6B–10 ENGINE COOLING (X22SE 2.2L) Main Data and Specifications General Specifications Special Tool Cooling system Engine Coolant forced circulation Radiator (1 tube in row) Tube type corrugated Heat radiation capacity 54,000 kcal/h (62.8 kw) Heat radiation area 7.677m 2 (0.878ft 2 ) Radiator front area 0.264m 2 (0.028ft 2 ) Radiator dry weight (with fan) 32N (7.2lb) Radiator cap valve opening pressure 93.3 ∼ 122.7kpa (13.5 ∼ 17.8psi) Engine coolant capacity 1.8lit (0.48 US gal) Engine coolant pump Centrifugal type Thermostat Bypass type Engine coolant total capacity 7.2lit (1.9 US gal) ILLUSTRATION TOOL NO. TOOL NAME 5–8840–0277–0 Tester; radiator cap 5–8840–2603–0 Adapter; radiator cap |
