8B-73 Air Bag System: DTC Troubleshooting Step Action Yes No 1 1) With ignition switch OFF, disconnect side-air bag (inflator) module connector under front seat cushion. 2) Check proper connection to left or right side-air bag (inflator) module at terminals in “L25” or “L30” connector. 3) If OK, then connect special tools (B) and (C) to side-air bag (inflator) module connector disconnected at the Step Special tool 4) Check SDM DTC. With ignition switch ON, is DTC B1321 or B1325 still Go to Step 2. Go to Step 3. “L25”, “L30” (C) (B) STEERING WHEEL I4RS0A820032-01 |
