Oras catalogue (2019) - page 6
Oras Cubista
2887 Cover part for shower faucet
160
Cover part for concealed thermostatic
Colour: Chrome
shower faucet for Oras No. 7127
Working pressure: 50 - 1000 kPa
Hot water supply: max. +80°C
.4ADA50-afcgbd.
6 414150 052613
2888 Cover part for bath and shower faucet
160
Cover part for concealed thermostatic
Colour: Chrome
bath and shower faucet for Oras No. 7128
Working pressure: 50 - 1000 kPa
Hot water supply: max. +80°C
.4ADA50-afcgca.
6 414150 052620
7127 Body for shower faucet
88 max
Concealed thermostatic shower faucet
185
58 min
body for Oras No. 2887, 7187, 8577 and
Pressure loss with flow (0.2 l/s): 165 kPa
G 1/2
28
8687. Non-return valves and litter filters
Working pressure: 100 - 1000 kPa
are included.
Flow-rate at 300 kPa: 0.27 l/s
Hot water supply: max. +80°C
Noise class: II (ISO 3822)
G 1/2
G 1/2
50
80
.4ADA50-afafch.
6 414150 050527
108
Oras Cubista
7128 Body for bath and shower faucet
88 max
Concealed thermostatic bath and shower
185
58 min
faucet body for Oras No. 2888, 7188,
Pressure loss with flow (0.3 l/s): 250 kPa
G 1/2
28
8578 and 8688. Non-return valves and
Working pressure: 100 - 1000 kPa
litter filters are included.
Flow-rate at 300 kPa: 0.33 l/s
Hot water supply: max. +80°C
Noise class: II (ISO 3822)
G 1/2
G 1/2
50
80
.4ADA50-afafde.
6 414150 050534
109
Oras Cubista
2890 Shower system
Thermostatic rain shower faucet with
Colour: Chrome
ø 238
fixed head shower pipe, rain shower and
400
soap holder.
Pressure loss with flow (0.2 l/s): 190 kPa
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.23 l/s
200
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
175
82±10
150±3
45
.4ADA50-aggccb.
6 414150 066221
2890U Shower system
Thermostatic rain shower faucet with
Colour: Chrome
ø 238
fixed head shower pipe, rain shower and
400
soap holder. Including eccentric unions
Pressure loss with flow (0.2 l/s): 190 kPa
and cover plates.
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.23 l/s
200
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
175
82±10
150±15
82
.4ADA50-aggfia.
6 414150 066580
110
Oras Cubista
2891 Shower system
Thermostatic rain shower faucet with
Colour: Chrome
ø 238
spout, fixed head shower pipe, rain
400
shower and soap holder.
Pressure loss with flow (0.2 l/s): 230 kPa
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.23 l/s
200
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
175
82±10
150±3
45
.4ADA50-aggcdi.
6 414150 066238
2891U Shower system
Thermostatic rain shower faucet with
Colour: Chrome
ø 238
spout, fixed head shower pipe, rain
400
shower and soap holder. Including
Pressure loss with flow (0.2 l/s): 230 kPa
eccentric unions and cover plates.
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.23 l/s
200
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
175
82±10
150±15
82
.4ADA50-aggfjh.
6 414150 066597
111
Oras Cubista
2892 Shower system
Thermostatic rain shower faucet with
Colour: Chrome
ø 238
fixed head shower pipe, rain shower, hand
400
shower, hand shower bracket and soap
Pressure loss with flow (0.2 l/s): 230 kPa
holder.
Working pressure: 100 - 1000 kPa
Flow-rate at 300 kPa: 0.23 l/s
200
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
175
82±10
G 1/2
150±3
45
.4ADA50-aggcef.
6 414150 066245
2892U Shower system
Thermostatic rain shower faucet with
Colour: Chrome
ø 238
fixed head shower pipe, rain shower, hand
400
shower, hand shower bracket and soap
Pressure loss with flow (0.2 l/s): 230 kPa
holder. Including eccentric unions and
Working pressure: 100 - 1000 kPa
cover plates.
Flow-rate at 300 kPa: 0.23 l/s
200
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
175
82±10
G 1/2
150±15
82
.4ADA50-agggad.
6 414150 066603
112
Oras Optima
Oras Optima faucet family provides a complete collection of faucets for
every possible purpose; touchless washbasin faucet, single lever wash-
basin faucet with smart solutions, thermostatic bath and shower faucets,
rain showers and kitchen faucets. Oras Optima single-lever washbasin and
kitchen faucets are also available with an eco-button that makes saving wa-
ter and energy easy with increased safety. EcoFlow control integrated into
the thermostatic shower faucet limits the flow rate, saving water while also
ensuring a sufficient flow for an enjoyable shower.
For the kitchen, a stylish, yet highly safe hybrid faucet is also available.
New Oras Optima kitchen faucet brings professional level features to your
kitchen in a stylish package. It has a touchless function as well as EasyGrip
handles for hot and cold water. High flexible spout with two sprays makes
cooking even more easy and comfortable. The front of the faucet features
a clear, digital water temperature display, which warns you by blinking if the
water temperature exceeds 42 degrees. What’s more, the touchless func-
tion allows you to wash your hands under the spout hygienically and con-
veniently. The integrated smart dishwasher valve closes automatically after
a set amount of time, providing excellent protection against water-related
accidents.
For the bathroom, Oras Optima provides our most extensive range for wash-
basins, including both single-lever and touchless faucets. Coupled with the
Smart Bidetta hand shower, taking care of personal hygiene has never been
easier. The remote-operated Bidetta hand shower can be used at the touch
of its trigger, without the need to open the faucet itself. As a result, the hand
shower can be placed away from the washbasin.
