Fig. 419: Identifying O1, O2, O7 And O8 Speaker Connectors NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE REAR NO. 2 SPEAKER (See REMOVAL ) 16. INSPECT BOX SPEAKER a. Disconnect the P14 speaker connector. b. Measure the resistance according to the value(s) in the table below. Standard resistance BOX SPEAKER TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition 1 - 2 Always 1.5 to 2.1 ohms
2009 Toyota Tundra 2009 ACCESSORIES AND EQUIPMENT Navigation - Tundra
|
