Api Pneumatic. GENERAL CATALOG (2019) - page 33

Accessories with integrated function

Pneumatic switch

4.83.61

D1

L1

L2

L3

CH1

CH2

The V46 is a pneumatic switch. It is available in a 2/2 and 3/2-
way version.
The goal of the 2/2 way switch is to cut off the flow in the circuit
whenever needed by simply operating the lever. The 3/2 way
valve cuts off the flow and vents to atmosphere the terminal
part of the circuit.

Note:   The banjo to couple to the valve have to be ordered

separately (R35 - RT28 - C23 - O25)

Technical data

Fluid

Compressed air

Pressure range

Max. 15 bar

Temperature range

-10 °C ÷ + 70°C

Parallel threads

UNI - ISO 228 / 1 (BSPT)

Flow rate at 6 bar (Nl/min)

1/8” = 610    -    1/4” = 850

Tubes tolerances

± 0,05 mm

Materials

Body:

Nickel plated brass

Spring:

Stainless steel AISI 302

Washers:

Nylon (PA6)

Seals:

Nitrile rubber (NBR)

Version

L

1

L

2

L

3

CH

1

CH

2

1/8”

6

16

55

14

15

1/4”

8

19

60

17

15

Ingresso

Uscita

ON

OFF

OFF

In

2/2

3/2

ON

OFF

OFF

In

Out

Out

Version

Symbol

Code

Item

Switch 1/8”, 2 way

030125

V4600182V

Switch 1/4”, 2 way

030165

V4600142V

Switch 1/8”, 3 way

030166

V4600183V

Switch 1/4”, 3 way

030167

V4600143V

4

4.83.62

Ø T

ube

L1

D1

L2

L3

CH

The V48 is a pneumatic switch. It is available in a 2/2 and 3/2-
way version.
The goal of the 2/2 way switch is to cut off the flow in the circuit
whenever needed by simply operating the lever. The 3/2 way
valve cuts off the flow and vents to atmosphere the terminal
part of the circuit.

Technical data

Fluid

Compressed air

Pressure range

Max. 15 bar

Temperature range

-10 °C ÷ + 70°C

Flow rate at 6 bar (Nl/min)

1/8” = 610    -    1/4” = 850

Tubes tolerances

± 0,05 mm

Washers

Body: POM

Spring:

Stainless steel AISI 302

Switch:

Nickel plated brass

Seals:

Nitrile rubber (NBR)

Version

D

1

L

1

L

2

L

3

CH

Ø 6

3,2

16

45

49

15

Ø 8

3,2

16

46

50

15

Accessories with integrated function

In line pneumatic switch

Version

Symbol

Code

Item

Switch for Ø 6 mm
tube, 2 way

030172

V4800062V

Switch for Ø 8 mm
tube, 2 way

030173

V4800082V

Switch for Ø 6 mm
tube, 3 way

030164

V4800063V

Switch for Ø 8 mm
tube, 3 way

030163

V4800083V

New

4.83.66

Accessories with integrated function

Slow starter

This fitting allows for a progressive pressurization of the installation
and prevents the actuators from being hit hard in case of sudden
pressure feeding of the previously vented circuit.
Depending on the desired spindle setting, the Slow Start Fitting will
open gradually, pressure will progressively flow into the circuit and
the actuators will go back to their working position without being hit.
Pressure feeding speed is indeed determined by the rotation of
the spindle.
If turned clockwise, a very smooth pressurization will be achieved.

D1

L1

L2

L3

CH

D1

Version

Symbol

Type

Slow starter

V61

Code

Item

D

1

D

2

L

1

L

2

L

3

CH

024475

V61 00 14

1/4”

1/4”

6,5

17

66

20

024476

V61 00 38

3/8”

3/8”

9

21

71,5

20

024477

V61 00 12

1/2”

1/2”

10

24,5

74,5

25

Technical data

Fluid

Compressed air

Pressure range

3 ÷ 10 bar (P1)   -   Total opening 2/3 P1

Temperature range

0 °C ÷ + 70°C

Parallel threads

UNI - ISO 228 / 1 (BSP)

Flow rate at 6 bar (Nl/min)

1/4” = 1800    -    3/8” = 2400    -    1/2” = 2900

Materials

Body:

