Parker Variable Speed Drive AC30 series. User’s Manual (2017)

12-19

Ethernet

PTP Profile

Each PTP device has a set of attributes as define by IEEE1588-2008. On the inverter the default attributes values are set as follows. Note that
some may be modified by a parameter.

Attribute

Description

Inverter default value

Modified by parameter

domainNumber

A domain consists of one or more PTP devices
communicating with each other. Devices on the
same domain will have the same domain number.

1787 PTP Domain Number

slaveOnly

When

slaveOnly

is TRUE the PTP device may only

be a slave and not become a master clock.

FALSE

1684 PTP Clock Type

logAnnounceInterval

A port in the MASTER state will periodically transmit
an Announce message.
Announce messages will be transmitted such that the
logarithm to the base 2 of the mean value of the
interval in seconds between message transmissions
is the value of the

logAnnounceInterval

1
(2 seconds)

logSyncInterval

A port in the MASTER state will periodically transmit
a Sync message.
Sync messages will be transmitted such that the
logarithm to the base 2 of the mean value of the
interval in seconds between message transmissions
is the value of the

logSyncInterval

-1
(0.5 seconds)

1681 PTP Log Sync Interval

logMinDelayReqInterval

The

logMinDelayReqInterval

will specify the

minimum permitted mean time interval between
successive Delay_Req messages.
This value is determined and advertised by a master
clock based on the ability of the master clock to
process the Delay_Req message traffic.

announceReceiptTimeout

The value of

announceReceiptTimeout

will specify

the number of announceInterval that has to pass
without receipt of an Announce message

Ethernet

12-20

The following attributes are used to determine the best master clock. They are listed in order of precedence.

Attribute

Description

Inverter Default Value

Modified by parameter

priority1

Lower values of

Priority1

take precedence.

128

clockClass

Used to define a clock’s TAI traceability.

248 or
255 (slave only)

clockAccuracy

Indicates the expected accuracy of a clock. Given
as an enumerated value.

FEh

offsetScaledLogVariance

This defines the stability of the clock.

FFFFh
(not computed)

priority2

Lower values of

Priority2

take precedence.

128

1686 PTP Priority2

clockIdentity

The

clockIdentity

identifies a clock. The

clockIdentity is an 8-octet identifier created from the
Ethernet MAC address in the format:
First 3 octets – most significant octets of MAC
address
Next 2 octets – have values FFh and FEh
respectively
Last 3 octets – least significant octets of MAC
address

The clockIdentity is used as a tie-breaker for the
master clock.

0920 MAC Address

12-21

Ethernet

PTP PARAMETER SUMMARY

Note: The value of the PTP configuration parameters only become active when the PTP module initialises, i.e. on inverter power-up, on transition
of the parameter 1661 PTP Enable to TRUE or connection of one or more Ethernet cables.

Parameter Name

No.

Path

Default

Range

Units

Writable

PTP Enable

1661

Setup::Communications::PTP
Parameters::Base Comms::PTP

FALSE

TRUE

ALWAYS

PTP parameter.

Enables the precision time protocol.

PTP Clock Type

1684

Setup::Communications::PTP
Parameters::Base Comms::PTP

0: MASTER OR SLAVE

0:MASTER OR SLAVE

1:SLAVE ONLY

ALWAYS

PTP parameter.

Sets if the inverter can become a master or slave clock, or a slave clock only.

Enumerated values:

0: MASTER OR SLAVE

- the device clock will become a Master if it is determined to be the best master in a network,

otherwise it will become a Slave

1: SLAVE ONLY

- the device clock can only become a Slave

PTP Clock Mode

1683

Setup::Communications::PTP
Parameters::Base Comms::PTP

0:E2E

ALWAYS

PTP parameter.

Sets the PTP clock mode to either end-to-end (E2E) or peer-to-peer (P2P). See description in section

Advanced Users

for more

details. Note that currently E2E is only available.

Enumerated values:

0: E2E

PTP Domain
Number

1787 Setup::Communications::PTP

Parameters::Base Comms::PTP

0 to
127

ALWAYS

PTP parameter.
Sets the Domain Number of the inverter. A PTP device will only communicate with other PTP devices that have the same domain
number even if it is on the same physical network.

Ethernet

12-22

Parameter Name

No.

Path

Default

Range

Units

Writable

PTP Log Sync Interval

1681

Setup::Communications::PTP
Parameters::Base Comms::PTP

-1

-1 to

ALWAYS

PTP parameter.

