Last Modified: 9-16-2014 6.6 D Doc ID: RM000000W780URX Model Year: 2015 Model: Tundra Prod Date Range: [08/2014 - ] Title: AB60F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMISSION SYSTEM: CHECK MODE PROCEDURE; 2015 MY Tundra [08/2014 - ] CHECK MODE PROCEDURE 1. DESCRIPTION (a) Check mode has a higher sensitivity to malfunctions and can detect malfunctions that normal mode cannot detect. Check mode can also detect all the malfunctions that normal mode can detect. In check mode, DTCs are detected with 1 trip detection logic. 2. CHECK MODE PROCEDURE (a) Make sure that the following conditions are met: (1) Battery positive voltage 11 V or more. (2) Throttle valve fully closed. (3) Shift lever in P or N position. (4) A/C OFF. (b) Connect the Techstream to the DLC3. (c) Turn the ignition switch to ON. (d) Turn the Techstream on. (e) Enter the following menus: Powertrain / Engine and ECT / Utility / Check Mode. (f) Check that the MIL flashes as shown in the illustration. NOTICE: (h) Perform "MONITOR DRIVE PATTERN" for the ECT test