Nickel plated brass

Spring:

Stainless steel AISI 302

Seals:

Nitrile rubber (NBR) - Polyurethane (PU)

Rondello:

Nylon (PA6)

P (bar)

t (s)

0

P= 2/3 P1

With V61

Without V61

4.83.71

Accessories with integrated function

Threshold sensor

Threshold sensor can detect a pressure drop and signal it with a
command signal (s).
This component turns out to be especially useful when assembled
directly on the cylinder.
When the piston completes its stroke (no more counter pressure
available in the cylinder ), a command signal is given out to a
direction valve to have the piston change the stroke.
Sole condition required for perfect component performance is that
the piston has to complete its
stroke.
No intermediate positions are allowed.
Major advantage of this component is to command the piston
stroke changes without electrical connections.

CH1

L2

L1

L4

D1

D3

L3

D2

D2

CH2

Version

Symbol

Type

Threshold sensor

V62

V62

V62

V62

Code

Item

D

1

D

2

D

3

L

1

L

2

L

3

L

4

CH

1

CH

2

024008

V62 00 18

1/8”

4

1/8”

5

11

29,5

38

13

16

024010

V62 00 14

1/4”

4

1/4” 6,5

13

33

40

16

16

024011

V62 00 38

3/8”

4

3/8”

7

13

33

42

20

20

Technical data

Fluid

Compressed air

Pressure range (bar)

Exercise:

3

4

5

6

7

8

9

10

Commutation:

0,3

0,5

0,65

0,9

1

1,2

1,4

1,6

Temperature range

0 °C ÷ + 70°C

Parallel threads

UNI - ISO 228 / 1 (BSP)

Materials

Body:

Nickel plated brass

Collet:

Stainless steel

Seals:

Nitrile rubber (NBR)

STEP 1

STEP 2

STEP 3

Out

In

In

In

Out

S
P

S
P

S
P

S

P

4

Silencers

In plastic polymer

4.85.1

Version

Symbol

Type

Dynamic (self-cleaning)

SPD

Static (with felt)

SPF

Static high flow rate

SPS

In Polyethylene

AS19

In polyethylene with stem

AS22

Technical data

Type

SPD

SPF

SPS

AS19 - AS22

Fluid

Compressed air

Pressure range

0 ÷

6

 bar

0 ÷ 10 bar

Temperature range

-10 °C ÷ + 70°C

Parallel threads

UNI - ISO 228/1

UNI - EN 10226/1

UNI - ISO 228/1

UNI - ISO 228/1 (AS19)

Mounting position

Any position

Body material

Acetal resin

Acetal resin

Polyacetal

Polyethylene

Noise absorbing material

Granulated acetal resin

Pressed felt and
aluminium net

Polyethylene

Polyethylene

Options

Suffix

Threaded NPT  (Only for SPD, SPF and SPS)

NPT

Series of silencers in plastic polymers to be fitted on exhausts for
reducing noise.

SPD

Self cleaning dynamic silencer in acetal resin. The sound-
absorbing material, composed by moving elements, avoids the risk
of obstructions maintaining constant in time the air flow.

SPF

Static silencer in acetal resin, sound-absorbing material: felt.

SPS

High flow static silencer in polyacetal resin. Overall dimensions
and sound-absorbing material, in micro porous polyethylene, grant
high flow-rates and low noise values.

AS19 e AS22

Static silencer in polyethylene with compact overall dimensions.
Available for threaded or push-in connections.

For standard items, codes and dimensions, see tables at page
4.85.2.

Silencers

In Acetal resin

Dynamic (self-cleaning)

Ø

Static (with felt)

Static (with felt)

4.85.2

Blue

Black

Yellow

A

B

C

D

Code

Item

Code

Item

Code

Item

016001 SPD18BL 016011 SPD18NE 010001 SPD18GI

1/8”

15,5

6

32,5

016002 SPD14BL 016012 SPD14NE 010002 SPD14GI

1/4”

19,5

8

43

016003 SPD38BL 016013 SPD38NE 010003 SPD38GI

3/8”

24,5

11

58

016004 SPD12BL 016014 SPD12NE 010004 SPD12GI

1/2”

24,5

11

58

016005 SPD34BL 016015 SPD34NE 010005 SPD34GI

3/4”