Sets the Log Sync Interval. See description in section

Advanced Configuration

for more details. This parameter should be set to

the same value on all inverters using PTP.

PTP Priority2

1686

Setup::Communications::PTP
Parameters::Base Comms::PTP

128

0 to

255

ALWAYS

PTP parameter.

Sets the Priority 2 used as part of the process in determining which PTP device becomes the master clock. See description in
section

Advanced Configuration

for more details.

PTP Lock Threshold

1685

Setup::Communications::PTP
Parameters::Base Comms::PTP

0.5 us

0.1 us to

100 us

ALWAYS

PTP parameter.

Sets the Lock Threshold when the inverter is a slave clock. When the average offset between the slave clock and the master clock
falls below the Lock Threshold then the slave clock is deemed to be synchronised as indicated by the parameter 1688 PTP Locked.
Note that it will take longer for a slave clock to be deemed synchronised when a smaller threshold is set.

PTP State

1689

Monitor::Communications::PTP
Parameters::Base Comms::PTP

NONE

0:NONE

1:INITIALISNG

2:FAULTY

3:DISABLED

4:LISTENING

5:PRE-MASTER

6:MASTER

7:PASSIVE

8:UNCALIBRATED

9:SLAVE

NEVER

PTP parameter.

A diagnostic parameter indicating the state of the internal PTP state machine.

Enumerated values:

0: NONE

- the PTP module is disabled or the Ethernet cables are removed

1: INITIALISNG

- the PTP is initialising the data sets and communications

2: FAULTY

- the PTP module failed to initialise

12-23

Ethernet

Parameter Name

No.

Path

Default

Range

Units

Writable

3: DISABLED

- the PTP will not send any messages and will accept only PTP management messages

4: LISTENING

- the PTP is listening for Announce messages from a master or waiting to timeout on received announce

messages.

5: PRE-MASTER

- the PTP behaves as though it were in the MASTER state but will not send any messages except for

peer delay, signalling or management messages.

6: MASTER

- the PTP is behaving as a master

7: PASSIVE

- the PTP will not send any messages except for peer delay, signalling or management messages

8: UNCALIBRATED

- the PTP is in a transient state.

One or more master ports have been detected in the domain. The

appropriate master port has been selected, and the local port is preparing to synchronize to the selected

master port.

9: SLAVE

- the PTP is synchronizing or synchronized to a master

PTP Clock

1699

Monitor::Communications::PTP
Parameters::Base Comms::PTP

1970/01/01 00:00:00

NEVER

PTP parameter.

Diagnostic parameter giving the current value of the PTP clock to 1 second accuracy. Note this is not intended to represent the
actual date and time.

PTP Offset

1687

Monitor::Communications::PTP

Parameters::Base Comms::PTP

0 ns

-2000000000 to

2000000000

NEVER

PTP parameter.

Diagnostic parameter giving the average offset in nanoseconds between the PTP clock and the master clock.

PTP Locked

1688

Monitor::Communications::PTP
Parameters::Base Comms::PTP

FALSE

TRUE

NEVER

PTP parameter.

Diagnostic parameter indicating when the inverter is a slave that the PTP clock has synchronised to a master clock determined by
parameter 1685 PTP Locked Threshold. If the inverter is a master then this parameter will be set to TRUE.

12-25

Ethernet

PEER TO PEER PARAMETER SUMMARY

Note: The value of the Peer to Peer configuration parameters only become active when the Peer to Peer module initialises, i.e. on inverter power-
up or transition of the parameter 1725 Peer to Peer Enable to TRUE.

Parameter Name

No.

Path

Default

Range

Units

Writable

Peer to Peer Enable

1725

Setup::Communications::Peer to Peer
Parameters::Base Comms::Peer to Peer

FALSE

TRUE

ALWAYS

Peer to Peer Parameter.

Enables the Peer to Peer module.

Destination IP Address

1726

Setup::Communications::Peer to Peer
Parameters::Base Comms::Peer to Peer

255.255.255.255

0.0.0.0 to

255.255.255.255

ALWAYS

Peer to Peer Parameter.

Sets the destination IP address of the data when the Peer to Peer module is sending. If the Destination IP Address is set to 255.255.255.255 then
the sent data is broadcast and all listening inverters will receive the data.