Design: Kirsi Svärd
Kirsi Svärd
113
Oras Optima
2738F Kitchen faucet
Kitchen faucet with with side operated
Colour: Chrome
easy-grip lever, flexible high swivel spout
and aerator. Spout’s swing angle is factory
Working pressure: 100 - 1000 kPa
preset at 120° (can be limited to 60° or
Flow-rate at 300 kPa: 0.2 l/s
80°).
Hot water supply: max. +70°C
F = with flexible pipes
Noise class: I (ISO 3822) Oras lab.
Ø34.5
G3/8
ORAS PROTEC
WATER HYGIENE
T
.4ADA50-ahjfgg.
6 414150 079566
2739F Kitchen faucet with dishwasher valve, 6 V
Kitchen faucet with side operated easy-
Colour: Chrome
grip lever, flexible high swivel spout,
aerator and smart dishwasher valve.
Working pressure: 100 - 1000 kPa
Spout’s swing angle is factory preset
Flow-rate at 300 kPa: 0.2 l/s
at 120° (can be limited to 60° or 80°).
Hot water supply: max. +70°C
Dishwasher valve closes automatically
Dishwasher valve open period: 4 h / 12 h
after 4 or 12 hours (one push opens the
EMC Directive: 2014/30/EU
valve for 4 hours, pushing for 5 seconds
Ø34.5
opens the valve for 12 hours). Battery
Protection class: IP 55
operated, 6 V.
Noise class: I (ISO 3822) Oras lab.
The faucet is equipped with litter filters.
Battery: Lithium 2CR5 6 V
F = with flexible pipes.
G3/8
G1/2
ORAS PROTEC
WATER HYGIENE
T
.4ADA50-ahjfhd.
6 414150 079573
2728F Kitchen faucet, 230/5 V
Kitchen faucet with easy-grip levers for
Colour: Chrome
hot and cold water, touchless function,
temperature display with hot water
Electrical Connection: 230 / 5 V
warning, flexible high swivel spout and
Working pressure: 100 - 1000 kPa
aerator. The flow-rate of hot and cold
Flow-rate at 300 kPa: 0.2 l/s
water is adjusted by separate levers.
Max. flow period: 40 s (10/40/60/120/180 s)
Spout’s swing angle is factory preset at
Hot water supply: max. +70°C
120° (can be limited to 60° or 80°). The
touchless function is turned on by taking
Flow period (touchless function): 4 s
hands within the recognition range. The
(2/4/8/10/20 s)
water temperature for the touchless
EMC Directive: 2014/30/EU
function is adjusted by turning the ring
Recognition range: optimally preset
G3/8
between the faucet and the spout.
Protection class: IP 54 / transformer IP 40
Touchless function can be easily switched
Noise class: I (ISO 3822) Oras lab.
on/off. Electrical connection with a
plug transformer 230/5 V. The faucet is
equipped with litter filters.
ORAS PROTEC
F = with flexible pipes.
WATER HYGIENE
T
.4ADA50-ahjfec.
6 414150 079542
114
Oras Optima
2729F Kitchen faucet with dishwasher valve, 230/5 V
Kitchen faucet with easy-grip levers for
Colour: Chrome
hot and cold water, touchless function,
temperature display with hot water
Electrical Connection: 230 / 5 V
warning, flexible high swivel spout,
Working pressure: 100 - 1000 kPa
aerator and smart dishwasher valve. The
Flow-rate at 300 kPa: 0.2 l/s
flow-rate of hot and cold water is adjusted
Max. flow period: 40 s (10/40/60/120/180 s)
by separate levers. Spout’s swing angle
is factory preset at 120° (can be limited
Hot water supply: max. +70°C
to 60° or 80°). The touchless function
Flow period (touchless function): 4 s
is turned on by taking hands within the
(2/4/8/10/20 s)
recognition range. The water temperature
Dishwasher valve open period: 4 h / 12 h
for the touchless function is adjusted by
EMC Directive: 2014/30/EU
G3/8
turning the ring between the faucet and
Recognition range: optimally preset
the spout. Touchless function can be easily
Protection class: IP 54 / transformer IP 40
switched on/off. The dishwasher valve is
Noise class: I (ISO 3822) Oras lab.
opened by pressing a switch with signal
light, and the valve closes automatically
ORAS PROTEC
WATER HYGIENE
after preset period. Dishwasher valve
closes automatically after 4 or 12 hours
T
(one push opens the valve for 4 hours,
pushing for 5 seconds opens the valve
for 12 hours). Electrical connection with
a plug transformer 230/5 V. The faucet is
.4ADA50-ahjffj.
equipped with litter filters.
6 414150 079559
2720F Kitchen faucet, 3 V
Kitchen faucet with easy-grip levers for
Colour: Chrome
hot and cold water, touchless function,
122
high swivel spout and aerator. The flow-
193
Pressure loss with flow (0.2 l/s): 290 kPa
223
rate of hot and cold water is adjusted
Working pressure: 100 - 1000 kPa
by separate levers. Spout’s swing angle
Flow-rate at 300 kPa: 0.2 l/s
is factory preset at 120° (can be limited
Max. flow period: 40 s
to 60° or 80°). The touchless function
ø 34 - 37
Hot water supply: max. +70°C
ø 62
is turned on by taking hands within the
recognition range. The water temperature
Flow period (touchless function): 4 s
for the touchless function is adjusted by
EMC Directive: 2004/108/EY
turning the ring between the faucet and
Recognition range: optimally preset
G 3/8
the spout. Touchless function can be
Protection class: IP 54
easily switched on/off. Battery operated, 3
Noise class: I (ISO 3822)
V. The faucet is equipped with litter filters.
Battery: AA 1.5 V Lithium x 2
F = with flexible pipes
ORAS PROTEC
WATER HYGIENE
T
.4ADA50-ahaadh.