48

18

115

016006 SPD01BL 016016 SPD01NE 010006 SPD01GI

1”

48

18

115

Blue

Black

White

A

B

C

CH

D

E

F

Code

Item

Code

Item

Code

Item

017031 SPF18BL 010021 SPF18NE 017021 SPF18NT 1/8” 15,5

6

10 25,5 33

2,5

017032 SPF14BL 010022 SPF14NE 017022 SPF14NT 1/4” 19,5

8

12

32

43

3

017033 SPF38BL 010023 SPF38NE 017023 SPF38NT 3/8” 24,5 11

16

44

58

3

017034 SPF12BL 010024 SPF12NE 017024 SPF12NT 1/2” 24,5 11

16

44

58

3

Blue

Black

Yellow

A

B

C

D

Code

Item

Code

Item

Code

Item

017035 SPF34BL 010025 SPF34NE 017045 SPF34GI

3/4”

48

18

115

017036 SPF01BL 010026 SPF01NE 017046 SPF01GI

1”

48

18

115

* Measured at 6 bar at a distance of 1 m.

* Measured at 6 bar at a distance of 1 m.

* Measured at 6 bar at a distance of 1 m.

Technical data

Item

Flow rate (l/min)

Noise* (dB)

Weight (g)

SPF34..

-

< 90

69,5

SPF01..

-

< 90

72,5

Technical data

Item

Flow rate (l/min)

Noise* (dB)

Weight (g)

SPF18..

650

< 90

3

SPF14..

1050

< 90

6

SPF38..

2760

< 90

11,5

SPF12..

2760

< 90

13,5

Technical data

Item

Flow rate (l/min)

Noise* (dB)

Weight (g)

SPD18..

700

< 90

3

SPD14..

1100

< 90

6,5

SPD38..

2900

< 90

14

SPD12..

2900

< 90

15,5

SPD34..

5000

< 90

107,5

SPD01..

5000

< 90

110,5

4

Silencers

In Acetal resin

4.85.3

ØB

A

C

C

ØB

A

In Polyethylene

In polyethylene with stem

Code

Item

A

B

C

016108

AS19 M5

19

7

M5

016103

AS19 18

25

13

1/8”

016102

AS19 14

31

17

1/4”

016104

AS19 38

54

25

3/8”

016105

AS19 12

58.5

25

1/2”

016106

AS19 34

122.5

37

3/4”

016107

AS19 01

138.5

48

1”

Ø

Static high flow rate

Code

Item

A

B

C

D

016171

SPS18NE

1/8”

15.2

5.3

35.6

016172

SPS14NE

1/4”

19.2

6.5

57.4

016173

SPS38NE

3/8”

33.2

9

77.8

016174

SPS12NE

1/2”

43

10

87.4

016175

SPS34NE

3/4”

44.5

11.5

119.5

016176

SPS01NE

1”

55

13

125

* Measured at 6 bar at a distance of 1 m.

Technical data

Item

Flow rate (l/min)

Noise* (dB)

Weight (g)

SPS18

2050

< 77

2

SPS14

3400

< 77

8

SPS38

5900

< 82

30

SPS12

10600

< 80

58

SPS34

15000

< 83

83

SPS01

19900

< 84

140

* Measured at 6 bar at a distance of 1 m.

Technical data

Item

Flow rate (l/min)

Noise* (dB)

Weight (g)

AS19 M5

-

-

0,4

AS19 18

-

-

2,6

AS19 14

-

-

5,2

AS19 38

-

-

10,5

AS19 12

-

-

-

AS19 34

-

-

-

AS19 01

-

-

-

Code

Item

A

B

C

016152

AS22 06

45

12.5

6

016153

AS22 08

43.6

13.5

8

016154

AS22 10

57.5

15.5

10

016155

AS22 12

82

18.5

12

* Measured at 6 bar at a distance of 1 m.

Technical data

Item

Flow rate (l/min)

Noise* (dB)

Weight (g)

AS22 06

-

-

1,1

AS22 08

-

-

2,3

AS22 10

-

-

5,5

AS22 12

-

-

11,2

4

4.85.11

Silencers

Sintered silencers

Series of silencers with metal nipple and 36 micron sintered bronze
filter element.
They can applied to valve exhausts to reduce noise level.

