Suzuki Grand Vitara JB627. Manual - part 407

9M-1 Exterior Trim:

Body, Cab and Accessories

Exterior Trim

Repair Instructions

Roof Drip Molding Removal and Installation (If Equipped)

S6JB0B9D06001

1

3

2

4

4

6

5

5

[A]

[B]

a

a

b

b

c

5

5

5

4

I6JB019D0001-01

[A]: Molding Cap Removal

Remove cap by pushing in arrow direction shown on cap and then pulling in
alphabetical order indicated in figure.

 3. Roof drip rear molding

[B]: Molding Cap Installation

Be sure to direct arrow mark of left side molding cap to vehicle forward and
arrow mark of right side molding cap to vehicle rearward.

4. Roof carrier bracket

1. Roof drip front molding

5. Roof drip molding cap

2. Roof drip center molding

6. Roof drip molding clip (Push-in type)

Exterior Trim:  9M-2

Roof Rail Removal and Installation (If Equipped)

S6JB0B9D06002

1

2

3

4

4

4

5

5

5

I6JB019D0002-01

1. Roof rail

 3. Roof drip molding clip (Push-in type)

5. Roof rail bolt

2. Roof drip front molding

4. Roof rail cap

9M-3 Exterior Trim:

Splash Guard Removal and Installation (If Equipped)

S6JB0B9D06003

A

A

A

B

A

A

A

A

A

B

1

2

A

A

A

A

A

A

A

A

A

A

A

3

A

A

A

A

A

A

4

4

I6JB019D0003-01

1. Side sill splash guard

3. Rear door splash guard

2. Front door splash guard

4. Cap

Table of Contents 10- i

10

Section 10

CONTENTS

Control Systems

Precautions ...............................................10-1

Precautions........................................................... 10-1

Precautions for Control Systems......................... 10-1

Cruise Control System.......................... 10A-1

Precautions.........................................................10A-1

Precautions in Diagnosing Troubles ................. 10A-1

General Description ...........................................10A-2

Cruise Control System Construction ................. 10A-2
Components and Functions of Cruise Control

System ............................................................10A-3

Cancel Conditions of Cruise Control System .... 10A-4
On-Board Diagnostic System Description.........10A-4
Cruise Control System Diagnosis Introduction ..10A-4

Schematic and Routing Diagram......................10A-5

Cruise Control System Input / Output Diagram ..10A-5
Cruise Control System Wiring Diagram ............10A-6

Diagnostic Information and Procedures..........10A-7

Cruise Control System Check........................... 10A-7
Customer Questionnaire (Example)..................10A-8
DTC Check .......................................................10A-8
DTC Clearance ................................................. 10A-8
DTC Table.........................................................10A-9
Cruise Control System Symptom Diagnosis .....10A-9
DTC P0565: Cruise Control On Signal............ 10A-10
DTC P0566 / P0567 / P0568: Cruise Control

Off Signal / Resume Signal / Set Signal ....... 10A-12

DTC P0571: Brake Switch Circuit ................... 10A-13
Inspection of Cruise Control System Circuit.... 10A-15

Repair Instructions ..........................................10A-16

Cruise Control Switch Removal and

Installation..................................................... 10A-16

Cruise Control Switch Inspection .................... 10A-16
CPP Switch (for Cruise Control) Removal and

Installation..................................................... 10A-16

Clutch Pedal Position (CPP) Switch (for

Cruise Control) Inspection and Adjustment .. 10A-17

Brake Light Switch Removal and Installation .. 10A-17
Brake Light Switch Inspection......................... 10A-17
ECM Removal and Installation........................ 10A-17

Specifications...................................................10A-17

Tightening Torque Specifications.................... 10A-17

Body Electrical Control System ........... 10B-1

Precautions.........................................................10B-1

Precautions in Diagnosing Trouble ...................10B-1

General Description ...........................................10B-1

BCM General Description .................................10B-1
CAN Communication System Description.........10B-2
Theft Deterrent Light Description ......................10B-3

Schematic and Routing Diagram......................10B-4

Body Electrical Control System Wiring Circuit

Diagram...........................................................10B-4

Connector Layout Diagram of BCM ..................10B-5

Component Location .........................................10B-6

BCM and Related System Component

Location...........................................................10B-6

Diagnostic Information and Procedures..........10B-7

BCM Self-Diagnosis Function ...........................10B-7
Body Electrical Control System Check..............10B-9
Scan Tool Data ...............................................10B-11
DTC Table.......................................................10B-13
DTC Check......................................................10B-14
DTC Clearance ...............................................10B-15
BCM Power Circuit and Ground Circuit Check 10B-16
DTC B1133 (No. 1133): Battery Voltage Too

High...............................................................10B-17

DTC B1141 / B1142 (No. 1141 / No. 1142):

Outside Air Temperature (Ambient Temp.)
Sensor Circuit Malfunction ............................10B-18

DTC B1150 (No. 1150): Air Bag

Communication Circuit Malfunction...............10B-19

DTC B1157 (No. 1157): Air Bag Deployment

Signal Input ...................................................10B-20

DTC B1170 (No. 1170): EEPROM access

error...............................................................10B-20

DTC U0155 (No. 0155): Lost Communication

with Instrument Panel Cluster (IPC) Control
Module ..........................................................10B-21

DTC U1073 (No. 1073): Control Module

Communication Bus Off ................................10B-23

DTC U1100 (No. 1100): Lost Communication

with ECM.......................................................10B-25

DTC U1101 (No. 1101): Lost communication

with TCM .......................................................10B-26

DTC U1144 (No. 1144): Lost Communication

with Keyless Start Control Module ................10B-28

Inspection of BCM and Its Circuits ..................10B-30

Repair Instructions ..........................................10B-36
