SANY Crawler Hydraulic Excavator (SY195C9, SY205C9, SY215C9, SY225C9). Shop Manual (2013) - page 25





Troubleshooting
H-15 Travel speed is low
Trouble
Ɣ Machine travel speed is low.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Travel control lever
Pilot valve output pressure
Malfunction of travel
1
Forward
3.5~3.9 MPa
pilot valve
Reverse
{ 36~40 kg/cm²}
Difference occurs between left and
”0.4 MPa
right output
”{4 kg/cm²}
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Malfunction of pilot
Control lever
Control circuit source pressure
2
relief valve
3.5~3.9 MPa
All levers in "NEUTRAL"
{ 36~40 kg/cm²}
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Travel speed
Travel control lever
Reading on monitor
3.5~3.9 MPa
3
Failure of sensor
Lo
Operated
{ 36~40 kg/cm²}
3.5~3.9 MPa
Hi
Operated
{ 36~40 kg/cm²}
Check the sensor by replacing it with another one.
Malfunction of travel
4
Spool of travel control valve may have malfunction. Check it directly.
control valve (spool)
Malfunction of travel
The makeup valve in travel control valve may have malfunction. Check
5
control valve (make-
it directly.
up valve)
Stop the engine. Perform troubleshooting while the engine is running at
Failure of travel mo-
high idle.
6
tor
Travel control lever
Oil leakage of travel motor
Travel relief
27.2 ml/min
Final drive may have internal defect. Check it directly.
Ɣ Internal defect of the final drive can be determined through abnor-
7
Failure of final drive
mal noise, abnormal heat, and metal powder or debris contained in
the oil drained.
7-111
Troubleshooting
H-16 Machine is not steered well or steering power is low
Trouble
Ɣ Machine is not steered well or steering power is low
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is
running at high idle.
Malfunction of travel pilot
Travel control lever
Pilot valve output pressure
1
valve
Both sides in "NEUTRAL"
0 {0}
3.5~3.9 MPa
Either side operated
{ 36~40 kg/cm²}
Ɣ Stop the engine. Perform troubleshooting while the engine is
running at high idle.
Travel control lever
Solenoid valve output pressure
Malfunction of travel pilot
2
3.5~3.9 MPa
Both sides operated
pressure sensor
{ 36~40 kg/cm²}
3.5~3.9 MPa
Either side operated
{ 36~40 kg/cm²}
Malfunction of travel
Spool of travel control valve may have malfunction. Check it direct-
3
control valve (spool)
ly.
Malfunction of travel
The makeup valve in travel control valve may have malfunction.
4
control valve (makeup
Check it directly.
valve)
Seal of relief valve in travel motor may be defective. Check it di-
Failure of travel motor
rectly.
5
(relief valve)
Ɣ The failure of seal can be determined by swapping the front
and back motors or the left and right motors.
Seal of check valve in travel motor may be defective. Check it di-
Failure of travel motor
rectly.
6
(check valve)
Ɣ The failure of seal can be determined by swapping the front
and back motors or the left and right motors.
7-112
Troubleshooting
H-17 Travel speed cannot be changed
Trouble
Ɣ Travel speed cannot be changed.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Solenoid valve output
Malfunction of travel
Travel speed
Travel control lever
pressure
1
speed shifting solenoid
Lo
Operated
0 {0}
valve
3.5~3.9 MPa
Hi
Operated
{ 36~40 kg/cm²}
Failure of travel motor (in
Speed shifting assembly of travel motor may have malfunction.
2
speed change)
Check it directly.
7-113
Troubleshooting
H-18 Travel system fails (only at one side)
Trouble
Ɣ One side of the tracks cannot make a turn.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Defective seat of travel
Seat of makeup valve in travel control valve may have malfunction.
1
control valve (makeup
Check it directly.
valve)
Defective seat of travel
Seat of relief valve in travel control valve may have malfunction.
2
motor (relief valve)
Check it directly.
Defective seat of travel
Seat of check valve in travel motor valve may have malfunction.
3
motor valve (makeup
Check it directly.
valve)
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Speed of travel motor
4
Travel control lever
Leakage from travel motor
drops.
