7A-14 Heater and Ventilation: Additional Heater Assembly Removal and S6JB0A7106026 Removal 1) Disconnect negative (–) cable at battery. Draining: For Petrol Engine Model in Section 1F”. 3) Remove intercooler outlet pipe referring to “Intercooler and Air Intake Pipe Components: For 4) Disconnect additional heater wires (1) and heater hoses (2) from additional heater assembly (3). NOTE
5) Remove additional heater assembly (3) from its bracket. Installation Tightening torque • Fill engine coolant referring to step 13) to 20) of “Cooling System Refilling: For Diesel Engine Model in HVAC Control Module Removal and Installation S6JB0A7106011 Removal 1) Disconnect negative (–) cable at battery. and HVAC control module referring to “Audio Unit 3) Remove HVAC control module mounting screws and then, remove HVAC control module (2) from center Installation HVAC Control Module and Its Circuits S6JB0A7106012 HVAC control module and its circuits inspection is the Air Flow Control Actuator Removal and S6JB0A7106013 Removal 1) Disconnect negative (–) cable at battery. panel. 3) Disconnect air flow control actuator connector (2). actuator (1) from HVAC unit. Installation 2 3 2 1 I5JB0B710008-01 (a) I5JB0B710009-01 1 2 I5JB0A710013-01 1 2 I5JB0A710014-02 |