6 414150 070037
2722F Kitchen faucet, 230/5 V
Kitchen faucet with easy-grip levers for
Colour: Chrome
hot and cold water, touchless function,
122
temperature display with hot water
193
Electrical Connection: 230 / 5 V
223
warning, high swivel spout and aerator.
Pressure loss with flow (0.2 l/s): 290 kPa
The flow-rate of hot and cold water
Working pressure: 100 - 1000 kPa
is adjusted by separate levers. Spout’s
Flow-rate at 300 kPa: 0.2 l/s
swing angle is factory preset at 120° (can
ø 34 - 37
Max. flow period: 40 s (10/40/60/120/180 s)
ø 62
be limited to 60° or 80°). The touchless
function is turned on by taking hands
Hot water supply: max. +70°C
within the recognition range. The water
Flow period (touchless function): 4 s
temperature for the touchless function is
(2/4/8/10/20 s)
G 3/8
adjusted by turning the ring between the
EMC Directive: 2004/108/EY
faucet and the spout. Touchless function
Recognition range: optimally preset
can be easily switched on/off. Electrical
Protection class: IP 54 / transformer IP 40
connection with a plug transformer
Noise class: I (ISO 3822)
230/5 V. The faucet is equipped with litter
filters.
ORAS PROTEC
F = with flexible pipes
WATER HYGIENE
T
.4ADA50-ahaafb.
6 414150 070051
115
Oras Optima
2725F Kitchen faucet with dishwasher valve, 3 V
Kitchen faucet with easy-grip levers for
Colour: Chrome
hot and cold water, touchless function,
122
high swivel spout, aerator and smart
Pressure loss with flow (0.2 l/s): 290 kPa
193
223
dishwasher valve. The flow-rate of hot
Working pressure: 100 - 1000 kPa
and cold water is adjusted by separate
Flow-rate at 300 kPa: 0.2 l/s
levers. Spout’s swing angle is factory
Max. flow period: 40 s
ø 34 - 37
preset at 120° (can be limited to 60° or
ø 62
80°). The touchless function is turned on
Hot water supply: max. +70°C
G 3/8
by taking hands within the recognition
Flow period (touchless function): 4 s
range. The water temperature for the
Dishwasher valve open period: 4 h / 12 h
touchless function is adjusted by turning
EMC Directive: 2004/108/EY
G 3/8
G 3/8
the ring between the faucet and the
Recognition range: optimally preset
spout. Touchless function can be easily
Protection class: IP 54
switched on/off. The dishwasher valve is
Noise class: I (ISO 3822)
opened by pressing a switch with signal
Battery: AA 1.5 V Lithium x 2
light, and the valve closes automatically
ORAS PROTEC
after preset period. Dishwasher valve
WATER HYGIENE
closes automatically after 3 or 12 hours
(one push opens the valve for 3 hours,
T
pushing for 5 seconds opens the valve
for 12 hours). Battery operated, 3 V. The
faucet is equipped with litter filters.
F = with flexible pipes
.4ADA50-ahaaee.
6 414150 070044
2727F Kitchen faucet with dishwasher valve, 230/5 V
Kitchen faucet with easy-grip levers for
Colour: Chrome
hot and cold water, touchless function,
122
temperature display with hot water
193
Electrical Connection: 230 / 5 V
223
warning, high swivel spout, aerator and
Pressure loss with flow (0.2 l/s): 290 kPa
smart dishwasher valve. The flow-rate of
Working pressure: 100 - 1000 kPa
hot and cold water is adjusted by separate
Flow-rate at 300 kPa: 0.2 l/s
levers. Spout’s swing angle is factory
ø 34 - 37
ø 62
Max. flow period: 40 s (10/40/60/120/180 s)
preset at 120° (can be limited to 60° or
G 3/8
80°). The touchless function is turned on
Hot water supply: max. +70°C
by taking hands within the recognition
Flow period (touchless function): 4 s
range. The water temperature for the
(2/4/8/10/20 s)
G 3/8
G 3/8
touchless function is adjusted by turning
Dishwasher valve open period: 4 h / 12 h
the ring between the faucet and the
EMC Directive: 2004/108/EY
spout. Touchless function can be easily
Recognition range: optimally preset
switched on/off. The dishwasher valve is
Protection class: IP 54 / transformer IP 40
opened by pressing a switch with signal
Noise class: I (ISO 3822)
light, and the valve closes automatically
ORAS PROTEC
WATER HYGIENE
after preset period. Dishwasher valve
closes automatically after 3 or 12 hours
T
(one push opens the valve for 3 hours,
pushing for 5 seconds opens the valve
for 12 hours). Electrical connection with
a plug transformer 230/5 V. The faucet is
.4ADA50-ahaagi.
equipped with litter filters.
6 414150 070068
2733F Kitchen faucet
280
Kitchen faucet with an easy-grip lever,
Colour: Chrome
high swivel spout and aerator. Spout’s
swing angle is factory preset at 120° (can
Pressure loss with flow (0.2 l/s): 250 kPa
ø 22
be limited to 0° or 60°). All materials used
Working pressure: 50 - 1000 kPa
in connection with water are lead-free.
Flow-rate at 300 kPa: 0.22 l/s
F = with flexible pipes
Hot water supply: max. +80°C
54
217
Noise class: I (ISO 3822)
ø 34 - 37
EN standard: EN 817
G 3/8
ORAS PROTEC
WATER HYGIENE
T
.4ADA50-ahaabd.
6 414150 070013
116
Oras Optima
2733FG Kitchen faucet
280
Kitchen faucet with an easy-grip lever
Colour: Chrome
equipped with an eco-button for limiting
flow-rate. High swivel spout and aerator.