Travel relief
27.2 ml/min
Final drive may have internal defect. Check it directly.
Ɣ Internal defect of final drive can be determined with abnormal
5
Failure of final drive
noise, overheat, and metal powder or debris contained in the oil
drained.
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Travel control lever
Pilot valve output pressure
Defective pilot pressure
Forward
3.5~3.9MPa
6
sensor
Reverse
{ 36~40 kg/cm²}
Difference occurs between left and
0.4 MPa {4 kg/cm²}
right output
Check it with swapping method.
7-114
Troubleshooting
H-19 Swing operation fails
Trouble (1)
Ɣ Upper structure fails to swing in either direction.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Malfunction of swing
1
Parking brake of swing motor may have malfunction. Check it directly.
motor (parking brake)
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Improper adjustment
Swing control lever
Swing relief pressure
or malfunction of
25.5~28.5 MPa
2
Swing relief
swing motor (relief
{260~291 kg/cm²}
valve)
If oil pressure does not become normal after adjustment, swing motor
relief valve may have malfunction or internal defect. Check the relief
valve directly.
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
3
Failure of swing motor
Swing control lever
Leakage from swing motor
Swing relief
•10 ml/min
Swing mechanism may have internal defect. Check it directly.
Failure of swing
Ɣ Internal defect of swing mechanism can be determined with ab-
4
mechanism
normal noise, overheat, and metal powder or debris contained in
the oil drained.
7-115
Troubleshooting
Trouble (2)
Ɣ Upper structure only fails to swing in one direction.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Malfunction of pilot
Left control lever
Pilot valve output pressure
1
valve
"NEUTRAL"
0 {0}
Swing
•3.5MPa {•36 kg/cm²}
Malfunction of swing
2
Spool of swing control valve may have malfunction. Check it directly.
control valve (spool)
Defective seal of
Seal of makeup valve in swing motor may have defect. Check it directly.
3
swing motor (makeup
Ɣ Failure of the seal can be determined by swapping the right and left
valve)
makeup valves and check for any changes.
7-116
Troubleshooting
H-20 Swing acceleration poor or swing speed low
Trouble (1)
Ɣ Swing acceleration is poor, or swing speed is low.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Malfunction of swing
1
Parking brake of swing motor may have malfunction. Check it directly.
motor (parking brake)
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Swing control lever
Swing relief valve
Improper adjustment
or malfunction of
25.5~28.5 MPa
2
Swing relief
swing motor (relief
{260~291 kg/cm²}
valve)
If oil pressure does not become normal after adjustment, swing motor
relief valve may have malfunction or internal defect. Check the relief
valve directly.
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Failure of swing mo-
3
Swing control lever
Leakage from swing motor
tor
Swing relief
”10 ml/min
Clogging of brake
4
Disassemble, clean and check.
control lines
7-117
Troubleshooting
Ɣ Swing acceleration is only poor on one side, or swing speed is
Trouble (2)
low.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Malfunction of pilot
Swing control lever
Pilot valve output pressure
1
valve
"NEUTRAL"
0 {0}
Left swing
•3.5MPa {•36 kg/cm²}
Right swing
Malfunction of swing
Pressure compensation valve of swing motor may have malfunction.
2
motor (pressure com-
Check it directly.
pensation valve)
Seal of makeup valve in swing motor may have defect. Check it di-
Defective seal of swing
rectly.
3
motor (makeup valve)
Ɣ Swap the left and right makeup valves and observe the result in
order to determine whether the seal fails.
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
One-side leakage of
Swing control lever
Pilot valve output pressure
4
swing pilot pressure
"NEUTRAL"
0 {0}
sensor (shuttle valve)
Left swing
3.5~3.9MPa {36~40 kg/cm²}
Right swing
7-118
Troubleshooting
H-21 Upper structure overruns remarkably when it stops swinging
Ɣ Upper structure overruns remarkably when it stops swinging in
Trouble (1)
both directions.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Swing control lever
Swing relief pressure
Improper adjustment
25.5~28.5 MPa
1
or malfunction of swing
Swing relief
{260~291 kg/cm²}
motor (relief valve)
If oil pressure does not become normal after adjustment, swing motor
relief valve may have malfunction or internal defect. Check the relief
valve directly.