Destination Port

1727

Setup::Communications::Peer to Peer
Parameters::Base Comms::Peer to Peer

1250

1 to

65535

ALWAYS

Peer to Peer Parameter.

Sets the UDP port number the Peer to Peer module sends data to. Normally this will be set the same as the Local Port.

Local Port

1728

Setup::Communications::Peer to Peer
Parameters::Base Comms::Peer to Peer

1250

1 to

65535

ALWAYS

Peer to Peer Parameter.

Sets the UDP port number the Peer to Peer module receives the data on. Normally this will be set the same as the Destination Port.

Peer to Peer State

1729

Monitor::Communications::Peer to Peer
Parameters::Base Comms::Peer to Peer

DISABLED

ACTIVE

ERROR

NEVER

Peer to Peer Parameter.

A diagnostic parameter indicating the state of the Peer to Peer module.

Enumerated values:

0: DISABLED

- the Peer to Peer module is disabled.

1: ACTIVE

- the Peer to Peer module is enabled and ready for communications.

2: ERROR

- the Peer to Peer module is in an error state and communications could not be established.

Fire Mode

13-1

Chapter 13:

Fire Mode

Caution

When Fire Mode is active the Drive and Motor protection trips are disabled. The use of Fire Mode itself increases the risk of causing a fire by

overloading the drive or motor, so it must only be used after assessing the risks.

Intended Use

Fire mode is intended for use in critical situations where it is imperative for the motor to be kept running if at all possible. In such a situation it may be

reasonable to override the drive’s normal protective functions. An example of a critical situation may be a ventilation fan in a stairwell, where

continued operation in the event of a fire may assist the safe evacuation of personnel.

Summary

When Fire Mode is enabled the drive firmware attempts to keep the drive running wherever possible. If the drive was running when Fire Mode was

activated it will continue to run. If the drive was stopped when Fire Mode was activated then the Fire Mode firmware will attempt to start it. While Fire

Mode is enabled the majority of trips will be ignored, (possibly leading to damage to the drive, motor or attached equipment). If one of the remaining

enabled trips does occur then the Fire Mode firmware will wait until the trip source has become inactive and will then restart the drive.
When Fire Mode is deactivated the drive will return to its previous sequencing mode. If the drive was running in Local mode the motor will be

stopped. If the drive was running in remote terminals or remote communications mode the drive will continue running according to the relevant

control word, (refer to Appendix B).

13-2

Fire Mode

Configuration

The parameters used to configure Fire Mode are detailed in Appendix D. This description is partially duplicated here for convenience.

PNO*

Parameter Descriptions

Activate

A Boolean input. Set to TRUE to enable Fire Mode according to the Fire Mode parameter. This input parameter may only be set by

connection to a digital input.
Default value FALSE

1961*

Setpoint

A reference value to be used when Fire Mode is active. Setting a negative setpoint will cause the drive to rotate in reverse direction.
Default value 0.0%. Range -100% to 100%

1962*

Level

An enumerated input parameter. Selects the mode of operation when Fire Mode is enabled

0. DISABLED

1. PARTIAL

2. FULL

Default value is DISABLED.

1963*

Restart Delay

Specifies the time to wait before attempting to reset a trip.

1964*

Activated

A Boolean output that indicates when Fire Mode is active. This is TRUE when

Level

is either PARTIAL or FULL, the

Setpoint

is not

0.0% and

Activate

is TRUE.

1965*

Enabled

A Boolean output that indicates when Fire Mode will be activated if

Activate

is set TRUE. This is TRUE when

Level

is either

PARTIAL or FULL and the

Setpoint

is not 0.0%.

1966*

Last Activated

A Data and Time output parameter that records the last time that the fire mode became active. This may be used to validate that

the fire mode has been tested. This value is recorded in non-volatile memory. The value will be reset if an application is loaded that

does not implement Fire Mode.

1967*

Activation Count

An integer output parameter that records the number of times the fire mode has become active. This value is saved in non-volatile

memory. The activation count will be reset if an application is loaded that does not implement Fire Mode.



These PNO values are correct for the Fan Application. Custom configurations may assign the Fire Mode parameter to different PNOs.

Fire Mode

13-3

Functional Description

When Fire Mode is enabled the normal speed reference and start / stop control of the drive are modified.

Sequencing

Sequencing is the term given to controlling when the drive runs. When Fire Mode is enabled the normal sequencing control signals are over-ridden.

