Takeuchi Hydraulic excavator TB135 (Serial No.13510004~). Parts Manual - page 6
PUMP DRIVE (13510004-13512532)
Item
Part number
Description
Q'ty Chan. Serial No. Serv.
Remarks
PUMP ASSY, drive
X03752-03000-3
1
0375202100
HOUSING
1
2
0375203100
FLANGE
1
5
1902016100
PUMP, hydraulic
1
6
1603101600
COUPLING
1
7
1512340004
ELBOW
2
1420010180
O-RING
1
8
1512340005
ELBOW
1
1420010180
O-RING
1
9
1420100400
O-RING
1
11
1501750002
PLUG
3
1420010110
O-RING
1
12
1100041025
BOLT
8
13
1101041235
BOLT
2
14
1110041025
SCREW, cap
4
15
1140020010
WASHER, spring
8
16
1140020012
WASHER, spring
2
17
1140420010
WASHER, spring
4
18
0007300041
CLAMP
2
19
1515100110
ELBOW
3
1420010110
O-RING
1
G4d060
Reference:G4D060
Page:4-13
TB135 Book No. BG4Z010 S/N 13510004-
PUMP DRIVE (13512533-)
1
16
13
11
11
7
8
11
6
10
11
20
15
12
5
9
17
19
14
2
Ref G4D062
Page
4-14
PUMP DRIVE (13512533-)
Item
Part number
Description
Q'ty Chan.
Serial No.
Serv.
Remarks
PUMP ASSY, drive
X03752-05500-0
1
0375202100
HOUSING
1
2
0375203100
FLANGE
1
5
1902019800
PUMP, hydraulic
1
13512533~13516744
1902022300
PUMP, hydraulic
1
(H)
13516745~
6
1603101600
COUPLING
1
7
1512340004
ELBOW
1
1420010180
O-RING
1
8
1512340005
ELBOW
1
1420010180
O-RING
1
9
1420100400
O-RING
1
10
1512340007
ELBOW
1
1420010140
O-RING
1
11
1501750002
PLUG
4
1420010110
O-RING
1
12
1100041025
BOLT
8
13
1101041230
BOLT
2
14
1110041025
SCREW, cap
4
15
1140020010
WASHER, spring
8
16
1140020012
WASHER, spring
2
17
1140420010
WASHER, spring
4
19
1515100110
ELBOW
3
1420010110
O-RING
1
20
1512340018
ELBOW
1
1420010140
O-RING
1
G4d064
Reference:G4D062
Page:4-14
TB135 Book No. BG4Z010 S/N 13510004-
PUMP DRIVE (with air conditioner)
1
16
13
11
35
11
10
11
11
7
8
6
23
24
20
21
24
34
24
30
29
15
12
5
25
29-1
22
2827
33
26
9
19
17
2
14
Ref G4D111
Page
4-15
PUMP DRIVE (with air conditioner)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
PUMP ASSY, drive
X03752-05600-1
1
0375202100
HOUSING
1
2
0375203100
FLANGE
1
5
1902020800
PUMP, hydraulic
1
13510004~13516744
1902022400
PUMP, hydraulic
1
(H)
13516745~
6
1603101600
COUPLING
1
7
1512340004
ELBOW
1
1420010180
O-RING
1
8
1512340005
ELBOW
1
1420010180
O-RING
1
9
1420100400
O-RING
1
10
1512340007
ELBOW
1
1420010140
O-RING
1
11
1501750002
PLUG
4
1420010110
O-RING
1
12
1100041025
BOLT
8
13
1101041230
BOLT
2
14
1110041025
SCREW, cap
4
15
1140020010
WASHER, spring
8
16
1140020012
WASHER, spring
2
17
1140420010
WASHER, spring
4
19
1515100110
ELBOW
3
1420010110
O-RING
1
20
1512340018
ELBOW
1
1420010140
O-RING
1
21
0375205110
BRACKET
1
22
1901746600
VALVE, solenoid
1
23
1513390015
TEE
1
24
1515012040
ELBOW
3
1420010110
O-RING
1
25
1515600200
ADAPTOR
1
1420010110
O-RING
1
26
1100040614
BOLT
2
27
1140020006
WASHER, spring
2
28
1141110006
WASHER
2
29
0375205120
RESISTOR
1
29-1
1730500008
DIODE (3A, yellow)
1
30
1150110306
SCREW
1
33
0375205130
HOSE ASSY
1
18010-52085
34
0375205140
HOSE ASSY
1
18010-22057
35
0375205150
HOSE ASSY
1
18010-22040
G4d114
Reference:G4D111
Page:4-15
TB135 Book No. BG4Z010 S/N 13510004-
HYDRAULIC TANK (13510004-13514050)
23
26
8
3
28
18
15
4
16
9
5
11
13
20
27
10
7
14
25
22
21
13
24
17
29
31
12
19
32
2
33
15
1
18
28
26
23
Ref G4D071
Page
4-16
HYDRAULIC TANK (13510004-13514050)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
TANK ASSY, hydraulic
X03780-04000-5
1
0378004100
TANK, hydraulic
1
2
0378004300
PIPE
1
3
0378004310
NIPPLE
1
4
0378004320
COVER
1
5
0378004340
PLATE
1
7
0373504320
RUBBER
1
8
1553020655
GAUGE
1
9