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
2
Failure of swing motor
Control lever
Leakage from swing motor
Swing relief
”10 ml/min
Trouble (2)
Ɣ Swing acceleration is only poor on one side, or swing speed is low.
Ɣ Set the working mode at gear (10) of power mode (S) to perform
Related information
troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is
running at high idle.
Swing control lever
Pilot valve output pressure
1
Malfunction of pilot valve
"NEUTRAL"
0 {0}
Left swing
•3.5MPa {•36 kg/cm²}
Right swing
Malfunction of swing con-
Spool of swing control valve may have malfunction. Check it direct-
2
trol valve (spool)
ly.
Seal of makeup valve in swing motor may be defective. Check it
Malfunction or defec-
directly.
3
tive seal of swing motor
Ɣ Swap the left and right makeup valves and observe the result
(makeup valve)
in order to determine whether the seal fails.
7-119
Troubleshooting
H-22 Large shock is produced when upper structure stops swinging
Trouble
Ɣ Large shock is produced when upper structure stops swinging.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Ɣ Stop the engine. Perform troubleshooting while the engine is run-
ning at high idle.
Swing control lever
Pilot valve output pressure
Malfunction of swing
1
pilot valve
"NEUTRAL"
0 {0}
Left swing
•3.5MPa {•36 kg/cm²}
Right swing
Reverse prevention valve of swing motor may have malfunction.
Malfunction of swing
Check it directly.
2
reverse prevention
Ɣ Replace the valve with a new on in order to determine whether the
valve
valve fails.
Malfunction of swing
3
Swing relief valve may be worn or sluggish.
relief valve
H-23 High noise is produced when upper structure stops swinging
Trouble
Ɣ High noise is produced when upper structure stops swinging.
Ɣ Set working mode to (S) and fuel control dial at position (10) to
Related information
carry out troubleshooting.
Cause
Standard value in normal state/Remarks on troubleshooting
Malfunction of back
1
Back pressure valve may have malfunction. Check it directly.
pressure valve
Malfunction of swing
2
Relief valve of swing motor may have malfunction. Check it directly.
motor (relief valve)
Seal of makeup valve in swing motor may have malfunction. Check it
Malfunction of swing
directly.
3
motor (makeup valve)
Ɣ Swap the left and right makeup valves and observe the result in
order to determine whether the seal fails.
The swing mechanism is suspected of an internal failure. Check the
inside of the machinery itself.
Failure of swing mecha-
4
Ɣ Internal defect of swing mechanism can be determined with ab-
nism
normal noise, overheat, and metal powder or debris contained in
the oil drained.
7-120
Troubleshooting
H-24 Swing drift excessive
Ɣ Hydraulic drift of swing is large (when swing holding brake is ap-
Trouble (1)
plied).
Ɣ When swing lock switch is turned ON or when swing holding
Related information
brake release switch is in normal position, swing holding brake
operates and upper structure is fixed with disc brake.
Cause
Standard value in normal state/Remarks on troubleshooting
Failure of swing hold-
Swing holding brake control lines and holding brake pilot valve may be
1
ing brake control lines
defective. Check them directly.
Malfunction of swing
2
Parking brake of swing motor may have malfunction. Check it directly.
motor (parking brake)
Ɣ Hydraulic drift of swing is large (when swing holding brake is re-
Trouble (2)
leased).
Ɣ When swing holding brake release switch is in release position,
Related information
swing holding brake is released and upper structure is secured
by only hydraulic pressure.
Cause
Standard value in normal state/Remarks on troubleshooting
Malfunction or defec-
Swing control valve spool may have malfunction or defective seal.
1
tive seal of swing
Check it directly.
control valve (spool)
Failure of swing motor
2
Seal of relief valve in swing motor may be defective. Check it directly.
(relief valve)
Failure of swing motor
Seal of makeup valve in swing motor may be defective. Check it di-
3
(makeup valve)
rectly.