* How to order: ACQ14N

* For standard items, codes and dimensions see tables from

 page 4.85.12.

Options

Suffix

Completely nickel plated

N

Threads

 M5

1/8”

1/4”

3/8”

1/2”

3/4”

1”

Code

 M5

18

14

38

12

34

01

ACQ

14

N

Type

Thread code

Option code

Technical data

Fluid

Compressed air

Pressure range

0 ÷ 12 bar

Temperature range

-10 °C ÷ + 80°C

Parallel threads

UNI - ISO 228 / 1 (BSP)

Metric threads

ISO R / 262

Materials

Filter element:

Sintered spherical bronze (AFE with sintered stainless steel AISI 304 net)

Nipple:

Brass (AEB in copper plated steel)

Filter degree:

36 micron

Version

Symbol

Type

Truncated cone

AC

Truncated cone with wrench
in top

ACQ

Truncated cone with hex. key
on nipple

AE

Extended truncated cone with
hex. key on nipple

AEA

Truncated cone with hex. key
on copper plated steel nipple

AEB

Truncated cone with slot cut
fully sintered bronze

ACT

Flat filter and hex. key on
nipple

AEP

Stainless steel mesh filter hex.
key on nipple

AFE

Flat insert

AP

Cylindrical

AT

Cylindrical with slot cut

ATT

Truncated cone push-in

ACI

4.85.12

Silencers

Sintered silencers

C

Truncated cone

Truncated cone with wrench in top

Truncated cone with hex. key on nipple

Extended truncated cone with hex. key on nipple

Code

Item

A

B

F

C

D

E

010031

AC18

1/8”

12

8

6

15

21

010032

AC14

1/4”

15

11

6

19

25

010033

AC38

3/8”

19

15

8

30

36

010034

AC12

1/2”

23

18

10

32

43

010035

AC34

3/4”

31

23

13

32.5

53

010036

AC01

1”

37

32,5

12

40,5

52,5

010037

ACM5

5MA

6

5

4,5

9,5

13

Code

Item

A

B

CH

C

D

E

010051

ACQ18

1/8”

12

7

6

15

21

010052

ACQ14

1/4”

15

9

6

19

25

010053

ACQ38

3/8”

19

10

8

28

37

010054

ACQ12

1/2”

23

14

10

33

41

010055

ACQ34

3/4”

31

20

13

40

51

010056

ACQ01

1”

37

23

15

48

60

010057

ACQM5

5MA

12

7

6

15

19

Code

Item

A

B

CH

C

D

010121

AE18

1/8”

8

13

6

28

010122

AE14

1/4”

9

16

8

32

010123

AE38

3/8”

12

19

7,5

41

010124

AE12

1/2”

16

24

10

46,5

010125

AE34

3/4”

20

30

10

50

010126

AE01

1”

21

36

10,5

60

010127

AEM5

5MA

4,5

8

4

16

010128

AE18F

1/8”F

7

13

6

28

Code

Item

A

B

CH

C

D

010161

AEA18

1/8”

7

13

6

41,5

010162

AEA14

1/4”

8

16

8

52

010163

AEA38

3/8”

10

19

7,5

56

010164

AEA12

1/2”

14

24

10

67

010165

AEA34

3/4”

17

30

10

70

010166

AEA01

1”

20

36

10,5

78

010167

AEAM5

5MA

4

8

4

24

010168

AEA18F

1/8”F

7

13

6

 41,5

010169

AEA21

1 1/2”

-

55

20

140

010170

AEA20

2”

-

65

17

213

4

4.85.13

Silencers

Sintered silencers

Truncated cone with hex.

key on copper plated steel nipple

A

B

C

Truncated cone with slot cut, fully sintered bronze

Flat filter and hex. key on nipple

Stainless steel mesh filter, hex. key on nipple

Code

Item

A

B

CH

C

D

010141

AEB18

1/8”

8,5

12

4,5

21

010142

AEB14

1/4”

11

15

6

27

010143

AEB38

3/8”

14

19

7

35

010144

AEB12

1/2”

17

23

8

43

010145

AEB34

3/4”

21

30

9

54

010146

AEB01

1”

26,5

36

11

67

010147

AEBM5

5MA

4,5

7

4

18

Code

Item

A

B

C

010265

ACT18

1/8”