The parameters that control this are

Activate

Setpoint

Level

PNO 0610

Sequencing::App Control Word bit 0, Switch On, (refer to Appendix B:Sequencing Logic). In typical applications bit 0 of the App

Control Word is driven from a digital input, used as a Coast Stop signal.

Level

is set to DISABLED or

Setpoint

is zero then setting

Activate

to TRUE will have no effect.

Level

is set to either PARTIAL or FULL and

Setpoint

is not zero then setting

Activate

to TRUE will activate Fire Mode. When Fire Mode is active

the drive will run, (turn the motor).

The only reasons that the drive will not run are:



Level

is changed back to DISABLED



Activate

is changed back to FALSE



Setpoint

is change to zero



The Coast Stop input is activated.



The STO circuit is activated.



An enabled trip source becomes active.



A hardware fault

Reference

The Fire Mode

Setpoint

parameter is selected automatically whenever Fire Mode is

Activated

. The Setpoint is passed through the System Ramp,

(see Appendix D).

Caution

Fire Mode does not override the standard Ramp features. Specifically

0497 Ramp Hold

can prevent the setpoint changing to

the Fire Mode

Setpoint

value.

13-4

Fire Mode

TRIPS AND AUTO RESTART

The following table summarizes which trips are disabled in the two modes of operation. Also shown are those trips which are designed to protect the

drive.

Trip Name

Disabled in Partial mode

Disabled in Full mode

Drive Protection

OVER VOLTAGE



UNDER VOLTAGE

(1)

Note 1

OVER CURRENT



STACK FAULT



STACK OVER CURRENT



CURRENT LIMIT



MOTOR STALL



INVERSE TIME



MOTOR I2T



LOW SPEED I



HEATSINK OVERTEMP



AMBIENT OVERTEMP



MOTOR OVERTEMP



EXTERNAL TRIP



BRAKE SHORT CCT



BRAKE RESISTOR



BRAKE SWITCH



LOCAL CONTROL



COMMS BREAK



LINE CONTACTOR



PHASE FAIL



VDC RIPPLE



Caution

Disabling the Drive Protection trips will invalidate the drive’s warranty. Selecting PARTIAL mode leaves the drive protection

features enabled. Selecting FULL mode disables some of the drive protection features.

Caution

Regardless of the setting of

Level

, activating Fire Mode may cause damage to the motor or attached equipment.

Fire Mode

13-5

Trip Name

Disabled in Partial mode

Disabled in Full mode

Drive Protection

BASE MODBUS BREAK



24V OVERLOAD



PMAC SPEED ERROR



OVERSPEED



SAFE TORQUE OFF

Note 1. The Under Voltage trip is enabled when Fire Mode is active, but the trip level is reduced by 50%.

If a trip source becomes active when the associated trip is disabled the drive will continue to run. This is also the normal behavior of the drive, (when

Fire Mode is not active). If the associated trip is designed for drive protection, this will be recorded in non-volatile memory. The recorded values are

available to view in the Trips History parameter block, (refer to Appendix D).

When Fire Mode is activated and a trip source becomes active and the associated trip is enabled, the drive will trip, causing the motor to stop. This

is similar to the normal behavior of the drive, (when Fire Mode is not active). However, when Fire Mode is active the drive firmware continues to

monitor the trip source, once the trip source has become inactive the drive automatically resets the trip condition and restarts the drive.

The Fly catching feature can be used to allow the drive to smoothly resume control of a moving load on restart.

Motor Control Modes

The operation of Fire Mode is independent of the motor type motor and the control mode, (Open Loop or Sensorless Vector control).

A-1

Fieldbuses

Appendix A:

Fieldbuses

Modbus TCP

INTRODUCTION

The inverters built-in Ethernet includes a Modbus TCP server. The Modbus registers are mapped to the inverters parameters. Up to 3
simultaneous connections to Modbus clients are possible. TCP port 502 is used.

Making a connection to the Ethernet and setting an IP address on the inverter is described in Chapter 12 (Ethernet). If the Modbus TCP is used
as part of a process control it is recommended a dedicated network be used with fixed IP addresses for the inverter.

To allow Modbus TCP connections to the inverter, the parameter

0939 Maximum Connections

must be set to a value greater than zero.

Modbus Register Mapping Summary

The inverter parameters are mapped to the Holding Registers and Input Registers, either as a fixed mapping or as a user-defined mapping.
There is no mapping to Coils or Discrete Inputs.