Pressure loss with flow (0.2 l/s): 250 kPa
ø 22
Spout’s swing angle is factory preset
Working pressure: 50 - 1000 kpa
at 120° (can be limited to 0° or 60°). All
Flow-rate at 300 kPa: 0.22 l/s
materials used in connection with water
Hot water supply: max. +80°C
are lead-free.
54
217
F = with flexible pipes
Noise class: I (ISO 3822)
ø 34 - 37
EN standard: EN 817
Eco-flow at 300 kPa: 0.1 l/s
G 3/8
ORAS PROTEC
WATER HYGIENE
T
.4ADA50-ahdbee.
6 414150 073144
2734F Kitchen faucet with dishwasher valve, 6 V
280
Kitchen faucet with an easy-grip lever,
Colour: Chrome
high swivel spout, aerator and smart
dishwasher valve. Spout’s swing angle
Pressure loss with flow (0.2 l/s): 300 kPa
is factory preset at 120° (can be limited
ø 22
Working pressure: 50 - 1000 kPa
to 0° or 60°). Dishwasher valve closes
Flow-rate at 300 kPa: 0.2 l/s
automatically after 4 or 12 hours (one
Hot water supply: max. +80°C
push opens the valve for 4 hours, pushing
Dishwasher valve open period: 4 h / 12 h
54
217
for 5 seconds opens the valve for 12
ø 34 - 37
hours). Battery operated, 6 V. All materials
EMC Directive: 2004/108/EY
used in connection with water are lead-
Protection class: IP 55
free.
Noise class: I (ISO 3822)
G 3/8
F = with flexible pipes
Battery: Lithium 2CR5 6 V
G 1/2
EN standard: EN 817
ORAS PROTEC
WATER HYGIENE
T
.4ADA50-ahaaca.
6 414150 070020
2734FG Kitchen faucet with dishwasher valve, 6 V
280
Kitchen faucet with an easy-grip lever
Colour: Chrome
equipped with an eco-button for limiting
flow-rate. High swivel spout, aerator and
Pressure loss with flow (0.2 l/s): 300 kPa
smart dishwasher valve. Spout’s swing
ø 22
Working pressure: 50 - 1000 kPa
angle is factory preset at 120° (can be
Flow-rate at 300 kPa: 0.2 l/s
limited to 0° or 60°). Dishwasher valve
Hot water supply: max. +80°C
closes automatically after 3 or 12 hours
Dishwasher valve open period: 4 h / 12 h
54
217
(one push opens the valve for 3 hours,
ø 34 - 37
pushing for 5 seconds opens the valve
EMC Directive: 2004/108/EY
for 12 hours). Battery operated, 6 V. All
Protection class: IP 55
materials used in connection with water
Noise class: I (ISO 3822)
G 3/8
are lead-free.
Battery: Lithium 2CR5 6 V
G 1/2
F = with flexible pipes
EN standard: EN 817
Eco-flow at 300 kPa: 0.1 l/s
ORAS PROTEC
WATER HYGIENE
T
.4ADA50-ahdbgi.
6 414150 073168
117
Oras Optima
2713F Washbasin faucet, 3 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control
144
154
120
unit and remote operated Smart Bidetta.
Pressure loss with flow (0.1 l/s): 200 kPa
The Easy-Grip lever is pleasant to touch
Working pressure: 100 - 1000 kPa
ø 33 - 35
98
G 1/2
G 1/2
and adjusts both the water flow and
Flow-rate at 300 kPa: 0.12 l/s
l
= 1500
temperature. Thermostatic control
G 1/2
32
Max. flow period: 2 min
l
= 350
G 1/2
unit maintains the requested water
temperature when using the Smart
Hot water supply: max. +70°C
G 3/8
Bidetta hand shower. All materials used in
Number of devices connected: max. 8
connection with water are lead-free. The
EMC Directive: 2004/108/EY
3 x l = 400
faucet is equipped with flexible pipes.
Protection class: IP 55
The function of remote operated Smart
Noise class: I (ISO 3822)
Bidetta hand shower: when lifting the
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V
hand shower from the holder water starts
to flow from the faucet. When pressing
the hand shower trigger the water supply
transfers from faucet to hand shower.
When placing the Smart Bidetta hand
shower back to its holder the faucet
closes automatically.
.4ADA50-agjjfg.
6 414150 069956
2713FG Washbasin faucet, 3 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever equipped with an eco-
144
154
120
button for limiting water temperature and
Pressure loss with flow (0.1 l/s): 170 kPa
flow-rate. Thermostatic control unit and
Working pressure: 100 - 1000 kPa
98
G 1/2
G 1/2
remote operated Smart Bidetta. The Easy-
Flow-rate at 300 kPa: 0.13 l/s
ø 33 - 35
l
= 1500
Grip lever is pleasant to touch and adjusts
G 1/2
32
Max. flow period: 2 min
l
= 350
G 1/2
both the water flow and temperature.
Hot water supply: max. +70°C
Thermostatic control unit maintains
G 3/8
the requested water temperature when
Number of devices connected: max. 8
using the Smart Bidetta hand shower. All
EMC Directive: 2004/108/EY
3 x l = 400
materials used in connection with water
Protection class: IP 55
are lead-free. The faucet is equipped with
Noise class: I (ISO 3822)
flexible pipes.
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V
Eco-flow at 300 kPa: 0.1 l/s
.4ADA50-ahdbhf.