7-121
Disassembly and Assembly
Disassembly and Assembly
8 Disassembly and Assembly
8.1
How to Read This Manual
8-5
8.1.1 Removing and Installing an Assembly
8-5
8.1.2 Disassembling and assembling an assembly
8-5
8.1.3 Special tools
8-5
8.2.1 The symbols used in this section
8-6
8.2
Operating Precautions
8-6
8.3
Start Motor AS - Remove and Install
8-10
8.3.1 Removal
8-10
8.3.2 Installation
8-10
8.4
Injection Pump AS - Remove and Install
8-11
8.4.1 Removal
8-11
8.4.2 Installation
8-13
8.5
Engine Front Seal - Remove and Install
8-15
8.5.1 Removal
8-15
8.5.2 Installation
8-15
8.6
Engine Rear Seal - Remove and Install
8-16
8.6.1 Removal
8-16
8.6.2 Installation
8-17
8.7
Cylinder Head AS - Remove and Install
8-18
8.7.1 Removal
8-18
8.7.2 Installation
8-22
8.8
Radiator AS - Remove and Install
8-24
8.8.1 Removal
8-24
8.8.2 Installation
8-27
8.9
Engine and Hydraulic Pump AS - Remove and Install
8-28
8.9.1 Removal
8-28
8-1
Disassembly and Assembly
8.9.2 Installation
8-34
8.10 Final Drive AS - Remove and Install
8-35
8.10.1 Removal
8-35
8.10.2 Installation
8-36
8.11 Final Drive AS - Disassemble and Assemble
8-37
8.11.1 Disassembly
8-37
8.11.2 Assembly
8-41
8.12 Swing Motor and Swing Drive AS - Remove and Install
8-46
8.12.1 Removal
8-46
8.12.2 Installation
8-47
8.13 Swing Motor and Swing Drive AS - Disassemble and Assemble
8-48
8.13.1 Disassembly
8-48
8.13.2 Assembly
8-53
8.14 Idler AS - Disassemble and Assemble
8-58
8.14.1 Disassembly
8-58
8.14.2 Assembly
8-59
8.15 Sprocket - Remove and Install
8-62
8.15.1 Removal
8-62
8.15.2 Installation
8-62
8.16 Track AS - Remove and Install
8-63
8.16.1 Removal
8-63
8.16.2 Installation
8-65
8.17 Swing Bearing AS - Remove and Install
8-66
8.17.1 Removal
8-66
8.17.2 Installation
8-67
8.18 Swing Platform AS - Remove and Install
8-68
8.18.1 Removal
8-68
8.18.2 Installation
8-71
8.19 Swivel Joint AS - Remove and Install
8-72
8.19.1 Removal
8-72
8.19.2 Installation
8-74
8.20 Swivel Joint AS - Disassemble and Assemble
8-75
8.20.1 Disassembly
8-75
8.20.2 Assembly
8-76
8.21 Hydraulic Tank AS - Remove and Install
8-77
8.21.1 Removal
8-77
8.21.2 Installation
8-79
8.22 Control Valve AS - Remove and Install
8-80
8-2
Disassembly and Assembly
8.22.1 Removal
8-80
8.22.2 Installation
8-84
8.23 Hydraulic Pump AS - Remove and Install
8-85
8.23.1 Removal
8-85
8.23.2 Installation
8-89
8.24 Middle Oil Seal (Hydraulic Pump Input Shaft)- Remove and Install
8-90
8.24.1 Removal
8-90
8.24.2 Installation
8-90
8.25 Pilot Valve AS (Work Equipment) - Disassemble and Assemble
8-91
8.25.1 Assembly
8-91
8.26 Pilot Valve AS (Travel) - Disassemble and Assemble
8-93
8.26.1 Assembly
8-93
8.27 Hydraulic Cylinder AS - Disassemble and Assemble
8-94
8.27.1 Disassembly
8-95
8.27.2 Assembly
8-100
8.28 Work Equipment AS - Remove and Install
8-105
8.28.1 Removal
8-105
8.28.2 Installation
8-107
8.29 Air Conditioner AS - Remove and Install
8-108
8.29.1 Removal
8-108
8.29.2 Installation
8-112
8.30 Counterweight AS - Remove and Install
8-113
8.30.1 Removal
8-113
8.30.2 Installation
8-114
8.31 Cab AS - Remove and Install
8-115
8.31.1 Removal
8-115
8.31.2 Installation
8-119
8.32 Cab Window Glass - Disassemble and Assemble
8-120
8.32.1 Removal
8-121
8.32.2 Installation
8-125
8.33 Front Window AS - Disassemble and Assemble
8-138
8.33.1 Disassemble
8-138
8.33.2 Assemble
8-141
8.34 Monitor - Remove and Install
8-146
8.34.1 Removal
8-146
8.34.2 Installation
8-146
8.35 Controller AS - Remove and Install
8-147
8.35.1 Removal
8-147
8-3
Disassembly and Assembly
