCH AND SUSPENSION

Torque Adapter

Essential Tool

• Used to remove and install 2 cab ROPS bolts

Specifications

located in front corners on cab floor

Model Usage: IT28G Integrated Toolcarrier

• Square drive: 3/4 in

Machines-Special Defense Products and

• Used with a 3/4 inch square drive 9U-5007

• Socket size: 30 mm, 12 point

Standard Production Units

Torque Wrench

•

Center-to-center distance from drive to socket:

Warranty: Caterpillar ^®Six Months

• Fits into limited clearance area where sockets

203.2 mm (8.00 in)

or other tools will not fit

• Essential for applying proper bolt torque

Part Number

Description

239-2296

Torque Adapter

Compressor Group

Essential Tool

• Used to install and remove 238-7693 Spring

• Lock pins on end of tool arms prevent spring

onoptional quick coupler arrangement

from ejecting during replacement procedure

Model Usage: 246C, 256C, 262C, 272C, 277C,

287C, and 297C Skid Steer Loaders

• Used with two, 12 mm wrenches to tighten

• Durablesteel construction

spring compression bolt

Warranty: Caterpillar ^®Six Months

Part Number

Description

312-2967

Compressor Group

Service/Repair Parts

149-0206

Hex Nut

5P-0372

LockPin

8T-0106

Bolt

8T-4223

Washer - Hard M12

Sleeve Assembly

Model Usage: 994D Wheel Loader; 994F Wheel

• Used to install and remove loader arm linkage

• Requires 6D-7726 Hydraulic Hose Assembly

Loader

pins

• Designed to clear newer style flag pins

Warranty: Caterpillar ^®Six Months

• Used with 350-7768 Hydraulic Pump

• Easily suspended with lifting loops

(115 VAC), 350-7769 Hydraulic Pump

• Durable, hardened-steel construction

(230 VAC), or 9U-6600 Hydraulic Hand Pump

Part Number

Description

323-7335

Sleeve Assembly

Canister Socket

Essential Tool

• Used to remove and install 241-3352 Filter

• Used on canister-style hydraulic filter, which

Housing

has a square socket on housing bottom

Model Usage: Wheel Loaders, Track-Type

Tractors, Pipelayers, and Motor Graders

• Used with 1/2 inch square drive wrench

• Socket is open on one end to clear drain plug

on filter housing

Warranty: Caterpillar ^®Six Months

Part Number

Description

320-6627

Canister Socket

7-222 JULY 2018 Vehicle System Tools

Caterpillar. Dealer service tools catalog (2018) - page 38
