Toyota Tundra (2015 year). Manual - part 2414
Last Modified: 9-16-2014
6.6 A
Doc ID: RM000002V5700MX
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: METER: COMBINATION METER: REMOVAL; 2015 MY Tundra [08/2014 - ]
REMOVAL
1. PRECAUTION
NOTICE:
After turning the ignition switch off, waiting time may be required before disconnecting the cable from the
battery terminal. Therefore, make sure to read the disconnecting the cable from the battery terminal notice
before proceeding with work
.
2. DISABLE AUTOAWAY/RETURN FUNCTION (for Power Tilt and Power Telescopic
Steering Column)
(a) Disable the Autoaway/Return function by changing the customize parameter
.
NOTICE:
Record the above operation causes the Autoaway/Return function to be disabled when the ignition switch is
turned off.
(b) Turn the ignition switch to ON. Operate the tilt and telescopic switch to fully extend and lower the steering
column.
(c) Turn the ignition switch off.
3. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
(a) Disconnect the cable from the negative (-) battery terminal.
CAUTION:
Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the
SRS system.
NOTICE:
When disconnecting the cable, some systems need to be initialized after the cable is reconnected
.
4. REMOVE NO. 1 INSTRUMENT PANEL REGISTER SUB-ASSEMBLY
5. REMOVE INSTRUMENT SIDE PANEL LH
6. REMOVE LOWER CENTER INSTRUMENT COVER (for Column Shift Type)
7. REMOVE FRONT DOOR SCUFF PLATE LH
(a) for Double Cab:
(b) for CrewMax:
(c) for Regular Cab:
8. REMOVE COWL SIDE TRIM BOARD LH
9. REMOVE LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LH