8.35.2 Installation
8-147
8.36 Radio
8-148
8.36.1 Structure
8-148
8.36.2 Removal
8-149
8.36.3 Installation
8-150
8.36.4 Connector model and wiring
8-150
8.37 Battery
8-151
8.37.1 Structure
8-151
8.37.2 Removal
8-152
8.37.3 Installation
8-153
8.37.4 Replacement
8-153
8.38 Start Switch
8-154
8.38.1 Structure
8-154
8.38.2 Removal
8-155
8.39 Fuse Box
8-157
8.39.1 Removal
8-157
8.40 Wiper
8-158
8.40.1 Structure
8-158
8.40.2 Working principle
8-158
8.40.3 Removal
8-159
8.40.5 Installation
8-160
8.40.4 Angle adjustment of wiper arm
8-160
8.41 Relay
8-161
8.41.1 Engine relays
8-161
8.41.2 Other relays
8-162
8.42 Sensor
8-165
8.43 Connector Terminals - Insert and Remove
8-167
8.43.1 Insertion
8-167
8.43.2 Removal
8-168
8-4
Disassembly and Assembly
8 DISASSEMBLY AND ASSEMBLY
8.1 How to Read This Manual
8.1.1 Removing and Installing an Assembly
Removal
Ɣ The "Removal" section contains procedure, precautions and the amount of oil or water to be
discharged.
Installation
Ɣ Unless specified otherwise, installation of a part is a reverse procedure of removing the part.
8.1.2 Disassembling and assembling an assembly
Disassembly
Ɣ The "Disassembly" section contains procedure, precautions and the amount of oil or water to
be discharged.
Assembly
Ɣ The "Assembly " section contains operating procedure, precautions, technical specification
and the amount of oil or water to be added.
8.1.3 Special tools
Ɣ Special tools for parts disassembly and assembly are listed.
Ɣ Necessary characteristics of the tools are noted in the list of special tools.
Ŷ: Special tools that cannot be replaced and must be used.
Ɣ: Very useful tools, which can be replaced with commercially available ones.
8-5
Disassembly and Assembly
8.1.4 The symbols used in this section
This section uses some symbols and icons that are not used elsewhere in this manual. They in-
clude:
This symbol indicates the amount of oil or water to be discharged.
This symbol indicates that specific coating agent must be used.
This symbol indicates the lubricant required.
This symbol indicates a torque specified.
This symbol indicates the amount of oil or water to be added.
This symbols indicates the weight of a component or an assembly.
8.2 Operating Precautions
The following precautions must be observed before removing or installing (disassembling or as-
sembling) a component.
1.
Precautions to be observed prior to removal operation
Ɣ
Dispose the engine coolant properly if antifreeze is contained in the engine coolant.
Ɣ
After disconnecting a hose or tube, cover or plug must be used to prevent invasion of dirt
or dust.
Ɣ
A suitable container must be prepared to collect oil when draining the oil.
Ɣ
Matching mark must be made at where is necessary before removing in order to avoid
mistake during reinstallation.
Ɣ
Do not pull the wire and avoid the wire coming off. To avoid excessive force imposing on
the wire, hold the connector when disconnecting a wire.
Ɣ
Tag the wires and the hoses in order to ensure their connecting positions. By doing so,
mistakes can be avoided during reinstallation.
Ɣ
Count and check the number and thickness of the shims, and keep them in a safe place.
Ɣ
When raising or lifting components, be sure to use proper lifting equipment of ample
strength and safety.
Ɣ
When forcing screws are used to remove any components, tighten the screws evenly in
turn.
Ɣ
The surrounding area must be cleaned before removing a unit. Cover the unit after remov-
al in order to prevent invasion of dirt or dust.