0007000031
SPRING
1
10
1551100700
ELEMENT
1
11
1551100300
VALVE
1
12
1550014150
STRAINER
1
13
1515012040
ELBOW
2
1420010110
O-RING
1
14
1515012510
ELBOW
2
1420010110
O-RING
1
15
1420010290
O-RING
3
16
1420101250
O-RING
1
17
1420101450
O-RING
1
18
0007256006
PLUG
3
19
1654601010
TRIM
1
sold by the meter
20
1654601004
TRIM
1
sold by the meter
21
1654302008
SPONGE
2
sold by the meter
22
1100040820
BOLT
2
23
1100041016
BOLT
10
24
1100041035
BOLT
3
25
1140020008
WASHER, spring
2
26
1140020010
WASHER, spring
10
27
1141110008
WASHER
2
28
1141110010
WASHER
10
29
1141550010
WASHER
3
31
0003900025
SHIM
AR
t=1.2mm
32
0438211063
SHIM
AR
t=2.0mm
33
0438211062
SHIM
AR
t=3.2mm
G4d072
Reference:G4D071
Page:4-16
TB135 Book No. BG4Z010 S/N 13510004-
HYDRAULIC TANK (13514051-)
23
26
8
3
28
18
15
4
16
9
5
11
13
20
27
10
7
14
25
22
21
13
24
17
29
31
12
19
32
2
33
15
1
18
28
26
23
Ref G4D073
Page
4-17
HYDRAULIC TANK (13514051-)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
TANK ASSY, hydraulic
X03780-07000-3
1
0378007100
TANK, hydraulic
1
2
0378004300
PIPE
1
13514051~13515256
0378007200
PIPE
1
13515257~
3
0378004310
NIPPLE
1
4
0378004320
COVER
1
5
0378004340
PLATE
1
7
0373504320
RUBBER
1
8
1553020655
GAUGE
1
9
0007000031
SPRING
1
10
1551103300
ELEMENT
1
11
1551100300
VALVE
1
12
1550014150
STRAINER
1
13
1515012040
ELBOW
2
1420010110
O-RING
1
14
1515012510
ELBOW
2
1420010110
O-RING
1
15
1420010290
O-RING
3
16
1420101250
O-RING
1
17
1420101450
O-RING
1
18
0007256006
PLUG
3
19
1654601010
TRIM
1
sold by the meter
20
1654601004
TRIM
1
sold by the meter
21
1654302008
SPONGE
2
sold by the meter
22
1100040820
BOLT
2
23
1100041016
BOLT
10
24
1100041035
BOLT
3
25
1140020008
WASHER, spring
2
26
1140020010
WASHER, spring
10
27
1141110008
WASHER
2
28
1141110010
WASHER
10
29
1141550010
WASHER
3
31
0003900061
SHIM
AR
M
t=1.2mm
32
0003900062
SHIM
AR
M
t=2.0mm
33
0003900063
SHIM
AR
M
t=3.2mm
G4d075
Reference:G4D073
Page:4-17
TB135 Book No. BG4Z010 S/N 13510004-
AIR BREATHER
3
4
1
1-1
1-8
2
5
Ref G4D100
Page
4-18
AIR BREATHER
Item
Part number
Description
Q'ty Chan. Serial No. Serv.
Remarks
BREATHER ASSY
X03780-04400-0
1
1552000900
BREATHER, air
1
1-1
1552000902
ELEMENT
1
1-8
1552000908
PACKING
1
2
0568026170
FLANGE
1
3
1100040614
BOLT
4
4
1140020006
WASHER, spring
4
5
1420010290
O-RING
1
G4d100
Reference:G4D100
Page:4-18
TB135 Book No. BG4Z010 S/N 13510004-
FUEL TANK & FUEL PIPING (13510004-13514050)
7
8
37
45
2
11
10
31
15
3
35
27
27
40
13
20
25
28
26
27
29
22
12
12 25
19
27
27
23
30
18
36
41
24
5
17
3840
40
21
27
38
12
1
5
26
29
27
6
43
9
39
27
37
32
24
46
14
5
40
33
40
38
5
Ref G4D081
Page
4-19
FUEL TANK & FUEL PIPING (13510004-13514050)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
TANK ASSY, fuel
X03781-03000-6
1
0378103100
TANK
1
2
0438101500
PACKING
1
3
0373504320
RUBBER
1
5
0007300050
CLAMP
4
6
0007300055
CLAMP
1
7
1552100500
CAP
1
8
1552100320
STRAINER
1
9
1522100014
COCK
1
10
1553201900
SENDER, fuel
1
11
1652041315
GROMMET
2
13510004~13510060
12
1652231140
BAND
3
13
1910030033
SEPARATOR, water
1
Y129335-55700
14
1910047033
PUMP, feed
1
Y129322-77401
15
1910065047
HOSE, bend
1
Y119840-59601
17
1531207015
HOSE
1
sold by the meter
18
1531207047
HOSE
1
sold by the meter
19
1531207230
HOSE
1
sold by the meter
20
1531207265
HOSE
1
sold by the meter
21
1531010046
HOSE
1
sold by the meter
22
1531010094
HOSE
1
sold by the meter
23
1531115010
PROTECTOR
1
sold by the meter
24
1531115019
PROTECTOR
2
sold by the meter
25