6 414150 073175
2703F Washbasin faucet, 3 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control unit,
144
154
120
remote operated Smart Bidetta and a
Pressure loss with flow (0.1 l/s): 200 kPa
rapid pop-up waste. The Easy-Grip lever
Working pressure: 100 - 1000 kPa
98
G 1/2
G 1/2
is pleasant to touch and adjusts both the
ø 33 - 35
l
= 1500
Flow-rate at 300 kPa: 0.12 l/s
water flow and temperature. Thermostatic
G 1/2
ø 63
32
Max. flow period: 2 min
l
= 350
G 1/2
control unit maintains the requested
Hot water supply: max. +70°C
water temperature when using the Smart
G 3/8
G 1 1/4
Bidetta hand shower. All materials used in
Number of devices connected: max. 8
connection with water are lead-free. The
EMC Directive: 2004/108/EY
3 x l = 400
faucet is equipped with flexible pipes.
Protection class: IP 55
The function of remote operated Smart
Noise class: I (ISO 3822)
Bidetta hand shower: when lifting the
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V
hand shower from the holder water starts
to flow from the faucet. When pressing
the hand shower trigger the water supply
transfers from faucet to hand shower.
When placing the Smart Bidetta hand
shower back to its holder the faucet
closes automatically.
.4ADA50-agjjgd.
6 414150 069963
118
Oras Optima
2703FT Washbasin faucet, 230/5 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control unit,
144
154
120
remote operated Smart Bidetta and a
Electrical Connection: 230 / 5 V
rapid pop-up waste. The Easy-Grip lever
Pressure loss with flow (0.1 l/s): 200 kPa
98
G 1/2
G 1/2
is pleasant to touch and adjusts both the
ø 33 - 35
l
= 1500
Working pressure: 100 - 1000 kPa
32
water flow and temperature. Thermostatic
G 1/2
ø 63
Flow-rate at 300 kPa: 0.12 l/s
l
= 350
G 1/2
control unit maintains the requested
230 V/5 V
water temperature when using the Smart
Max. flow period: 2 min
G 3/8
G 1 1/4
Bidetta hand shower. All materials used in
Hot water supply: max. +70°C
connection with water are lead-free. The
Number of devices connected: max 8
3 x l = 400
faucet is equipped with flexible pipes.
EMC Directive: 2004/108/EY
The function of remote operated Smart
Protection class: IP 55 / transformer IP 40
Bidetta hand shower: when lifting the
Noise class: I (ISO 3922)
hand shower from the holder water starts
Battery: CR 2450 3 V
to flow from the faucet. When pressing
the hand shower trigger the water supply
transfers from faucet to hand shower.
When placing the Smart Bidetta hand
shower back to its holder the faucet
closes automatically.
.4ADA50-ahccai.
6 414150 072208
2711F Washbasin faucet, 3 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control
144
154
120
ø 52
unit and Smart press pad. The Easy-Grip
Pressure loss with flow (0.1 l/s): 200 kPa
lever is pleasant to touch and adjusts
Working pressure: 100 - 1000 kPa
98
G 1/2
G 1/2
both the water flow and temperature.
ø 33 - 35
32
Flow-rate at 300 kPa: 0.12 l/s
Thermostatic control unit maintains the
G 1/2
Max. flow period: 6 s (4 - 15s)
l
= 350
requested water temperature when using
Number of devices connected: max. 8
the Smart press pad. All materials used in
G 3/8
connection with water are lead-free. The
EMC Directive: 2004/108/EY
faucet is equipped with flexible pipes.
Protection class: IP 55
3 x l = 400
The function of Smart press pad:
Noise class: I (ISO 3822)
pressing the press pad starts the water
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V
flow from the faucet. The faucet closes
automatically after 6 seconds or by re-
pressing the pad. Smart press pad can be
placed freely close to the faucet, e.g. on
the wall or on the side of the washbasin.
.4ADA50-agjjha.
6 414150 069970
2701F Washbasin faucet, 3 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control
144
154
120
unit, Smart press pad and a rapid pop-up
Pressure loss with flow (0.1 l/s): 200 kPa
ø 52
waste. The Easy-Grip lever is pleasant to
Working pressure: 100 - 1000 kPa
98
G 1/2
G 1/2
touch and adjusts both the water flow
ø 33 - 35
32
Flow-rate at 300 kPa: 0.12 l/s
and temperature. Thermostatic control
G 1/2
ø 63
Max. flow period: 6 s (4 - 15s)
l
= 350
unit maintains the requested water
Hot water supply: max. +70°C
temperature when using the Smart press
G 3/8
G 1 1/4
pad. All materials used in connection
Number of devices connected: max. 8
with water are lead-free. The faucet is
EMC Directive: 2004/108/EY
3 x l = 400
equipped with flexible pipes.
Protection class: IP 55
The function of Smart press pad:
Noise class: I (ISO 3822)
pressing the press pad starts the water
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V
flow from the faucet. The faucet closes
automatically after 6 seconds or by re-
pressing the pad. Smart press pad can be
placed freely close to the faucet, e.g. on
the wall or on the side of the washbasin.
.4ADA50-agjjih.
6 414150 069987
119
Oras Optima
2701FT Washbasin faucet, 230/5 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control
144
154
120
unit, Smart press pad and a rapid pop-up
Electrical Connection: 230 / 5 V
ø 52
waste. The Easy-Grip lever is pleasant to
Pressure loss with flow (0.1 l/s): 200 kPa
98
G 1/2
G 1/2
touch and adjusts both the water flow
ø 33 - 35
32
Working pressure: 100 - 1000 kPa
ø 63
and temperature. Thermostatic control
G 1/2
Flow-rate at 300 kPa: 0.12 l/s
l
= 350
unit maintains the requested water
230 V/5 V
Max. flow period: 6 s (4 - 15s)
G 1 1/4
temperature when using the Smart press
G 3/8
pad. All materials used in connection
Hot water supply: max. +70°C
with water are lead-free. The faucet is
Number of devices connected: max 8
3 x l = 400
equipped with flexible pipes.
