Specifications (3 Of 3) ON-VEHICLE INSPECTION 1. CHECK REAR AIRBAG SENSOR (VEHICLE NOT INVOLVED IN COLLISION) a. Perform a diagnostic system check (see DIAGNOSIS SYSTEM ). 2. CHECK REAR AIRBAG SENSOR (VEHICLE INVOLVED IN COLLISION AND AIRBAG HAS NOT DEPLOYED) a. Perform a diagnostic system check (see DIAGNOSIS SYSTEM ). b. When the quarter panel of the vehicle or its area is damaged, check if there is any damage to the rear airbag sensor. If there are any defects as mentioned below, replace the side airbag sensor with a Cracks, dents or chips on the sensor housing. Cracks or other damage to the connector. Peeling off of the label or damage to the serial number. 3. CHECK REAR AIRBAG SENSOR (VEHICLE INVOLVED IN COLLISION AND AIRBAG IS DEPLOYED) a. Replace the side airbag sensor. REMOVAL 1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: For removal and installation procedures of the side airbag sensor, be sure to follow the correct procedure. CAUTION: For removal and installation procedures of the side airbag If the airbags have deployed, replace the rear airbag CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt NOTE: After the ignition switch is turned OFF, the navigation system
2009 Toyota Tundra 2009 RESTRAINTS Supplemental Restraint System - Tundra
|