1531115073
PROTECTOR
3
sold by the meter
26
1531115084
PROTECTOR
3
sold by the meter
27
1533120012
BAND
8
28
1533120015
BAND
1
29
1533700017
CLIP
2
30
1553000001
FLOAT
1
31
1150110510
SCREW
5
32
1100040616
BOLT
2
33
1100040816
BOLT
1
35
1100040865
BOLT
1
36
1100041020
BOLT
1
37
1100041025
BOLT
6
38
1130040008
NUT
3
39
1140020006
WASHER, spring
2
40
1140020008
WASHER, spring
5
41
1140020010
WASHER, spring
1
43
1141110006
WASHER
2
45
1141550010
WASHER
5
46
0003600025
WASHER
1
G4d081
Reference:G4D081
Page:4-19
TB135 Book No. BG4Z010 S/N 13510004-
FUEL TANK & FUEL PIPING (13514051-)
7
20
7-1
27
8
10
37
19
45
10-1
12
31
36
41
3
35
40
13
12
28
27
6
29
22
12
25
27
27
18
23
30
24
15
5
17
3840
40
21
27
38
1
26
5
29
27
43
9
39
27
37
32
24
46
14
5
40
33
40
38
5
Ref G4D083
Page
4-20
FUEL TANK & FUEL PIPING (13514051-)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
TANK ASSY, fuel
X03781-06000-4
1
0378103100
TANK
1
3
0373504320
RUBBER
1
5
0007300050
CLAMP
4
6
0007300055
CLAMP
1
7
1552100500
CAP
1
7-1
1552100507
PACKING
1
8
1552100320
STRAINER
1
9
1522100014
COCK
1
10
1553201900
SENDER, fuel
1
10-1
1553201918
PACKING
1
12
1652231140
BAND
3
13
1910186033
SEPARATOR, water
1
Y129906-55700
14
1910199034
PUMP, feed
1
Y129612-52100
15
1531007011
HOSE
1
sold by the meter
17
1531207022
HOSE
1
sold by the meter
18
1531207049
HOSE
1
sold by the meter
19
1531207255
HOSE
1
sold by the meter
20
1531207285
HOSE
1
sold by the meter
21
1531010046
HOSE
1
sold by the meter
22
1531010094
HOSE
1
sold by the meter
23
1531115015
PROTECTOR
1
sold by the meter
24
1531115019
PROTECTOR
2
sold by the meter
25
1531115077
PROTECTOR
3
sold by the meter
26
1531115088
PROTECTOR
3
sold by the meter
27
1533120012
BAND
8
28
1533120015
BAND
1
29
1533700015
CLIP
2
30
1553000001
FLOAT
1
31
1150110510
SCREW
5
32
1100040616
BOLT
2
33
1100040816
BOLT
1
35
1100040870
BOLT
1
36
1100041020
BOLT
1
37
1100041025
BOLT
7
38
1130040008
NUT
3
39
1140020006
WASHER, spring
2
40
1140020008
WASHER, spring
6
41
1140020010
WASHER, spring
1
43
1141110006
WASHER
2
45
1141550010
WASHER
5
46
0003600025
WASHER
1
G4d083
Reference:G4D083
Page:4-20
TB135 Book No. BG4Z010 S/N 13510004-
COVER (1/3) (13510004-13514050)
1
19
2
4-2
23
12
32
25
13
9
10-1
22
26
11
16
17
22
13
26
25
10-3
4-3
23
10-4
20
10-2
4-4
9
34
26
31
28
22
4-1
13
12
16
16
16
16
22
29
17
3-1
24
32
30
22
7
26
25
14
3-3
23
28
27
23
20
6
8
22
21
16
3-2
15
24
21
23
19
23
25
27
5
33
25
23
19
Ref G4E012
Page
5-1
COVER (1/3) (13510004-13514050)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
COVER ASSY (cab)
X03782-06000-5
COVER ASSY (canopy)
X03782-08000-5
COVER ASSY (with air
X03782-07700-5
conditioner)
1
0378206100
HOOD, engine (cab)
1
see page (2/3)
0378208100
HOOD, engine (canopy)
1
see page (2/3)
2
0378206300
COVER, front
1
see page (3/3)
3
0378206500
COVER ASSY, side (L.H.)
1
3-1
0378206600
COVER (L.H.)
1
13510004~13510171
0378207300
COVER (L.H.)
1
(H)
13510172~
3-2
0378206510
ABSORBENT, noise
1
3-3
1654307049
SPONGE
1
sold by the meter
4
0378206700
COVER ASSY, side (R.H.)
1
4-1
0378206800
COVER (R.H.)
1
13510004~13510171
0378207400
COVER (R.H.)
1
(H)
13510172~
4-2
0378206710
ABSORBENT, noise
1
4-3
0378206720
ABSORBENT, noise
4
4-4
0378206730
ABSORBENT, noise
2
5
0378206910
COVER
1
6
0378206920
BOX, tool
1
7
0378206930
BRACKET
1
13510004~13510258
0378207600
BRACKET
1
13510259~
8
0378206940
BRACKET
1
9
0378206950
PIN
2
10
0378207100
COVER ASSY, center
1
0378207710
COVER ASSY, center
1
with air con.