EMC Directive: 2004/108/EY
The function of Smart press pad:
Protection class: IP 55 / transformer IP 40
pressing the press pad starts the water
Noise class: I (ISO 3822)
flow from the faucet. The faucet closes
Battery: CR 2450 3 V
automatically after 6 seconds or by re-
pressing the pad. Smart press pad can be
placed freely close to the faucet, e.g. on
the wall or on the side of the washbasin.
.4ADA50-ahccbf.
6 414150 072215
2715F Washbasin faucet, 3 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control
144
120
unit, Smart Bidetta and Smart press
154
Pressure loss with flow (0.1 l/s): 200 kPa
ø 52
pad. The Easy-Grip lever is pleasant to
Working pressure: 100 - 1000 kPa
98
G 1/2
G 1/2
touch and adjusts both the water flow
ø 33 - 35
l
= 1500
Flow-rate at 300 kPa: 0.12 l/s
and temperature. Thermostatic control
G 1/2
32
Max. flow period: 2 min Bidetta, 6 s (4-15 s)
l
= 350
G 1/2
unit maintains the requested water
press pad
G 3/8
temperature when using the Smart press
pad. All materials used in connection
Hot water supply: max. +70°C
with water are lead-free. The faucet is
Number of devices connected: max. 8
3 x l = 400
equipped with flexible pipes.
EMC Directive: 2004/108/EY
The function of remote operated Smart
Protection class: IP 55
Bidetta hand shower: when lifting the
Noise class: I (ISO 3822)
hand shower from the holder water starts
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V x 2
to flow from the faucet. When pressing
the hand shower trigger the water supply
transfers from faucet to hand shower.
When placing the Smart Bidetta hand
shower back to its holder the faucet
closes automatically.
.4ADA50-agjjje.
6 414150 069994
2705F Washbasin faucet, 3 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control
144
154
120
unit, remote operated Smart Bidetta hand
Pressure loss with flow (0.1 l/s): 200 kPa
ø 52
shower, Smart press pad and a rapid pop-
Working pressure: 100 - 1000 kPa
up waste. The Easy-Grip lever is pleasant
ø 33 - 35
98
G 1/2
G 1/2
Flow-rate at 300 kPa: 0.12 l/s
l
= 1500
to touch and adjusts both the water flow
G 1/2
ø 63
32
Max. flow period: 2 min Bidetta, 6 s (4-15 s)
l
= 350
G 1/2
and temperature. Thermostatic control
press pad
G 1 1/4
unit maintains the requested water
G 3/8
Hot water supply: max. +70°C
temperature when using the Smart Bidetta
hand shower or Smart press pad. All
Number of devices connected: max. 8
3 x l = 400
materials used in connection with water
EMC Directive: 2004/108/EY
are lead-free. The faucet is equipped with
Protection class: IP 55
flexible pipes.
Noise class: I (ISO 3822)
The function of remote operated Smart
Battery: AA 1.5 V Lithium x 2, CR 2450 3 V x 2
Bidetta hand shower: when lifting the
hand shower from the holder water starts
to flow from the faucet. When pressing
the hand shower trigger the water supply
transfers from faucet to hand shower.
When placing the Smart Bidetta hand
shower back to its holder the faucet
closes automatically.
.4ADA50-ahaaag.
6 414150 070006
120
Oras Optima
2705FT Washbasin faucet, 230/5 V
Single lever washbasin faucet with an
Colour: Chrome
Easy-Grip lever, thermostatic control
144
154
120
unit, remote operated Smart Bidetta hand
Electrical Connection: 230 / 5 V
ø 52
shower, Smart press pad and a rapid pop-
Pressure loss with flow (0.1 l/s): 200 kPa
98
G 1/2
G 1/2
up waste. The Easy-Grip lever is pleasant
ø 33 - 35
l
= 1500
Working pressure: 100 - 1000 kPa
to touch and adjusts both the water flow
G 1/2
ø 63
32
l
= 350
G 1/2
Flow-rate at 300 kPa: 0.12 l/s
and temperature. Thermostatic control
230 V/5 V
Max. flow period: 2 min Bidetta, 6 s (4-15 s)
G 3/8
G 1 1/4
unit maintains the requested water
temperature when using the Smart Bidetta
press pad
hand shower or Smart press pad. All
Hot water supply: max. +70°C
3 x l = 400
materials used in connection with water
EMC Directive: 2004/108/EY
are lead-free. The faucet is equipped with
Protection class: IP 55 / transformer IP 40
flexible pipes.
Noise class: I (ISO 3822)
The function of remote operated Smart
Battery: CR 2450 3 V x 2
Bidetta hand shower: when lifting the
hand shower from the holder water starts
to flow from the faucet. When pressing
the hand shower trigger the water supply
transfers from faucet to hand shower.
When placing the Smart Bidetta hand
shower back to its holder the faucet
closes automatically.
.4ADA50-ahcccc.
6 414150 072222
1714F Washbasin faucet, 6 V
134
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. Battery-
operated 6 V. The total height of the
Working pressure: 100 - 1000 kPa
faucet enables installation even in the
Flow-rate at 300 kPa (with flow controller):
smallest spaces. The faucet is equipped
0.08 l/s
with litter filters and non-return valves.
Max. flow period: 2 min
ø 34 -37
No adjustments are needed at installation
85
Hot water supply: max. +70°C
because of an advanced Autofocus
sensor. The impulse-controlled solenoid
Intelligent afterflow period: 2 s ± 1 s
valve gives the battery a long operating
EMC Directive: 2004/108/EY
life. Flow controller (5 l/min) guarantees
Recognition range: optimally preset
low water consumption.