11

15.5

010266

ACT14

1/4”

14

18.5

010262

ACT38

3/8”

18

25

010263

ACT12

1/2”

24

33

010264

ACT34

3/4”

29.5

53

010261

ACT01

1”

35.5

60

Code

Item

A

CH

C

D

010091

AEP18

1/8”

13

6

13

010092

AEP14

1/4”

16

8

17

010093

AEP38

3/8”

19

7,5

17

010094

AEP12

1/2”

24

10

19

010095

AEP34

3/4”

30

10

19

010096

AEP01

1”

36

10,5

20

010097

AEPM5

5MA

8

4

9

010098

AEP18F

1/8”F

14

6

20

Code

Item

A

CH

C

D

010311

AFE18

1/8”

13

6

16

010312

AFE14

1/4”

16

8

19

010313

AFE38

3/8”

19

7,5

19

010314

AFE12

1/2”

24

10

23

010315

AFE34

3/4”

30

10

25

010316

AFE01

1”

36

10,5

29

010317

AFEM5

5MA

8

4

9

010318

AFE18F

1/8”F

14

6

20

4.85.14

Silencers

Sintered silencers

Flat insert

Cylindrical

Cylindrical with slot cut

Ø C

B

A

Truncated cone push-in

Code

Item

A

C

D

010251

AP18

1/8”

6

4,5

010252

AP14

1/4”

8

6,5

010253

AP38

3/8”

9,5

7

010254

AP12

1/2”

12,5

8,5

010255

AP34

3/4”

19

8,5

010256

AP01

1”

24

10

Code

Item

A

B

C

D

010211

AT18

1/8”

10

4

10

010212

AT14

1/4”

13

7

15

010213

AT38

3/8”

17

7

15

Code

Item

A

B

C

D

010231

ATT18

1/8”

10

4

10

010232

ATT14

1/4”

13

7

15

010233

ATT38

3/8”

17

7

15

010234

ATT12

1/2”

25

10

18

010235

ATT34

3/4”

32

13

22

010236

ATT01

1”

39

14

25

Code

Item

A

B

C

010290

ACI04

4

13.7

10

010291

ACI06

6

16.4

13

010292

ACI08

8

24.4

17

4

4.85.21

Silencers

Metal silencers

Series of metal silencers particularly suitable for exhausts in big
plants and this thanks to their high flow and noise reduction.
They are normally used for presses.

* How to order: M12/40

*  For standard items, codes and dimensions see tables at page

4.85.22.

Version

Symbol

Type

Metal silencers for presses

M

For presses reduced sizes

MI

Threads

 1/8”

1/4”

3/8”

1/2”

3/4”

1”

1 1/4”

1 1/2”

2”

3”

4”

6”

Code

 01

02

00

05

07

10

12

15

20

30

40

60

Technical data

Fluid

Compressed air

Pressure range

M series: 0 ÷ 10 bar

MI series: 0 ÷ 12 bar

Temperature range

M series: -25 °C ÷ + 100°C

MI series: 0 °C ÷ + 70°C

Taper threads

M series: BSPT - NPTF

MI series: BSPT

Materials

Body:

Aluminium (M)  -  Zinc plated steel (MI)

Tie rods:

Steel (M)

Cartridge:

Noise absorbing fibre coated by metal drilled plate (M) - Stainless steel (MI)

M

12

/ 40

Type

Thread code

Option

Spare cartridges can be supplied upon request.

Flows at 6 bar (Type M)

Threads

1/8”

1/4”

3/8”

1/2”

3/4”

1”

1 1/4”

1 1/2”

2”

3”

4”

6”

l/min

1.553

3.105

6.210

9.035

19.760

28.230

45.168

73.398

118.600

254.000

508.000

1.130.000

Options

Suffix

Till 40 bar

(only for M series)

/40

Note:

 the silencer with the /40 option has  the same efficiency

features as standard silencers, moreover it is provided with
a balanced valve assembled on the top, which allows the
discharge of the air when the exit pressure changes. This
avoids damage which can be caused by air shock and
pulsating pressure.