10-1
0378207200
COVER
1
0378207720
COVER
1
with air con.
10-2
0378207110
ABSORBENT, noise
1
0378207730
ABSORBENT, noise
1
with air con.
10-3
1654606088
SEAL
1
sold by the meter
10-4
1654307027
SPONGE
1
sold by the meter
11
0358202400
SHEET
2
12
0398200800
COLLAR
2
13
0138255300
BOLT
4
14
0003900028
SPACER
1
15
0003900027
SPACER
1
16
1100040820
BOLT
12
17
1100040830
BOLT
6
19
1100041020
BOLT
9
20
1100041025
BOLT
4
21
1100041030
BOLT
4
22
1140020008
WASHER, spring
16
23
1140020010
WASHER, spring
17
24
1141110008
WASHER
6
25
1141110010
WASHER
13
26
0003608252
WASHER
10
27
0003600003
WASHER
4
28
1130040008
NUT
2
29
1120590412
SCREW
2
30
1652102410
RUBBER
2
31
1929900237
ROPE
1
32
1653900041
DAMPER
2
33
0378206961
PLATE
2
34
0358212034
RUBBER
AR
G4e012
Reference:G4E012
Page:5-1
TB135 Book No. BG4Z010 S/N 13510004-
COVER (2/3) (engine hood; 13510004-13514050)
1
3
11-6
11
1
20
13
18
12
2
4
2
19
10
8
17
6
16
15
14
5
9
10
7-1
7
Ref G4E021
Page
5-2
COVER (2/3) (engine hood; 13510004-13514050)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
0-1
0378206100
HOOD ASSY, engine (cab)
1
0378208100
HOOD ASSY, engine (canopy)
1
1
0378207000
HOOD, engine
1
cab
0378208200
HOOD, engine
1
canopy
2
0378206130
ABSORBENT, noise
1
cab
0378208110
ABSORBENT, noise
1
canopy
3
0378206140
ABSORBENT, noise
1
4
0378206150
ABSORBENT, noise
1
5
0378206320
HANDLE
1
13510004~13510258
0378207500
HANDLE
1
13510259~
6
0378206170
NOZZLE
1
cab
7
1653601395
LOCK
1
7-1
1700100019
KEY
1
8
0007000095
SPRING
1
9
0004206111
SHAFT
1
10
1224010004
E-RING
2
11
1703002000
LAMP, tail
2
11-6
1703002003
BULB
2
12
1130030004
NUT
4
13
1140020004
WASHER, spring
4
14
1654606255
SEAL
1
sold by the meter
15
1100040816
BOLT
3
cab
16
1140020008
WASHER, spring
3
cab
17
0003608252
WASHER
3
cab
18
0398205160
INSULATOR
1
cab
19
0378206180
INSULATOR
1
cab
20
0374203250
HARNESS, wiring
1
G4e021
Reference:G4E021
Page:5-2
TB135 Book No. BG4Z010 S/N 13510004-
COVER (3/3) (front cover; 13510004-13514050)
2
2-1
4
5
3
13
12
7
11
7-1
8
10
6
9
10
1
Ref G4E030
Page
5-3
COVER (3/3) (front cover; 13510004-13514050)
Item
Part number
Description
Q'ty Chan. Serial No. Serv.
Remarks
0-2
0378206300
COVER ASSY, front
1
1
0378206400
COVER
1
2
1703006200
LAMP ASSY
1
2-1
1703006205
BULB
1
3
0378206310
PLATE
1
4
0880841210
RUBBER
1
5
1654613006
PACKING
1
sold by the meter
6
0378206320
HANDLE
1
7
1653601395
LOCK
1
7-1
1700100019
KEY
1
8
0007000095
SPRING
1
9
0004206111
SHAFT
1
10
1224010004
E-RING
2
11
1100040820
BOLT
1
12
1140020008
WASHER, spring
1
13
1141110008
WASHER
1
G4e030
Reference:G4E030
Page:5-3
TB135 Book No. BG4Z010 S/N 13510004-
COVER (1/3) (13514051-13516744)
1
19
28
2
4-2
23
32
12
25
13
9
10-1
22
26
11
16
17
22
13
26
25
10-3
4-3
23
10-4
20
10-2
4-4
9
34
26
31
28
22
4-1
13
12
16
16
16
16
28
22
29
17
24
32
3-1
30
22
7
26
25
14
3-3
23
28
27
23
20
6
8
22
21
16
3-2
15
24
21
23
19
23
25
27
5
33
25
23
19
Ref G4E013
Page
5-4
COVER (1/3) (13514051-13516744)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
COVER ASSY (cab)
X03782-11000-4
COVER ASSY (canopy)
X03782-12000-4
COVER ASSY (with air
X03782-12100-4
conditioner)
1
0378211100
HOOD, engine (cab)
1
A
13514051~13514356
see page (2/3)
0378211500
HOOD, engine (cab)
1
a(H)
13514357~
see page (2/3)
0378208100
HOOD, engine (canopy)
1
B
13514051~13514356
see page (2/3)
0378208500
HOOD, engine (canopy)
1
b(H)
13514357~
see page (2/3)
2
0378211200
COVER, front
1
see page (3/3)
3
0378206500
COVER ASSY, side (L.H.)