Protection class: IP 55
G 3/8
F = with flexible pipes
Noise class: I (ISO 3822)
Battery: Lithium 2CR5 6 V
.4ADA50-agheii.
6 414150 067488
1724FT Washbasin faucet, 230/12 V
134
Touchless washbasin faucet with a
Colour: Chrome
temperature adjustment handle. The total
height of the faucet enables installation
Electrical Connection: 230 / 12 V
even in the smallest spaces. The faucet
Working pressure: 100 - 1000 kPa
is equipped with litter filters and non-
Flow-rate at 300 kPa (with flow controller):
return valves. No adjustments are needed
0.08 l/s
ø 34 -37
at installation because of an advanced
85
Max. flow period: 2 min
Autofocus sensor. Flow controller (5 l/
min) guarantees low water consumption.
Hot water supply: max. +70°C
Electrical connection with a plug
Intelligent afterflow period: 2 s ± 1 s
transformer 230/12 V.
EMC Directive: 2004/108/EY
Recognition range: optimally preset
G 3/8
Alternative: concealed power supply
Protection class: IP 55 / transformer IP 40
199275. A maximum five of these items
Noise class: I (ISO 3822)
can be connected to the power supply at
a time.
.4ADA50-ahgaga.
6 414150 076060
121
Oras Optima
2710F Washbasin faucet
144
Washbasin faucet with an easy-grip lever.
Colour: Chrome
Fixed spout and aerator. All materials used
in connection with water are lead-free.
Pressure loss with flow (0.1 l/s): 140 kPa
F = with flexible pipes
Working pressure: 50 - 1000 kPa
Flow-rate at 300 kPa: 0.15 l/s
Hot water supply: max. +80°C
98
Noise class: I (ISO 3822)
ø 33 - 35
EN standard: EN 817
G 3/8
.4ADA50-agjjbi.
6 414150 069918
2710FG Washbasin faucet
144
Washbasin faucet with an easy-grip leveris
Colour: Chrome
equipped with an eco-button for limiting
water temperature and flow-rate. Fixed
Pressure loss with flow (0.1 l/s): 140 kPa
spout and aerator. All materials used in
Working pressure: 50 - 1000 kPa
connection with water are lead-free.
Flow-rate at 300 kPa: 0.15 l/s
F = with flexible pipes
Hot water supply: max. +80°C
98
Noise class: I (ISO 3822)
ø 33 - 35
EN standard: EN 817
Eco-flow at 300 kPa: 0.08 l/s
G 3/8
.4ADA50-ahdbbd.
6 414150 073113
2700F Washbasin faucet
144
Washbasin faucet with an easy-grip lever.
Colour: Chrome
Fixed spout, aerator and rapid pop-up
waste. All materials used in connection
Pressure loss with flow (0.1 l/s): 140 kPa
with water are lead-free.
Working pressure: 50 - 1000 kPa
F = with flexible pipes
98
Flow-rate at 300 kPa: 0.15 l/s
ø 33 - 35
Hot water supply: max. +80°C
ø 63
Noise class: I (ISO 3822)
EN standard: EN 817
G 3/8
G 1 1/4
.4ADA50-agjjcf.
6 414150 069925
122
Oras Optima
2700FG Washbasin faucet
144
Washbasin faucet with an easy-grip lever
Colour: Chrome
equipped with an eco-button for limiting
water temperature and flow-rate. Fixed
Pressure loss with flow (0.1 l/s): 140 kPa
spout, aerator and rapid pop-up waste. All
Working pressure: 50 - 1000 kPa
materials used in connection with water
98
Flow-rate at 300 kPa: 0.15 l/s
ø 33 - 35
are lead-free.
Hot water supply: max. +80°C
ø 63
F = with flexible pipes
Noise class: I (ISO 3822)
Eco-flow at 300 kPa: 0.08 l/s
G 3/8
G 1 1/4
.4ADA50-ahdbag.
6 414150 073106
2712F Washbasin faucet
Washbasin faucet with an easy-grip lever.
Colour: Chrome
144
Fixed spout and aerator. Oras Bidetta
hand shower, shower hose and wall
Pressure loss with flow (0.1 l/s): 200 kPa
bracket. All materials used in connection
Working pressure: 50 - 1000 kPa
with water are lead-free.
Flow-rate at 300 kPa: 0.12 l/s
F = with flexible pipes
Hot water supply: max. +80°C
98
Noise class: I (ISO 3822)
ø 33 - 35
EN standard: EN 817
G 1/2
G 3/8
.4ADA50-agjjdc.
6 414150 069932
2712FG Washbasin faucet
Washbasin faucet with an easy-grip
Colour: Chrome
144
lever is equipped with an eco-button for
limiting water temperature and flow-rate.
Pressure loss with flow (0.1 l/s): 200 kPa
Fixed spout and aerator. Oras Bidetta
Working pressure: 50 - 1000 kpa
hand shower, shower hose and wall
Flow-rate at 300 kPa: 0.12 l/s
bracket. All materials used in connection
Hot water supply: max. +80°C
98
with water are lead-free.
ø 33 - 35
F = with flexible pipes
Noise class: I (ISO 3822)
EN standard: EN 817
G 1/2
Eco-flow at 300 kPa: 0.08 l/s
G 3/8
.4ADA50-ahdbdh.
6 414150 073137
123
Oras Optima
2702F Washbasin faucet
144
Washbasin faucet with an easy-grip lever.
Colour: Chrome
Fixed spout, aerator and rapid pop-up
waste. Oras Bidetta hand shower, shower
Pressure loss with flow (0.1 l/s): 200 kPa
hose and wall bracket. All materials used
Working pressure: 50 - 1000 kPa
in connection with water are lead-free.
