8A–6

LIGHTING SYSTEM

Front Combination Light Assembly

Removal

1. Disconnect the battery ground cable.

2. Remove the side combination light.

• Refer to Side Marker Light Bulb in this section.

3. Disconnect the connector.

Installation

To install, follow the removal steps in the reverse order.

Taillight Bulb

Removal

1. Disconnect the battery ground cable.

2. Remove the rear combination light assembly (1).

• Remove three screws.

3. Pull out the rear combination light assembly to ward

you.

825RX053

4. Remove the bulb holder (2).

• Remove the two wing nuts (1).

825RX054

• Remove the bulb (3) by turning it

counterclockwise while pushing it at the same
time.

825RX055

Installation

To install, follow the removal steps in the reverse order.

LIGHTING SYSTEM

8A–7

License Plate Light Bulb (Bumper Type)

Removal

1. Disconnect the battery ground cable.

2. Remove the lens cover (3).

• Remove two screws.

3. Remove the lens (2).

4. Remove the bulb (1).

• Pull out the bulb from the socket.

825RW070

Installation

To install, follow the removal steps in the reverse order.

License Plate Light Bulb (Tailgate Type)

Removal

1. Disconnect the battery ground cable.

2. Remove the lens cover (3).

• Remove two screws.

3. Remove the bulb (2).

• Pull out the bulb from the socket (1).

803RW014

Installation

To install, follow the removal steps in the reverse order.

8A–8

LIGHTING SYSTEM

Stoplight Bulb

Removal

1. Remove the bulb holder (2).

• Remove the two wing nuts (1).

825RX054

• Remove the bulb (3) by turning it

counterclockwise while pushing it at the same
time.

825RX058

Installtion

To install, follow the removal steps in the reverse order.

High Mounted Stoplight Assembly (4Door Model)

Removal

1. Disconnect the battery ground cable.

2. Remove the high mount stoplight assembly (2).

• Remove the cover (3).

• Disconnect the connectors (1).

• Remove two screws.

803RX001

Installation

To install, follow the removal steps in the reverse order.

LIGHTING SYSTEM

8A–9

High Mounted Stoplight Bulb (4Door Model)

Removal

1. Disconnect the battery ground cable.

2. Remove the cover.

3. Remove the bulb (1).

• Remove the socket by turning it

counterclockwise.

825RW071-1

Installation

To install, follow the removal steps in the reverse order.

High Mounted Stoplight Assembly (2Door Model)

Removal

1. Disconnect the battery ground cable.

2. Remove the high mounted stoplight assembly (1).

• Remove the two screws.

• Pull out the high mounted stoplight assembly (1).

• Disconnect the connectorb (2) .

803RX009

Installation

To install, follow the removal steps in the reverse order.