1
3-1
0378207300
COVER (L.H.)
1
3-2
0378206510
ABSORBENT, noise
1
3-3
1654307049
SPONGE
1
sold by the meter
4
0378206700
COVER ASSY, side (R.H.)
1
4-1
0378207400
COVER (R.H.)
1
4-2
0378206710
ABSORBENT, noise
1
4-3
0378206720
ABSORBENT, noise
4
4-4
0378206730
ABSORBENT, noise
2
5
0378206910
COVER
1
6
0378211400
BOX, tool
1
7
0378207600
BRACKET
1
A, B
13514051~13514356
0378207560
BRACKET
1
a, b(H)
13514357~
8
0378206940
BRACKET
1
9
0378206950
PIN
2
10
0378207100
COVER ASSY, center
1
0378212200
COVER ASSY, center
1
with air con.
10-1
0378207200
COVER
1
0378212210
COVER
1
with air con.
10-2
0378207110
ABSORBENT, noise
1
0378212230
ABSORBENT, noise
1
with air con.
10-3
1654606088
SEAL
1
sold by the meter
10-4
1654307027
SPONGE
1
sold by the meter
11
0358202400
SHEET
2
12
0398200800
COLLAR
2
13
0138255300
BOLT
4
14
0003900028
SPACER
1
15
0003900027
SPACER
1
16
1100040820
BOLT
12
17
1100040830
BOLT
6
19
1100041020
BOLT
9
20
1100041025
BOLT
4
21
1100041030
BOLT
4
22
1140020008
WASHER, spring
16
23
1140020010
WASHER, spring
17
24
1141110008
WASHER
6
25
1141110010
WASHER
13
26
0003608252
WASHER
10
27
0003600003
WASHER
4
28
1130040008
NUT
4
29
1120590412
SCREW
2
30
1652102410
RUBBER
2
31
1929900237
ROPE
1
32
1653900041
DAMPER
2
33
0378206961
PLATE
2
34
0358212034
RUBBER
AR
<<NOTE>>
SET "A" is interchangeable
with SET "a".
SET "B" is interchangeable
with SET "b".
G4e014
Reference:G4E013
Page:5-4
TB135 Book No. BG4Z010 S/N 13510004-
COVER (1/3) (13516745-)
4-10
1
19
4-9
12
2
4-2
23
28
32
9
25
13
10-1
22
26
37
11
17
22
13
26
10-3
25
23
10-4
19
10-2
9
4-4
26
34
22
4-8
4-7
31
12
28
37
4-6
13
4-1
37
24
4-5
37
24
16
28
22
29
4-3
17
32
3-1
24
30
22
26
7
25
14
3-3
23
28
27
23
19
6
8
21
22
16
3-2
15
24
21
23
19
23
25
27
33
25
5
23
35
19
Ref G4E402
Page
5-5
COVER (1/3) (13516745-)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
COVER ASSY (cab)
X03782-14000-3
COVER ASSY (canopy)
X03782-15000-3
COVER ASSY (with air conditioner)
X03782-16000-3
1
0378211500
HOOD, engine (cab)
1
see page (2/3)
0378208500
HOOD, engine (canopy)
1
see page (2/3)
2
0378211200
COVER, front
1
see page (3/3)
3
0378206500
COVER ASSY, side (L.H.)
1
3-1
0378207300
COVER (L.H.)
1
3-2
0378206510
ABSORBENT, noise
1
3-3
1654302049
SPONGE
1
M
sold by the meter
4
0378214100
COVER ASSY, side (R.H.)
1
4-1
0378214110
COVER (R.H.)
1
4-2
0378206710
ABSORBENT, noise
1
4-3
0398213250
NET
1
4-4
0378214120
NET
1
4-5
1130040006
NUT
13
4-6
1140020006
WASHER, spring
13
4-7
1141110006
WASHER
13
4-8
0003600090
WASHER
13
4-9
1654302049
SPONGE
1
M
sold by the meter
4-10
0378214140
ABSORBENT, noise
1
M
5
0378214130
COVER
1
6
0378211400
BOX, tool
1
7
0378207560
BRACKET
1
8
0378206940
BRACKET
1
9
0378206950
PIN
2
10
0378207100
COVER ASSY, center
1
0378212200
COVER ASSY, center
1
with air con.
10-1
0378207200
COVER
1
0378212210
COVER
1
with air con.
10-2
0378207110
ABSORBENT, noise
1
0378212230
ABSORBENT, noise
1
with air con.