98
Flow-rate at 300 kPa: 0.12 l/s
F = with flexible pipes
ø 33 - 35
Hot water supply: max. +80°C
ø 63
Noise class: I (ISO 3822)
G 1/2
EN standard: EN 817
G 3/8
G 1 1/4
.4ADA50-agjjej.
6 414150 069949
2702FG Washbasin faucet
144
Washbasin faucet with an easy-grip leveris
Colour: Chrome
equipped with an eco-button for limiting
water temperature and flow-rate. Fixed
Pressure loss with flow (0.1 l/s): 200 kPa
spout, aerator and rapid pop-up waste.
Working pressure: 50 - 1000 kpa
Oras Bidetta hand shower, shower hose
98
Flow-rate at 300 kPa: 0.12 l/s
and wall bracket. All materials used in
ø 33 - 35
Hot water supply: max. +80°C
connection with water are lead-free.
ø 63
Noise class: I (ISO 3822)
G 1/2
F = with flexible pipes
EN standard: EN 817
G 3/8
Eco-flow at 300 kPa: 0.08 l/s
G 1 1/4
.4ADA50-ahdbca.
6 414150 073120
7140 Bath and shower faucet
Thermostatic bath and shower faucet
Colour: Chrome
with easy-grip handles. Easy-to-use
150±3
diverter and temperature limiter in the
110
Pressure loss with flow (0.3 l/s): 300 kPa
handle. EcoFlow control. The faucet is
Pressure loss with flow (0.2 l/s): 230 kPa
equipped with litter filters and non-return
Working pressure: 100 - 1000 kPa
valves.
Flow-rate at 300 kPa: 0.33 / 0.23 l/s
Hot water supply: max. +80°C
G 1/2
285
Noise class: I (ISO 3822)
52
Eco-flow at 300 kPa: 0.16 l/s
93
.4ADA50-ahaeac.
6 414150 070402
124
Oras Optima
7140U Bath and shower faucet
Thermostatic shower faucet with easy-
Colour: Chrome
grip handles. Easy-to-use temperature
limiter in the handle. EcoFlow control. The
Pressure loss with flow (0.3 l/s): 250 kPa
150±15
136
faucet is equipped with eccentric unions
Pressure loss with flow (0.2 l/s): 230 kPa
and cover plates, litter filters and non-
Working pressure: 100 - 1000 kPa
return valves.
Flow-rate at 300 kPa: 0.33 / 0.23 l/s
Hot water supply: max. +80°C
G 1/2
Noise class: I (ISO 3822)
285
86
Eco-flow at 300 kPa: 0.16 l/s
127
.4ADA50-ahabaf.
6 414150 070105
7160 Shower faucet
Thermostatic shower faucet with easy-
Colour: Chrome
grip handles. Easy-to-use temperature
limiter in the handle. EcoFlow control. The
Pressure loss with flow (0.2 l/s): 160 kPa
150±3
90
faucet is equipped with litter filters and
Working pressure: 100 - 1000 kPa
non-return valves.
Flow-rate at 300 kPa: 0.27 l/s
Hot water supply: max. +80°C
Noise class: I (ISO 3822)
G 1/2
44
Eco-flow at 300 kPa: 0.21 l/s
285
.4ADA50-ahaebj.
6 414150 070419
7160U Shower faucet
Thermostatic shower faucet with easy-
Colour: Chrome
grip handles. Easy-to-use temperature
limiter in the handle. EcoFlow control. The
Pressure loss with flow (0.2 l/s): 160 kPa
150±15
faucet is equipped with eccentric unions
116
Working pressure: 100 - 1000 kPa
and cover plates, litter filters and non-
Flow-rate at 300 kPa: 0.27 l/s
return valves.
Hot water supply: max. +80°C
Noise class: I (ISO 3822) Oras lab.
G 1/2
Eco-flow at 300 kPa: 0.21 l/s
78
285
.4ADA50-ahaahf.
6 414150 070075
125
Oras Optima
7187 Cover part for shower faucet
160
Cover part for concealed thermostatic
Colour: Chrome
shower faucet for Oras No. 7127
Working pressure: 100 - 1000 kPa
Hot water supply: max. +80°C
°C
.4ADA50-afafgf.
6 414150 050565
7188 Cover part for bath and shower faucet
160
Cover part for concealed thermostatic
Colour: Chrome
bath and shower faucet for Oras No. 7128
Working pressure: 100 - 1000 kPa
Hot water supply: max. +80°C
°C
.4ADA50-afafhc.
6 414150 050572
7127 Body for shower faucet
88 max
Concealed thermostatic shower faucet
185
58 min
body for Oras No. 2887, 7187, 8577 and
Pressure loss with flow (0.2 l/s): 165 kPa
G 1/2
28
8687. Non-return valves and litter filters
Working pressure: 100 - 1000 kPa
are included.
Flow-rate at 300 kPa: 0.27 l/s
Hot water supply: max. +80°C
Noise class: II (ISO 3822)
Eco-flow at 300 kPa: 0.21 l/s
G 1/2
G 1/2
50
80
.4ADA50-afafch.
6 414150 050527
126
Oras Optima
7128 Body for bath and shower faucet
88 max
Concealed thermostatic bath and shower
185
58 min
faucet body for Oras No. 2888, 7188,
Pressure loss with flow (0.3 l/s): 250 kPa
G 1/2
28
8578 and 8688. Non-return valves and
Working pressure: 100 - 1000 kPa
litter filters are included.
Flow-rate at 300 kPa: 0.33 l/s
Hot water supply: max. +80°C
Noise class: II (ISO 3822)
Eco-flow at 300 kPa: 0.24 l/s
G 1/2
G 1/2
50
80
.4ADA50-afafde.
6 414150 050534
127
