TYPICAL MALFUNCTION THRESHOLDS Brake switch Stuck ON CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. 1. Turn the ignition switch to ON and turn the Techstream on. 2. Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). 3. Turn the ignition switch off and wait for at least 30 seconds. 4. Turn the ignition switch to ON and turn the Techstream on [A]. 5. Wait 5 seconds. 6. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B]. 7. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. 8. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. 9. Input the DTC: P0724. 10. Check the DTC judgment result. TESTER DISPLAY DESCRIPTION NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions 11. 3UR-FE ENGINE CONTROL SYSTEM: SFI SYSTEM: P0724; Brake... |