10-3
1654606088
SEAL
1
sold by the meter
10-4
1654307027
SPONGE
1
sold by the meter
11
0358202400
SHEET
2
12
0398200800
COLLAR
2
13
0138255300
BOLT
4
14
0003900028
SPACER
1
15
0003900027
SPACER
1
16
1100040820
BOLT
6
17
1100040830
BOLT
6
19
1100041020
BOLT
14
21
1100041030
BOLT
4
22
1140020008
WASHER, spring
16
23
1140020010
WASHER, spring
18
24
1141110008
WASHER
8
25
1141110010
WASHER
14
26
0003608252
WASHER
10
27
0003600025
WASHER
4
28
1130040008
NUT
4
29
1120590412
SCREW
2
30
1652102410
RUBBER
2
31
1929900237
ROPE
1
32
1653900041
DAMPER
2
33
0378206961
PLATE
2
34
0358212034
RUBBER
AR
35
1654619158
TRIM
1
sold by the meter
37
1100040825
BOLT
6
G4e403
Reference:G4E402
Page:5-5
TB135 Book No. BG4Z010 S/N 13510004-
COVER (1/3) (for China, with air conditioner)
19
28
4-2
1
23
32
2
25
12
9
10-1
13
22
26
11
16
17
22
25
26
23
10-3
20
10-4
4-4
10-2
4-5
9
34
4-8
26
4-1
4-7
31
28
4-3
22
4-6
12
13
16
4-8
16
16
16
4-7
4-6
17
28
22
29
22
24
32
3-1
30
7
26
14
25
23
3-3
28
27
23
20
6
8
21
22
16
3-2
15
24
21
23
19
23
25
27
5
33
25
23
19
Ref G4E420
Page
5-6
COVER (1/3) (for China, with air conditioner)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
COVER ASSY (cab)
X03782-12400-0
1
0378211500
HOOD, engine (cab)
1
see page (2/3)
2
0378211200
COVER, front
1
see page (3/3)
3
0378206500
COVER ASSY, side (L.H.)
1
3-1
0378207300
COVER (L.H.)
1
3-2
0378206510
ABSORBENT, noise
1
3-3
1654307049
SPONGE
1
sold by the meter
4
0378212300
COVER ASSY, side (R.H.)
1
4-1
0378212310
COVER (R.H.)
1
4-2
0378206710
ABSORBENT, noise
1
4-3
0398212680
NET
1
4-4
0378212350
NET
1
4-5
0378212360
PLATE
1
4-6
1100040816
BOLT
12
4-7
1140020008
WASHER, spring
12
4-8
1141110008
WASHER
12
5
0378206910
COVER
1
6
0378211400
BOX, tool
1
7
0378207560
BRACKET
1
8
0378206940
BRACKET
1
9
0378206950
PIN
2
10
0378212200
COVER ASSY, center
1
10-1
0378212210
COVER
1
10-2
0378212230
ABSORBENT, noise
1
10-3
1654606088
SEAL
1
sold by the meter
10-4
1654307027
SPONGE
1
sold by the meter
11
0358202400
SHEET
2
12
0398200800
COLLAR
2
13
0138255300
BOLT
4
14
0003900028
SPACER
1
15
0003900027
SPACER
1
16
1100040820
BOLT
12
17
1100040830
BOLT
6
19
1100041020
BOLT
9
20
1100041025
BOLT
4
21
1100041030
BOLT
4
22
1140020008
WASHER, spring
16
23
1140020010
WASHER, spring
17
24
1141110008
WASHER
6
25
1141110010
WASHER
13
26
0003608252
WASHER
10
27
0003600003
WASHER
4
28
1130040008
NUT
4
29
1120590412
SCREW
2
30
1652102410
RUBBER
2
31
1929900237
ROPE
1
32
1653900041
DAMPER
2
33
0378206961
PLATE
2
34
0358212034
RUBBER
AR
<<NOTE>>
13515089
G4e420
Reference:G4E420
Page:5-6
TB135 Book No. BG4Z010 S/N 13510004-
COVER (2/3) (engine hood; 13514051-)
1
11-6
3
11
1
20
21
13
18
12
2
4
2
19
10
8
21
17
6
16
15
14
5
9
10
7-1
7
Ref G4E023
Page
5-7
COVER (2/3) (engine hood; 13514051-)
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
0-1
0378211100
HOOD, engine (cab)
1
13514051~13514356
0378211500
HOOD, engine (cab)
1
13514357~
X03782-11500-2
0378208100
HOOD, engine (canopy)
1
13514051~13514356
0378208500
HOOD, engine (canopy)
1
13514357~
X03782-08500-2
1
0378211150
HOOD, engine
1
13514051~13514356
cab
0378211550
HOOD, engine
1
13514357~
cab
0378208200
HOOD, engine
1
13514051~13514356
canopy
0378208550
HOOD, engine
1
13514357~
canopy
2
0378206130
ABSORBENT, noise
1
cab
0378208110
ABSORBENT, noise
1
canopy
3
0378206140
ABSORBENT, noise
1
4
0378206150
ABSORBENT, noise
1
5
0378207500
HANDLE
1
13514051~13514356
0378211570
HANDLE
1
13514357~
6
0398212130
NOZZLE
1
cab
7
1653601395
LOCK
1
7-1
1700100019
KEY
1
8
0007000095
SPRING
1
9
0004206111
SHAFT
1
10
1224010004
E-RING
2
11
1703002000
LAMP, tail
2
11-6
1703002003
BULB
2
12
1130030004
NUT
4
13
1140020004
WASHER, spring
4
14
1654606215
SEAL
1
sold by the meter
15
1100040816
BOLT
3
cab
16
1140020008
WASHER, spring
3
cab
17
0003608252
WASHER
3
cab
18
0398212140
INSULATOR
1
cab
19
0378206180
INSULATOR
1
cab
20
0374203250
HARNESS, wiring
1
21
1654606018
SEAL
2
sold by the meter
G4e023
Reference:G4E023
Page:5-7
TB135 Book No. BG4Z010 S/N 13510004-
COVER (3/3) (front cover; 13514051-)
2
2-1
4
5
3
13
12
7
11
7-1
8
10
6
9
10
1
Ref G4E030A
Page
5-8
COVER (3/3) (front cover; 13514051-)
Item
Part number
Description
Q'ty Chan. Serial No. Serv.