8-6
Disassembly and Assembly
Ɣ
Precautions to be observed when disassembling the lines
The lines disassembled must be blinded with plugs.
A: Thread-connected hoses
I.D. (mm)
Code
Description
Light Thread Connection
6
B210780001189
Plug
8
B210780001190
Plug
10
B210780000077
Plug
12
B210780000078
Plug
15
B210780000883
Plug
20
B210780000079
Plug
22
60056667
Plug
Heavy Thread Connection
12
B210780001142
Plug
16
60002397
Plug
20
B210780000080
Plug
25
B210780000081
Plug
B: Thread-connected adaptors (plug and nut used in combination)
I.D. (mm)
Code
Description
Code
Description
Light Thread Connection
6
B210780000903
Taper bore plug
23002925
Nut
8
B210780001146
Plug
B210770000011
Nut
10
B210780000088
Plug
B210334000011
Nut
12
B210780000089
Plug
B210334000012
Nut
15
B210780000882
Plug
B210334000004
Nut
20
B210780000090
Plug
B210334000010
Nut
22
B210780000091
Plug
B210780000112
Nut
Heavy Thread Connection
12
B210780001143
Plug
B210780000406
Nut
16
A820205001523
Plug
B210780000405
Nut
20
B210780000902
Plug
B210780000904
Nut
25
B210780001172
Plug
B210334000006
Nut
8-7
Disassembly and Assembly
2.
Precautions prior to installation operation
Ɣ
Tighten all the screws and nuts (sleeve nuts) to specified torques.
Ɣ
Install the hoses without twisting or interference.
Ɣ
Replace the gaskets, O-rings, cotter pins and lock plates with new parts.
Ɣ
Bend the cotter pin or lock plate securely.
Ɣ
Before applying the adhesive, clean the parts of oil and dust. Apply 2 or 3 drops of adhe-
sive to the threaded portion.
Ɣ
Before applying the sealant to the gasket, clean the gasket surface of oil and dust. Check
the gasket for contamination or damage. Apply the gasket sealant evenly.
Ɣ
Clean all parts, and correct any damage, dents, burrs, or rust.
Ɣ
Apply engine oil to the moving parts.
Ɣ
Before installing a snap ring, make sure that the snap ring is mounted properly in the cir-
cular groove.
Ɣ
Before connecting the wiring connector, clean the wiring connector of oil, dirt or water.
Make sure that the wiring connector is connected securely.
Ɣ
Before using an eyebolt, check the eyebolt for deformation or deterioration. Screw on the
eyebolt as far as possible and align it to the direction of the hook.
Ɣ
Before tightening the split flange, tighten it evenly in turn in order to prevent over tighten-
ing on one side.
NOTE: After reassembling the hydraulic cylinder, main pump or other hydraulic equipment
that has been disassembled and repaired, it is necessary to bleed the air from the hydraulic
cylinder prior to initial operation of the cylinder. The purging procedure is performed as the
following:
1) Start the engine and run the engine at low idle.
2) Operate the work equipment control lever in order to cycle the movement of the hydraulic
cylinder 4 or 5 times. Hold the cylinder at where it is 100 mm from its stroke end.
3) Go on operating the hydraulic cylinder 3 or 4 times to its stroke end.
4) You can run the engine at normal speed after this operation.
NOTE: This procedure is to be performed before using your machine for the first time after
repair or long storage.
8-8
Disassembly and Assembly
3. Precautions to be observed upon completion of the operations
Ɣ Completely discharge the engine coolant, tighten the drain valve, and add coolant to the
specified level. Run the engine to circulate the coolant through the system. Check the
coolant level again.
Ɣ Add hydraulic oil to the specified level after disassembly and reinstallation of a hydraulic
unit. Run the engine to circulate the hydraulic oil through the system. Check the oil level
again.
Ɣ Bleed the air from the system after removing and repairing the lines or hydraulic unit and
reassembling the parts.
For more information, see “Air in Each Component - Bleed” on page 6-46.
Ɣ Add the specified amount of grease (molybdenum disulphide) to the work equipment re-
lated parts.
8-9















Content      ..     23      24      25      26     ..