4.85.22

Silencers

Metal silencers

Single chamber (till 2’’)

For presses

H

CH

G

4 chambers (from 3” to 6”)

For presses

A

D

CH

B

C

For presses, reduced sizes

Code

Item

A

B

C

D

E

011001

M01

1/8”

49

80

70

10

011002

M02

1/4”

49

106

93

13

011003

M00

3/8”

70

126

113

13

011004

M05

1/2”

86

146

132

13

011005

M07

3/4”

89

179

162

17

011006

M10

1”

103

212

192

20

011007

M12

1 1/4”

103

219

192

26

011008

M15

1 1/2”

136

351

318

33

011009

M20

2”

136

484

450

33

Code

Item

A

B

CH

C

D

011040

MI01

1/8”

28

11

35

11

011041

MI02

1/4”

33

14

44

14

011042

MI00

3/8”

43

18

56

17,5

011043

MI05

1/2”

52

22

68

22

011044

MI07

3/4”

64

27

81

27

011045

MI10

1”

76

33

98

33

011046

MI12

1-1/4”

90

46

113

42

011047

MI15

1-1/2”

100,6

50

124,2

50

011048

MI20

2”

114,7

60

141,2

60

Code

Item

A

B

C

D

E

F

G

CH

M

011501

M30

3”

179

623

421

56

219

33

93

35

011502

M40

4”

205

623

563

60

248

36

-

-

011503

M60

6”

288

815

732

83

348

39

172

42,5

4

4.90.1

Exhausts conveyor

The exhausts conveyor is a useful and practical tool to be used
where more exhausts (of one or more machines) have to be
conveyed to one silencing element only; the exhaust conveyor,
compared with the traditional silencer, keeps the work place
clean as it doesn’t exhaust the oil nebulized by the plant into
the air.
The various tubes from different machines are connected with
the exhaust conveyor upper side by pre-mounted push-in fittings
(female 1’’ thread can also be used).
The air mixed with oil flows into the respective chamber linked
with a connection and into a thick aluminium wire filter that
separates air from oil, keeping the latter back. The air passes
through the filter and then flows outside through a second
sintered bronze filter covering the whole conveyor circumference,
while the oil drops to a vessel below, which can be emptied by a
manual exhaust placed at the bottom of the conveyor.

Technical data

Fluid

Compressed air

Pressure range

0 ÷ 12 bar

Temperature range

-20 °C ÷ + 70°C

Connection

10 connections with integral 8 mm push-in fittings, 1 port with female BSP 1’’ thread

Connection tubes

Calibrated nylon, polyurethane and rilsan

Tubes tolerances

± 0,05 mm

Materials

Body:

Acetal resin

Separator filter:

Aluminium

External filter:

Sintered bronze

Connections: Brass

Bracket:

White zinc plated steel

Version

Symbol

Code

Item

Exhausts conveyor

080001

CSC1

4.90.2

Exhausts conveyor

Type:

CSC1

5

5.0

Stainless Steel components

from page 5.5.1

Stainless steel cylinders
ISO 21287

from page 5.16.1

from page 5.1.1

Stainless steel ball valves

from page 5.100.1

Stainless steel
uni-directional valves

from page 5.105.1

Stainless steel mounting
accessories for cylinders ISO
15552

from page 5.40.1

Stainless steel compression
fittings series OX

from page 5.160.1

Stainless steel push-in
fittings series RX

from page 5.150.1

Stainless steel air-reservoirs

from page 5.180.1

Stainless steel standard
fittings series AX

from page 5.165.1

Stainless steel mounting
accessories for cylinders
ISO 6432

from page 5.30.1

Stainless steel quick exhaust
valves

from page 5.110.1

Stainless steel rapid
fittings series CX

from page 5.155.1

Stainless steel swivel joints

from page 5.175.1

Stainless steel flow controls

from page 5.185.1

Stainless steel quick-lock
couplings

from page 5.170.1

Stainless steel cylinders
ISO 15552

Stainless steel cylinders
ISO 6432

Stainless steel piston rod
accessories

from page 5.20.1

Stainless steel airline
equipment

from page 5.140.20

Stainless steel silencers and
silenced exhaust restrictors

from page 5.190.1

Stainless steel NAMUR
solenoid valves

from page 5.70.1

Stainless steel mounting
accessories for round
cylinders

from page 5.30.1

Stainless steel round
cylinders

from page 5.11.1

New