Remarks
0-2
0378211200
COVER ASSY, front
1
1
0378211300
COVER
1
2
1703006200
LAMP ASSY
1
2-1
1703006205
BULB
1
3
0378206310
PLATE
1
4
0880841210
RUBBER
1
5
1654613006
PACKING
1
sold by the meter
6
0378206320
HANDLE
1
7
1653601395
LOCK
1
7-1
1700100019
KEY
1
8
0007000095
SPRING
1
9
0004206111
SHAFT
1
10
1224010004
E-RING
2
11
1100040820
BOLT
1
12
1140020008
WASHER, spring
1
13
1141110008
WASHER
1
G4e031
Reference:G4E030A
Page:5-8
TB135 Book No. BG4Z010 S/N 13510004-
FLOOR FRAME
55
55
24
54
42
7
33
28
22
38
42
46
23
41
33
22
56
54-3
53
21
5
62
36
9
16
25
14
55
42
10
46
9
58
16
14
8
36
42
46
54
31 39
16 11
27
14
1
35
54-4
53
58
52
18
61
54-3
48
30
62
57
44
47
60
28
18
54-4
39
7
38
39
2
48
41
44
59
57
20
46 42
19
24
29
48
34
38
45
56
49-1
4
13
37
19
3
40
51
20
50
15
46
12
43
26
42
17
32
49-2
9
Ref G4E045
Page
5-9
FLOOR FRAME
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
FLOOR ASSY (cab)
X03735-07000-12
FLOOR ASSY (canopy)
X03735-08000-12
FLOOR ASSY (with air
X03735-07600-12
conditioner)
1
0373504100
FRAME (canopy)
1
13510004~13510549
0373504600
FRAME (canopy)
1
13510550~13511578
0373507100
FRAME (canopy)
1
A
13511579~13512484
0373508100
FRAME (canopy)
1
a(H)
13512485~
0373504500
FRAME (cab)
1
13510004~13510549
0373504700
FRAME (cab)
1
13510550~13511578
0373507200
FRAME (cab)
1
B
13511579~13512484
0373507500
FRAME (cab)
1
b(H)
13512485~
2
0373504200
PLATE
1
13510004~13510765
0373504800
PLATE
1
13510766~13511578
0373507300
PLATE
1
13511579~
0394612400
PLATE
1
with air con.
3
0373504300
HINGE
2
4
0373504370
SHAFT
2
5
0373504350
ROD
1
7
0343500800
BOLT
1
A,B
13510004~13512484
0373507007
BOLT
1
a,b(H)
13512485~
8
0343500900
PLATE
1
9
0343503200
PIN
4
cab
0343503200
PIN
3
canopy
10
0373502600
SPACER
4
11
0343501200
SPACER
2
12
0373504360
SPACER
4
13
0373502900
SPACER
4
14
0343501400
CUSHION
6
15
0373502990
CUSHION
4
13510004~13513912
0373502995
CUSHION
4
13513913~
16
0343501600
PLATE
5
17
0343501700
PLATE
2
13510004~13513912
0373504510
PLATE
2
13513913~
18
0373504380
STOPPER
2
19
0433503100
RUBBER
8
20
0433503200
COVER
8
21
0373502800
HOOK
2
22
0393501000
COLLAR
2
23
0373504450
LOCK
2
24
0004010025
PIN
4
cab
0004010025
PIN
3
canopy
25
0007000029
SPRING
1
26
1100040612
BOLT
2
27
1100040640
BOLT
1
28
1100040816
BOLT
6
29
1100040830
BOLT
4
30
1100041030
BOLT
4
31
1100041040
BOLT
2
32
1100141605
BOLT
4
33
1110040820
BOLT
2
34
1111041265
SCREW, cap
4
35
1130040006
NUT
2
36
1130040010
NUT
8
37
1130040016
NUT
4
38
1140020008
WASHER, spring
10
39
1140020010
WASHER, spring
6
40
1140020016
WASHER, spring
4
41
1141110008
WASHER
6
42
1141110010
WASHER
8
cab
1141110010
WASHER
6
canopy
43
1141110016
WASHER
4
44
1141550010
WASHER
4
45
1141550012
WASHER
4
46
1214000008
PIN, snap
8
cab
1214000008
PIN, snap
6
canopy
47
1654312088
SPONGE
1
sold by the meter
48
0373504320
RUBBER
4
13510004~13512484
Reference:G4E045
Page:5-9
TB135 Book No. BG4Z010 S/N 13510004-
FLOOR FRAME
55
55
24
54
42
7
33
28
22
38
42
46
23
41
33
22
56
54-3
53
21
5
62
36
9
16
25
14
55
42
10
46
9
58
16
14
8
36
42
46
54
31 39
16 11
27
14
1
35
54-4
53
58
52
18
61
54-3
48
30
62
57
44
47
60
28
18
54-4
39
7
38
39
2
48
41
44
59
57
20
46 42
19
24
29
48
34
38
45
56
49-1
4
13
37
19
3
40
51
20
50
15
46
12
43
26
42
17
32
49-2
9
Ref G4E045
Page
5-9
FLOOR FRAME
Item
Part number
Description
Q'ty
Chan.