Holding Register Address

Input Register Address

Description

00001 - 00256

User-defined mapping to the inverter parameter values.

00257 - 00528

Reserved area.

Do not write into this register range.

00529 - onwards

Fixed mapping to the inverter parameter values.

Fieldbuses

A-2

FIXED PARAMETER MAPPING

Each parameter number is mapped onto

two

consecutive Modbus registers regardless of the parameter data type. The relationship between the

Holding Register or Input Register is given as:

Register number = (parameter number - 1) * 2 + 529

•

If the parameter has a data type that uses one byte then it will occupy the low byte of the first register and the high byte will be zero, i.e. the
register will not be sign extended.

•

If the parameter has a data type that uses two bytes then it will occupy the first register.

•

Unused register locations will read zero; writing to that location will have no effect.

•

The word order of 32-bit parameters is determined by the inverter parameter

0940 High Word First

•

Writable 32-bit parameters will only accept a change in value if

both

registers mapped to the parameter are written to in the same request.

Fixed Parameter Mapping - Arrays

Some parameters have multiple elements and are classified as parameter arrays. A parameter array has a parameter number that represents
the

whole

of the array, but also has parameter numbers that represent each

element

of the array. An example is given below.

Array Example

A parameter array called

Recent Trips

has 10 elements.

Parameter Number

Parameter – Recent Trips

895

Whole array

896

index 0

897

index 1

905

index 9

If the parameter number of the whole array is 895, then the parameter number of the element index 0 of the array will be 896, the parameter
number of the element index 1 will be 897, etc.

Note:

String

array parameters access their elements via parameter numbers that are calculated in a different way (see Fixed Parameter Mapping

- Strings).

Accessing the parameter arrays via the parameter number that represents the whole array is not recommended. This will access only the first
four bytes (2 registers) of the array. The array should rather be accessed via its elements.

A-3

Fieldbuses

Fixed Parameter Mapping - Strings

Strings parameters have a parameter number that represents the whole string. This parameter number is mapped to two registers so limits
access to the first four characters. Additional contiguous parameter numbers are set aside so that the whole string can be accessed: one
additional parameter number for each four characters. The strings are packed into the registers

low byte first

String Example

A string parameter called

My String

has a string length of 12 characters (plus the null terminator). This will have one parameter number allocated

for the whole string (in this example 161) and 3 further parameter numbers for the string fragments (162-164).

If the value of the string is “0123456789AB”:

Parameter
Number

Represents

Register Value

hi-byte

lo-byte

0161

whole string

“0123456789AB”

00849

‘1’

‘0’

00850

‘3’

‘2’

0162

Fragment

“0123”

00851

‘1’

‘0’

00852

‘3’

‘2’

0163

fragment

“4567”

00853

‘5’

‘4’

00854

‘7’

‘6’

0164

fragment

“89AB”

00855

‘9’

‘8’

00856

‘B’

‘A’

Note: This is example is not a real parameter.

As each inverter parameter maps to two registers, if the registers that represent the whole string are accessed then only the first four characters
will appear. To access the whole string over Modbus use the registers that map to the parameter number of the whole array plus one, in this
example

0162

(register

00851

). A multiple read or write of registers will then provide access to the whole string.

Fieldbuses

A-4

String Array Example

A string array parameter called

My String Array

has 2 elements of string length 5 characters (plus the null terminator) each. In this example the

parameter number of the whole array is 175.

If the values of the array elements are “12345” and “abc”:

Parameter
Number

Represents

Register Value

hi-byte

lo-byte

0175

whole array

[“12345”, “abc”]

00877

‘2’

‘1’

00878

‘4’

‘3’

0176

element

“12345”

00879

‘2’

‘1’

00880

‘4’

‘3’

0177

fragment

“1234”

00881

‘2’

‘1’

00882

‘4’

‘3’

0178

fragment

“5”

00883

null

‘5’

00884

undefined

0179

element

“abc”

00885

‘b’

‘a’

00886

null

‘c’

0180

fragment

“abc”

00887

‘b’

‘a’

00888

null

‘c’

0181

fragment

“”

00889

undefined

00890

undefined

Note: This example is not a real parameter.

To access the first element of the array over Modbus then parameter number

0177

(register

00881

) would be used. To access the second element

then parameter number

0180

(register

00887

) would be used.

Parker Variable Speed Drive AC30 series. User’s Manual (2017) - page 13
