Low backlash planetary gearheads
High End
TP
+
and
TP
+
HIGH TORQUE
Compact precision
Compact top performers with drive
flange. The standard version is ideally
suited for high positioning accuracy
and highly dynamic cyclic operation.
The TP
+
HIGH TORQUE is particularly
well suited for high-precision applica-
tions where high torsional rigidity is
required.
RP
+
The new high-performance planetary
gearhead
The RP
+
sets standards in terms of
power density, modularity and easy
installation.
The highly rigid gearhead design en-
sures maximum positioning accuracy.
alpheno
®
Perfection in a new dimension
Looking for a solution that is tailored to
your needs? Your requirements are our
challenge.
More performance in less space!
alpheno
®
– The sure way to success.
Maximum power density
And the torques?
Although the previous series achieved outstanding
results, we managed to increase the torques by up
to 40%. Raising the limits – Typical of WITTENSTEIN
alpha!
Versatile installation
In whatever position you install it –
your gearhead
always contains the same quantity of oil/grease.
The gearheads are so flexible, you can install them
vertically, horizontally or with the output facing up-
wards or downwards.
Simple motor installation
Safe, and secure motor installation is possible in
a single step. The WITTENSTEIN alpha-patented
motor mounting is also available with integrated
thermal length compensation as an option.
Maximum positioning accuracy
Upon request, the High End planetary gearheads are
available with torsional backlash of less than one arc
minute. This significantly increases the positioning
accuracy of your application.
Power density
20
alpheno
®
RP
+
TP
+
SP
+
SP
+
and SP
+
HIGH SPEED
The classic all-rounder among planetary
gearheads
The standard version is ideally suited
for high positioning accuracy and highly
dynamic cyclic operation.
The SP
+
HIGH SPEED is particularly well
suited for applications with maximum
speeds during continuous operation.
Superior running thanks to helical teeth
Our High End planetary gearheads “whisper”.
Compared to the straight-toothed gearheads, our
helical-toothed gearheads are 6 dB(A) quieter dur-
ing operation. And what a difference 64 instead of
70 decibels makes to added value. You will barely
notice vibrations because these gearheads run so
smoothly.
World-class lifespan
The seal rings on the High End planetary gearheads
were specially developed and the material and ge-
ometry are both optimized to ensure an extremely
long lifespan!
Planetary gearheads
High End
21