Serial No.
Serv.
Remarks
48
0373507048
RUBBER
3
13512485~
49
0373504400
COVER ASSY
1
49-1
0373504410
COVER
1
49-2
0373504420
RUBBER
1
50
1140020006
WASHER, spring
2
51
1141110006
WASHER
2
52
0373508010
CAP
4
cab
53
1652533010
CAP
2
54
0373504340
MAT, floor
1
13510004~13511578
cab
54
0373507410
MAT, floor
1
13511579~13516984
cab
54
0373507430
MAT, floor
1
13516985~
cab
54
0373504330
MAT, floor
1
13510004~13511578
canopy
54
0373507400
MAT, floor
1
13511579~13516984
canopy
54
0373507420
MAT, floor
1
13516985~
canopy
54-3
0373507423
SPONGE
1
13516985~
54-4
X
**********
SPONGE
2
13510418~
cab X03735-04345
55
1652533010
CAP
1
13513127~13516984
55
1652533013
CAP
1
13516985~
56
1653900043
SPRING, gas
4
cab
56
1653900043
SPRING, gas
3
canopy
57
0373504390
SHIM t=1.2
AR
58
0363511500
URETHANE
2
59
0373504470
PLATE
1
13510454~
60
0007000111
SPRING
1
13512485~
61
0353514055
RUBBER
1
62
0573500225
SPONGE
1
13516985~
62
<<NOTE>>
62
SET "A" is interchangeable
with SET "a".
62
SET "B" is interchangeable
with SET "b".
G4e046
Reference:G4E045
Page:5-9
TB135 Book No. BG4Z010 S/N 13510004-
SEAT BOX (13510004-13514050)
14
11
7
18
2
11
14
2
6
17
6-1
11
8
14
13 10
17
18
1
15
12
20
9
10
13
8
7 14
11
5
3
19
5
11
14
17
Ref G4E052
Page
5-10
SEAT BOX (13510004-13514050)
Item
Part number
Description
Q'ty Chan. Serial No. Serv.
Remarks
BOX ASSY, seat
X03734-11000-5
BOX ASSY, seat (with air conditioner)
X03734-11700-5
1
0373411100
BOX
1
0394612600
BOX
1
with air con.
2
0373411200
SIDE BOX (R.H.)
1
0394612500
SIDE BOX (R.H.)
1
with air con.
3
0373411300
SIDE BOX (L.H.)
1
5
0373411600
COVER
1
0394612310
COVER
1
with air con.
6
0373401640
LOCK
1
6-1
1700100019
KEY
1
7
0003600020
WASHER
2
8
0003608252
WASHER
4
9
1100040616
BOLT
4
10
1100040820
BOLT
4
11
1100041020
BOLT
10
12
1140020006
WASHER, spring
4
13
1140020008
WASHER, spring
4
14
1140020010
WASHER, spring
10
15
1141110006
WASHER
4
17
1141110010
WASHER
8
18
1653916020
TRIM
2
sold by the meter
19
1654302024
SPONGE
1
sold by the meter
20
1654309003
SPONGE
1
sold by the meter
G4e053
Reference:G4E052
Page:5-10
TB135 Book No. BG4Z010 S/N 13510004-
SEAT BOX (13514051-)
14
11
17
18
2
11
14
6
2
6-1
11
17
14
8
13
17
10
1
15
18
12
9
20
10
13
17
14
11
8
5
3
2
5
19
11
14
17
Ref G4E056
Page
5-11
SEAT BOX (13514051-)
Item
Part number
Description
Q'ty Chan.
Serial No.
Serv.
Remarks
BOX ASSY, seat
X03734-12000-2
BOX ASSY, seat (with air
X03734-12200-2
conditioner)
1
0373411100
BOX
1
0394612600
BOX
1
13514051~13516102
with air con.
0373412600
BOX
1
13516103~
with air con.
2
0373412300
SIDE BOX (R.H.)
1
0394612400
SIDE BOX (R.H.)
1
13514051~13516102
with air con.
0373412500
SIDE BOX (R.H.)
1
13516103~
with air con.
3
0373411300
SIDE BOX (L.H.)
1
5
0373411600
COVER
1
0394612310
COVER
1
with air con.
6
0373401640
LOCK
1
6-1
1700100019
KEY
1
8
1141110008
WASHER
4
9
1100040616
BOLT
4
10
1100040820
BOLT
4
11
1100041020
BOLT
10
12
1140020006
WASHER, spring
4
13
1140020008
WASHER, spring
4
14
1140020010
WASHER, spring
10
15
1141110006
WASHER
4
17
1141110010
WASHER
10
18
1653917022
TRIM
2
M
sold by the meter
19
1654302024
SPONGE
1
sold by the meter
20
1654309003
SPONGE
1
sold by the meter
G4e056
Reference:G4E056
Page:5-11
TB135 Book No. BG4Z010 S/N 13510004-
SEAT (1/2)
6
1
6
7
3
8
3
7
5
Ref G4E064
Page
5-12
